In the arc welding and cutting process, there is a risk of
injury to you and others. Take necessary precautions during welding
or cutting. Refer to the operator’s safety guide for detailed
instructions.

The flue gas produced during welding may be harmful to
health.
Arc radiation can damage your eyes and burn your skin.
Fire safety measures should be followed as per the manual.
The equipment needs to be equipped with a leakage protection
switch.

Description of this Machine

The welding machine uses advanced inverter technology and is
suitable for gas welding (solid wire) and gasless welding
(Flux-cored wire).

CAUTION: The machine is mainly used in the industry and may
produce radio waves. Workers should take necessary precautions for
protection.

MIG130/160 One Body Machine Series Parameter Table

Mode: MIG-130

Input Voltage: 1 Phase 110V
Frequency: 50/60Hz
Rated Input Current: 19A
Output Current: 20-30A
No-load Voltage: 56V
Duty Cycle: 60%
Power Factor: 0.93
Efficiency: 85%
Wire Feeder Speed: 2-13m/min
Wire Diameter: 0.8-1.0mm
Protection Degree: IP21
Insulation Class: F
Suitable Thickness: 0.8-2mm
Weight: 6.5kg
Dimension: 460x240x345mm

MIG130/160 Digital Display

Welding Gun
Abnormal Indicator Light
Current/Wire Feeding Speed Adjustment
Voltage Regulation
Negative Polarity Connector
Positive Polarity Connector
Cooling Vent
Power Switch
Power Cord
Ground Wire
High-Speed Fan

MIG-160/200D3/250/270 Single Voltage Series Panel
Introduction

Power Indicator Light
Switch Mode (MMA/LIFT-TIG/MIG)
MMA/TIG Welding Current Adjustment
MIG Voltage Adjustment
MIG Wire Speed Adjustment
Positive Polarity Connector
Overheating Alarm
Welding Current Display
Welding Wire Inching
Welding Voltage Display
Negative Polarity Connector
MIG Welding Gun
Polarity Conversion Cable Connector
Trachea Inlet Connector
Power Switch
Power Cord with Plug
Ground Wire
Built-in Cooling Fan and Ventilation

Note: When using solid carbon steel welding wire, connect the
polarity conversion cable connector to the positive polarity
connector and ground wire clamp to the negative polarity connector.
When using airless self-protective wire, connect the polarity
conversion cable connector to the negative polarity connector and
ground wire clamp to the positive polarity connector.

View Fullscreen

USER’S MANUAL
modelMIG-130/160/200/200D3/250/270
AC110-220V/AC220V

MIG All-in-one series

MIG Single voltage series

MIG Digital series

MIG Double voltage series

DIRECTORY

1.safety warning!

2.Description of this machine

3.MIG130/160One body machine series parameter table

4.MIG130/160Panel function explanation

5.MIG-160/200D3/250/270 Single voltage series panel introduction

6.MIG-160/200D3/250/270 Single voltage series parameters

7.MIG-160/200D3/250/270 Introduction to Dual Voltage Series Panel

8.MIG-160/200D3/250/270 Single voltage series parameters

9.MIG-160/200/250/270 Digital series panel introduction

10.MIG-160/200/250/270Digital series parameters

11.Description of various functions

12.Installation configuration

13.Precautions or precautions!

14.maintain

15.Check for failure

16.Accessories section

Safety warning!
In the arc welding and cutting process, may cause injury to you and others, during the welding or cutting take precautions. For details, please refer to the operator’s safety guide that meets the manufacturer’s accident prevention requirements.

Get an electric shock —- It can result in death ·Install the grounding device in accordance with the applicable standards.
·Do not touch live parts or welding electrodes when the skin is bare, wet gloves or wet clothes are worn.
·Make sure that you are insulated from the ground and the workpiece.
·Confirm that your workstation is in a safe state.

The flue gas

May be harmful to health !

·Keep your head out of the smoke.

·During arc welding, use ventilation or air extraction devices to avoid inhaling welding gas.

Arc radiation

It may damage your eyes and burn your skin!

·Use a suitable welding mask and filter, and wear protective clothing to protect your eyes and body.

·Use a suitable mask or curtain to protect bystanders from injury.

Fire
·Welding sparks may cause fire. Please make sure there is no flammable material near the welding station.

The noise —- Excessive noise is harmful to one’s hearing ! ·Protect your ears, use ear shields or wear other hearing protection.
·Warn bystanders of the potential damage to their hearing caused by noise.

The fault —- Seek professional help when you encounter difficulties! ·If you encounter difficulties during installation and operation, troubleshoot according to
relevant contents of this manual.
·If you do not fully understand after reading this manual or cannot solve the problem by following the instructions in this manual, you should immediately contact your supplier or The service center of Ruiling Company got in touch and sought professional help.

warning
The equipment needs to be equipped with leakage protection switch

-2-

Description of this machine
The welding machine is adopting the most advanced inverter technology, suitable for gas welding (solid wire) and gasless welding (Flux-cored wire).
The development of inverter welding equipment profits from the development of the inverter power supply theory and components. Inverter welding power source utilizes high-power component IGBT to transfer 50/60HZ frequency up to 100KHZ, then reduce the voltage and commutate, and output high-power voltage via PWM technology. Because of the great reduce of the main transformer’s weight and volume; the efficiency increases by 30%. The appearance of inverter welding equipment is considered to be a revolution for welding industry.
Inside of the machine is equipped with electronic reactor circuit which can accurately control the process of the electric short transition and blending transition and result excellent welding characteristic. Comparing with synergic welding machine and other machine, it has the following advantages: stable wire speed, compact, power saving, no electromagnetic noise. Continuous and stable operation with small current, especially suitable for welding sheet of low-carbon steel, alloyed steel and stainless steel. Automatic voltage pulsation compensation capability, small sparkle, good arcing, uniform welding pool, high duty cycle and so on.
Thanks for purchasing product and hope for your precious advice. We will dedicate to produce the best products and offer the best service.
CAUTION
The machine is mainly used in industry. It will produce radio wave, so the worker should make fully preparation for protection.
-3-

MIG130/160 One body machine series
parameter table

Mode
Input Voltage.V
FrequencyHZ

MIG-130 1 Phase 110V 15%
50/60

MIG-160 1 Phase 230V 15%
50/60

Rated input currentA

Output currentA
No-load Voltage (V)

20-30 56

20-160 56

Duty cycle% Power factor Efficiency 10/5000% Wire Feeder Wimre/msipneed Wire diametermm
Protection Degree
Insulation Class
Suitable thickness (mm
Weight kg 7/5000 Dimension (mm)

60% 0.93
85 Inside 2-13 0.8-1.0
IP21 F
0.8-2 6.5 460x240x345

60% 0.93
85 Inside 2.5-14 0.8-1.0
IP21 F
0.8-3 6.5
460x240x345

-4-

MIG130/160
Digital display

Welding gun

Abnormal indicator light Current/wire feeding speed adjustment Voltage regulation
Negative polarity connector
Positive polarity connector

Cooling vent

Menu Function Description 1. The maximum MMA electrode can be ø 3.2mm 2. Select 0.8mm for MIG airless self-protection wire 3. Select 1.0mm for MIG airless self-protection wire 4.LIFT TIG is simple scratch argon arc welding

The power switch
Power cord Ground wire

High-speed fan

Note: Very important!
1. The machine can only use non-air self-protection wire! 2. Connect the plug of the ground cable to the output port of the positive pole when airless welding (wire) is used. 3. Select the function menu. 4. The current/wire feeding speed is adjusted as the output current adjustment knob, if welding during MIG weldingLarger particles or welding pile height, can be appropriately adjusted to increase the voltage knob! 5. If there are air holes on the surface of welded products, it is necessary to turn down the voltage knob to improve it!
-5-

MIG-160/200D3/250/270
Single voltage series panel introduction

Power indicator light Switch mode
MMA/LIFT-TIG/MIG MMA/TIG Welding current
adjustment
MIG voltage adjustment MIG Wire speed adjustment
Positive polarity connector

Overheating alarm
Welding current display Welding Wire Inching Welding voltage display
Negative polarity connector MIG Welding gun

Polarity conversion cable connector
Trachea inlet connector
The power switch Power cord with plug Ground wire
Built-in coolingFan and ventilation

Note: Very important!
1. Connect the polarity conversion cable connector to the positive polarity connector when solid carbon steel welding wire is usedGround wire clamp negative polarity connector! 2. Connect the polarity conversion cable connector to the negative polarity connection when using the airless self-protective wireConnector, ground wire clamp with positive polarity connected machine!
-6-

MIG Single voltage series parameters (160/200D3/250/270)

Mode
Input Voltage.V

MIG- 160
1 Phase 230V 15%

MIG-200D3
1 Phase 230V 15%

MIG- 250
1 Phase 230V 15%

MIG-270
1 Phase 230V 15%

FrequencyHZ

50/60

Rated input currentA

Output currentA
No-load Voltage (V)

30-160 56

50/60 28
30-200 56

50/60 29
30-250 56

50/60 30
30-270 56

Duty cycle% Power factor

60% 0.93

Efficiency 10/5000%

Wire Feeder

Inside

Wimre/msipneed

2.5-14

Wire diametermm
Protection Degree

0.8-1.0 IP21

Insulation Class
Suitable thickness (mm

F 0.8-3

Weight kg 7/5000

Dimension (mm)

525x305x380 525x305x380 525x305x380 525x305x380

-7-

MIG-160/200/250/270 Introduction to Dual Voltage Series Panel
MMA/LIFT-TIG/MIG

Switch mode

Power indicator light

Welding Wire Inching

Overheating alarm Welding current display MIG welding voltage display
MIG burn-back function

Welding current adjustment
MIG Wire speed adjustment MIG Voltage adjustment

Positive polarity connector

Negative polarity connector
MIG Welding gun
Polarity conversion cable connector

Trachea inlet connector

The power switch Power cord with plug
Ground wire
Built-in coolingFan and ventilation

-8-

MIG-160/200/250/270 MIG Double voltage series parameters

Model Input Voltage (V) Input Voltage (V) Frequency (HZ)

MIG-160
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-200
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-250
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-270
1 Phase 230V±15%
1 Phase AC110/220V
50/60

Rated input current (A) 220V 20.2

27.6

Rated input current (A) 110V 34

41.1

43.1

Output current (A) 220V

40-160

40-200

40-250

40-270

Output current (A) 110V

30-120

30-130

40-140

40-150

No-load Voltage (V)

16.5-22.0

16.5-23.0

16.5-24.0

16.5-25.5

(25OC)Duty cycle (%)

60%

Power factor

0.93

Efficiency (%)

Wire Feeder

Inside

Wire speed (m/min)

2.5-15

2.5-14

Wire speed (m/min) 110V

2.5-10

3-8

Wire diameter (mm)

0.6/08/0.9

0.8/0.9/1.0

Protection Degree

IP21S

Insulation Class

Suitable thickness(mm)

0.8aboe

Weight (kg)

13.0

14.0

14.5

Dimension (mm)

520x300x370 520x300x370 520x300x370 520x300x370

-9-

MIG-160/200/250/270 Digital series panel introduction

MIG Welding Voltage Display

Welding Current Display

Weldin

Method

MIG welding material 8 4 4 4 4 and shielding gas

to adjust parameter
choose different functions
welding voltage and current
Welding Wire Diameter Polarity conversion cable connector

MIG welding gun
14

Ground wire

Negative polarity Positive polarity connector connector

Trachea

inlet connector

Power Switch 15 for ON/OFF

Power cord

17 with plug

Built-in cooling Fan and ventilation
19

– 10-

MIG-160/200/250/270
MIG Digital series parameter

Model Input Voltage (V) Input Voltage (V) Frequency (HZ)

MIG-160
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-200
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-250
1 Phase 230V±15%
1 Phase AC110/220V
50/60

MIG-270
1 Phase 230V±15%
1 Phase AC110/220V
50/60

Rated input current (A) 220V 20.2

27.6

Rated input current (A) 110V 34

41.1

43.1

Output current (A) 220V

40-160

40-200

40-250

40-270

Output current (A) 110V

30-120

30-130

40-140

40-150

No-load Voltage (V)

16.5-22.0

16.5-23.0

16.5-24.0

16.5-25.5

(25OC)Duty cycle (%)

60%

Power factor

0.93

Efficiency (%)

Wire Feeder

Inside

Wire speed (m/min)

2.5-15

2.5-14

Wire speed (m/min) 110V

2.5-10

3-8

Wire diameter (mm)

0.6/08/0.9

0.8/0.9/1.0

Protection Degree

IP21S

Insulation Class

Suitable thickness(mm)

0.8aboe

Weight (kg)

13.0

14.0

14.5

Dimension (mm)

520x300x370 520x300x370 520x300x370 520x300x370

– 11 –

Description for various functions

Item
Over-Heat Alarm
Power Indicator
Welding Current Display
MIG Welding Voltage DisplayMIG Switch for mode of mma/lift-tig/mig Welding Wire Inching MMA Welding Current Adjustment MMA

Note
When temperature of the machine is too high, this indicator will light and machine stop working.
/ While arc is struck (welding) displays actual welding current.
While MIG mode display actual welding voltage.MIG
Three kinds of welding models can be choose when turn to different position.
It can let welding wire reach contact tips in fast speed.
While MMA mode can adjust welding current from small to big

MIG Burnback Function MIG It can remove small ball after stopping welding

MIG Voltage Adjustment MIG While MIG mode can adjust voltage from low to high.

MIG Wire Speed Adjustment MIG stepless adjusment from slow to fast.

Polarity Conversion Cable Connector

When gas welding (solid wire),install this into Positive Polarity Connector When gasless welding (Flu/x wire),install this into Negative Polarity Connector

Positive Polarity Connector

Negative Polarity Connector

MIG Welding Torch

Integrated MIG TORCH or Binzel MIG Torch

Power Switch for ON/OFF

Gas Hose Inlet Connector

When use gas welding (solid welding wire), install gas hose into this connector.

Power Cable with Plug

Ground wire

Ground Nut

built-in cooling fan and ventilation

– 12 –

Install the configuration
The welding equipment is equipped with power voltage compensation set. When power voltage changes between±15% of rated voltage, it still works normally.
When using long cable, in order to minimize the reduce of voltage, big cable is suggested. If the cable is too long, it will affect the performance of arcing and other system function, so stated length is suggested.
1Make sure the intake of the machine is not covered or blocked to prevent the malfunction
of the cooling system.
2 Use earth cable that the section no less than 6mm2 to connect the housing and earth, the
method is from the connection in the back of the machine to the earth set, or make sure the earth end of power switch reaches the earth. Both ways can be used for better security.
Installment ,when use gas welding (solid wire)
1) Connect the gas bottle with CO2 regulator flow meter and the Input Gas Connector behind the machine via gas hose.
2) Insert the cable connector of earth cable into the socket in the front panel. 3) Set the welding wire spool on the wheel axis, the wheel hole should be matched with the
wheel fixer. 4) Choose wire slot according to wire size. 5) Loosen the screw of wire-pressing wheel, put the wire into slot via wire-lead tube, tune the
Wire-pressing wheel to fix wire from gliding, but pressure should be suitable in case the wire distorts and affects wire sending. 6) Wire roller should turn clockwise rotation to let out wire, to prevent wire from gliding; wire is usually set to the fixed hole on the wheel side. To prevent the bent wire from getting stuck, please cut off this part of the wire. 7) The MIG torch has been settled inside of the machine just need put the wire into the torch by hand.
– 13 –

Using the operating 1Put the power switch to “ON” position, open the valve of CO2 cylinder and adjust the flow. 2Choose suitable welding contact tips based on wire diameter. 3Tune the voltage switch, speed switch to the right position based on the thickness of the
work piece and mechanics.
4Press the torch switch to let out the wire to the torch head and begin to work.
Installment ,when use gasless welding (Flux-cored wire)
1) Insert the cable connector of earth cable into the socket in the front panel. 2) Set the welding wire spool on the wheel axis, the wheel hole should be matched with the
wheel fixer. 3) Choose wire slot according to wire size. 4) Loosen the screw of wire-pressing wheel, put the wire into slot via wire-lead tube, tune the
Wire-pressing wheel to fix wire from gliding, but pressure should be suitable in case the wire distorts and affects wire sending. 5) Wire roller should turn clockwise rotation to let out wire, to prevent wire from gliding; wire is usually set to the fixed hole on the wheel side. To prevent the bent wire from getting stuck, please cut off this part of the wire. 6) The MIG torch has been settled inside of the machine just need put the wire into the torch by hand.
– 14 –

NOTES OR PREVENTIVE MEASURES
1Environment
1) The machine can perform in environment where conditions are dry with a dampness lever of max 90%.
2) Ambient temperature is between 10 to 40 degrees centigrade. 3) Avoid welding in sunshine or drippings. 4) Do not use the machine in environment where condition is polluted with conductive dust
on the air or corrosiveness gas on the air. 5) Avoid gas welding in the environment of strong airflow.
2Safety norms
The welding machine has installed protection circuit of over voltage and current and heat. When voltage and output current and temperature of machine are exceeding the rate standard, welding machine will stop working automatically. Because that will be damage to welding machine, user must pay attention as following.
1) The working area is adequately ventilated The welding machine is powerful machine, when it is being operated, it generated by high currents, and natural wind will not satisfy machine cool demands. So there is a fan in intermachine to cool down machine. Make sure the intake is not in block or covered, it is 0.3 meter from welding machine to objects of environment. User should make sure the working area is adequately ventilated. It is important for the performance and the longevity of the machine.
2) Do not over load The operator should remember to watch the max duty current (Response to the selected duty cycle). Keep welding current is not exceed max duty cycle current. Over-load current will damage and burn up machine.
3) No over voltage Power voltage can be found in diagram of main technical data. Automatic compensation circuit of voltage will assure that welding current keep in allowable arrangement. If power voltage is exceeding allowance arrangement limited, it is damaged to components of machine. The operator should understand the situation and take preventive measures.
4) There is a grounding screw behind welding machine, there is grounding marker on it Mantle must be grounded reliable with cable which section is over 6 square millimeter I order to prevent from static electricity and leaking.
– 15 –

5) If welding time is exceeded duty cycle limited, welding machine will stop working for protection. Because machine is overheated, temperature control switch is on “ON” position and the indicator light is red. In this situation, you don’t have to pull the plug, in order to let the fan cool the machine. When the indicator light is off, and the temperature goes down to the standard range, it can weld again.
QUESTIONS IS BE RUN INTO IN WELDING
Fittings, welding materials, environment factor, supply powers maybe have something to do with welding. User must try to improve welding environment.
AArcing-striking is difficult and easy to pause
1) Make sure the earth cable clincher connects the work piece well. 2) Check each connecting point connected or not.
BOutput current can not reach rated volume
That supplied voltage is different from the rated will lead to unconformity of the output current and the adjusted current. When Supplied voltage lower than the rated, the max output current will be lower than the rated.
CCurrent is not stabilizing when machine is been operating.
It has something with factors as following: 1) Electric wire net voltage has been changed
2) There is harmful interference from electric wire net or other equipment
D Welding gap has air hole. 1) Check the gas supply loop leaks or not. 2) Surface of mother material has oil, stain, rust, lacquer or other impurity.
– 16 –

MAINTENANCE
CAUTION
Before Maintenance and checking, power must be turned off, and before Opening the housing, make sure the power plug is pulled off..
1 Remove dust by dry and clean compressed air regularly, if welding machine is operating in environment where is polluted with smokes and pollution air, the machine need remove dust everyday. 2 Pressure of compressed air must be inside the reasonable arrangement in order to prevent damaging to small components of inter-machine. 3 Check inter circuit of welding machine regularly and make sure the cable Circuit is connected correctly and connectors are connected tightly (especially insert connector and components). If scale and loose are found, please give a good polish to them, then connect them again tightly. 4Avoid water and steam enter into inter-machine, if them enter into machine, Please dry inter-machine then check insulation of machine. 5If welding machine will not be operated long time, it must be put into packing Box And store in dry environm ent. 6 When wire machine operates for every 300 hours, the electric carbon brush and armature rectifier should be polished, the reducer should be cleaned, and lubricator should be added to the turbo and bearing.
CHECK FAULT
Notes: If user wants to operate machine as following, the operator must be a personnel in a specific field of electricity and safety and hold the relevant certificate that proves their ability and knowledge. Before maintenance, contact with our sale agent for authorization is suggested.
– 17 –

Faults
Power indicator is not lit, fan does not work and no welding

Resolvable Method
1Make sure air switch is closed. 2Check if electric wire net is in work. 3Some of heat-variable resistors(four) of power panel is
Damaged, when it happen, general DC24v relay is open or Connectors are poor contact. 4Power panel(bottom board) is damaged, DC 310V voltage Cannot be output. (1)Silicon bridge is broken or connector of silicon bridge Poor contact. (2) Power panel has been burned up. (3) Check the wire from the power switch to input cable is poor contact or not 5Auxiliary power of control panel is in fault.

Power indicator is lit, fan works, no welding output
Power indicator is lit, fan works, abnormal indicator is lit.

1Check if all kinds of cables of inter-machine are poor contact. 2Output connector is cut off or poor contacted. 3Control cable or switch of torch is broken. 4Control circuit is broken.
1Maybe it is overheated protection, please turn off machine first, then turn on the machine again after abnormal indicator is off.
2 Maybe it is overheated protection, wait for 2-3 minutes. 3 Maybe inverter circuit is in fault: (1) If abnormal indicator is still lit, some of IGBT is damaged on the
main board, find out and replace it with same model. (2) If abnormal indicator is not lit,: a.Maybe transformer is damaged, measure inductance volume and
Q volume of main transformer by inductance bridge. b.Maybe secondary rectifier tube of transformer is damaged, find
out faults and replace rectifier tube with it.

– 18 –

i Note: The operations below require the operator with enough knowledge of electricity
and overall common sense of security, qualification certificate which can proof their ability and knowledge is a necessary. Before the inspection, we recommend that you should contact with us and get approval from them.
CHECK FAULTS
When abnormal situation such as failure of welding, unstable arc, poor welding result, do not consider that it must be some faults. The machine may be well but just some reasons cause abnormality such as that some connectors are loosened, forget to turn on the switch, wrong setting, broken cable and gas pipe, etc. So before maintenance, Please check it up first, some problem may be solved. The following is earlier checking diagram by this way. In the top right corner item you can find the problem, please check according to the diagram for the one with “O” mark.
– 19 –

EARLIER CHECKING DIAGRAM FOR THE ABNORMAL
The abnormal

Place and item to be checked

Power supply box (input protective set )

1.connected or not 2.fuse broken 3.connector loosen

Input cable Power

1.Broken or not 2.Connector loosen 3.Overheat
1Switched or not 2lack phase

Gas cylinder& adjuster

1.open cover 2.remains of gas 3.flow setting volume 4.Connecting point loosen

Gas pipe (access from the high-pressure

1.Connecting point loosen

cylinder to torch)

2.Pipe broken

Wire sending equipment

1.Wheel and leading tube not match 2.Wheel broken, slot blocked or lack 3.Over pressing or loosen, powder store up in entrance of SUS tube

– 20 –

Have air hole
fcon conglutinated
Wire and Material conglutinated
Welding margin unclean Unstable arc Poor Arcing initiation Can not Send wire No gas No arcing

DAILY CHECKING

WELDING POWER SUPPLY

Position Control panel Cooling fan
Power part
Periphery

Checking keys
1.switch condition of operation, transfer and installment. 2.test the power indicator
1.check if there is wind and the sound normal or not.
1.when electrified, abnormal smell or not. 2.when electrified, abnormal vibration and buzz or not. 3.color changing and heating or not in appearance.
1.gas pipe broken, loosen or not. 2.housing and other fixed parts loosen or not.

Remarks
If abnormal noise and no wind, to check the inner.

WELDING TORCH

Position Loophole
Electric hole
Wire sending tube

Checking keys 1.If installment fixed, the front distorted
2.attach splash or not.
1.If installment fixed 2.damage of its head and hole blocked nor not
1.check the extended size of the pipe
2.wire diameter and the tube inner diameter match or not
3.partial winding and extended
4.block caused by dirt in the tube and the remains of the wire plating lay.

Remarks
Reason for air hole.
Reason for burning the torch. (can use splash-proof material ) Reason of torch screw thread damage
Reason of unstable arc and broken arc
Have to be changed when less than 6mm, when the extended part too small, the arc will be unstable. Reason of unstable arc, please use the suitable tube. Reason of poor wires sending and unstable arc, please change. Reason of poor wire sending and unstable arc, (use kerosene to wipe or change new one.)

Gas bypass

5.wire sending tube broken O circle wear out
Forget to insert or the hole blocked or different factory component.

1.Pyrocondensation tube broken, change new tube 2.Change new O circle
May lead to vice (splash) because of poor gas shield, torch body get burned (arc in the torch), please handle.

– 21 –

DAILY CHECK

WIRE FEEDER

Position Checking keys

Remarks

Pressing 1.If put the arm to the suitable indicating level. Lead to unstable arc and wire

arm

(notesnot to damage wire less than 1.0mm sending.

1.If powder or residue store up in the mouth

of the tube.

Wire Lead Tube

Clean the residue and check the reason and solve it.
3.If the tube mouth center matches the wire wheel slot center or not.

Wire wheel

1.Wire diameter matches the wheel’s requirement 2.If the wheel slot blocked

Pressure Check the stability of its move, and wheel wearing-out of pressed wire, the narrowing
of its contact surface

Clean the residue and check the reason and solve it.
If not match, lead to unstable arc and residue.
3.If the tube mouth center matches the wire wheel slot center or not. 1.Lead to unstable arc and residue and block wire tube. 2.Change new one if necessary
Lead to unstable arc and wire sending.

CABLE

Position

Checking keys

Torch 1.If torch cable over bended. cable 2.If the metal connecting point of mobile plug loosen

Remarks
1. Cause poor wire sending 2.Unstable arc if cable over bended

Output cable

1. Wearing-out of the cable insulated material. 2.Cable connecting head naked (insulation damage), or loosen (the end of power supply, and cable of main material connecting point.)

For life security and stable welding, adopt suitable method to check according to

Input cable

1.If the connect of power supply input, protective equipment input and the output end fixed or not. 2.If the security equipment cable reliably connected. 3.If the power input end cable fixed 4.If the input cable is worn out and bares the conductor.

working place. Simple check daily Careful and in-depth check on fixed period

Earth cable

1.If the earth cable that connects the power supply is broken and connect tightly. 2. If the earth cable that connects the main part is broken and connects tightly.
– 22-

To prevent creep age and insure security, please make daily check.
