Next Trend Portable Outdoor Wireless Speaker User Manual (+ PDF)

The Portable Outdoor Wireless Speaker is a Bluetooth-enabled
speaker that can be used outdoors. It is IPX6 rated for water
resistance and comes with a USB-C charging cable, a 3.5mm jack
audio cable, and a user manual. The speaker features TWS (True
Wireless Stereo) technology and can be used with a MicroSD card or
connected to an audio source via Bluetooth or the 3.5mm jack.

Packaging Contents:

IPX6 Portable Wireless Speaker
USB-C Charging Cable
User Manual
3.5mm Jack Audio Cable

Hereby, CVA ELECTRONICA, LDA declares that this equipment type
is in compliance with the mandatory directives for the CE
certification. The full text of the EU declaration of conformity is
available at the following internet address: www.nextaudiogroup.com/en/apoio-ao-cliente/downloads

Power On/Off:

Long press the power switch for 2 seconds to turn on, the LED
indicator flashes blue.
Long press the power switch for 2 seconds to turn off, the LED
status indicator goes off.

BT Wireless Connection:

To unpair a previously paired device, double press the mode
button. The status LED will flash blue searching for a new device
to pair.

Answering Incoming Calls:

To answer incoming calls, short press the Play/Pause button. To
end the current call, short press the Play/Pause button once. To
reject an incoming call, long press the Play/Pause button for 2
seconds. To redial the last called number, double press the
Play/Pause button.

Operating Mode:

To select the desired operation mode – BT / Micro SD card / AUX
in, short press the Mode button. The Micro SD Card allows MP3 music
format and a maximum storage of 32Gb.

Voice Assistant:

To activate your mobile voice assistant, long press the
Play/Pause button.

Music Playback:

Short press the Play/Pause button to pause or play.
Long press the – to select previous track.
Long press the + to select next track.
Short press the – to decrease the volume level.
Short press the + to increase the volume level.

TWS (True Wireless Stereo):

The speaker features TWS (True Wireless Stereo) technology.

Charging the Portable Speaker:

The speaker is equipped with an 18Wh Lithium-ion battery
(Equivalent to 3.6V, 5000mAh) that provides up to 15 hours of
playtime. The battery can be charged using the provided USB-C
charging cable. Charging voltage/current is DC 5V/2.4A and charging
time is approximately 5 hours.

Technical Specifications:

FR Driver: 2 x 75mm Full-Range Driver
SW Driver: 2 x 82mm Passive Sub. Radiator
RMS Power: 30W
Frequency Response: 80Hz – 16kHz
BT Technology: v5.0
BT Range: Up to 18m
Audio Inputs: Stereo BT, 3.5mm Stereo Jack, MicroSD Card
IP Rating: IPX6
Battery Type: 18Wh Lithium-ion (Equivalent to 3.6V,
5000mAh)
Battery Play Time: Up to 15 Hours
Battery Charge Time: 5 Hours
Charging Voltage/Current: DC 5V/2.4A
Dimensions (WxHxD): 300 x 160 x 102mm
Net weight: 1.34kg

Correct Disposal:

The speaker should be disposed of according to local
regulations.

Warnings:

To reduce the risk of fire or electric shock, do not expose
this speaker to rain or moisture.
Do not attempt to open the speaker as there are no
user-serviceable parts inside.
To reduce the risk of electric shock, do not remove the cover
or back of the speaker.

View Fullscreen

USER MANUAL

Portable Outdoor Wireless Speaker

www.nextaudiogroup.com

v202210

PACKAGING CONTENTS

IPX6 Portable Wireless Speaker

USB-C Charging Cable

USER MANUAL

User Manual

3.5mm Jack Audio Cable

Hereby, CVA ELECTRONICA, LDA declares that this equipment type is in compliance with the mandatory directives for the CE certification. The full text of the EU declaration of conformity is available at the following internet address: www.nextaudiogroup.com/en/apoio-ao-cliente/downloads

TRËND OVERVIEW

POWER ON/OFF
1. Long press the power switch for 2 seconds to turn on, the LED indicator flashes blue. 2. Long press the power switch for 2 seconds to turn off, the LED status indicator goes off.
BT WIRELESS CONNECTION
1. Switch to BT (Using the mode button), the LED indicator flashes blue continuously while waiting for pairing. 2. Then, activate the BT of your mobile device and search for “NEXT TRËND”. Click to connect. If the connection is successful, the LED indicator will turn solid blue. 3. The speaker automatically reconnects to the last paired device when both devices are close to each other.
UNPAIR BT DEVICE
Double press the mode button to unpair the previously paired BT devices. The status LED will flash blue searching for a new device to pair.

ANSWERING INCOMING CALLS Short press the Play/Pause button to answer incoming calls.
END CURRENT CALL Short press the Play/Pause button once to end the current call.
REJECT INCOMING CALL Long press the Play/Pause button for 2 seconds to reject the incoming call.
LAST NUMBER REDIAL Double press the Play/Pause button to redial the last called number.
OPERATING MODE Short press the Mode button to select the desired operation mode – BT / Micro SD card / AUX in. The Micro SD Card allows MP3 music format and a maximum storage of 32Gb.

VOICE ASSISTANT
Long press the Play/Pause button to activate your mobile voice assistant.
MUSIC PLAYBACK
1. Short press the Play/Pause button to pause or play 2. Long press the “-” to select previous track 3. Long press the “+” to select next track 4. Short press the “-” to decrease the volume level 5. Short press the “+” to increase the volume level
TWS (TRUE WIRELESS STEREO)
You can connect two TRËND speakers wirelessly, using BT only. 1. Make sure the BT function is OFF on your mobile device. 2. Turn on the two TRËND speakers. 3. Long press the mode button on both speakers for 8 seconds, then there comes up a tone meaning both speakers are now in TWS mode. 4. Activate the BT of your mobile device and search for “NEXT TRËND”. Click to connect.

CHARGING THE PORTABLE SPEAKER
1. As the speaker has a built-in, non-removable and rechargeable battery, please use the provided USB-C cable to charge it. 2. The charging voltage and current is 5V/2.4A. Please charge the TRËND with an input power equal or below 12W (2.4A). 3. Fully charge the speaker before the first use. It takes around five hours to charge for the subsequent use. 4. During charging, the LED lights up red, and goes off upon charging is completed. 5. The battery performance may decrease with increasing number of charging cycles and natural battery aging.
TECHNICAL SPECIFICATIONS
FR Driver: 2 x 75mm Full-Range Driver SW Driver: 2 x 82mm Passive Sub. Radiator RMS Power: 30W Frequency Response: 80Hz – 16kHz BT Technology: v5.0

BT Range: Up to 18m Audio Inputs: Stereo BT, 3.5mm Stereo Jack, MicroSD Card IP Rating: IPX6 Battery Type: 18Wh Lithium-ion (Equivalent to 3.6V, 5000mAh) Battery Play Time: Up to 15 Hours Battery Charge Time: 5 Hours Charging Voltage/Current: DC 5V/2.4A Dimensions (WxHxD): 300 x 160 x 102mm Net weight: 1.34kg
CORRECT DISPOSAL
When the TRËND is to be definitively discarded, take the product to a local recycling plant for a disposal which is not harmful to the environment. This equipment should not be treated as general household waste. Devices marked with this symbol must not be disposed of as household waste. For more information, please contact your retailer or local authorities.

WARNINGS
1. Please follow these instructions before use. 2. Do not immerse the speaker in any liquid. Any water damage won’t be covered by warranty. 3. Please charge the speaker with a 5V/2.4A DC charger. Other chargers may damage the speaker. 4. Please store or use the speaker in a normal temperature environment (5ºC to 25ºC). 5. Please keep the speaker away from heat sources, such as radiators, hot air regulators, stoves, or other heat generating instruments. 6. Do not jam the in/out speaker ports, such as charger, microphone and audio jack. 7. In order to protect your hearing and extend the speaker service life, it is not recommended to adjust the volume to the maximum level for a long period of time. 8. If the equipment is not functioning properly or has been damaged in any way, switch it off immediately. 9. Do not open or try to service the equipment. It may only be repaired by authorized, qualified personnel.
