Acuitybrands H-type Adapter Installation Guide

H-Type Adapter

Product Information

This product is an H-Type Adapter designed for installation in a
track. It is used to connect and secure electrical components in a
circuit. The adapter box has a latch and a polarity line to ensure
proper alignment and connection.

Product Usage Instructions

1. Locate the latch and the polarity line on the adapter box.
2. Align the parts as shown in the diagram.
3. Insert the adapter box into the track.
4. Rotate the adapter box in the opposite direction of the arrows
   until the latch snaps in place between the two track rails.
5. Continue to depress the latch until the adapter box reaches its
   final position.
6. To position the second circuit, follow these steps:
   1. Hold onto the Adapter Box with one hand.
   2. Place the end of a flat head screwdriver under the contact
      shown in the diagram.
   3. Gently pull up on the screwdriver, causing the contact to move
      vertically until it hits a hard stop.
   4. Follow the instructions for inserting the adapter box into the
      track.

Please refer to the accompanying diagrams for visual assistance
in understanding the installation process.

Coming Soon

INSTALLATION INSTRUCTIONS
For H-Type Adapter

SAVE THESE INSTRUCTIONS

Find the latch and the polarity line. Align parts as shown below and insert the adapter box into the track

Rotate the adapter box opposite the arrows until the latch snaps in place between the two track rails

Final Position

Polarity Line

Latch on adapter box

Rotate adapter box opposite the arrows

Continue to depress latch until final position

Second Circuit Positioning
1. Hold onto Adapter Box with one hand 2. Place the end of a flat head screw driver under the contact shown below 3. Gently pull up, the contact should move vertically until hitting a hard stop 4. Follow instructions for inserting into track

Place flat head under the contact

Latch snaps into place between rails
Final Position

1300 S. Wolf Road · Des Plaines, IL 60018 · 800-323-5068 ·www.acuitybrands.com ©2017 Acuity Brands Lighting, Inc. Rev 4/18 P4677

1 of 1
