G-Type Adapter
Product Information
The G-Type Adapter is a device designed for installation
purposes. It is used to connect and secure two track rails
together. The adapter box has a latch and a polarity line that
assist in aligning and locking the adapter into position.
Product Usage Instructions
- Locate the latch and polarity line on the G-Type Adapter.
- Align the parts as shown in the diagram below.
- Insert the adapter box into the track.
- Rotate the adapter box in the opposite direction of the arrows
until the latch snaps in place between the two track rails. - Ensure that the polarity line is correctly aligned.
- Depress the latch until the adapter box reaches its final
position. - Confirm that the latch securely snaps into place between the
track rails.
Note: Please refer to the diagram in the user manual for
visual guidance on the installation process.
Coming Soon
INSTALLATION INSTRUCTIONS
For G-Type Adapter
SAVE THESE INSTRUCTIONS
Find the latch and the polarity line. Align parts as shown below and insert the adapter box into the track
Rotate the adapter box opposite the arrows until the latch snaps in place between the two track rails
Final Position
Polarity Line
Rotate adapter box opposite the Latch on adapter box arrows
Continue to depress latch until final position
Latch snaps into place between rails
One Lithonia Way · Conyers, GA 30012 · 1-800-705-SERV (7378) · www.acuitybrands.com 1 of 1 ©2020 Acuity Brands Lighting, Inc. Rev 4/20 P4676
