EB2840 Bluetooth Module
Product Information
| Product Model | EB2840 |
|---|---|
| Manufacturer | KAGA FEI Co., Ltd. |
| FCC ID | 2A6NFEB2840 |
| IC | 28568-EB2840 |
Product Usage Instructions
- Installation: This module should be installed
in the host device according to the interface specification. - Japan Regulatory Information:
- This module is approved with the specific antenna on this
module. - Please ensure that your product can bear a label with the
following information. If the product is so small that it is not
practicable to place the label, please place it in the instruction
manual and package. This product installs a radio system which has
been approved as a radio station in a low power data communication
system based on the Radio Law. EB2840: 005-103106
- This module is approved with the specific antenna on this
- Canada Regulatory Information:
- This device complies with Innovation, Science and Economic
Development Canada’s applicable licence-exempt RSSs. Operation is
subject to the following two conditions: (1) This device may not
cause interference; and (2) This device must accept any
interference, including interference that may cause undesired
operation of the device. - This product is certified as type of the portable device with
Innovation, Science and Economic Development Canada Rules. To
maintain compliance with RF Exposure requirement, please use within
specification of this product and have a separation distance of
minimum 15 mm between the user and/or bystander and the antenna
and/or radiating element. This distance ensures that the output
power (e.i.r.p.) of EB2840 is below the SAR evaluation Exemption
limits defined in RSS-102 issue 5.
- This device complies with Innovation, Science and Economic
- FCC Regulatory Information:
- This device complies with part 15 of the FCC Rules.
- The following statement shall be indicated on the host device
or the user manual of the host device; Operation is subject to the
following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired
operation. - Please notify certified ID by either one of the following
method on your product:- Contains Transmitter Module FCC ID: 2A6NFEB2840
- Contains FCC ID: 2A6NFEB2840
- The following statement shall be indicated in the user manual
of the host device: CAUTION: Changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment. - The modular transmitter is only FCC authorized for the specific
rule parts (Part 15 Subpart C) listed on the grant, and the host
product manufacturer is responsible for compliance to any other FCC
rules that apply to the host not covered by the modular transmitter
grant of certification. The final host product still requires Part
15 Subpart B compliance testing with the modular transmitter
installed. - This product is certified as type of the portable device with
FCC Rules. To maintain compliance with RF Exposure requirement,
please use within specification of this product.
EB2840
27-Jan.2023 Ver.0.1 KAGA FEI Co., Ltd.
User manual
(for EB2840)
FCC ID: 2A6NFEB2840 IC: 28568-EB2840
KAGA FEI Co., Ltd.
1/6
EB2840
27-Jan.2023 Ver.0.1 KAGA FEI Co., Ltd.
This module should be installed in the host device according to the interface specification .
1) Japan Regulatory Information a) This module is approved with the specific antenna on this module. b) Please ensure that your product can bear a label with the following information. If the product is so small that it is not practicable to place the label, please place it in the instruction manual and package. This product installs a radio system which has been approved as a radio station in a low power data communication system based on the Radio Law. EB2840 : 005-103106
2) Canada Regulatory Information The following information must be indicated on the host device of this module; a) This device complies with Innovation, Science and Economic Development Canada’s applicable licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’ Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) l’appareil ne doit pas produire de brouillage; 2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
b) This product is certified as type of the portable device with Innovation, Science and Economic Development Canada Rules. To maintain compliance with RF Exposure requirement, please use within specification of this product and have a separation distance of minimum 15 mm between the user and/or bystander and the antenna and /or radiating element. This distance ensures that the output power (e.i.r.p.) of EB2840 is below the SAR evaluation Exemption limits defined in RSS-102 issue 5.
Ce produit est certifié comme type de l’appareil portable avec Règles de Innovation, Sciences et Développement économique Canada. Pour maintenir l’acquiescement avec exigence Exposition de RF, veuillez utiliser dans spécification de ce produit et respecter une distance de séparation d’au moins 15 mm entre l’utilisateur et / ou un tiers et l’antenne et / ou l’élément rayonnant. Cette distance garantit que la puissance de sortie (p.i.r.e.) d’EB2840 est inférieure aux limites d’exemption de l’évaluation SAR définies dans le numéro 5 de la norme RSS-102. – IC: 28568-EB2840
KAGA FEI Co., Ltd.
2/6
EB2840
27-Jan.2023 Ver.0.1 KAGA FEI Co., Ltd.
c) Please notify certified ID by either one of the following method on your product. -Contains IC : 28568-EB2840 Specifiez ID certifiée dans votre produit par une de méthode suivante. -Contains IC : 28568-EB2840
3) FCC Regulatory Information
a) This device complies with part 15 of the FCC Rules.
-Part 15 Subpart C
b) The following statement shall be indicated on the host device or the user manual of the
host device; Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
c) Please notify certified ID by either one of the following method on your product.
-Contains Transmitter Module FCC ID: 2A6NFEB2840
-Contains FCC ID: 2A6NFEB2840
d) The following statement shall be indicated in the user manual of the host device;
CAUTION: Changes or modifications not expressly approved by the party responsible
for compliance could void the use’s authority to operate the equipment.
e) The modular transmitter is only FCC authorized for the specific rule parts (Part 15
Subpart C) listed on the grant, and the host product manufacturer is responsible for
compliance to any other FCC rules that apply to the host not covered by the modular
transmitter grant of certification. The final host product still requires Part 15 Subpart B
compliance testing with the modular transmitter installed.
f) This product is certified as type of the portable device with FCC Rules. To maintain
compliance with RF Exposure requirement, please use within specification of this
product.
g) The following statement shall be indicated in the user manual of the host device; The
antenna used for this transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
h) This module can change the output power depending on the circumstances by the
application software which is developed by module installer. Any end user cannot
change the output power.
i) Antenna List
No.1
Antenna Category Monopole
Antenna Type
PCB antenna
Dimensions
9.6mm x 3.75mm
4) CE Regulatory Information a) When your end product installs this module, it is required to proceed additional certification processes before placing on the market in EU member states to make your products fully comply with relative EU standards. b) KAGA FEI can provide you the test reports of conducted measurement portion for the radio module. You can utilize the test reports for the certification processes of your end product as it requires radio testing.
KAGA FEI Co., Ltd.
3/6
EB2840
Control No.
Pin Descriptions
Pin
Pin name
1 GND
2 P0.29_AIN5
3 P0.31_AIN7
4 P0.05_AIN3
5 P0.26 6 P1.08 7 P0.06 8 GND 9 VDD 10 GND 11 VDDH 12 VBUS 13 D14 D+ 15 P0.13
16 P0.18_RESET
17 P0.20 18 P0.21 19 P0.24 20 P1.00
21 SWDIO
22 SWDCLK
23 P1.04 24 P1.06
25 P0.09_NFC1
26 P0.10_NFC2
27 P1.12 28 GND
Control name (1/3) Pin Layout
27-Jan.2023 Ver.0.1 KAGA FEI Co., Ltd.
Pin function
Description
Ground
Ground
Digital I/O Analog input Digital I/O Analog input
General purpose I/O Analog input General purpose I/O Analog input
Digital I/O Analog input Digital I/O Digital I/O
General purpose I/O Analog input General purpose I/O General purpose I/O
Digital I/O
General purpose I/O
Ground Power
Ground Power supply
Ground
Ground
Power
High voltage power supply
Power
5 V input for USB 3.3 V regulator
Digital I/O Digital I/O
USB DUSB D+
Digital I/O
General purpose I/O
Digital I/O Digital I/O
General purpose I/O Configurable as system RESET (Factory default : GPIO) General purpose I/O
Digital I/O
General purpose I/O
Digital I/O Digital I/O
Debug
General purpose I/O General purpose I/O Serial wire debug I/O for debug and programming
Debug Digital I/O
Serial wire debug clock input for debug and programming General purpose I/O
Digital I/O
General purpose I/O
Digital I/O NFC input
General purpose I/O NFC antenna connection
Digital I/O NFC input
General purpose I/O NFC antenna connection
Digital I/O
General purpose I/O
Ground
Ground
KAGA FEI Co., Ltd.
4/6
EB2840
Control No.
Pin
Pin name
29 OUT_MOD
30 OUT_ANT 31 GND 32 P0.02_AIN0
33 P0.28_AIN4
34 P0.30_AIN6
35 P0.27
36 P0.04_AIN2
37 P0.07 38 P0.08 39 P1.09 40 P0.11 41 P0.12 42 P0.14 43 P0.15 44 P0.16 45 P0.17 46 P0.19 47 P0.22 48 P0.23 49 P0.25 50 P1.01 51 P1.03 52 P1.05 53 P1.07 54 P1.02
55 P0.03_AIN1
27-Jan.2023 Ver.0.1
KAGA FEI Co., Ltd.
Control name (2/3) Pin Layout
Pin function
RF In/Out
Antenna In/Out
Ground Digital I/O Analog input Digital I/O Analog input Digital I/O Analog input Digital I/O Digital I/O Analog input Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Analog input
Description RF I/O pin. It should be connected to Pin30 OUT_ANT for normal operation. Internal antenna. It should be connected to Pin29 OUT_MOD for normal operation Ground General purpose I/O Analog input General purpose I/O Analog input General purpose I/O Analog input General purpose I/O General purpose I/O Analog input General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O Analog input
KAGA FEI Co., Ltd.
5/6
EB2840
Control No.
Pin
Pin name
56 P1.14
57 P1.11
58 P1.15
59 P1.10
60 P1.13
61 Corner pad
62 Corner pad
63 Center pad
27-Jan.2023 Ver.0.1
KAGA FEI Co., Ltd.
Control name (3/3) Pin Layout
Pin function Digital I/O Digital I/O Digital I/O Digital I/O Digital I/O Ground Ground Ground
Description General purpose I/O General purpose I/O General purpose I/O General purpose I/O General purpose I/O Ground 1.0mm x 0.7mm Ground 1.0mm x 0.7mm Ground 4.3mm x 3.0mm
KAGA FEI Co., Ltd.
6/6
