Quoizel Sglm434mbk Seigler 4-light Matte Black Linear Chandelier Installation Guide

SGLM434MBK Seigler 4-Light Matte Black Linear Chandelier

Product Information: SGLM434MBK

SGLM434MBK is a ceiling fixture with a black frame surface. It
comes with a 12L Rod X4, AC Fixture Loop X2, 6L Rod X4, Mica Sheet
X 47pcs, Clasp X 47, Crossbar Assembly X1, Wire Connector X3,
Outlet Box Screw X2, and an AE Ceiling Canopy X1. The fixture is
compatible with medium (E26) bulb base type and supports a maximum
wattage of 100W.

Product Usage Instructions

Please read and understand the entire manual before attempting
to assemble, install or operate the product.

Safety Information

Before beginning installation, turn off electricity at the
circuit breaker box or the main fuse box to avoid the risk of
electric shock. Use bulbs specified by the markings and/or labels
on the fixture to avoid the risk of fire. If in doubt about
electrical installation, consult a licensed electrician. Turn off
electricity to fixture before replacing the bulb(s).

Tools Required

No tools are required for installation.

Care and Maintenance

Wipe clean using a soft, dry cloth or static duster. Always
avoid using harsh chemicals and abrasives to clean fixture as they
may damage the finish. If you need further assistance call Quoizel
Customer Care at 1-800-645-3184(9:00 am – 5:00 pm EST) or visit us
online at www.quoizel.com.

Installation

1. Install Fixture Loop.
2. Install Rods. Optional Rods: 8 Feet Ceiling: (2) 12L Rods each
   side. 9 Feet Ceiling: (2) 6L Rods + (2) 12L Rods each side.
3. Separate Swivels from Ceiling Canopy.
4. Install Swivels and Ceiling Canopy to Upper Rods.
5. Install Crossbar Assembly. Swivel 90Degree. For angled
   ceilings, Swivels opening towards wall. Make sure two swivels
   opening are in the same direction while assembling.
6. Install Lanyards. Button Stop Lanyard Lanyard.
7. Wiring. White wire from supply Black (or red) wire from supply
   Ground wire from supply Green ground screw.
8. Install Ceiling Canopy.
9. Install Mica Sheets. Mica Sheet X 47pcs [1pc Replacement Mica
   included]. The black frame surface is outside.
10. Install Bulbs. Install four correct bulbs referring to fixture
    markings and/or labels for maximum wattage. Recommended Bulb Type
    (not included): 100W MAX BULB BASE TYPE BULB TYPE Medium (E26) TYPE
    A.

Your installation is now complete! Restore electricity and save
this sheet for future reference.

INSTALLATION GUIDE FOR SGLM434MBK

SAFETY INFORMATION

Released Date: 2022-03-14

Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
. RISK OF ELECTRIC SHOCK – Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box. . RISK OF FIRE – Use bulbs specified by the markings and/or labels on the fixture.
CAUTION
. For your safety, read instructions completely before beginning installation. . If in doubt about electrical installation, consult a licensed electrician. . Turn off electricity to fixture before replacing the bulb(s).
TOOLS REQUIRED

CARE AND MAINTENANCE
. Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish. If you need further assistance call Quoizel Customer Care at 1-800-645-3184(9:00am – 5:00pm EST), or visit us on-line at www.quoizel.com
PACKAGE CONTENTS

A 12″L Rod X4

AC Fixture Loop X2

B 6″L Rod X4
MOUNTING HARDWARE

D

Mica Sheet X 47pcs

Mica included]

F

Clasp X 47

Clasp included]

AE Ceiling Canopy X1

AG Fixture Body X1

AA

Crossbar Assembly X1

BB

Wire Connector X3

CC

Outlet Box Screw X2

– 1 of 3 –

INSTALLATION
1 Install Fixture Loop

2 Install Rods
Optional Rods: 8 Feet Ceiling: (2) 12″L Rods each side. 9 Feet Ceiling: (2) 6″L Rods + (2) 12″L Rods each side.

3 Separate Swivels from Ceiling Canopy

4

Install Swivels and Ceiling Canopy to Upper Rods

5 Install Crossbar Assembly

Swivel

90Degree
For angled ceilings, Swivels opening towards wall.

* Make sure two swivels opening are in the same direction while assembling.

6 Install Lanyards

Button Stop

Lanyard Lanyard

– 2 of 3 –

INSTALLATION
7 Wiring
White wire from supply Black (or red) wire from supply
Ground wire from supply Green ground screw
8 Install Ceiling Canopy

9 Install Mica Sheets
*Mica Sheet X 47pcs [1pc Replacement Mica included]

The black frame surface is outside.

10 Install Bulbs
Install four correct bulbs referring to fixture markings and/or labels for maximum wattage. Recommended Bulb Type (not included):
100W MAX

BULB BASE TYPE BULB TYPE

Medium (E26)

TYPE A

Your installation is now complete! Restore electricity and save this sheet for future reference.

– 3 of 3 –
