4G-CAT1 Q Series Micro Locator Vehicle Wireless Terminal
Product Information: 4G-CAT1 Q Series Specification V1.0
The 4G-CAT1 Q series is a micro locator designed for personnel
or asset monitoring and management. It can be used for various
purposes such as elderly, children or field personnel tracking,
rental vehicles, credit vehicles, valuables storage and
transportation, auto finance risk control, etc. The device is
equipped with low power consumption, anti-removal alarm and good
concealment features. It supports GPS, BD, LBS, and WiFi multiple
positioning and is fully compatible with 4G network LTE. The device
has an accurate positioning system, reliable network, real-time
location tracking, intelligent working mode, and multiple security
guarantees.
Product Usage Instructions:
- Before installing the vehicle wireless terminal, read the
function manual carefully. - Check the items in the packaging box before installation. If
there is any omission, contact the dealer immediately. - The device is a security product and should only be used in
legal scenes. Using it in illegal scenes may result in disputes and
legal liabilities. - The device supports GPS, BD, LBS, and WiFi multiple
positioning. It also has an accurate positioning system, reliable
network, real-time location tracking, intelligent working mode, and
multiple security guarantees. - The device has low power consumption, standby length,
long-range FOTA remote sets the terminal parameters, and supports
SMS mode to set the terminal parameters. - The device supports shock alarm, multiple security guarantees,
dormant type long standby, high concealment, long standby and
real-time track tracking mode free switch, power saving and
tracking each other. It also has remote update and upgrade the
device program. - Support light sensing alarm, removal alarm, and other multiple
alarm work ability. It can be uploaded to the platform when the
alarm occurs. - The device can be installed through strong magnetic adsorption
and has a standby current of 2mA and GPS sensitivity of
160dBm. - The device has a lithium polymer battery with a battery
capacity, voltage, and power consumption that varies based on
usage.
Technical Parameters:
Location mode: GPS, BD, LBS, and WiFi for
multiple positioning
Work frequency band: 2.4GWIFI:2412-2462MHz LTE
B5/38/41
Cell positioning accuracy: 10 m (this data for
reference, positioning error and the terrain of the vehicle is
timely Among other factors)
Working temperature: -25~+75
Working humidity: 5%~95% do not condense
Storage temperature: -40 — +85
Way to install: Strong magnetic adsorption
Standby current: 2mA
GPS sensitivity: 160dBm
Battery capacity, voltage and power
consumption: Varies based on usage
The 4G-CAT1 Q series specification V1.0
Preface
Please read this function manual in detail before installing the vehicle wireless terminal. The appearance picture is subject to change without notice.
Please carefully check the items in the packaging box before installation. If there is any omission, please contact the dealer immediately.The equipment is a security product, only used in legal scenes. If it is used in illegal scenes, disputes and legal liabilities have nothing to do with our company.
4G-CAT1 Q series, the product is a micro locator used for personnel or asset monitoring and management. Mainly used for the elderly, children or field personnel, rental vehicles, credit vehicles, valuables storage and transportation, auto finance risk control, etc. The equipment has the characteristics of low power consumption, anti-removal alarm and good concealment.
1. Product characteristics
Feature function: Standard 808 standard protocol. Support G-sensor speed sensing, judge the device wake up, dormancy, vibration alarm. Internal light sensor, support anti-disassembly alarm function. FOTA mobile terminal aerial download software upgrade to upgrade the devices with network function remotely through cloud upgrade technology.
2. Description of functional features
Functions and characteristics
Accurate positioning The network is reliable Real-time location and track tracking
Intelligent working mode
Function declaration
High sensitivity GPS & BD positioning module, accurate modulation of RF Parameters, support GPS, BD, LBS, WiFi multiple positioning
Fully compatible with 4G network LTE
B5/38/41) Intelligent dynamic reporting, embedded inflection point compensation, blind spot supplement reporting algorithm Power saving mode motor pattern Real-time online mode Roll Call mode (Q1 / Q3)
Low power consumption, standby length
long-range FOTA Remote sets the terminal parameters
Used in many ways Shock alarm
Multiple security guarantees
Dormant type long standby, high concealment.
Long standby and real-time track tracking
mode free switch, power saving and tracking
each other. Remote update and upgrade the device program
Support the SMS mode to set the terminal parameters
SMS, web page, APP
Vehicle vibration is an intelligent reminder The electronic fence function is supported. Users can delimit the virtual electronic fence through the platform / APP. The devices can be recognized by the platform and alerted when entering and leaving the fence. Support light sensing alarm, removal alarm
and other multiple alarm work ability. It can be uploaded to the platform when the alarm occurs.
3. Technical parameters
location mode Work frequency band cell positioning accuracy
working temperature Working humidity Storage temperature way to install Standby current GPS sensitivity
GPS, BD, LBS, and WiFi for multiple positioning 2.4GWIFI:2412-2462MHz LTE B5/38/41 Polymer lithium battery 10 m (this data for reference, positioning error and the terrain of the vehicle is timely Among other factors) -25~+75
5%~95% do not condense -40 — +85
Strong magnetic adsorption 2mA 160dBm
Battery capacity, voltage and power consumption
model
battery capacity
voltage
working current
Q1
1250 mAh DC 5V 1. Movement mode (WiFi is preferred)
Q3
1500 mAh
is 7 mA 2. Movement mode (GPS is preferred),
Q5
5000 mAh
Q7
10000 mAh
17.4mA 3. Intelligent mode is in a stationary state of 6.2 mA 4. Timing upload mode is 6.5 mA
5. Power saving mode is 3.1 mA
6. Deep dormancy mode is 4.2 mA
4. Product usage
1.SIM card insertion, open SIM card plug
This device needs to insert a traffic card traffic card with the GPRS traffic and SMS function. Please use the Nano card, as shown in the figure below
2. Indicator lamp
Equipment switch: Long press open key 5-6 seconds, three lights at the same time.
indicator status: power indicator constant in charging the device until the device is fully charged
Note: When the key fails to activate the indicator, the equipment power may run exhausted and the device should be charged
pilot lamp
Always on (press the key activation indicator constant for 40 seconds)
Slow flash
Power supply indicator light Equipment charging (red)
LTE indicator lamp (green) Networking success
Is the search net
GPS indicator light (blue) Has been positioned
Search for positioning
5. Product configuration list
Accessories name main engine USB cable instructions
quantity 1 1 1
Standard / optional standard configuration standard configuration standard configuration
FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: · Reorient or relocate the receiving antenna. · Increase the separation between the equipment and receiver. · Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. · Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.
