IBB64200CB Built-in Induction Plate Hob
Product Information
The AEG IBB64200CB is an induction hob with a cooking surface
layout of 1 induction cooking zone and a control panel layout of 5
sensor fields. It has a built-in design and requires a qualified
person for installation. The hob has a rating plate at the bottom,
which contains the model, PNC, and serial number. The appliance
requires an electrical connection and has different voltage
requirements based on the wiring colors.
Product Usage Instructions
Before installation and use, carefully read the supplied
instructions to prevent any injuries or damage. Always keep the
status of the appliance in check and use original spare parts. If
you need to contact the authorized service center, make sure to
provide them with the model, PNC, and serial number.
Installation
Refer to the safety chapters before installation. Write down the
serial number from the rating plate before installation. Only use
the built-in hobs after you assemble the hob into correct built-in
units and work surfaces that align with the standards. Follow the
connection diagram to connect the hob to the electrical supply.
Assembly
If you install the hob under a hood, refer to the installation
instructions of the hood for the minimum distance between the
appliances. If the appliance is installed above a drawer, the hob
ventilation can warm up the items stored in the drawer during the
cooking process. You can find a video tutorial on how to install
your AEG Induction Hob – Worktop installation by visiting
www.youtube.com/electrolux or www.youtube.com/aeg.
Control Panel
Use the sensor fields to operate the appliance. The displays,
indicators, and sounds tell which functions operate. The first
sensor field is for On/Off function.
IBB64200CB
EN User Manual Hob
USER MANUAL
2 www.aeg.com
CONTENTS
1. SAFETY INFORMATION………………………………………………………………………….. 2 2. SAFETY INSTRUCTIONS………………………………………………………………………… 5 3. INSTALLATION………………………………………………………………………………………..7 4. PRODUCT DESCRIPTION………………………………………………………………………..8 5. DAILY USE…………………………………………………………………………………………….. 9 6. HINTS AND TIPS……………………………………………………………………………………11 7. CARE AND CLEANING………………………………………………………………………….. 13 8. TROUBLESHOOTING……………………………………………………………………………. 14 9. TECHNICAL DATA………………………………………………………………………………… 15 10. ENERGY EFFICIENCY………………………………………………………………………….16 11. ENVIRONMENTAL CONCERNS…………………………………………………………….16
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support
Register your product for better service: www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance: www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, PNC, Serial Number. The information can be found on the rating plate.
Warning / Caution-Safety information General information and tips Environmental information
Subject to change without notice.
1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the
ENGLISH 3
instructions in a safe and accessible location for future reference. 1.1 Children and vulnerable people safety · This appliance can be used by children aged from 8
years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children of less than 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. · Children should be supervised to ensure that they do not play with the appliance. · Keep all packaging away from children and dispose of it appropriately. · WARNING: The appliance and its accessible parts become hot during use. Keep children and pets away from the appliance when in use and when cooling down. · If the appliance has a child safety device, it should be activated. · Children shall not carry out cleaning and user maintenance of the appliance without supervision. 1.2 General Safety · This appliance is for cooking purposes only. · This appliance is designed for single household domestic use in an indoor environment. · This appliance may be used in, offices, hotel guest rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. · WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements.
4 www.aeg.com
· WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.
· Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid.
· WARNING: The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
· CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously.
· WARNING: Danger of fire: Do not store items on the cooking surfaces.
· Metallic objects such as knives, forks, spoons and lids should not be placed on the hob surface since they can get hot.
· Do not use the appliance before installing it in the built-in structure.
· Do not use a steam cleaner to clean the appliance. · After use, switch off the hob element by its control and
do not rely on the pan detector. · If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains. In case the appliance is connected to the mains directly using junction box, remove the fuse to disconnect the appliance from power supply. In either case contact the Authorised Service Centre. · If the supply cord is damaged, it must be replaced by the manufacturer, an authorized Service or similarly qualified persons in order to avoid a hazard. · WARNING: Use only hob guards designed by the manufacturer of the cooking appliance or indicated by the manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents.
2. SAFETY INSTRUCTIONS
2.1 Installation
WARNING! Only a qualified person must install this appliance.
WARNING! Risk of injury or damage to the appliance.
· Remove all the packaging. · Do not install or use a damaged
appliance. · Follow the installation instructions
supplied with the appliance. · Keep the minimum distance from
other appliances and units. · Always take care when moving the
appliance as it is heavy. Always use safety gloves and enclosed footwear. · Seal the cut surfaces of the cabinet with a sealant to prevent moisture from causing swelling. · Protect the bottom of the appliance from steam and moisture. · Do not install the appliance next to a door or under a window. This prevents hot cookware from falling from the appliance when the door or the window is opened. · Each appliance has cooling fans on the bottom. · If the appliance is installed above a drawer: Do not store any small pieces or
sheets of paper that could be pulled in, as they can damage the cooling fans or impair the cooling system. Keep a distance of minimum 2 cm between the bottom of the appliance and parts stored in the drawer. · Remove any separator panels installed in the cabinet below the appliance.
2.2 Electrical Connection
WARNING! Risk of fire and electric shock.
ENGLISH 5
· All electrical connections should be made by a qualified electrician.
· The appliance must be earthed if the
symbol ( ) is not printed on the rating plate. · Before carrying out any operation make sure that the appliance is disconnected from the power supply. · Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply. · Make sure the appliance is installed correctly. Loose and incorrect electricity mains cable or plug (if applicable) can make the terminal become too hot. · Use the correct electricity mains cable. · Do not let the electricity mains cable tangle. · Make sure that a shock protection is installed. · Use the strain relief clamp on the cable. · Make sure the mains cable or plug (if applicable) does not touch the hot appliance or hot cookware, when you connect the appliance to a socket. · Do not use multi-plug adapters and extension cables. · Make sure not to cause damage to the mains plug (if applicable) or to the mains cable. Contact our Authorised Service Centre or an electrician to change a damaged mains cable. · The shock protection of live and insulated parts must be fastened in such a way that it cannot be removed without tools. · Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation. · If the mains socket is loose, do not connect the mains plug. · Do not pull the mains cable to disconnect the appliance. Always pull the mains plug. · Use only correct isolation devices: line protecting cut-outs, fuses (screw type
6 www.aeg.com
fuses removed from the holder), earth leakage trips and contactors. · The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.
2.3 Use
WARNING! Risk of injury, burns and electric shock.
· Do not change the specification of this appliance.
· Remove all the packaging, labelling and protective film (if applicable) before first use.
· Make sure that the ventilation openings are not blocked.
· Do not let the appliance stay unattended during operation.
· Set the cooking zone to “off” after each use.
· Do not put cutlery or saucepan lids on the cooking zones. They can become hot.
· Do not operate the appliance with wet hands or when it has contact with water.
· Do not use the appliance as a work surface or as a storage surface.
· If the surface of the appliance is cracked, disconnect immediately the appliance from the power supply. This to prevent an electrical shock.
· Users with a pacemaker must keep a distance of minimum 30 cm from the induction cooking zones when the appliance is in operation.
· When you place food into hot oil, it may splash.
WARNING! Risk of fire and explosion
· Fats and oil when heated can release flammable vapours. Keep flames or heated objects away from fats and oils when you cook with them.
· The vapours that very hot oil releases can cause spontaneous combustion.
· Used oil, that can contain food remnants, can cause fire at a lower
temperature than oil used for the first time. · Do not put flammable products or items that are wet with flammable products in, near or on the appliance.
WARNING! Risk of damage to the appliance.
· Do not keep hot cookware on the control panel.
· Do not put a hot pan cover on the glass surface of the hob.
· Do not let cookware boil dry. · Be careful not to let objects or
cookware fall on the appliance. The surface can be damaged. · Do not activate the cooking zones with empty cookware or without cookware. · Do not put aluminium foil on the appliance. · Cookware made of cast iron or with a damaged bottom can cause scratches on the glass / glass ceramic. Always lift these objects up when you have to move them on the cooking surface.
2.4 Care and cleaning
· Clean the appliance regularly to prevent the deterioration of the surface material.
· Switch off the appliance and let it cool down before cleaning.
· Do not use water spray and steam to clean the appliance.
· Clean the appliance with a moist soft cloth. Use only neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.
2.5 Service
· To repair the appliance contact the Authorised Service Centre. Use original spare parts only.
· Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, vibration, humidity, or are intended to signal information about the operational
ENGLISH 7
status of the appliance. They are not intended to be used in other applications and are not suitable for household room illumination.
2.6 Disposal
WARNING! Risk of injury or suffocation.
· Contact your local authority for information on how to dispose of the appliance.
· Disconnect the appliance from the mains supply.
· Cut off the mains electrical cable close to the appliance and dispose of it.
3. INSTALLATION
WARNING! Refer to Safety chapters.
3.1 Before the installation
Before you install the hob, write down the information below from the rating plate. The rating plate is on the bottom of the hob.
Serial number ………………………
3.2 Built-in hobs
Only use the built-in hobs after you assemble the hob into correct built-in units and work surfaces that align to the standards.
3.4 Connection diagram
3.3 Connection cable
· The hob is supplied with a connection cable. The connection cable may only be installed by a qualified electrician.
· To replace the damaged mains cable, use the cable type: H05V2V2-F or equivalent, which withstands a temperature of 90 °C or higher. Contact an Authorised Service Centre. The connection cable may only be replaced by a qualified electrician.
· The appliance works either at 50 Hz or 60 Hz and does not require any additional action from a qualified electrician in order to switch between frequencies.
380 – 415V 2N ~
220 – 240V ~ 220 – 240V ~
220 – 240V 1N ~
220 – 240V ~
NL 220 – 240V ~
220 – 240V ~ 220 – 240V ~
N2 Blue
Wiring colours
N1
L2
Blue – Gray
Brown
L1 Black
8 www.aeg.com
3.5 Assembly
If you install the hob under a hood, please see the installation instructions of the hood for the minimum distance between the appliances.
min. 500mm
min. 50mm
If the appliance is installed above a drawer, the hob ventilation can warm up the items stored in the drawer during the cooking process.
Find the video tutorial “How to install your AEG Induction Hob – Worktop installation” by typing out the full name indicated in the graphic below.
www.youtube.com/electrolux www.youtube.com/aeg
How to install your AEG Induction Hob – Worktop installation
4. PRODUCT DESCRIPTION
4.1 Cooking surface layout
1
1
145 mm
180 mm
1
210 mm
145 mm
1 Induction cooking zone 2 Control panel
1
2
4.2 Control panel layout
1 2 34
5
ENGLISH 9
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate.
Sensor field
1
2
3
4-
5
/
Function
Comment
On / Off
To activate and deactivate the hob.
Lock / Child Safety De- To lock / unlock the control panel. vice
–
To select the cooking zone.
Heat setting display –
To show the heat setting. To set a heat setting.
4.3 Heat setting displays
Display
Description The cooking zone is deactivated.
–
The cooking zone operates.
Booster operates.
+ digit
There is a malfunction. A cooking zone is still hot (residual heat).
Lock / Child Safety Device operates.
Incorrect or too small cookware or no cookware on the cooking zone.
Automatic Switch Off operates.
5. DAILY USE
WARNING! Refer to Safety chapters.
5.1 Activating and deactivating
Touch for 1 second to activate or deactivate the hob.
10 www.aeg.com
5.2 Automatic Switch Off
The function deactivates the hob automatically if:
· all cooking zones are deactivated, · you do not set the heat setting after
you activate the hob, · you spill something or put something
on the control panel for more than 10 seconds (a pan, a cloth, etc.). An acoustic signal sounds and the hob deactivates. Remove the object or clean the control panel. · the hob gets too hot (e.g. when a saucepan boils dry). Let the cooking zone cool down before you use the hob again. · you use incorrect cookware. The
symbol comes on and the cooking zone deactivates automatically after 2 minutes. · you do not deactivate a cooking zone or change the heat setting. After some
time comes on and the hob deactivates. The relation between the heat setting and the time after which the hob deactivates:
Heat setting
1 – 2 3 – 4 5 6 – 9
The hob deacti- vates after 6 hours
5 hours
4 hours
1.5 hour
5.3 Selecting the cooking zone
To select a cooking zone touch the
sensor field corresponding to this zone. The display shows the heat setting
( ).
5.4 The heat setting
Set the cooking zone.
Touch Touch
to increase the heat setting. to decrease the heat setting.
Touch and at the same time to deactivate the cooking zone.
5.5 Residual heat indicator
WARNING! As long as the indicator is
on, there is a risk of burns from residual heat.
The induction cooking zones produce the heat necessary for the cooking process directly in the bottom of the cookware. The glass ceramic is heated by the heat of the cookware.
The indicator appears when a cooking zone is hot.
The indicator may also appear: · for the neighbouring cooking zones
even if you are not using them, · when hot cookware is placed on cold
cooking zone, · when the hob is deactivated but the
cooking zone is still hot.
The indicator disappears when the cooking zone has cooled down.
5.6 Booster
This function makes more power available to the induction cooking zones. The function can be activated for the induction cooking zone only for a limited period of time. After this time the induction cooking zone automatically sets back to the highest heat setting.
Refer to “Technical data” chapter.
To activate the function for a cooking zone: first set the cooking zone and than set the maximum heat setting. Touch
until comes on.
To deactivate the function: touch .
5.7 Lock
You can lock the control panel while cooking zones operate. It prevents an accidental change of the heat setting.
Set the heat setting first.
To activate the function: touch . comes on for 4 seconds.
To deactivate the function: touch . The previous heat setting comes on.
When you deactivate the hob, you also deactivate this function.
5.8 Child Safety Device
This function prevents an accidental operation of the hob. To activate the function: activate the hob with . Do not set any heat setting. Touch for 4 seconds. comes on. Deactivate the hob with . To deactivate the function: activate the hob with . Do not set any heat setting. Touch for 4 seconds. comes on. Deactivate the hob with . To override the function for only one cooking time: activate the hob with .
comes on. Touch for 4 seconds. Set the heat setting in 10 seconds. You can operate the hob. When you deactivate the hob with the function operates again.
5.9 OffSound Control (Deactivation and activation of the sounds)
Deactivate the hob. Press for 3 seconds. Press for 3 seconds. The display shows on the front left zone and or on the front right zone.
6. HINTS AND TIPS
WARNING! Refer to Safety chapters.
ENGLISH 11
Touch sensor field for the right rear zone
to choose one of the following:
· – the sounds are off
· – the sounds are on
When the function is set to you can hear the sounds only when:
· you touch · there is an error in the hob.
5.10 Power management
If multiple zones are active and the consumed power exceeds the limitation of the power supply, this function divides the available power between all cooking zones. The hob controls heat settings to protect the fuses of the house installation.
· If the hob reaches the limit of maximum available power (refer to the rating plate), the power of the cooking zones will be automatically reduced.
· The heat setting of the cooking zone selected last is always prioritised. The remaining power will be divided between the previously activated cooking zones in reverse order of selection.
· The heat setting display of the reduced zones changes between the initially selected heat setting and the reduced heat setting.
· Wait until the display stops flashing or reduce the heat setting of the cooking zone selected last. The cooking zones will continue operating with the reduced heat setting. Change the heat settings of the cooking zones manually, if necessary.
6.1 Cookware
For induction cooking zones a strong electro-magnetic field creates the heat in the cookware very quickly.
Use the induction cooking zones with suitable cookware.
12 www.aeg.com
· The bottom of the cookware must be as thick and flat as possible.
· Ensure pan bases are clean and dry before placing on the hob surface.
· In order to avoid scratches, do not slide or rub the pot across the ceramic glass.
Cookware material
· correct: cast iron, steel, enamelled steel, stainless steel, multi-layer bottom (with a correct marking from a manufacturer).
· not correct: aluminium, copper, brass, glass, ceramic, porcelain.
Cookware is suitable for an induction hob if:
· water boils very quickly on a zone set to the highest heat setting.
· a magnet pulls on to the bottom of the cookware.
Cookware dimensions
· Induction cooking zones adapt to the dimension of the bottom of the cookware automatically.
· The cooking zone efficiency is related to the diameter of the cookware. The cookware with a diameter smaller than the minimum receives only a part of the power generated by the cooking zone.
· For both safety reasons and optimal cooking results, do not use cookware larger than indicated in “Cooking zones specification”. Avoid keeping cookware close to the control panel during the cooking session. This might impact the functioning of the
control panel or accidentally activate hob functions.
Refer to “Technical data”.
6.2 The noises during operation
If you can hear:
· crack noise: cookware is made of different materials (a sandwich construction).
· whistle sound: you use a cooking zone with a high power level and the cookware is made of different materials (a sandwich construction).
· humming: you use a high power level. · clicking: electric switching occurs. · hissing, buzzing: the fan operates. The noises are normal and do not indicate any malfunction.
6.3 Examples of cooking applications
The correlation between the heat setting of a zone and its consumption of power is not linear. When you increase the heat setting, it is not proportional to the increase of the consumption of power. It means that a cooking zone with the medium heat setting uses less than a half of its power.
The data in the table is for guidance only.
Heat setting 1 1 – 2 2
Use to:
Time (min)
Hints
Keep cooked food warm.
as nec- Put a lid on the cookware. essary
Hollandaise sauce, melt: but- 5 – 25 ter, chocolate, gelatine.
Mix from time to time.
Solidify: fluffy omelettes, baked 10 – 40 Cook with a lid on. eggs.
ENGLISH 13
Heat setting 2 – 3
3 – 4 4 – 5
4 – 5 6 – 7
7 – 8 9
Use to:
Time (min)
Hints
Simmer rice and milkbased dishes, heat up ready-cooked meals.
25 – 50
Add at least twice as much liq- uid as rice, mix milk dishes halfway through the proce- dure.
Stew vegetables, fish, meat.
20 – 45
Add a few tablespoons of wa- ter. Check the water amount during the process.
Steam potatoes and other veg- 20 – 60 etables.
Cover the bottom of the pot with 1-2 cm of water. Check the water level during the process. Keep the lid on the pot.
Cook larger quantities of food, 60 – 150 Up to 3 l of liquid plus ingredi-
stews and soups.
ents.
Gentle fry: escalope, veal cor- don bleu, cutlets, rissoles, sausages, liver, roux, eggs, pancakes, doughnuts.
as nec- essary
Turn over when needed.
Heavy fry, hash browns, loin steaks, steaks.
5 – 15
Turn over when needed.
Boil water, cook pasta, sear meat (goulash, pot roast), deep-fry chips.
Boil large quantities of water. Booster is activated.
7. CARE AND CLEANING
WARNING! Refer to Safety chapters.
7.1 General information
· Clean the hob after each use. · Always use cookware with a clean
base. · Scratches or dark stains on the
surface have no effect on how the hob operates. · Use a special cleaner suitable for the surface of the hob. · Use a special scraper for the glass.
7.2 Cleaning the hob
· Remove immediately: melted plastic, plastic foil, salt, sugar and food with
sugar, otherwise, the dirt can cause damage to the hob. Take care to avoid burns. Use a special hob scraper on the glass surface at an acute angle and move the blade on the surface. · Remove when the hob is sufficiently cool: limescale rings, water rings, fat stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non-abrasive detergent. After cleaning, wipe the hob dry with a soft cloth. · Remove shiny metallic discoloration: use a solution of water with vinegar and clean the glass surface with a cloth.
14 www.aeg.com
8. TROUBLESHOOTING
WARNING! Refer to Safety chapters.
8.1 What to do if…
Problem
Possible cause
Remedy
You cannot activate or op- The hob is not connected to
erate the hob.
an electrical supply or it is
connected incorrectly.
Check if the hob is correctly connected to the electrical supply.
The fuse is blown.
Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician.
You did not set the heat set- Activate the hob again and set
ting for 10 seconds.
the heat setting in less than 10
seconds.
You touched 2 or more sen- Touch only one sensor field. sor fields at the same time.
There is water or fat stains on the control panel.
Clean the control panel.
You can hear a constant beep noise.
The electrical connection is incorrect.
Disconnect the hob from the electrical supply. Ask a quali- fied electrician to check the in- stallation.
An acoustic signal sounds and the hob deactivates. An acoustic signal sounds when the hob is deactiva- ted.
You put something on one or more sensor fields.
Remove the object from the sensor fields.
The hob deactivates.
You put something on the sensor field .
Remove the object from the sensor field.
Residual heat indicator does not come on.
The zone is not hot because it operated only for a short time or the sensor is dam- aged.
If the zone operated sufficient- ly long to be hot, speak to an Authorised Service Centre.
The heat setting changes Power management oper-
between two levels.
ates.
Refer to “Daily use”.
The control panel be- comes hot to the touch.
The cookware is too large or Put large cookware on the rear
you put it too close to the
zones, if possible.
control panel.
ENGLISH 15
Problem There is no sound when you touch the panel sen- sor fields.
comes on. comes on.
and a number come on.
Possible cause
Remedy
The sounds are deactivated. Activate the sounds. Refer to “Daily use”.
Child Safety Device or Lock Refer to “Daily use”. operates.
There is no cookware on the Put cookware on the zone. zone.
The cookware is unsuitable.
Use cookware suitable for in- duction hobs. Refer to “Hints and tips”.
The diameter of the bottom of the cookware is too small for the zone.
Use cookware with correct di- mensions. Refer to “Technical data”.
There is an error in the hob.
Deactivate the hob and acti- vate it again after 30 seconds.
If comes on again, discon- nect the hob from the electrical supply. After 30 seconds, con- nect the hob again. If the prob- lem continues, speak to an Au- thorised Service Centre.
8.2 If you cannot find a solution…
If you cannot find a solution to the problem yourself, contact your dealer or an Authorised Service Centre. Give the data from the rating plate. Give also three digit letter code for the glass ceramic (it is in the corner of the glass
9. TECHNICAL DATA
9.1 Rating plate
surface) and an error message that comes on. Make sure, you operated the hob correctly. If not the servicing by a service technician or dealer will not be free of charge, also during the warranty period. The information about guarantee period and Authorised Service Centres are in the guarantee booklet.
Model IBB64200CB Typ 64 B4A 00 AA Induction 6.9 kW Ser.Nr. …………….. AEG
PNC 949 492 597 00 220 – 240 V / 400 V 2N, 50 / 60 Hz Made in: Romania 6.9 kW
16 www.aeg.com
9.2 Cooking zones specification
Cooking zone
Nominal power (maximum heat setting) [W]
Booster [W]
Left front
2200
2400
Left rear
1400
1500
Right front
1400
1500
Right rear
1700
1800
Booster maxi- Cookware di- mum duration ameter [mm] [min]
4
125 – 210
4
125 – 145
4
125 – 145
4
150 – 180
The power of the cooking zones can be different in some small range from the data in the table. It changes with the material and dimensions of the cookware.
For optimal cooking results use cookware no larger than the diameter in the table.
10. ENERGY EFFICIENCY
10.1 Energy saving
You can save energy during everyday cooking if you follow the hints below.
· When you heat up water, use only the amount you need.
· If it is possible, always put the lids on the cookware.
· Put the cookware directly in the centre of the cooking zone.
· Use the residual heat to keep the food warm or to melt it.
11. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances. Do not dispose of
appliances marked with the symbol with the household waste. Return the product to your local recycling facility or contact your municipal office.
*
www.aeg.com/shop
867378389-B-452022
Welcome to AEG
Welcome to AEG
