CUBO2 Smart Condensing Units

CUBO Smart Reference Guide

Product Information

The CUBO2 Smart Condensing Units is a range of CO transcritical
condensing units that use inverter technology with the Carel Hecu
smart control strategy to give lower energy consumption than
traditional HFC solutions. With a GWP of 1, R744 systems provide a
long term environmentally friendly solution. The compact condensing
unit comes factory pre-set making it easy to install and maintain.
The product is available in two configurations: Medium Temperature
and Low Temperature. The Medium Temperature model is available in
four variants: UMTT 030 MTDX, UMTT 045 MTDX, UMTT 067 MTDX, and
UMTT 100 MTDX. The Low Temperature model is available in three
variants: UMTT 030 BTDX, UMTT 045 BTDX, and UMTT 067 BTDX.

Standard Configuration

The standard configuration of the Medium Temperature model is 80
Bar (Liquid Line) / 80 Bar (Suction). The standard configuration of
the Low Temperature model is not specified.

Specifications

Model	Part No.	-15Qo (W)	-10Qo (W)	-5Qo (W)	0Qo (W)	5Qo (W)	Pel (W)	*COP	**MEPS	V/Ph/Hz	Connections	MRA	P max W
UMTT 030 MTDX	480000	2181	2548	–	2939	3362	1419	1.54	1.76	230 / 1+N+PE / 50	K65 Gas Liquid	MRA A	3300
UMTT 045 MTDX	480001	3293	3847	–	4437	5077	2142	1.54	1.76	230 / 1+N+PE / 50	K65 Gas Liquid	MRA A	4650
UMTT 067 MTDX	480002	4722	–	–	5502	6359	3090	1.53 / 1.73	1.97 / 2.23	230 / 1+N+PE / 50 / 400 / 3+N+PE / 50	K65 Gas Liquid	MRA A	6630
UMTT 100 MTDX	480003	7047	–	–	8211	9491	4612	1.53 / 1.73	1.97 / 2.25	400 / 3+N+PE / 50	–	–	–
UMTT 030 BTDX	480050	3343	3904	–	–	–	2147 / 2149 / 2153	1.56 / 1.70 / 1.81	2.3	230 / 1+N+PE / 50	K65 MRA	–	12700
UMTT 045 BTDX	480051	5049 / 5331 / 5700	3242 / 3250 / 3242	–	–	–	–	1.56 / 1.64 / 1.76	2.3	230 / 1+N+PE / 50	K65 Gas Liquid	MRA A	7360
UMTT 067 BTDX	480052	6599 / 7268 / 7797	4902 / 4994 / 5097	1.35 / 1.46 / 1.53	–	–	–	2.24	400 / 3+N+PE / 50	230 / 1+N+PE / 50	K65 Gas Liquid	MRA A	10620

Features

Inverter modulation from 25 to 100% (1500 –> 6000 rpm)

Dimensions and Weight

The Medium Temperature model has dimensions of 1150 x 620 x 805
mm and weighs 150 kg. The Low Temperature model has dimensions of
1545 x 620 x 805 mm and weighs 176 kg.

Sound Pressure

The Medium Temperature model has a sound pressure of dB(A) 38 (@
10m field). The Low Temperature model has a sound pressure of dB(A)
41 (@ 10m field).

Usage Instructions

The CUBO2 Smart Condensing Units are designed for use in
refrigeration systems. The product comes factory pre-set making it
easy to install and maintain. Follow the instructions provided in
the product manual for installation and maintenance. The product is
available in two configurations: Medium Temperature and Low
Temperature. Choose the appropriate configuration based on your
refrigeration system requirements. Refer to the product
specifications for details on each model and choose the appropriate
model based on your specific requirements.

View Fullscreen

CUBO SMART
REFERENCE GUIDE

CUBO2 Smart Condensing Units

SCM have developed a range of CO transcritical condensing units that use inverter technology with the Carel Hecu smart control strategy to give lower energy consumption than traditional HFC solutions. This compact condensing unit comes factory pre-set making it easy to install and maintain. With a GWP of 1, R744 systems provide a long term environmentally friendly solution.
Standard Configuration:
· Toshiba DC Brushless Rotary Compressor with Inverter Modulation 25%-100%
· EC Fans · K65 Connections · 120 Bar (High Pressure side)
/ 80 Bar (Liquid Line) / 80 Bar (Suction)

Medium Temperature

Model

Part No.

UMTT 030 MTDX 480000

Performance at amb. +32°C
Qo (W) Pel (W) *COP **MEPS V / Ph / Hz

-15 2181 1419 1.54

-10 2548

Tev (°C)

-5

2939

3362

1444 1456

1452

1.76 2.02

2.32

1.76

230 / 1+N+PE / 50

CO ready

5 3826 1430 2.68

Connections K65 Gas Liquid

MRA A

3/8″

11.6

P max W
3300

Model UMTT 045 MTDX

Part No. 480001

Performance at amb. +32°C
Qo (W) Pel (W) *COP **MEPS V / Ph / Hz

-15 3293 2142 1.54

-10 3847

Tev (°C)

-5

4437

5077

2180 2198

2192

1.76 2.02

2.32

1.76

230 / 1+N+PE / 50

5 5778 2159 2.68

Connections K65 Gas Liquid

MRA A

3/8″

16.1

P max W
4650

Model UMTT 067 MTDX

Part No. 480002

Performance at amb. +32°C
Qo (W) Pel (W) *COP **MEPS V / Ph / Hz

-15 4722 3090 1.53

Tev (°C)

-10

-5

5502 6359

7280

3174 3234

3272

1.73 1.97

2.23

3.44 230 / 1+N+PE / 50

5 8251 3285 2.51

Connections K65 Gas Liquid

MRA A

3/8″

23.1

P max W
6630

* Coefficient Of Performance ** Minimum energy performance standard

CUBO Smart Reference Guide

Model UMTT 100 MTDX

Part No. 480003

Performance at amb. +32°C
Qo (W) Pel (W) *COP **MEPS V / Ph / Hz

-15 7047 4612 1.53

Tev (°C)

-10

-5

8211 9491 10866

4737 4827

4827

1.73 1.97

2.25

3.45

400 / 3+N+PE / 50

All models Inverter modulation from 25 to 100% (1500 –> 6000 rpm)

Dimensions: mm 1150 x 620 x 805 Weight: kg 150 Sound Pressure: dB(A) 38 (@ 10m field) PED: 1

Low Temperature

Model

Part No.

UMTT 030 BTDX

480050

Performance at amb +32 °C Qo [W] Pel (W) *COP **MEPS V/Ph/Hz

-30 3343

Tev (°C) -25 3662

-20 3904

2147 2149 2153

1.56 1.70 1.81

2.3

230 / 1+N+PE / 50

Connections K65 MRA P max

Gas Liquid A

–

1/2″ 3/8″ 17.3 12700

Connections K65

Gas

Liquid

MRA A

P max W

3/8″

16.1

6160

Model UMTT 045 BTDX

Part No. 480051

Performance at amb +32 °C
Qo [W] Pel (W) *COP **MEPS V/Ph/Hz

Tev (°C)

-30

-25

-20

5049 5331 5700

3242 3250 3242

1.56 1.64 1.76

2.3

230 / 1+N+PE / 50

Connections K65

Gas

Liquid

3/8″

MRA A
22.9

P max W
7360

Model UMTT 067 BTDX

Part No. 480052

Performance at amb +32 °C
Qo [W] Pel (W) *COP **MEPS V/Ph/Hz

Tev (°C)

-30

-25

-20

6599 7268 7797

4902 4994 5097

1.35 1.46 1.53

2.24 400 / 3+N+PE / 50

All models Inverter modulation from 25 to 100% (1500 –> 6000 rpm)

Dimension: mm 1545 x 620 x 805 Weight: kg 176 Sound Pressure: dB(A) 41 (@ 10m field) PED: 1

Connections K65

Gas

Liquid

MRA A

P max W

3/8″

20.4

10620

* Coefficient Of Performance ** Minimum energy performance standard

CUBO Smart Reference Guide

F27 HC 85 bar Unit Cooler for cold rooms

Model Fin 4.5mm
F27HC254 F27HC364 F27HC494 F27HC714 F27HC1074 F27HC1424
Model Fin 6.0mm
F27HC286 F27HC386 F27HC556 F27HC856 F27HC1106
Model Fin 7.0mm
F27HC167 F27HC237 F27HC317 F27HC467 F27HC707 F27HC927

Code
10200050 10200051 10200052 10200053 10200054 10200055
Code
10200061 10200062 10200063 10200064 10200065
Code
10200070 10200071 10200072 10200073 10200074 10200075

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

1510 1870 3060 3480 5600 7100

900 900 1800 1800 2700 3600

10.5 415 678 330 12 10.5 415 678 330 13 12.5 415 1048 330 19 12.5 415 1048 330 21 14 415 1418 330 28 15.5 415 1788 330 36

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

1610 2600 3100 4880 6300

950 1900 1900 2850 3800

11 415 678 330 12 13 415 1048 330 18 13 415 1048 330 20 14 415 1418 330 27 16 415 1788 330 34

CO2 Bar
85 85 85 85 85 85

# Fans 230v
1 1 2 2 3 4

Capacity Watts 8DT1
1120 1450 2330 2840 4420 5800

Air Volume m3/hr
1000 1000 2000 2000 3000 4000

Air Throw M
12 12 14 14 16 17

Dimensions
HWD
415 678 330 415 678 330 415 1048 330 415 1048 330 415 1418 330 415 1788 330

Weight Kg.
10 11 17 19 26 32

Key Features
New super efficient TURBOCOIL 2 Heat Exchanger – high efficiency small diameter copper tubes with turbulated aluminium fins. Suction pressure gauge connection allows checking of suction pressure and correct performance of unit cooler.

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions

CUBO Smart Reference Guide

F30 HC 85 bar Unit Cooler for cold rooms

Model Fin 4.5mm
F30HC4114 F30HC4124 F30HC4214 F30HC4224 F30HC4314
Model Fin 6.0mm
F30HC5116 F30HC5126 F30HC5216 F30HC5226 F30HC5316
Model Fin 7.0mm
F30HC6117 F30HC6127 F30HC6217 F30HC6227 F30HC6317 F30HC6327

Code

CO2 Bar

# Fans

Capacity Watts 8DT1

Air Volume Air Throw

m3/hr

Dimensions HWD

Weight Kg.

10200080 85

10200081 85

10200082 85

10200083 85

10200084 85

2560 2880 5200 6200 7400

1450 1300 2900 2600 4350

415 760 451 23

415 760 451 25

415 1210 451 39

415 1210 451 44

415 1660 451 56

Code

CO2 Bar

# Fans

Capacity Watts 8DT1

Air Volume Air Throw

m3/hr

Dimensions HWD

Weight Kg.

10200090 85

10200091 85

10200092 85

10200093 85

10200094 85

2190 2630 4410 5500 6400

1500 1400 3000 2800 4500

415 760 451 22

415 760 451 24

415 1210 451 38

415 1210 451 42

415 1660 451 54

Code
10200100 10200101 10200102 10200103 10200104 10200105

CO2 Bar
85 85 85 85 85 85

# Fans
1 1 2 2 3 3

Capacity Watts 8DT1
1960 2460 3950 5100 5800 7600

Air Volume m3/hr
1550 1450 3100 2900 4650 4350

Air Throw M
18 16 21 19 24 22

Dimensions
HWD
415 760 451 415 760 451 415 1210 451 415 1210 451 415 1660 451 415 1660 451

Weight Kg.
21 23 37 41 53 58

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions

CUBO Smart Reference Guide

F31HC 85 bar Unit Cooler for cold rooms

Model Fin 4.5mm
F31HC1154 F31HC1164 F31HC1254 F31HC1264
Model Fin 6.0mm
F31HC2156 F31HC2166 F31HC2256 F31HC2266 F31HC2356
Model Fin 7.0mm
F31HC3157 F31HC3167 F31HC3257 F31HC3267 F31HC3357

Code
10200110 10200111 10200112 10200113
Code
10200120 10200121 10200122 10200123 10200124
Code
10200130 10200131 10200132 10200133 10200134

CO2 Bar

# Fans

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

2840 3220 5800 7000

1650 1500 3300 3000

17 415 760 451 23 15 415 760 451 25 20 415 1210 451 39 18 415 1210 451 44

CO2 Bar

# Fans

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

2150 2720 4340 5700 6400

1800 1650 3600 3300 5400

19 415 760 451 22 16 415 760 451 24 22 415 1210 451 38 19 415 1210 451 42 25 415 1660 451 54

CO2 Bar

# Fans

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

2150 2720 4340 5700 6400

1800 1650 3600 3300 5400

20 415 760 451 21 17 415 760 451 23 23 415 1210 451 37 20 415 1210 451 41 26 415 1660 451 53

Key Features

New super efficient TURBOCOIL 2 Heat Exchanger – high efficiency small diameter copper tubes with turbulated aluminium fins. Suction pressure gauge connection allows checking of suction pressure and correct performance of unit cooler.

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions

CUBO Smart Reference Guide

F35HC 85 bar Unit Cooler for cold rooms

Model Fin 4.5mm
F35HC734 F35HC1064
Model Fin 6.0mm
F35HC596 F35HC846 F35HC1176
Model Fin 7.0mm
F35HC477 F35HC697 F35HC947

Code
10200140 10200141
Code
10200142 10200143 10200144
Code
10200150 10200151 10200152

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

3950 5300

2600 2400

487 865 416 27

487 865 416 32

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

3430 4670 7000

2650 2500 5300

487 865 416 26

18.5 487 865 416 31

23.5 487 1420 416 42

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

3110 4270 6300

2700 2600 5400

20.5 487 865 416 25

487 865 416 30

487 1420 416 41

Key Features

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions

CUBO Smart Reference Guide

SMA 85 bar Angled metal cased coolers for coldrooms

Model Fin 4.5mm
SMA21145 SMA21245 SMA21345 SMA21445 SMA22145 SMA22245 SMA23145 SMA23245
Model Fin 7.0mm
SMA31170 SMA31270 SMA31370 SMA31470 SMA32170 SMA32270 SMA33170 SMA33270 SMA34170

Code
10200030 10200031 10200032 10200033 10200034 10200035 10200036 10200037
Code
10200040 10200041 10200042 10200043 10200044 10200045 10200046 10200047 10200048

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

2070 2490 2830 3180 4170 5000 6300 7600

1200 1100 1400 1300 2400 2200 3600 3300

10 292 7921 683 20

292 792 683 22

292 1137 683 25

292 1137 683 28

12 292 1347 683 32

11 292 1347 683 36

13 292 1902 683 44

12 292 1902 683 50

CO2 # Fans Capacity Watts Air Volume Air Throw Dimensions Weight

Bar 230v

8DT1

m3/hr

H W D Kg.

1560 2050 2160 2680 3120 4130 4780 6200 6400

1300 1200 1450 1400 2600 2400 3900 3600 5200

11 292 7921 683 19

10 292 7921 683 20

10 292 1137 683 25

292 1137 683 28

13 292 1347 683 30

12 292 1347 683 33

14 292 1902 683 42

13 292 1902 683 46

15 292 2457 683 54

Key Features

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise level · Low energy consumption · Very compact overall dimensions · EC fans available

CUBO Smart Reference Guide

FHA 85 bar Angled unit coolers for small coldrooms

Model Fin 3.0mm
FHA4032 FHA6032 FHA8032 FHA12032 FHA16032
Model Fin 4.5mm
FHA2750 FHA4150 FHA5350 FHA7950 FHA10650
Model Fin 7.0mm
FHA2880 FHA3580 FHA5280 FHA7080

Code
10200001 10200002 10200003 10200004 10200005
Code
10200011 10200012 10200013 10200014 10200015

CO2 Bar

# Fans 230v

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

1550 2510 3060 4730 6200

650 1100 1300 1950 2600

260 740 555 13

260 920 555 19

260 1170 555 24

10 260 1640 555 34

11 260 2010 555 44

CO2 Bar

# Fans 230v

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

1390 2270 2820 4300 5700

720 1200 1440 2160 2880

260 740 555 12

10 260 920 555 18

10 260 1170 555 22

11 260 1640 555 32

12 260 2010 555 42

Code
10200022 10200023 10200024 10200025

CO2 Bar

# Fans 230v

Capacity Watts 8DT1

Air Volume m3/hr

Air Throw M

Dimensions HWD

Weight Kg.

1740 2180 3260 4390

1340 1500 2250 3000

11 260 920 555 17 11 260 1170 555 21 12 260 1640 555 30 13 260 2010 555 40

Key Features

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions · EC fans available

CUBO Smart Reference Guide

FHD 85bar Dual discharge unit coolers with twin Speed EC Fans

Model Fin 3.0mm
FHD7113 FHD7123 FHD7213 FHD7223

Code
10200160 10200161 10200162 10200163

CO2 Bar
85 85 85 85

# Fans 230v
1 1 2 2

Capacity Watts

H Speed 8 DT1

1100 1100 1100 1100

3060 3790 6200 7800

Air Volume m3/hr
1800 1800 3600 3600

Air Throw
M
2 x 11 2 x 11 2 x 12 2 x 12

Capacity Watts

Speed DT1

870 2670 870 3290 870 5400 870 6800

Air Volume m3/hr
1400 1400 2800 2800

Air Throw
M
2 x 9 2 x 9 2 x 9 2 x 9

Dimensions FHD
HW D
263 888 886 263 888 886 263 1443 1443 263 1443 1443

Weight FHD Kg.
23 24 26 42

Model Fin 4.5mm
FHD8114 FHD8124 FHD8214 FHD8224

Code
10200170 10200170 10200170 10200170

CO2 Bar
85 85 85 85

# Fans 230v
1 1 2 2

Capacity Watts

H Speed 8 DT1

1100 1100 1100 1100

1520 3490 5100 7200

Air Volume m3/hr
1900 1900 3800 3500

Air Throw
M
2 x 11 2 x 11 2 x 13 2 x 12

Capacity Watts

Speed DT1

870 2240 870 3080 870 4490 870 6300

Air Volume m3/hr
1500 1500 2900 3500

Air Throw
M
2 x 9 2 x 10
2 x 7.5 2 x 10

Dimensions FHD
HW D
263 888 886 263 888 886 263 1443 886 263 1443 886

Weight FHD Kg.
21 22 35 38

Model Fin 7.0mm
FHD9117 FHD9127 FHD9217 FHD9227

Code
10200180 12022181 13844182 15666183

CO2 Bar
85 85 85 85

# Fans 230v
1 1 2 2

Capacity Watts

H Speed 8 DT1

1100 1100 1100 1100

1770 2740 3550 5600

Air Volume m3/hr
2000 2000 4000 4000

Air Throw
M
2 x 19 2 x 21 2 x 14 2 x 14

Capacity Watts

Speed DT1

870 1590 870 2440 870 3180 870 4900

Air Volume m3/hr
1600 1600 3100 3100

Air Throw
M
2 x 10 2 x 11 2 x 11 2 x 11

Dimensions FHD
HW D
263 888 886 263 888 886 263 1443 886 263 1443 886

Weight FHD Kg.
19 21 32 35

Key Features

· Reduced dehumidification · Reduced frost formation · Increased air throw · Greatly reduced internal volume

· Low noise levels · Low energy consumption · Very compact overall dimensions · EC fans available

CUBO Smart Reference Guide

Carel Hecu – Real capacity modulation for CO condensing units
Manufactured by Carel, the Hecu controller provides control for commercial condensing units ensuring a highly efficient system. It has now evolved to work with CO. By using DC inverter compressors, the Carel Hecu system can offer real modulation of cooling capacity to achieve low energy consumption at part loads. The high performance attainable with CO means the system complies with the Ecodesign directive on energy performance.
Hecu has real-time communication with the evaporator controllers, allowing implementation of advanced system optimisation, with dynamic set points and extremely stable control to ensure perfect food preservation and reduce food waste. Hecu also incorporates an oil recovery mode ensuring the compressor operates effectively and reliably.
The CUBO Smart units by SCM Frigo include all the controls and valves necessary to control the condensing unit in subcritical and transcritical operation.
It is recommended that the coldroom or cabinet should be connected to a Carel controller to fully benefit from the integrated and optimised control system. This would comprise of:
· Coldroom – UltraCella + EVD module + E2V expansion valve or FastLine control panel + E2V expansion valve · Cabinet – MPX PRO + EV + related probes and cables
If required the CUBO Smart can operate with a 3rd party controller fitted to the cabinet or coldroom.

CUBO Smart Reference Guide

Cold Room Package
Ultracella is a wall mounted coldroom controller that, when combined with additional modules, controls the functions of the coldroom including the E2V expansion device. When networked to other coldroom / cabinet controllers and the CUBO2 Smart, the system provides a fully integrated control solution with features such as smooth lines and floating suction pressure (the latter providing further energy savings). In addition, the EVD Module is required for all installations and controls the expansion valve(s) and includes an internal transformer. As an option we offer a power module to provide electrical overload protection for the coldroom.

P/N

Description

WB000**0F0 MX30M25HO0

Cold room controller 230 Vac power supply, 6 relays, 0…10 V analog output, 3 NTC/PT1000 inputs, NTC/0…10 V input, 4…20 mA/0…5 Vrat input, 3 multifunction digital inputs, RTC, screw terminals. Purpose:Coldroom controller.

WM00EU*000

Ultra EVD expansion valve module, 230 Vac power supply, with Ultracap. Purpose:Driver for EEV on evaporator

WM00P000NN Ultracella Power Module

Qty Notes 1 ** = DW –> LED display double row, white LEDs
1 * = N –> blind, UltraCella combined modular mounting –> EEV commissioning by UltraCella
1 Power Module Main Switch

E2VxxZyy13

E2Vxx Smart Z with 1 integrated orifice, without sight glass, with bipolar stator hermetic IP69K, with cable 0,3mt and superseal connector IP67. Purpose: EEV on evaporator.

E2VCABS*I0

Bipolar valve

cable shielded with

superseal connector

IP67.To connect

expansion valve to

EEV driver.

SPKT00G1S0 Pressure

transducers “S”

series steel: 1/4″

SAE female fitting

with deflector, 7/16″

-20 UNF, PACKARD

connector (single

package), 0 to 5 Vdc

ratiometric pressure

transducers, 0 to 60

barg (0 to 870 psig).

Purpose: Pressure

transducer for

superheat control (to

MPXPRO)

xx = 03 –> orifice size 3 yy = WF –> fitting 1/2″-1/2″ ODF
xx = 05 –> orifice size 5 yy = WF –> fitting 1/2″-1/2″ ODF xx = 09 –> orifice size 9 yy = WF –> fitting 1/2″-1/2″ ODF xx = 11 –> orifice size 11 yy = WF –> fitting 1/2″-1/2″ ODF xx = 14 –> orifice size 14 yy = WF –> fitting 1/2″-1/2″ ODF xx = 18 –> orifice size 18 yy = WF –> fitting 1/2″-1/2″ ODF xx = 24 –> orifice size 24 yy = SM –> fitting 16mm(5/8″)16mm(5/8″) ODF * = 3 –> cable 3 mt * = 6 –> cable 6 mt * = 9 –> cable 9 mt

Full P/N

Part No

WB000DW0F0 58963

WM00EUN000 58964

WM00P000NN 58959

E2V03ZWF13 58966

E2V05ZWF13 E2V09ZWF13 E2V11ZWF13 E2V14ZWF13 E2V18ZWF13 E2V24ZSM13

58968 58970 58972 58974 58976 58979

E2VCABS3I0 E2VCABS6I0 E2VCABS9I0

58980 58955 58981

SPKT00G1S0 58991

CUBO Smart Reference Guide

P/N SPKC00**10
NTC0**HF01
NTC0**HP00

Description

Qty Notes

IP67 cable with co- 1 moulded PACKARD connector for SPKT*. To connect transducer to EVD/ NPX pro driver.

** = 53 –> cable 5 mt ** = A3 –> cable 12 mt

NTC sensor IP67, 1 fast reading, strap-on. Purpose:Temperature sensor on evaporator outlet pipe for EEV control.(to EVD module)

** = 60 –> cable 6,0 mt

NTC sensor IP67, 2 ** = 60 –> cable 6,0 mt -50T105 °C (on air). Purpose: Sensor for air and defrost temperature.

Full P/N SPKC005310 SPKC00A310

Part No 5459 58984

NTC060HF00 5672

NTC060HP00 5594

An alternative option to the UltraCella controller is to use our Fastline coldroom control panel to save on-site wiring time. The panel incorporates the Carel MPXPRO for accurate EEV control, display, MCBs for individual evaporator fan, defrost heater, coldroom lights and drain heater protection, with LED indicators for panel live and defrost. The panel cuts installation time significantly and provides the ultimate ready to go solution.

Fastline Control Panel

Code 58814 58814P 58815 58815P 58816

Description 1PH Glass re-enforced plastic Fastline control panel 1PH Polymer enclosure Fastline control panel 3PH Glass re-enforced plastic Fastline control panel 3PH Polymer enclosure Fastline control panel Twin evaporator Fastline control panel

Code 58992 5440

Description Carel Hecu User Terminal PGD Evolution Carel S900CONN003 Tele cable 6m

WB000DW0F0 Cold Room Controller

WM00EU*000 Ultra EVD Expansion Module

E2Vxx2YY13 Expansion Valve SPKT00G1S0 Pressure Transducer

CUBO Smart Reference Guide

Cabinet Package
MPXpro is a DIN rail mounted cabinet controller that, when combined with additional modules, controls the functions of the cabinet including the E2V expansion device. When networked to other cabinet/coldroom controllers and the CUBO Smart, the system provides a fully integrated control solution with features such as smooth lines temperature control and floating suction pressure (the latter providing further energy savings). MPXpro includes the EVD Module which controls the expansion valve(s). As an option we offer a power module to provide electrical overload protection for the coldroom.

P/N MX30M25HO0 IR00UGC300 E2VxxZyy13
E2VCABS*I0 SPKT00G1S0 SPKC00**10 NTC0**HF01 NTC0**HP00

Description

Qty Notes

MPXPRO step3 with vertical out, silk-screened connectors,

Master 5 relays, 115 to 230 Vac power supply, EXV driver,

ultracap. Purpose: Cabinet control with integrated driver for EEV.

User terminal (green LEDs, Keypad, Buzzer, Commissioning

port, IR)

E2Vxx Smart Z with integrated orifice, without sight glass, with 1 xx = 03 –> orifice size 3

bipolar stator hermetic IP69K, with cable 0,3mt and superseal

yy = WF –> fitting 1/2″-1/2″ ODF

connector IP67. Purpose:EEV on evaporator.

xx = 03 –> orifice size 3

yy = SF –> fitting 12mm-12mm

xx = 05 –> orifice size 5 yy = WF –> fitting 1/2″-1/2″ ODF

x = 05 –> orifice size 5 yy = SF –> fitting 12mm-12mm

xx = 09 –> orifice size 9 yy = WF –> fitting 1/2″-1/2″ ODF

xx = 09 –> orifice size 9 yy = SF –> fitting 12mm-12mm

xx = 11 –> orifice size 11 yy = WF –> fitting 1/2″-1/2″ ODF

xx = 11 –> orifice size 11 yy = SF –> fitting 12mm-12mm

xx = 14 –> orifice size 14 yy = WF –> fitting 1/2″-1/2″ ODF

xx = 14 –> orifice size 14 yy = SF –> fitting 12mm-12mm

xx = 18 –> orifice size 18 yy = WF –> fitting 1/2″-1/2″ ODF

xx = 18 –> orifice size 18 yy = SF –> fitting 12mm-12mm

xx = 24 –> orifice size 24 yy = SF –> fitting 12mm-12mm

xx = 24 –> orifice size 24 yy = SM –> fitting 16mm(5/8″)16mm(5/8″) ODF

Bipolar valve cable shielded with superseal connector IP67

1 * = 9 –> cable 9 mt

Pressure transducers “S” series steel: 1/4″ SAE female fitting

with deflector, 7/16″ -20 UNF, PACKARD connector (single

package), 0 to 5 Vdc ratiometric pressure transducers, 0 to 60

barg (0 to 870 psig). Purpose: Pressure transducer for superheat

control (to MPXPRO)

IP67, cable with co-moulded PACKARD connector for SPKT*

1 ** = 53 –> cable 5 mt

** = A3 –> cable 12 mt

NTC sensor IP67, fast reading, strap-on,

-50T105 1

°C. Purpose:Temperature sensor on evaporator outlet pipe for

EEV control.(to MPXPRO)

** = 60 –> cable 6,0 mt

NTC sensor IP67, -50T105 °C (on air). Purpose: Temperature sensor for air and defrost control. (to MPXPRO)

2 ** = 60 –> cable 6,0 mt

Full P/N

Code

MX30M25HO0 5906

IR00UGC300 5907 E2V03ZWF13 58966 E2V03ZSF13 58967 E2V05ZWF13 58968 E2V05ZSF13 58969 E2V09ZWF13 58970 E2V09ZSF13 58971 E2V11ZWF13 58972 E2V11ZSF13 58973 E2V14ZWF13 58974 E2V14ZSF13 58975 E2V18ZWF13 58976 E2V18ZSF13 58977 E2V24ZSF13 58978 E2V24ZSM13 58979

E2VCABS9I0 SPKT00G1S0

58981 58991

SPKC005310 SPKC00A310 NTC060HF00

5459 58984 5672

NTC060HP00 5594

CUBO Smart Reference Guide

Bacharach Refrigerant Leak Detection
Human safety is a common reason for refrigerant leak detection in cold rooms and walk-in freezers. This is because refrigerant leaks can create a risk of asphyxiation in an enclosed space. Bacharach has a number of solutions for refrigeration systems using HFC refrigerants and those using natural refrigerants such as CO, assisting in compliance with regulations including ASHRAE 15 and EN378.
The MGS-150 Gas Detector can meet almost any gas detection need with multiple sensor options for real-time monitoring of refrigerants, oxygen, combustible and toxic gases. It includes user-selectable current or volt analogue outputs, allowing connectivity to most BMS, SCADA or central control systems. Status LEDs and a buzzer are integrated for local alarming while an on board relay with user-adjustable set-point can connect to external visual/audible alarms.
A variety of enclosure options, including an economical IP41 housing and a dust/water tight IP66 housing, allow the MGS-150 transmitters to be placed in the toughest environments. Special remote sensor configurations are available for applications where mounting in vent pipes, duct work or other tight spaces is required.

In situations where the total charge volume of R744 is more than the limit of 0.1kg for every cubic meter of enclosed space (coldroom/plant room size) a leak detection system is required. We can provide a charge calculator to assist in this calculation

CUBO Smart Reference Guide

Code 58992 5440

Description Carel Hecu User Terminal PGD Evolution
Carel S900CONN003 Tele cable 6m

K65 Copper Tube Code 181900 181910

Description 1/2″ x 0.6mm x 6m 3/8″ x 0.65mm x 5m

PS 80 Bar 120 bar

Metres 6 5

Insulation Code 6963 6964

Description Armaflex 3/8 x 3/4 Wall Class O 2 Metre Armaflex 1/2 x 3/4 Wall Class O 2 Metre

K65 Copper Fittings Code 182000 182001 182020 182021 182007 182008 138410 138408 182115

Description K65 3/8″ 90Deg Long Radius Elbow CxC K65 1/2″ 90Deg Long Radius Elbow CxC
K65 3/8″ Coupling with Stop K65 1/2″ Coupling with Stop
K65 3/8″ Equal Tee K65 1/2″ Equal Tee
K65 ½” P-Trap K65 3/8″ P-Trap K65 1/2″ x 3/8″ Reducing Coupler

PS 120 bar 120 bar 120 bar 120 bar 120 bar 120 bar 120 bar 120 bar 120 bar

Klo-Shure Clamps Part No 150030 150031

Description Klo-shure Clamp Assembly 3/8 – 3/4 wall Klo-shure Clamp Assembly 1/2 – 3/4 wall

Brazing Rod Code 6837

Description JM Sil-Fos (5%) Rod 2.5mm x 600mm

CO Refrigerant Code
H642746

Description 7kg Dual Port

Rental Period 1 Month

K65 Copper Tube K65 Copper Fittings
K65 P Trap Klo Shure Clamps

CO Refrigerant

CUBO Smart Reference Guide

Oil Code 71200

Description PAG VG 100

Condensing Unit Cage

Code

Description

4521

Cond Unit Cage H1120mm x W1120mm x D640mm

Condensing Unit Brackets

Code

Description

B6382 Aspen Xtra B-Quick Bracket up to 220kg

Tools Code
45925
600667 6313 93265 21922

Description
Yellow Jacket Titan CO Manifold gauge with (3) black and (1) yellow hose
Gas Arc 100 Bar Nitrogen Regulator ITE Charging scales 150kg
Yellow Jacket 4CFM dual voltage Vac pump
CO Charging Line

Cable Code 110622

Description 18 AWG Foil Screened data cable 600V rated

Anti Vibration Pads Code 1496 1495

Description 500 (L) x 50 (W) x 15 (H) 1200 (L) x 75 (W) x 15 (H)

PPE Code A120 140893 633815

Description Gloves
Safety Glasses Ear Defenders SNR 2db

Leak Detection Code
6300-2091 6300-1091

Description MGS-150 IP66 Stand-alone C0 sensor MGS-150 IP41, Stand-alone C0 sensor

PAG VG 100

CO Charging Line

Yellow Jacket Titan CO Manifold gauge

ITE Charging scales 150kg
