STX-8 1 by 10 Scale Electric Touring Car

Product Information

The STX is a high-quality 1/10 scale touring car designed for
experienced individuals in the field of RC model cars. It comes
with an instruction manual and is intended for use by individuals
over 16 years old. Children and individuals without experience must
be supervised by a knowledgeable adult.

Safety Precautions

Before building and operating the STX, it is essential to read
and fully understand the instruction manual. Keep the manual in a
safe place and use only original WRC spare parts.

General Information

Warranty: Contact WRC support at [email protected] for any
problems or questions.
Customer Support: Visit www.wrc-racing.com for updates, set-up
information, option parts, and other information.
Technical Information:
- Transmission: 4-wheel drive
- Body: Touring model (not included)
- Adjustable front toe, camber, and caster
- Adjustable rear toe and camber
- Bumper/front backstop
- Carbon chassis
- Full ball bearing
- Differential gear
Technical Data:
- Length: 373mm
- Width: 187mm
- Adjustable wheelbase: min. 250mm, max. 256mm
- Weight chassis: 515g
Additional Items Needed for Completion:
- Electric motor pinion gear
- Low profile steering servo
- Transmitter
- Receiver
- Batteries for transmitter
- Wheels, tyres, inserts
- Lipo battery
- Speed controller
Tools Required:
- Allens: 1.5mm, 2mm, 3mm
- Socket: 5mm, 7mm
- Side cutters
- Combination pliers
- Scissors
- Tool for turnbuckles/nuts
- Grease
- Oils: bearing oil, silicone oil

Product Usage Instructions

Read and fully understand the instruction manual before
building and operating the STX.
Use only original WRC spare parts.
Ensure that all additional items needed for completion are
obtained from your local hobby shop.
Use the required tools for proper assembly, which are not
included in the kit.
Mount the front and rear bulkheads as per the
instructions.
Mount the rear differential gear correctly as per the
instructions. Do not force it to close.
Mount the central transmission using the provided parts.
Install the required electronics, including the electric motor
pinion gear, low profile steering servo, transmitter, receiver,
batteries for the transmitter, Lipo battery, and speed
controller.
Adjust the front toe, camber, and caster as well as the rear
toe and camber to your preference.
Place the body on the chassis (not included).
Use the STX as per the manufacturer’s instructions.

View Fullscreen

INTRODUCTION
STX is a new generation high quality 1/10 scale touring car. STX is supplied in a box equipped with Instruction Manual. Its use is intended for more than 16 years old persons with experience on rc model car field. Children and all the persons without this requirement MUST have direct supervision of a knowledgeable adult responsible.
SAFETY PRECAUTIONS
Instruction Manual MUST be read and fully understood before to start building and operating functions. Always keep Instruction Manual in safety place, ready to be consulted for any reference you need. Use only original WRC spare parts.
GENERAL INFORMATION
Assemble the kit only away from the reach of children. Follow the building and operating instructions using the utmost care. Don’t put any part of your body inside rotating and moving elements as this may cause damage or serious injury. Check and clean the model before putting it away. Don’t use your model car in public places or in roads and areas where it could generate conflict with person or vehicular traffic. The model car is controlled by radio: you MUST put great care to avoid loss of radio control always keeping a safety margin all around your model in order to prevent any collision. Operating frequency: check and be sure it is clear and not shared with anybody at same time; it could cause loss of control of the RC model. Always turn on your transmitter before you turn on the receiver in the car and always turn off the receiver before you turn off your transmitter. Keep the wheels of the model off the ground when checking the operation of the radio equipment. Disconnect the battery pack before storing your model.
WARRANTY
WRC guarantees this model kit to be free from defects in both material and workmanship within 30 days of purchase. The total monetary value under warranty will in no case exceed the cost of the original kit purchased. This warranty doesn’t cover any compnents damaged by use or modification or as result of wear. Part or parts missing from this kit must be reported within 30 days of purchase. No part or parts will be sent under warranty without proof of purchase. If you find a defective or missing part, contact the local distributor. Customer service and support will be provided through local hobby store. No warranties are expressed or implied that cover damage caused by what is considered normal use or cover or imply how long any model cars’ components or electric components will last before requiring replacement. Due to the high performance level of this model car you will need to periodically maintain and replace consumable components; any and all warranty coverage will not cover replacement of any part or component damaged by neglect, abuse or improper or unreasonable use. This includes but is not limited to damage from crashing, excessive moistur, improper use or no maintenance or user modifications which compromise the integrity of components. Warranty will not cover compnents that are considered consumable on RC model car. WRC doesn’t pay nor refund on any component sent from WRC or its distributor for warranty. WRC reserves the right to make final determination of the warranty status of any component or part Use only original WRC spare part:
CUSTOMER SUPPORT
Please don’t hesitate to contact WRC support at [email protected] for any problem or question. Also kindly visit our website www.wrc-racing.com to find last updates, set-up information, option parts and other information.
W.R.C. world racing car s.r.l.
Via A. Volta, 2 bis 36040 Brendola (VI)
ITALY
Phone: 0039 0 444 1792263 E-mail: [email protected] Website: www.wrc-racing.com

TECHNICAL INFORMATION
– TRANSMISSION: 4 DRIVE WHEELS – BODY: TOURING MODEL (NOT INCLUDED) – ADJUSTABLE FRONT TOE, CAMBER AND CASTER – ADJUSTABLE REAR TOE AND CAMBER – BUMPER /FRONT BACKSTOP – CARBON CHASSIS – FULL BALL BEARING – DIFFERENTIAL GEAR

TECHNICAL DATA
– LENGHT ……………………………………… 373 MM. – WIDTH ………………………………………187 MM. – ADJUSTABLE WHEEL BASE …………MIN. 250 MM. – MAX 256 MM. – WEIGHT CHASSIS……………………….. 515 GR.

ADDITIONAL ITEMS NEEDED FOR COMPLETION (REQUIRED BUT NOT INCLUDED IN THE KIT)

ELECTRIC MOTOR PINION GEAR
LOW PROFILE STEERING SERVO

TRANSMITTER

RECEIVER

BATTERIES FOR TRANSMITTER

WHEEL – TYRES – INSERTS

LIPO BATTERY

SPEED CONTROLLER

TOOLS REQUIRED
THESE TOOLS ARE NOT INCLUDED IN THE KIT BUT ARE REQUIRED FOR PROPER ASSEMBLY

LEXAN BODY + DECALS
INCLUDED

ALLENS: 1.5 mm 2 mm 3 mm

SOCKET 5mm 7mm

SIDE CUTTERS

COMBINATION PLIERS

SCISSORS

TOOL FOR TURNBUCKLES/NUTS

GREASE

OILS: BEARING OIL SILICONE OIL

NOTICE:
THE FOLLOWING ITEMS ARE NEEDED FOR COMPLETION OF THE STX; THEY ARE NOT INCLUDED IN THIS KIT (UNLESS NOTED) AND SHOULD BE OBTEINED FROM YOUR LOCAL HOBBY SHOP. BE SURE TO READ THE INSTRUCTION COMPLETELY PRIOR TO ASSEMBLY
2

Front Bulkheads
92001 M3x6

BAG 1

03007-5
OPTIONAL 03019-3 BR (brass) Weight: 4gr.
03019-3
03072-3 (1mm)

Rear Bulkheads

OPTIONAL 500104-1 ALU 7075 T6 500101-1 ALU 7075 T6 FLEX

500104

03019-3

03072-3 (1mm)

03007-5

92001 M3 x6

BAG 2
Rear Differential Gear FOLLOW CLOSELY THE INSTRUCTIONS, THIS DIFF GEAR
HAS TO BE MOUNTED CORRECTLY TO WORK WELL
1

97031 Ø2×16

500004-3 500004-2

95006 8906 5x10x0.1 97006 Ø2×9

03089-3 500004-1

SILICONE OIL 1000 Q.ty 1g

4
92034 M2.5 x12

95020 31×1

500004-3

95006 8906 5x10x0.1 97006 Ø2×9

03089-3 500004-1

If the gears are alligned the 2 sides of the Diff should close easily.
DON’T FORCE IT TO CLOSE
4

BAG 3
Central Transmission

03004 20T 03004-1
90000 5x10x4

03004 20T

03004-1

90000 5x10x4

RC 4087 (87T)

SPUR GEAR P48

RC4078 RC4084 RC4087

78 T 84 T 87 T

SPUR GEAR P64

RC6092 RC6096 RC60100 RC60104 RC60106 RC60108 RC60110 RC60112 RC60114 RC60116 RC60118

92 T 96 T 100 T 104 T 106 T 108 T 110 T 112 T 114 T 116 T 118 T

Solid Front Axel

93004 M3 x12

500033-2

500033-1

500033-2

93004 M3 x12

03015
03294 90006 10x15x4

BAG 4
Transmission

93001 M3 x6 03002-6

03065 447T

93001 M3 x6

93001 M3 x6
03015 03294

90006 10x15x4

500202 500201

03002-6 03066 255T
90006 10x15x4
03294
03015

03294 03015

92001 M3 x6

–

FRONT BELT ADJUSTMENT

REAR BELT ADJUSTMENT

Belt Tensioner

94009

93004 M3 x12

90021 4x7x2.5

03076 90021 4x7x2.5

2 0 2.2

X2
98007 M4X8

BAG 5
Front Lower Arms
03003 (short)
93009 M2 x 5 03048-2
03048-2 03048-1-S
OPTIONAL
03048-1-H (hard)

98005 M3X8

LEFT SIDE SHOWN ABOVE
Rear Lower Arms

2,5 2.2

98007 M4X8

98005 M3X8

03035-4

03049-1-S
OPTIONAL
03049-1-H (hard)

LEFT SIDE SHOWN ABOVE
7

0 ° 4 6 4 2
3 °

BAG 6
Front Arm Angles Diagram

1 3.5 3.5 1 1.5 3 3 1.5

2 2.5 2.5 2

2.5 2 2 2.5

3 1.5 1.5 3 3.5 1 1 3.5

1 3.5 3.5 1 1.5 3 3 1.5 2 2.5 2.5 2 2.5 2 2 2.5 3 1.5 1.5 3 3.5 1 1 3.5

FR FF

FR
FF RF
RR

RF RR

Rear Arm Angles Diagram

1 3.5 3.5 1 1.5 3 3 1.5

2 2.5 2.5 2 2.5 2 2 2.5

3 1.5 1.5 3 3.5 1 1 3.5

1 3.5 3.5 1 1.5 3 3 1.5 2 2.5 2.5 2 2.5 2 2 2.5 3 1.5 1.5 3 3.5 1 1 3.5

BAG 6
Rear Lower Arms Mounting
03018
OPTIONAL
03018-BR (brass) Weight: 8gr.

03200 3x6x2

03072-3 (1mm)

03018-1

03200-1 3x6x1
03200-2 3x6x2
03040
OPTIONAL
03040-1 (brass)

92001 M3 x6 97010 Ø3×50

03049

Front Lower Arms Mounting

03018
03072-3 (1mm)
OPTIONAL CARBON
03072-25 sp.0.25mm 03072-50 sp.0.5mm 03072-100 sp.1mm

03018-1

92001 M3 x6

03200-2 3x6x2
03040 03018-1

97012 Ø3×45

03040

03048
9

BAG 7
Left & Right Front Hub

90020 5x10x3

500034 90020 5x10X3

03054-1 Ø 2

OPTIONAL 03082-5.5 03082-6.0
03082-5.0

92001 M2.5×5

500035-L

500035-R

91003 M2X5

97005 Ø2×10

03075 (short)

03071-SX

93003 M3x10

03076 (long) 03071-DX
RIGHT SIDE SHOWN ABOVE

90000 5x10x4

Rear Hub

90000 5x10x4
03056-1 Ø 2

OPTIONAL 03082-5.5 03082-6.0
03082-5.0

03027
OPTIONAL 500036 ALU 7075 T6

91003 M2x5

97005 Ø2×10

Front Upper Arms
03050 93001 M3 x6 03033-6

BAG 8

03003

15,5

03003

03035-4 03200-2

03061-32.5

03035-10 03200-1

Rear Upper Arms

98000 M3X3

03035-10

03050

98000 M3X3

03032-7
03200-2 03035-4

03003

03061-32.5

93001 M3 x6
OPTIONAL
03035-6 (6mm) 03035-10 03200-2

03050

98000 M3X3
11

BAG 8
Servo

Adjust the distance from the servo lever to the ball as needed using the alu shims. 03200-1

03055 93001 M3 x6

03461

93001 M3 x6

03035-10

93002 M3 x8

03055

93001 M3 x6
03055

500024-1 servo (not included)
93002 M3 x8

92003 M3 x10

93001 M3 x6

03035-4 93001 M3 x6

Steering levers
93001 M3 x6

90014 3x6x2.5 flanged
500023 03200-1

03035-4 90019
5×8 flanged 500031

500031

90019 5×8 flanged
500022 90019 5×8 flanged

93001 M3 x6
12

BAG 9
Steering Arms

9,5

03035-4

03003 03061-20 03003
24

OPTIONAL
500406-3 One piece upperdeck

03003 03061-40

03003

Upperdeck

93001 M3 x6

500406-1

500406-2 93001 M3 x6

93001 M3 x6

BAG 9
Front Anti Roll Bar

03042

98000 M3X3

03042

Front Anti Roll Bar Options

COD

03031-2

Ø 1.2

OPTIONAL

03031-3 03031-4 03031-5

Ø 1.3 Ø 1.4 Ø 1.5

STANDARD IN KIT OPTIONAL OPTIONAL

03031-6

Ø 1.6

OPTIONAL

90016 4x7x2.5
03034-1

90016 4x7x2.5 03034-1

03003

98000 M3X3

Rear Anti Roll Bar

03034-1 98000 M3x3

90016 4x7x2.5

03035-4

Rear Anti Roll Bar Options

COD

03031-1

Ø 1.1

OPTIONAL

03031-2

Ø 1.2

STANDARD IN KIT

03031-3

Ø 1.3

OPTIONAL

03031-4

Ø 1.4

OPTIONAL

03031-5

Ø 1.5

OPTIONAL

03031-6

Ø 1.6

OPTIONAL

98000 M3X3

03003

03035-4 03003

BAG 1O
Shock Absorbers
03170-12 95013 12×1 02043-10 95016
QUADRI-RING
02043 03170-13
03170-7

COD 03170-5

SPRINGS Force (lb) COLOUR
2.1 BLACK

03170-6

2.2 YELLOW

03170-7

2.3 RED (IN KIT)

03170-8

2.6 BLUE

PROGRESSIVE SPRINGS

03170-9 1.3-2.9 FUCHSIA

03170-10 1.4-3.5 GREEN

02043

03086-3 03086

03170-14 03086

02043 3 HOLES 99003

03170-11 03170-15

1.5 2.5
9

FRONT

REAR

SHOCK FILLING
Fully extend the piston rod so the piston is at the bottom of the shock body. Hold the shock upright and fill the shock body with shock oil as in the picture. Let the oil settle and allow air bubbles to rise to the top. Slowly move the piston up and down until no more air bubbles appear. Add shock oil as necessary. Pull the piston rod most of the way out of the shock bod. Let the shock rest for 5 minutes to allow the air bubbles to scape.

P-ONE SHOCKS OIL

CODE

CST

SO-350

350

SO-400

400 (IN KIT)

SO-450

450

SO-500

500

SO-550

550

SO-600

600

SO-650

650

SO-700

700

SO-800

800

BAG 1O
Rear Suspensions
93001 M3 x6

03069

03069
Front Suspensions
93001 M3 x6

03170

03069
16

93004 M3 x12
03467

BAG 11
Battery Holder
03025 Adjust the battery holder height according to the dimension of your battery using the shims.

03023-5

03467 03023-6
92003 M3 x10

Battery Holder Adjustments

Height

Width

Lenght

OPTIONAL 500407
This optional battery holder is designed to hold the battery laterally, it’s fixed to the battery using double side tape. By using this part you can delete the lateral battery holder.
17

BAG 11
Front Body Support and Bumper

03080 92002 M3X8

500009

03068

93001 M3 x6

03016-1 97005 2×10
03080

92002 M3 x8

Rear Body Support

97005 2×10

03081-1

93002 M3 x8
500005-1

03011-2 92002 M3 x8
