Hue Go BT Portable Lamp
Installation Guide
Hue Go BT Portable Lamp
Warnings
Always make sure the luminaire is detached from the mains socket
Always make sure the DC cable is detached from the power supply
Staring at the operating light source may cause eye injury
| # | Disassemble/dismantle steps | Tools needed |
| a | Rotate the head [1] counterclockwise from the diffuser [9] over 10° until stopper | |
| b | Open and remove the head [1] from the diffuser [9] | FLATHEAD SCREWDRIVER |
| c | Unplug flat cable [not visible] from Light Source -Led Module [6] | |
| d | Unplug red and black wires [5] from Light Source -Led Module [6] | WAGO TOOL #2065 |
| e | Unscrew 3 screws [3] and remove heatsink [2] with Light Source -Led Module [6] and foil [4] | TORXHEAD SCREW DRIVER T10 |
| # | COMPONENT | QTY |
| 1 | Head | 1 |
| 2 | Heatsink | 1 |
| 3 | Screw | 6 |
| 4 | Foil | 1 |
| 5 | Wire | 1 |
| 6 | Light Source -Led Module | 1 |
| 7 | Washer | 3 |
| 8 | 0-ring | 1 |
| 9 | Diffuser | 1 |
| SKU | Color | Country |
| 929003128401 | White | EU/UK |
| 929003128501 | Black | EU/UK |
| 929003128601 | White | NAM |
| 929003128701 | Black | NAM |
| 929003521401 | White | EU/UK |
| 929003521501 | Black | EU/UK |
| 929003521601 | White | NAM |
| 929003521701 | Black | NAM |
| 929003128801 | White | AU/NZ |
| 929003128901 | White | CN |
| 929003129001 | White | JP/K/TW |
