Laser 5740 Engine Timing Tool Kit Instructions

5740 Engine Timing Tool Kit

Product Information

Part No.: 5740

Product Name: Engine Timing Tool Kit

Compatible Models: BMW N51/52/53/54/55 &
S55

Manufacturer: Laser Tools

Website: www.lasertools.co.uk

Introduction

The Engine Timing Tool Kit is designed to assist in locking the
camshafts in position during timing procedures. It includes various
components to ensure accurate timing for BMW N51, N52, N53, N54,
N55, and S55 engines.

Components

• Camshaft Alignment Tool (N51, N52 and N55, S55)
• Camshaft VANOS Sensor Alignment Tool
• Camshaft Alignment Tool (N53, N54)
• Timing Chain Pre-Tensioning Tool
• Flywheel/Crankshaft alignment pin

Applications

Please refer to the website for the most up-to-date
applications: www.lasertools.co.uk/product/5740

Instructions

1. Ensure that the engine is at TDC (Top Dead Center) with the
   flywheel/crankshaft alignment pin (Item E) in place.
2. Use the Camshaft Alignment Tool (Item A) to lock both camshafts
   in their timed positions as shown in Fig. 1.
3. For N53 and N54 engines, use the Camshaft Alignment Tool (Item
   C) in the same way as Item A.
4. Use the Timing Chain Pre-Tensioning Tool (Item D) to
   pre-tension the timing chain tensioner.
5. Use the VANOS sensor alignment tool (Item B) by fitting it with
   the two locating pins into the holes in the VANOS units (refer to
   Fig. 2).

Note: Always refer to OEM derived data or the
vehicle manufacturers’ own data for specific instructions and
guidance.

Safety Warnings

Please read the following safety warnings before using the
product:

• Use the product correctly and with care for its intended
  purpose.
• The Tool Connection Ltd. cannot be held responsible for any
  damage caused by incorrect use of the product.
• Incorrect use of the product may invalidate the warranty.

Part No. 5740
Instructions
Engine Timing Tool Kit
BMW N51/52/53/54/55 & S55
www.lasertools.co.uk

Introduction
The locking plates have been designed to lock the camshafts in position while other timing procedures are undertaken. The camshaft VANOS sensor alignment tool has been designed to combine two OEM designs, allowing one tool to be used for the applications.
Components

C
E A
Applications

B D

Ref. Code OEM A C587 11 4 280
B C588 11 4 290
C C589 11 4 280 D C328 11 9 340 E C592 11 0 300

Description
Camshaft Alignment Tool (N51, N52 and N55, S55)
Camshaft VANOS Sensor Alignment Tool
Camshaft Alignment Tool (N53, N54)
Timing Chain Pre-Tensioning Tool
Flywheel/Crankshaft alignment pin

Make, Model, Range, Year

Eng Codes

BMW

1 Series 1 Series 2 Series 3 Series 3 Series 4 Series 5 Series 5 Series 6 Series 6 Series 7 Series 7 Series X1 X3 X3 X4 X5 X5 X6 X6 Z4 Z4

125i, 130i, 135i, M Coupe

(E81/82/87/88)

2005 – 2014

M135i/xDrive

(F20)

2012 – 2016

M235i/xDrive, M2

(F22/23)(F87)

2014 – on

323i, 325i, 330i, 335i

(E90/91/92/93)

2005 – 2014

335i/xDrive, M3

(F30/31/34)(F80) 2012 – 2019

435i/xDrive, M4

(F32/33/36)(F82/83) 2013 – 2020

523i, 525i, 530i, Xi/xDrive

(E60/61)

2005 – 2010

523i, 528i, 530i

(F10/11)

2010 – 2017

630i

(E63/64)

2004 – 2011

640i/xDrive

(F12/13/06)

2011 – 2018

730i

(E65/66)

2005 – 2008

730i, 740i

(F01/02/04)

2008 – 2015

xDrive 25i, xDrive 28i

(E84)

2009 – 2011

si, xDrive 25i, xDrive 30i

(E83)

2006 – 2010

xDrive 28i

(F25)

2011 – 2017

xDrive35i, M40iX

(F26)

2014 – 2018

si, xDrive 30i

(E70)

2006 – 2013

xDrive35i

(F15)

2013 – 2018

xDrive35i

(E71)

2008 – 2014

xDrive35i

(F16)

2015 – 2019

si

(E85/86)

2006 – 2009

sDrive23i, sDrive30i, sDrive35i (E89)

2009 – 2017

Always refer to the website for most up to date applications: www.lasertools.co.uk/product/5740

2,5 N52 B25 A N52 B25 AE N52 B25 AF N53 B25 A
3,0 N51 B30 A N52 B30 A N52 B30 AF N53 B30 A N54 B30 A N55 B30 A S55 B30 A

www.lasertools.co.uk 2

The following instructions are for guidance only. Please refer to OEM derived data such as the vehicle manufacturers’ own data or Autodata.
The use of this engine timing tool kit is purely down to the user’s discretion and The Tool Connection Ltd. cannot be held responsible for any damage caused whatsoever.

Instructions
Preparation: · Raise vehicle · Remove the under shield · Remove engine top cover · Remove cam cover · Remove sump · Ensure the engine is positioned at TDC No.
1 cylinder.
Item A: Specifically designed to fit the BMW N51/ N52/ and N55/S55 engines; it is designed to be used to lock both camshafts in their timed positions as shown in Fig. 1. Ensure the engine is at TDC with Item E in place.

Item C:

Fig. 2

Fitted and used in the same way as Item A but is specific to the N53 and N54 engines.

Item D:
Designed to pre-tension the timing chain tensioner.

Item E:
This tool is used to lock the flywheel in position and thereby lock the crankshaft in the TDC No. 1 cylinder position (refer to Fig. 3).

Item B:

Fig. 1

The VANOS sensor alignment tool is double-sided with clear markings to distinguish between engine applications.

When fitting, ensure that the two locating pins

enter into the holes in the VANOS units (refer

E

to Fig. 2).

www.lasertools.co.uk

Fig. 3
3

Safety Warnings – please read

· If the engine has been identified as an Interference engine, damage to the engine will occur if the timing belt has been damaged. A compression check of all the cylinders should be taken before the cylinder head (s) are removed.
· Do not turn crankshaft or camshaft when the timing belt/chain has been removed.
· To make turning the engine easier, remove the spark plugs/glow plugs or injectors.
· Observe all tightening torques.
· Do not turn the engine using the camshaft or any other sprocket.
· Disconnect the battery earth lead (check Radio code is available).

· Do not use cleaning fluids on belts, sprockets or rollers.
· Some toothed timing belts are not interchangeable. Check the replacement belt has the correct tooth profile.
· Always mark the belt with the direction of running before removal.
· Do not lever or force the belt onto its sprockets.
· Do not use timing pins to lock the engine when slackening or tightening the crankshaft pulley bolts.
· ALWAYS REFER TO A REPUTABLE MANUFACTURERS WORKSHOP MANUAL.

Our products are designed to be used correctly and with care for the purpose for which they are intended. No liability is accepted by the Tool Connection for incorrect use of any of our products, and the Tool Connection cannot be held responsible for any damage to personnel, property or equipment when using the tools. Incorrect use will also invalidate the warranty.
If applicable, the applications database and any instructional information provided has been designed to offer general guidance for a particular tool’s use and while all attention is given to the accuracy of the data no project should be attempted without referring first to the manufacturer’s technical documentation (workshop or instruction manual) or the use of a recognised authority such as Autodata.
It is our policy to continually improve our products and thus we reserve the right to alter specifications and components without prior notice. It is the responsibility of the user to ensure the suitability of the tools and information prior to their use.

5740_Instructions_v4
