IQ Duo Plus Alarm
One alarm, two functions
59-0210 Iq Dual Plus Patient Sensor Alarm
- Dual functionality—choose sensor or pull-cord
- Compact and easy to use
- Extended battery life
IQ Duo Plus Alarm
The dual-functioning IQ Duo Plus Alarm operates as either a sensor or pull-cord alarm, enabling staff to choose the best option for their patient’s needs. Durable construction and an easy-to-use, compact design make the IQ Duo Plus Alarm an integral part of any Fall Management program.
Once activated, the alarm’s protected settings and “Always On” technology eliminate the need for reconfiguration and prevent staff from accidentally switching off the power.
The alarm’s extended battery life means less frequent battery replacement and fewer occurrences of low-battery warnings.
Compatible with AliMed sensors, the IQ Duo Plus works in tandem with pressure and ultra-thin sensor pads, roll-control bed belts, seatbelts, or cushions to create a complete fall monitoring system.
To order, see reverse side.
Alarm Specifications:
| Functionality | Pull-Cord or Sensor | Pull-cord is included (cord adjusts to 28”-58”) For use with a sensor, see below |
| Low Battery Indicator | Yes | Flashes red when batteries need to be changed |
| Reset Button | Yes | Reset button is located on the front of the unit |
| Nurse-Call Integration | Yes | Compatible with most nurse-call systems |
| Number of Tones | 2 | Chime and alarm |
| Silent Setting | Yes | For use with nurse-call |
| Number of Delays | 2 | 0 sec., 2 sec. |
| Volume | High/Low | 100dB/85dB |
| Size | Compact | 2 ½”W x 3 ¾”H x 1”D |
| Power Source | 3 AAA Batteries | Included, average 6 months between battery changes* |
| Mounting Hardware | Yes | Holster with clip, strap |
| Warranty | Yes | 1 year |
* Results may vary, based on alarm use.
Compatible with AliMed sensors:
Pressure Sensor Pads
- 30-day bed and chair pads
- 6-month bed and chair pads
- 12-month bed and chair pads
Ultra-Thin ™, Touch-Sensitive Sensor Pads
- 30-day pads
- 6-month pads
Belts
- Roll-control belts for beds
- Seatbelts for chairs
Cushions
- BreakAway Lap cushion
- Sit-Straight ™ wedge cushion
- Sensor cushion
Ordering Information:
#711290 IQ Duo Plus Alarm
