FHT Series Full Height Turnstile

Product Information

The Full Height Turnstile Series is a range of turnstile models
manufactured by ZKTeco. The applicable models in this series are
FHT2300 Series, FHT2300D Series, FHT2400 Series, and FHT2400D
Series. The user manual provided here is applicable to all these
models. The manual version is 1.3 and the date of publication is
March 2022.

ZKTeco is the registered trademark of the company that produces
these turnstiles. Any other trademarks mentioned in the manual
belong to their respective owners.

The manual contains important information on the operation and
maintenance of the ZKTeco equipment. The copyright of all the
documents and drawings related to the supplied equipment belongs to
ZKTeco.

It is necessary for the operating and maintenance personnel to
fully understand the design and receive proper training before
operating and maintaining the turnstiles. Safety instructions
provided in the manual must be followed for safe operation.

In case of any conflict between the terms and conditions of the
manual and the contract specifications, the contract
conditions/documents take precedence.

ZKTeco does not provide any warranty or guarantee regarding the
completeness of information in the manual. The user assumes all
risks associated with using the information provided.

ZKTeco shall not be liable for any damages, including loss of
business, profits, or business interruption, arising from the use
of the information in the manual.

Product Usage Instructions

Read the user manual carefully before operating the Full Height
Turnstile.
Ensure that you have received proper training in operating and
maintaining the turnstile.
Familiarize yourself with the design and functionality of the
turnstile.
Follow the safety instructions provided in the manual for safe
operation.
Refer to the specific instructions for your model within the
Full Height Turnstile Series.
If you encounter any issues or have any questions, contact
ZKTeco for support.

For more detailed information and updates, please visit ZKTeco’s
official website at www.zkteco.com.

View Fullscreen

Full Height Turnstile Series

User Manual

User Manual
Full Height Turnstile Series
Applicable Models: FHT2300 Series, FHT2300D Series, FHT2400 Series, FHT2400D Series Date: March 2022 Doc Version: 1.3 English

Thank you for choosing our product. Please read the instructions carefully before operation. Follow these instructions to ensure that the product is functioning properly. The images shown in this manual are for illustrative purposes only.
For further details, please visit our Company’s website www.zkteco.com.

P a g e |1

Full Height Turnstile Series

User Manual

Copyright © 2022 ZKTECO CO., LTD. All rights reserved.
Without the prior written consent of ZKTeco, no portion of this manual can be copied or forwarded in any way or form. All parts of this manual belong to ZKTeco and its subsidiaries (hereinafter the “Company” or “ZKTeco”).
Trademark
is a registered trademark of ZKTeco. Other trademarks involved in this manual are owned by their respective owners.
Disclaimer
This manual contains information on the operation and maintenance of the ZKTeco equipment. The copyright in all the documents, drawings, etc. in relation to the ZKTeco supplied equipment vests in and is the property of ZKTeco. The contents hereof should not be used or shared by the receiver with any third party without express written permission of ZKTeco.
The contents of this manual must be read as a whole before starting the operation and maintenance of the supplied equipment. If any of the content(s) of the manual seems unclear or incomplete, please contact ZKTeco before starting the operation and maintenance of the said equipment.
It is an essential pre-requisite for the satisfactory operation and maintenance that the operating and maintenance personnel are fully familiar with the design and that the said personnel have received thorough training in operating and maintaining the machine/unit/equipment. It is further essential for the safe operation of the machine/unit/equipment that personnel has read, understood and followed the safety instructions contained in the manual.
In case of any conflict between terms and conditions of this manual and the contract specifications, drawings, instruction sheets or any other contract-related documents, the contract conditions/documents shall prevail. The contract specific conditions/documents shall apply in priority.
ZKTeco offers no warranty, guarantee or representation regarding the completeness of any information contained in this manual or any of the amendments made thereto. ZKTeco does not extend the warranty of any kind, including, without limitation, any warranty of design, merchantability or fitness for a particular purpose.
ZKTeco does not assume responsibility for any errors or omissions in the information or documents which are referenced by or linked to this manual. The entire risk as to the results and performance obtained from using the information is assumed by the user.
ZKTeco in no event shall be liable to the user or any third party for any incidental, consequential, indirect, special, or exemplary damages, including, without limitation, loss of business, loss of profits, business interruption, loss of business information or any pecuniary loss, arising out of, in connection with, or relating

P a g e |1

Full Height Turnstile Series

User Manual

to the use of the information contained in or referenced by this manual, even if ZKTeco has been advised of the possibility of such damages.
This manual and the information contained therein may include technical, other inaccuracies or typographical errors. ZKTeco periodically changes the information herein which will be incorporated into new additions/amendments to the manual. ZKTeco reserves the right to add, delete, amend or modify the information contained in the manual from time to time in the form of circulars, letters, notes, etc. for better operation and safety of the machine/unit/equipment. The said additions or amendments are meant for improvement /better operations of the machine/unit/equipment and such amendments shall not give any right to claim any compensation or damages under any circumstances.
ZKTeco shall in no way be responsible (I) in case the machine/unit/equipment malfunctions due to any noncompliance of the instructions contained in this manual (ii) in case of operation of the machine/unit/equipment beyond the rate limits (iii) in case of operation of the machine and equipment in conditions different from the prescribed conditions of the manual.
The product will be updated from time to time without prior notice. The latest operation procedures and relevant documents are available on http://www.zkteco.com
If there is any issue related to the product, please contact us.

ZKTeco Headquarters

Address

ZKTeco Industrial Park, No. 32, Industrial Road,

Tangxia Town, Dongguan, China.

Phone

+86 769 – 82109991

Fax

+86 755 – 89602394

For business-related queries, please write to us at: [email protected].

To know more about our global branches, visit www.zkteco.com.

P a g e |2

Full Height Turnstile Series

User Manual

About the Company
ZKTeco is one of the world’s largest manufacturer of RFID and Biometric (Fingerprint, Facial, Finger-vein) readers. Product offerings include Access Control readers and panels, Near & Far-range Facial Recognition Cameras, Elevator/floor access controllers, Turnstiles, License Plate Recognition (LPR) gate controllers and Consumer products including battery-operated fingerprint and face-reader Door Locks. Our security solutions are multi-lingual and localized in over 18 different languages. At the ZKTeco state-of-the-art 700,000 square foot ISO9001-certified manufacturing facility, we control manufacturing, product design, component assembly, and logistics/shipping, all under one roof.
The founders of ZKTeco have been determined for independent research and development of biometric verification procedures and the productization of biometric verification SDK, which was initially widely applied in PC security and identity authentication fields. With the continuous enhancement of the development and plenty of market applications, the team has gradually constructed an identity authentication ecosystem and smart security ecosystem, which are based on biometric verification techniques. With years of experience in the industrialization of biometric verifications, ZKTeco was officially established in 2007 and now has been one of the globally leading enterprises in the biometric verification industry owning various patents and being selected as the National High-tech Enterprise for 6 consecutive years. Its products are protected by intellectual property rights.
About the Manual
This manual introduces the operations of Full Height Turnstile Series.
All figures displayed are for illustration purposes only. Figures in this manual may not be exactly consistent with the actual products.
Features and parameters with are not available in all devices.

P a g e |3

Full Height Turnstile Series

User Manual

Document Conventions

Conventions used in this manual are listed below: GUI Conventions

Convention

For Software Description

Bold font

Used to identify software interface names e.g. OK, Confirm, Cancel.

> Convention

Multi-level menus are separated by these brackets. For example, File > Create > Folder.
For Device Description

< >

Button or key names for devices. For example, press <OK>.

[ ]

Window names, menu items, data table, and field names are inside square brackets. For example, pop up the [New User] window.

Multi-level menus are separated by forwarding slashes. For example, [File/Create/Folder].

Symbols Convention

Description This represents a note that needs to pay more attention to.

The general information which helps in performing the operations faster.

The information which is significant.

Care taken to avoid danger or mistakes. The statement or event that warns of something or that serves as a cautionary example.

P a g e |4

Full Height Turnstile Series

User Manual

Table of Contents
1 PRODUCT INTRODUCTION…………………………………………………………………………………………………… 6
MODEL NUMBER AND ACCESS CONTROL ……………………………………………………………………………………………. 6 STRUCTURES AND DIMENSIONS ………………………………………………………………………………………………………… 6 MECHANICAL SYSTEM OF FHT2300&FHT2400 SERIES……………………………………………………………………….. 7 ELECTRONIC CONTROL SYSTEM ………………………………………………………………………………………………………… 7 THE WORKING PRINCIPLE OF FULL HEIGHT TURNSTILES ………………………………………………………………………… 8 TECHNICAL SPECIFICATIONS …………………………………………………………………………………………………………….. 8
2 WIRING DIAGRAM ………………………………………………………………………………………………………………. 9
3 DIP SWITCH………………………………………………………………………………………………………………………. 10
4 PRODUCT MAINTENANCE………………………………………………………………………………………………….. 11
MAINFRAME-BOX MAINTENANCE ……………………………………………………………………………………………………. 11
5 PRODUCT MAINTENANCE………………………………………………………………………………………………….. 11
MAINFRAME-BOX MAINTENANCE ……………………………………………………………………………………………………. 11 MOVEMENT MAINTENANCE……………………………………………………………………………………………………………. 11 POWER MAINTENANCE………………………………………………………………………………………………………………….. 11

P a g e |5

Full Height Turnstile Series

User Manual

1 Product Introduction

Model Number and Access Control

Access No
Model

FHT2300

FHT2311

FHT2322

FHT2400

FHT2411

FHT2422

C3-200 with two KR101E reader

inBIO260 with two FR1200/ID reader

Structures and Dimensions
FHT2300 series and FHT2400 series has stainless steel casing, which provides corrosion resistance and durability. FHT2300’s appearance and dimensions are as shown in figure 1-2A:

P a g e |6

Figure 1-2A
Copyright©2022 ZKTECO CO., LTD. All rights reserved.

Full Height Turnstile Series
FHT2400’s appearance and dimensions are as shown in figure 1-2B:

User Manual

Figure 1-2B
Mechanical System of FHT2300&FHT2400 Series
The mechanical system of the full height turnstiles includes a mainframe box and a frame.
The direction indicator, core, control panel, access controller and lock are installed in the mainframe box. The core component mainly consists of two solenoids, a spring and a transmission mechanism. The frame supports the entire mainframe box.
Electronic Control System
The electronic control system of the full height turnstile is composed of reader, control panel, access controller, direction indicator, speaker, and transformer.
Reader: The reader reads the data from the card and sends it to the controller.
Control panel: The control panel is the system’s control center that receives signals from the controller. After the signals have been processed by the control panel, the control panel will deliver commands to the indicator.
Direction indicator: This indicator displays the current status of the sign at the channel, and directs the pedestrian to pass the channel.

P a g e |7

Full Height Turnstile Series

User Manual

The Working Principle of Full Height Turnstiles

1. After the power is turned on, the system will perform self-check. If no fault is detected, the device will operate as usual. If a fault is detected, the system will display the related messages on the LCD screen. This can be useful for error checking and troubleshooting.
2. When the reader detects a valid signal, the buzzer will give pedestrians a voice prompts to remind pedestrians have been successful credit card. And then, the reader sends signals to the access controller to request permission to pass through the passage. After the access controller send the signals to the control panel, the control panel will send out a pass.
3. After receiving the signal from the access controller, the control panel sends signals to the direction indicator and solenoid. Then the direction arrow will turn green. Also the solenoid will loose that the pedestrian can push the rod to pass the passage.

Technical Specifications

Feature Dimensions (mm)
Communication Interface Input Control Signal Working Environment Temperature Input Voltage Output Voltage Relative Humidity
Pass Speed

Specification FHT2000: L=1400, W=1310, H=2200 FHT2400: L=1400, W=1370, H=2200 Relay
Switching signal Indoor/Outdoor (if sheltered) -28 °C to 60°C AC 100 – 120V/200 – 240V, 50 – 60Hz DC 24V 25% to 75% RFID: Maximum 30/minute Fingerprint: Maximum25/minute Face: Maximum 15/minute Vein: Maximum 15/minute

P a g e |8

Full Height Turnstile Series
2 Wiring Diagram
Check circuit according to the following wiring diagram:

User Manual

P a g e |9

Full Height Turnstile Series
3 DIP Switch

User Manual

Pin
Function setting
Default

Figure3-1

1 2 3
Opening duration
1 1 1

4 5
Direction indicator
0 0

6 7
Memory function
1 0

8
Testing mode
0

Setting the turnstile opening duration

Opening duration

Bit setting Duration Bit setting

111

011

110

10s

010

101

15s

001

100

20s

000

Note: The turnstile opening duration is set to 5s by default

Duration 30s 40s 50s 60s

Setting the turnstile direction indicator

Bit setting
00 01 11 10

Direction indicator
Direction passing is allowed in both directions one way traffic ,right passing is allow one way traffic ,left passing is allow both ways forbidden

Setting the memory function

Bit setting 00 10

Memory function Mermory unable mermory function allow mermory function

P a g e | 10

Full Height Turnstile Series

Setting the testing mode

Bit setting
0 1

Testing mode
Solenoid automatically open and close unable auto testing allow auto testing

User Manual

4 Product Maintenance
Cabinet Maintenance
The cabinet is made of 304 stainless steels. So after a long period of operation, its surface may have some stains. It can use gauze to clean the Cabinet. In order to protect the lines of surface, please wipe along the lines direction. It’s best to polish and wax.
Movement Maintenance
Cut off power supply before maintenance. Open the barriers and clean the dust on surface, add lubricating oil to the transmission mechanism. Check and tighten others connection parts.
Power Maintenance
Cut off power supply before maintenance. Check whether the plug is loose, if loose, it needed to tightly it. Please do not replace the connection position at random. Check whether the external power supply is exposed and wrap it. Check whether there is any leakage, found to be timely processing. Check the technical parameters at the interface are regular and replace the old electronic components in time.
(Attention: Above full height turnstile maintenance must be maintained by professional personnel. Especially the movement and the electric control part, first cut off the power supply, ensure the operation safety. )

P a g e | 11
