MGC EOL-103 Network Service Kit
Part Description
| Quantity | Part Number | Part Description | Notes |
| 20 | EOL-103 | End of line resistor – 10K, 2W, 5% | For TNC-5000 telephone network controller module and QAA-5230, QAA-5230S, QAA-5160 amplifiers |
| 20 | EOL-223 | End of line resistor – 22K, 2W, 5% | For QAA-5415 amplifiers |
| 20 | EOL-392 | End of line resistor – 3K9, 2W, 5% | For on-board NAC circuits |
| 20 | EOL-473 | End of line resistor – 47K, 2W, 5% | For M500M module |
| 100 | HD-029 | MET SCR, #8 x 1/4″,PAN,PH,’B’,ST.ZINC | Self-tapping screw |
| 100 | HD-050 | Nut, #6-32 x 1/4″, hex, integral lockwasher | |
| 100 | HD-112 | Machine screw, #6-32 x 1/4″, PAN, PH, ST.ZINC | |
| 100 | HD-212 | Nut, #8-32, hex, integral lockwasher, ST.ZINC | |
| 100 | HD-215 | Nut, #10-32, hex, integral lockwasher, ST.ZINC | |
| 5 | MD-525 | Flat cable assembly, 34 conductors, 60″ | Ribbon cable for QBB-5001 multiple cabinet extension |
| 5 | MD-575 | Flat cable assembly, 26 conductors, 24″ | Ribbon cable for RM-1008A, DM-1008A, SGM-1004A adder modules |
| 5 | MD-579 | Power cable, 4 conductors, 5″ | Power cable for RM-1008A, DM-1008A, SGM-1004A adder modules |
| 5 | MD-580 | Power cable, 4 conductors, 24″ | Power cable for RM-1008A, DM-1008A, SGM-1004A adder modules |
| 5 | MD-650 | Extender ribbon cable, 34cct, 36″ | Ribbon cable for display modules (except main display) |
| 5 | MD-678 | Flat cable assembly, 50 conductors, 36″ | Ribbon cable for main display module |
| 5 | MD-687 | Extender ribbon cable, 34cct, 12″ | Ribbon cable for display modules (except main display) |
| 5 | MD-903 | Ribbon Cable, 60 pins 25 mils 6″ Long F-F | Ribbon cable for FNC-2000 network interface controller module |
| 5 | MD-985 | Ribbon cable, 8 pins, 35″, F-F-F | High-speed audio cable for ANC-5000 network audio controller module |
| Quantity | Part Number | Part Description | Notes |
| 5 | MD-991 | Ribbon cable,10cct, 20″, F-F- RS-485 | RS-485 cable for ANC-5000 audio network controller module |
| 5 | NP-680 | Slide-in paper label | For RAM-1016(TZ)(DS), RAM-1032(TZ)(DS) |
| 5 | NP-681 | Slide-in paper label | For RAX-1048(TZ)(DS) |
| 5 | NP-7015 | Slide-in paper label | For RAXN-LCDG |
| 5 | NP-7173 | Slide-in paper label | For MGC network panels |
| 5 | NP-741 | Slide-in paper label | For IPS-2424, QAZT- 5302(DS) |
| 5 | NP-818 | Display label | For QAA-5415 amplifiers |
| 5 | NP-836 | Slide-in paper label | For RAX-LCD, RAXN-LCD |
| 5 | NP-836F | Slide-in paper label | French label for RAX-LCD, RAXN-LCD |
| 5 | NP-851 | Slide-in paper label | For FDX-008(KI) |
| 10 | OP-116 | 4 A fuse, fast AGC4 | For QAA-5230, QAA-5230S amplifiers |
| 5 | OP-119 | 20 A fuse | Install in WX-059 |
| 10 | OP-122 | 8 A fast acting fuse, AGC-8 | For QAA-5160 amplifier |
| 10 | OP-210 | 3 A fuse GMA (5×20 mm) | For QAA-5415 amplifiers |
| 100 | SK-014 | Socket jumper 2-pins, 100 mils PITCH | To terminate jumper pins |
| 5 | WX-050 | Battery bundled wires | For the QBB-5001 expansion audio cabinet |
| 5 | WX-059 | 16 AWG bundled battery wire assembly – 36″ | For MGC network panels, install OP-119 |
www.mircom.com LT-6116 Rev. 2 August 2018.
