Hale Outdoor Kitchen Garden Fireplace
Product Information
The Hale Outdoor Kitchen Garden Fireplace is a versatile outdoor
fireplace designed for cooking and creating a cozy ambiance in your
garden. It comes with various components including build,
rendering, firebricks, and accessories.
Components included:
- Capping
- Chimney blocks x 2
- Gather front, back, and sides x 4
- Frame section x 2
- Base plate x 1
- Firebricks
- 1 bag of lip glue adhesive (for pumice components)
- 1 bag of Calderys fire brick mortar
- 1 bag of render
- 1 log retainer kit (2 metal bars + 2 fixing brackets)
- 1x grill and fixing brackets
The Hale Outdoor Kitchen Garden Fireplace is available in both
right-hand side and left-hand side designs.
Product Usage Instructions
Preparation
Prior to building the Garden Fire, ensure that you have a firm
foundation. Do not build the fireplace directly onto decking. We
recommend using a minimum 100mm reinforced concrete base to support
the structure. Maintain a distance of 100mm between the Garden Fire
and any wooden or combustible material.
Log store and firechest (Step 1)
- Position the base plate onto a solid surface, preferably a
100mm thick reinforced concrete foundation. - Bed the two Frame sections together using the supplied lip glue
adhesive. - Mix the lip glue jointing adhesive as per the instructions on
the bag and apply 15-20mm beads using the supplied application
bag. - Apply lip glue around the top of the frame section and then
glue on the next two frame sections. Press the base plate down into
position and ensure it is level.
Gather unit (Step 2)
- Apply lip glue to the top layer of the gather unit and press
the front and rear sections into place. - Apply lip glue to the joints on the sides of the front and rear
panels of the gather. - Press the side panels of the gather into place.
- The fireplace with the gather unit should resemble the provided
image. Apply a layer of lip glue around the top of the first block
and press the second block into place. Ensure the top is level and
clean off any excess glue. - Apply a layer of glue on the 2 chimney blocks, ensuring
everything is level, and wipe off any excess glue.
Capping (Step 3)
- Apply lip glue to the top of the final chimney block.
- Position the capping over the glue and ensure it is
centered. - Push and adjust the capping into place.
Side log stores (Step 4)
To assemble the side log stores:
- Place the base and add the three frame sections using the
supplied lip glue adhesive. - Check each stage for levelness.
For more detailed diagrams and information, please refer to the
user manual available at www.schiedel.com/uk.
CANIC PU
ND VOL
MICE HE
KLA ICELA
Hale Outdoor Kitchen Garden Fireplace
Build, rendering, firebricks and accessories
www.schiedel.com/uk
April 2023
Hale Outdoor Kitchen Garden Fireplace
Capping
Chimney blocks x 2
Gather front, back and sides x 4
Frame section x 2
Base plate x 1 Firebricks
Frame section x 2
Base plate x 1
Right hand kit example. Note that this is available in right hand side and left hand side. Instructions are very similar for both designs.
Frame section x 3
Frame section x 3
Base plate x 1
2 | The latest version of this brochure is available online at www.schiedel.com/uk
Base plate x 1
The Hale Outdoor Kitchen Garden Fireplace model comes complete with the following components: 1 bag of lip glue adhesive (for pumice components) 1 bag of Calderys fire brick mortar 1 bag of render 1 log retainer kit (2 metal bars + 2 fixing brackets) 1x grill and fixing brackets
Fire brick diagram and parts (see page 6 for more details)
Side (x 2)
Back (x 1)
Log retainer kit (see page 10 for more details)
Base (x 1)
Grill and fixing brackets
Front left and right side (x4)
Back left and right side (x4)
Preparation
The Garden Fire needs to be built onto a firm foundation. It should not be built directly onto decking. Schiedel recommends that a minimum 100mm reinforced concrete base is used to support the structure. A distance of 100mm should be left between the Garden Fire and any wooden or other combustible material.
The latest version of this brochure is available online at www.schiedel.com/uk | 3
Instructions – Log store and firechest (Step 1)
Position the base plate onto a solid surface. Please note that we recommend 100mm thick reinforced concrete. Bed the two Frame sections using the supplied lip glue adhesive.
Mix lip glue jointing adhesive as per instructions on the bag. Apply 15-20mm beads using the supplied application bag as shown in the picture above.
Apply lip glue around the top of the frame section and then Glue on the next two frame sections press the base plate down into position. Check that it is level.
4 | The latest version of this brochure is available online at www.schiedel.com/uk
Instructions – Gather unit (Step 2)
Apply lip glue to the top layer and then press the front and rear sections of the gather into place.
Apply lip glue to the joints on the sides of the front and rear panels of the gather.
Press the side panels of the gather into place.
The fireplace with the gather unit should resemble the image above.
Apply a layer of lip glue around the top of the first block and then press the second block into place. Ensure the top is level and clean off any excess glue.
Apply a layer of glue on the 2 x chimney blocks. Check all is level and wipe off excess glue.
The latest version of this brochure is available online at www.schiedel.com/uk | 5
Instructions – Capping (Step 3)
Apply lip glue to the top of the final chimney block.
Position the capping over the glue and central.
Push and adjust in to place.
6 | The latest version of this brochure is available online at www.schiedel.com/uk
Instructions – Side log stores (Step 4)
For the side storage, place the base and then add the three frame sections sections using the supplied lip glue adhesive. Check each stage is level.
Do the same with the adjacent frame sections.
BASE TO BE PHOTOSHOPPED ADD THIRD LAYER
Apply lip glue around the top of the frame section.
Build up to 3 frame sections.
Repeat the process for the adjacent storage.We recommend rendering the Hale before fitting the doors and granite tops
The latest version of this brochure is available online at www.schiedel.com/uk | 7
Garden Fireplace firebricks guide
500 model
Side (x 2)
Back (x 1)
Base (x 1)
Brick
LW D
A
230 114 50
L
230 114 25
M
156 114 25
N
78 114 25
Sizes in mm
Brick
LW D
T
35 114 25
U
154 114 50
V
35 114 50
X
124 114 50
Note for all models 8mm gap between bricks. Bedded on 1-3mm thick firebrick mortar Firebricks to be glued on and pointed with the Calderys firebrick mortar as per enclosed instructions
Front bracket x 4
Back bracket x 4
Prior to gluing the bricks, remember to place the 8 x brackets (2 front and 2 back brackets on each side) supported on the firebricks, before the next row of firebricks are added. These are supports for the grill.
PLEASE NOTE: Firebrick colours will vary in shade to photographs shown in these instructions. This is natural due to the production process.
8 | The latest version of this brochure is available online at www.schiedel.com/uk
Instructions – Firebricks and grill supports (Step 5)
Mortar bag – Used for gluing on firebricks and pointing in. Mix as per instructions on the bag
Bed the firebricks on to a 3mm layer of firebrick mortar. Use the tables on the previous page as a guide.
Complete the bottom layer of firebricks, then fasten the rear firebricks in place using the firebrick mortar. Use a tile spacer to keep an 8mm gap.
Once the bottom and rear firebricks are in place, fasten the side bricks in
position using the firebrick mortar. Use a tile spacer to keep an 8mm gap.
During the first and second level, you must slot in the grill supports as shown in the next step
Inset grill support front and back brackets prior to fitting the firebricks on the side walls. These can be supported on the firebrick layer as shown.
Use the mortar mix to point up the joints between the firebricks once they are all in position. Clean off excess mor tar.
The latest version of this brochure is available online at www.schiedel.com/uk | 9
Instructions – Log retainer (Step 6)
Drill 2 x 12mm diameter holes in the front row of the firebricks. Push log retainer holders in place.
Then push fit the log retainer bars into the slots.
10 | The latest version of this brochure is available online at www.schiedel.com/uk
Instructions – Rendering (Step 7)
Render plaster To be mixed and adhered to the surface and smoothed by a competent person. As this is heat resistant plaster, it requires more care and pressure to spread. in comparison to traditional plaster which is much more smoother.
Render plaster is designed for one coat, if you require more coats you will need to purchase more render.
Burn off the fibres on external surface before rendering.
Mix the render as per the instructions
Render the surface areas.
Ensure the edges are smooth and wait to dry.
The latest version of this brochure is available online at www.schiedel.com/uk | 11
Instructions – Wood doors (Step 8)
Align the hinge to the logstore, ensuring the door is below the top of the logstore (a 5mm gap is fine).
Secure the hinge to the pumice logstore with the screws provided.
Attach the magnetic latch to the inside of the logstore with the screws provided.
Mark with a pencil the end of the magnetic latch on the door.
Attach the metal ring to the door.
Test that the door closes and opens correctly. Adjust where needed.
12 | The latest version of this brochure is available online at www.schiedel.com/uk
Instructions – table top and wood background (Step 9)
Lay the granite surface on a bed of lip glue.
Ensure that the granite is level.
Place the second granite surface on the logstore and ensure these are level.
Place the side wooden panel on top of the granite. Fix with screws provided, flush to the back.
Re-fix the two long supports to the back panel, as shown above. Then fix the back wooden panel to the log stores with the screws provided.
Attach the bottom metal bracket to the side and back panels.
The latest version of this brochure is available online at www.schiedel.com/uk | 13
Instructions – Wood background (Step 10)
Attach the top metal bracket to the side and back panels. You have now completed the build 🙂 Enjoy cooking on the Outdoor Kitchen.
14 | The latest version of this brochure is available online at www.schiedel.com/uk
After completion
Once build and rendering is complete, please do not use for at least 72 hours after completion. On first use, always light a small fire first and increase the size of the fire once the firechest has fully dried out. Only use dried and seasoned wood for the fire. Do not burn plastic or waste products.
Guarantee
INTRODUCTION We are confident in our products and so offer you (the owner) a generous guarantee in relation to the Garden Fireplace. Provided that you comply in full with your responsibilities (below) and subject to the Small Print (below), we guarantee to you that the fireplace will be free from defects on delivery to you via pallet. Any blocks or firebricks which are cracked or damaged at the time of delivery will be replaced free of charge. This guarantee does not cover any major impact to the fireplace (such as wear and tear, wind damage) once the item has been constructed and rendered. As the fireplace is an outdoor product, standard wear and tear will occur and any structural damage would have to be investigated. In the unlikely event that the fireplace becomes defective during the guarantee period, we will provide replacement component parts and render material free of charge. YOUR RESPONSIBILITIES To benefit from our guarantee, this product will be registered to the address where we delivered it. Please inform us if the fireplace was installed elsewhere. HOW TO CLAIM UNDER YOUR GUARANTEE To claim under your guarantee, please email us at [email protected]. You will be asked to provide proof that you have complied in full with the terms of usage of the fireplace and that only dried and seasoned firewood has been used as a fuel.
If you are an installer / builder
If you are a regular builder of our Garden Fireplaces, then please get in touch with us. We are looking for competent builders throughout the UK and Republic of Ireland to promote as “recommended builders” in certain areas. Builders are able to benefit from joining our Installer Loyalty scheme with points awarded for installations, which can then be redeemed for vouchers. Please see details at www.schiedelrewards.co.uk.
