ASD Series Mesh Door Kits
Product Information
The product is a Mesh Door Kit designed for use on specific
fireplace models. It is available in various models, including
ASD-36, ASD-42, LSD-36, LSD-42, VOFBSD-36, and VOFBSD-42. Each
model has a corresponding door model number for easy
identification.
The Mesh Door Kit is made of sheet metal and features a
screen/mesh and glass doors. It is designed to be installed on
fireplace models BUF36A and BUF42A.
During installation, it is important to wear protective gloves
and safety glasses due to the risk of cuts and abrasions from the
sharp sheet metal edges.
It is also important to note that the screen/mesh, glass doors,
and other surfaces of the Mesh Door Kit can become hot during
operation and take time to cool down. Caution should be exercised
to avoid burns.
Prior to the initial burning of the fireplace, all fingerprints
and smudges must be wiped clean from the viewable surfaces of the
door kit. Failure to do so may result in these prints and smudges
becoming permanent. To maintain the finish of the door kit, it is
recommended to gently wipe it with a soft cloth and, if necessary,
soap and water. Thinner or abrasive cleaners should never be used
as they can damage the finish.
Product Usage Instructions
- Remove the existing screens from the fireplace.
- Hang the door frame assembly into the slots located on the
firebox using the corresponding hooks on the door frame. Ensure
that the door is fully down on the hooks and that there is
approximately a 1/2 inch gap at the bottom of the frame. - Install the inner hood by using the bend tabs to locate it.
Slightly pry up the hand band tabs to position it correctly. Secure
it in place using the screws from the screen rods. - Leave the original hood in place.
- The mesh door installation is now complete.
Note: It is recommended to have two installers to handle the
heavy door kit during installation.
Installation Instructions
tm
Models: ASD-36, ASD-42, LSD-36, LSD-42, VOFBSD-36 and VOFBSD-42 Mesh Door Kits
Door Model Number ASD-36 ASD-42 VOFBSD-36 VOFBSD-42 LSD-36 LSD-42
ACUF36-BD ACUF42-BD VOBF36-T VOBF42-T LCUF36CR-C LCUF42CR-C
ACUF36-GD ACUF42-GD VOBF36-H VOBF42-H LCUF36CR-BT LCUF42CR-BT
For Use on Models BUF36A BUF42A
LCUF36CR-GT LCUF42CR-GT
BUF36-T BUF42-T
LCUF36CR-GH LCUF42CR-GH
BUF36-H BUF42-H
These mesh door kits have been tested for use with specific Hearth & Home Technologies products. Check with your local building code agency before you begin installation to ensure compliance with local codes, including the need for permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need clarification of any of the instructions contained here, contact your Hearth & Home Technologies Inc. dealer. For the dealer nearest you, please visit www.hearthnhome.com.
CAUTION! Risk of Cuts/Abrasions. Wear protective gloves and safety glasses during installation. Sheet metal edges are sharp.
WARNING
HOT SURFACES! Screen/mesh, glass doors and other surfaces are hot during operation AND cool down.
NOTICE: All fingerprints and smudges must be wiped clean from the viewable surfaces of the door kit prior to the initial burning of the fireplace. If this is not done, these prints and smudges will be cured into the finish and set for the life of the fireplace. To keep the finish looking its best, gently wipe with a soft cloth and if desired, soap and water. Never use thinner or abrasive cleaners since these products will damage the finish.
Hot screen/mesh and glass doors will cause burns.
· Do not touch screen/mesh or glass doors until cooled · NEVER allow children to touch screen/mesh or glass
doors
· Keep children away · CAREFULLY SUPERVISE children in same room as
fireplace. · Alert children and adults to hazards of high
temperatures.
High temperatures may ignite clothing or other flammable materials. · Keep clothing, furniture, draperies and other flammable
materials away.
Figure 1 Mesh Door Kit
Hearth & Home Technologies · Outdoor Mesh Doors · 4136-918 Rev B · 04/23
1
CAUTION! The door kit is heavy. We recommend two installers to put the front assembly in place.
Installation: 1. Remove the existing screens from the fireplace. See Figure 2:
· Remove one screw in each of the screen rods behind the upper screen cover
· Slide screen rods out of support holes. · Rods and screen will come out as an assembly. · Discard.
Mesh Door Hang Holes
3. Hang door frame assembly into the (4) slots located on the firebox (see Figure 2) with the corresponding hooks on the door frame. See Figure 4. Be sure door is all the way down on the hooks. Door frame will have approximatley 1/2 inch gap on the bottom of frame. See Figure 6.
Screen Rod Screws
Hang Hooks
Figure 4 Frame Assembly
Figure 2 Remove Existing Screens
2. Install inner hood by using the (4) bend tabs to locate. Pry up hand band tabls slightly to locate. See Figure 3. Use the (2) screws from the screen rods to secure into place. See Figure 5. Leave original hood in place.
Screws Figure 5 Frame Assembly
Tabs Figure 3 Bend Tabs
Figure 6 Completed Mesh Door Installation
2
Hearth & Home Technologies · Outdoor Mesh Doors · 4136-918 Rev B · 04/23
