Sbs Tws Beat Free Tws Wireless Earphones User Manual

Tws Beat Free TWS Wireless Earphones
User ManualTEEARTWSBEATFREEBTK – TEEARTWSBEATFREEBTW
Tws Beat Free
TWS Wireless Earphones

Tws Beat Free TWS Wireless Earphones

SPECIFICATION

• Wireless: V 5.0
• Impedance: 32Ω
• Working Range:10m
• Frequency Range: 20Hz-20kHz
• Sensitivity: 110dB
• Input: 5 V D.C.
• Charging Box: 200mAh
• Battery Earphone: 30mAh
• Microphone | Music & Phone Calls
• Charge Port: Type-C
• Charging Time: 1.5 hours
  PRF: 6 m W max
  f: 2402 ÷ 2480 MHz

For other informations please contact us at [email protected]

Charging the earbuds

Insert the earbuds into the charging case, the LED will light up. When charging is complete, it will turn off.

Charging the case

Charging via cable
Plug the Type C connector of the supplied cable into the Type C port on the case and the other end into a USB port.
The LED on the case will flash and remain steady when charging is complete.

Turning on the earbuds

Take the earbuds out of the charging case, they will automatically turn on and pair with each other.
Or press both MLF buttons on the earbuds for 5 seconds,

Turning off the earbuds

When you put the TWS earphones into the case, they will turn off automatically.
Alternatively, press the MLF button on one of the earbuds for 5 seconds.

Pairing with devices

1. Take the earbuds out of the charging case: they will turn on and pair with each other automatically
2. Turn on Bluetooth on the device and search for “SBS BEAT FREE” in the list of available devices, then select it.
3. After the first pairing with the device (if Bluetooth is turned on), the earbuds will automatically pair every time they are taken out of the case.

SBS spa – Via Circonvallazione s/n
28010 Miasino (No) – Italy
sbsmobile.com
made in China
TEEARTWSBEATFREEBThttps://www.sbsmobile.com/ita/en/search?s=TEEARTWSBEATFREEBT
Printed in ChinaREV0_12-22
