L-868 DC Radio Tubular Motor
Product Information: SunTop L-868 DC Assembly
The SunTop L-868 DC Assembly is a motorized blind system that
can be programmed to open, close, and set end positions using a
transmitter. It comes with a QUICKON power connector that allows
for easy installation and connection to a power source. The end
positions of the blinds can be adjusted in four different
variations, depending on the user’s preference.
Safety Instructions
Before assembling and using the SunTop L-868 DC Assembly, please
read and follow the safety instructions provided in the user
manual. Failure to do so may result in injury or damage to the
product.
Assembly
Follow the assembly instructions provided in the user manual to
properly install the SunTop L-868 DC Assembly. Use the QUICKON
power connector to connect the motorized blind system to a power
source, following the pin assignment for correct connection. See
figure in the user manual for reference.
Commissioning
After assembly, programming the transmitters and deleting
transmitters can be done to operate the blinds. Disconnect the plug
to the energy unit then wait for approximately 20 seconds before
proceeding with programming.
Setting the End Positions
The end positions of the blinds can be adjusted in four
variations: A, B, C, and D. See the user manual for reference of
each variation.
Variation A: Freely Adjustable Top End Position, Freely
Adjustable Bottom End Position
- Press the UP button with a programmed transmitter until the
blind has reached the desired top end position. The drive will
begin to travel, briefly stop, and travel further (for as long as
the UP button remains pressed). - Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set. - Press the DOWN/CLOSED button again until the blind has reached
the desired end position. The drive will begin to travel, briefly
stop, and travel further (for as long as the DOWN/CLOSED button
remains pressed). - Press the UP button until the drive stops automatically. The
lower end position has been set. - Adjustment of the Variation A end position is complete.
Variation B: Top End Position to the Stop, Freely Adjustable
Bottom End Position
- Press the UP button with a programmed transmitter until the
blind has reached the top end position (travels to the top stop).
The drive will begin to travel, briefly stop, and travel further
(for as long as the UP button remains pressed). The drive switches
off automatically when the upper limit stop is reached. - Activating the top release function (optional): While pressing
and holding the UP button, press the DOWN/CLOSED button
(simultaneously) until the blind stops. The top release function is
activated. - Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set. - Press the DOWN/CLOSED button again until the blind has reached
the desired end position. The drive will begin to travel, briefly
stop, and travel further (for as long as the DOWN/CLOSED button
remains pressed). - Press the UP button until the drive stops automatically.
- Adjustment of the Variation B end position is complete.
Variation C: Top End Position to the Stop, Bottom End Position
to the Stop
- Press the UP button with a programmed transmitter until the
blind has reached the top end position (travels to the top stop).
The drive will begin to travel, briefly stop, and travel further
(for as long as the UP button remains pressed). The drive switches
off automatically when the upper limit stop is reached. - Activating the top release function (optional): While pressing
and holding the UP button, press the DOWN/CLOSED button
(simultaneously) until the blind stops. The top release function is
activated. - Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set. - Press the DOWN/CLOSED button again until the blind has reached
the desired end position. The drive will begin to travel, briefly
stop, and travel further (for as long as the DOWN/CLOSED button
remains pressed). - Press the UP button until the drive stops automatically.
- Adjustment of the Variation C end position is complete.
Variation D: Freely Adjustable Top End Position, Bottom End
Position to the Stop
This variation is similar to Variation A, with the difference
being that the bottom end position is set to stop instead of being
freely adjustable. Follow the same steps as Variation A but set the
bottom end position to stop instead of freely adjustable.
SunTop L-868 DC Assembly instructions
General
· Application: radio control for textile sun protection · Power supply: direct current (DC) 12 V from battery · Limit switch: electronic with soft brake · Special feature: blockage detection UP or DOWN/CLOSE
for blind protection (available after a complete and continuous upward or downward movement). · End positions can be adjusted using the assembly cable and hand-held transmitter · Wave frequency: from 63 mm Ø Standard scope of delivery · 3 m plug-in connecting cable, assembly instructions Accessories · Adapter sets, motor bearing, energy unit, radio transmitter, sensors
Safety instructions
&$87,21
General safety instructions for use including installation of motors for roller shutters, awnings, textile sun protection and Venetian blinds can be found in the “Safety instructions” leaflet supplied with each motor. Please read the general safety instructions and this installation manual carefully as the procedure in this manual is a prerequisite for correct use of the product. Any intervention by unqualified personnel or failure to comply with warnings may lead to personal injury or material damage. Figures included are for illustration purposes only. The illustrations may differ from your product with respect to minor details and are provided for general information only. elero GmbH is continually striving to improve all products. As a result, the specifications, features and technology of this product may be changed at any time. The information provided is based on current information at the time of publication. No claims can be derived from the technical data, images and information in this manual.
Assembly
· Only connect once the power is turned off. · The drive is only capable of operation as installed. · The length of the winding shaft is determined for each
specific installation depending on the drive head and motor bearing used at the installation site. Installation in profile tubes · Push the drive with mechanical seal ring on the motor head and the appropriate adapter set (drive adapter and crown adaptor, accessories) in the profile tube. · Secure the counterpart support to prevent axial movement (screw or rivet on the idler). · Secure the drive axially in the support. · Attach the blind to the shaft. Do not drill holes near the drive area.
QUICKON power connector (figure)
Connection example (pin assignment)
Function
PIN (QUICKON)
UP or DOWN/CLOSE 1 (brown)
+ 12 V (positive terminal) 2 (white)
DOWN/CLOSE or UP 3 (blue)
– 0 V (negative terminal) 4 (black)
Wire colour brown white red black
QUICKON power connector
see energy unit (138178002) pin assignment assembly instructions · Cut the connection cable to the appropriate length · Connect the connection plug (component of the energy
unit) to the connection cable · Insert the plug into the energy unit
Commissioning
· Only during initial commissioning: the blind travels up and down briefly to signal that it is in programming mode. The transmitter can be programmed.
· Each movement that is interrupted by a short STOP places the drive in setting mode.
Programming transmitters / Deleting transmitters
Requirements: · Drive is in radio mode. · The end positions must be programmed · If the end positions have not been programmed, release the
blind from the shaft. Programming the first transmitter 1. Disconnect the plug to the energy unit. Wait approx. 20 s for
the integrated condenser to discharge. Re-insert the plug. After this voltage break, the drive will be in programming mode for 5 minutes. 2. Press the programming button P on the transmitter to be programmed for 1 second. The drive will travel up and down (programming mode for the receiver, travel movement for 2 minutes). The transmitter changes into unidirectional radio operation. 3. Immediately press the UP button (max. 1 second) on the transmitter to be programmed after the start of upward travel. 4. Immediately press the DOWN/CLOSE button (max. 1 second) on the transmitter to be programmed after the start of downward travel. The drive stops (programming mode ends). The transmitter is now programmed. Programming will have to be repeated if the blind does not stop. Programming additional transmitters A maximum of 16 transmitters may be programmed. 2 alternative procedures: First alternative: Repeat the actions used in the “Programming the first transmitter” with the new transmitter to be programmed. Second alternative: 1. On the transmitter that has already been programmed, press the 3 buttons UP and DOWN/CLOSE and P for at least 3 seconds. The drive will be in programming mode for 5 minutes and performs the travel movements. 2. Press the P button on the transmitter to be programmed, so that it changes into unidirectional radio operation. The drive will perform additional travel movements. 3. as in “Programming the first transmitter”. 4. “Programming the first transmitter” The drive stops (programming mode ends). The transmitter is now programmed. Deleting the transmitter See the elero operating instructions for the transmitter concerned.
138187001_EN_0217
SunTop L-868 DC Assembly instructions
Setting the end positions
Requirement: · The transmitter must be programmed. Interrupting and restoring the power supply: · The drive remains in programming mode or commissioning
mode for 5 minutes. · The end positions may be adjusted, deleted and then
changed.
Adjusting the end positions (4 variations)
Top
Bottom
A
Freely adjustable
Freely adjustable
B
To stop
Freely adjustable
C
To stop
To stop
D
Freely adjustable
To stop
Variation A: Freely adjustable top end position, Freely adjustable bottom end position
Starting from a central position of the blind, press the UP button
with a programmed transmitter until the blind has reached the desired top end position. The drive begins to travel, briefly stops and travels further (for as long as the UP button remains pressed). Corrections are possible using the and buttons.
Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set.
Press the DOWN/CLOSED button again until the blind has
reached the desired end position. The drive begins to travel, briefly stops and travels further (for as long as the DOWN/CLOSED remains pressed). Corrections are possible using the and buttons.
Press the UP button until the drive stops automatically.
The lower end position has been set.
Adjustment of the Variation A end position is complete.
Variation B: Top end position to the stop, Freely adjustable bottom end position
Starting from a central position of the blind, press the UP button
with a programmed transmitter until the blind has reached the top end position (travels to the top stop). The drive begins to travel, briefly stops and travels further (for as long as the UP button remains pressed). The drive switches off automatically when the upper limit stop is reached. Activating the top release function (optional): While pressing and holding the UP button, press the DOWN/ CLOSED button (simultaneously) until the blind stops. The top release function is activated.
Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set.
Press the DOWN/CLOSED button again until the blind has
reached the desired end position. The drive begins to travel, briefly stops and travels further (for as long as the button remains pressed). Corrections are possible using the and buttons.
Press the UP button until the drive stops automatically.
Adjustment of the Variation B end position is complete.
Variation C: Top end position to the stop, Bottom end position to the stop
Starting from a central position of the blind, press the UP button
with a programmed transmitter until the blind has reached the top end position (travels to the top stop). The drive begins to travel, briefly stops and travels further (for as long as the UP button remains pressed). The drive switches off automatically when the upper limit stop is reached. Activating the top release function (optional): While pressing and holding the UP button, press the DOWN/ CLOSED button (simultaneously) until the blind stops. The top release function is activated.
Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set.
Press the DOWN/CLOSED button again until the blind has
reached the desired end position (travels to the lower stop). The drive begins to travel, briefly stops and travels further (for as long as the DOWN/CLOSED remains pressed). The drive switches off automatically when the lower limit stop is reached. Activating the lower release function (optional): While pressing and holding the DOWN/CLOSED button, press the UP button (simultaneously) until the blind stops. The lower release function is activated.
Press the UP button until the drive stops automatically.
The lower end position has been set.
Adjustment of the Variation C end position is complete.
Variation D: Freely adjustable top end position, Bottom end position to the stop
Starting from a central position of the blind, press the UP button
with a programmed transmitter until the blind has reached the desired top end position. The drive begins to travel, briefly stops and travels further (for as long as the UP button remains pressed). Corrections are possible using the and buttons.
Press the DOWN/CLOSED button until the drive stops
automatically. The upper end position has been set.
Press the DOWN/CLOSED button again until the blind has
reached the desired end position (travels to the bottom stop). The drive begins to travel, briefly stops and travels further (for as long as the DOWN/CLOSED remains pressed). The drive switches off automatically when the lower limit stop is reached. Activating the lower release function (optional): While pressing and holding the DOWN/CLOSED button, press the UP button (simultaneously) until the blind stops. The lower release function is activated.
Press the UP button until the drive stops automatically.
The lower end position has been set.
Adjustment of the Variation D end position is complete.
Changing / Deleting the end positions
Starting from a central position of the blind, press the UP and
DOWN/CLOSED simultaneously with a programmed transmitter until the drive briefly travels up and down.
The adjusted end positions have been deleted. The end positions may be readjusted.
SunTop L-868 DC Assembly instructions
Technical data and dimensions
The technical data specified are subject to tolerance factors (according to applicable standards).
Size / Type
SunTop L40 -868 DC
Rated voltage [V]
12 (DC)
Rated torque Nm
40
Rated speed (rpm)
12
Rated current [A]
10
Rated power consumption [W]
120
Shaft diameter
63
Protection class (IP)
44
Limit switch range (revolutions) 40
Operating time (min S2)
10
Length C [mm]
542
Length D [mm]
525
Length E [mm]
16
Weight [kg]
3.78
Ambient operating temperature [°C] Conformity
-20 … 60 C D
Protection class III
O 55
Plug-in connection cable [m]
Item number
E= 14
3.0 365200001
Circuit diagram · Radio mode
C D
Problem
Possible cause
Remedial action
Radio programming mode does not start
· Faulty connection
· Timer frame already expired (5 min)
· Radio transmitter has no battery
· Check connection
· Briefly interrupt the power supply
· Check the radio transmitter (LED must be illuminated)
Radio transmitter not in programming mode
· Button for UP or DOWN/CLOSED pressed too late. Note time frame (1 s)
· Transmitter is already programmed
· Restart radio programming mode
· Press the STOP button
Drive is not reacting to a double click on DOWN/ CLOSED or a double click on DOWN on the radio transmitter
· Timer frame after voltage break already expired (5 min)
· Transmitter is not programmed
· Briefly interrupt the power supply
· Program the transmitter
Drive is no longer · Energy unit is not
responding
charged
· Charge energy unit
Drive stops after short time
· End position is not saved
· Stiff blind
Drive stops during travel
· End positions are not set
· Drive is in setting
33 mode
Drive does not accept programmed end positions
· Random travel
· Travel to end position / limit stop too short
55
· Set second end position
· Check the smooth running of the blind
· Set end positions
· Delete end positions, re-program end positions
· Drive performs travel movements until STOP is pressed on a programmed transmitter
55
O 55
E= 14
EU Conformity
elero hereby de3c3lares that this product is in compliance with
the essential requirements and other relevant provisions of European directives that are applicable in Europe. A declaration of conformity is available at the website www.elero.com/downloads-service .
Manufacturer’s address
Service
elero GmbH
If malfunctions have occurred or the
73278 Schlierbach device has been damaged despite
GERMANY
proper handling, contact your contrac-
www.elero.de
tor or dealer.
