DESK-GM48BG Gaming Desk with RGB Lighting
Product Information:
The Black 48 x 24 Gaming Desk with RGB Lighting is a sturdy and
spacious desk designed for gamers. The desk comes with a
remote-controlled RGB lighting system that can be customized to
match your gaming setup. The desk is made of high-quality materials
that ensure durability and stability. The desk has a weight
capacity of 220lbs (100kg) and comes with a cable cover, cup
holder, hook, and cable clips to keep your gaming setup organized
and clutter-free.
Product Usage Instructions:
- Unpack all the components of the desk and ensure that you have
all the necessary tools. - Place the Desktop (A) upside down on a flat surface and align
the Left Leg (B) and Right Leg (C) over the mounting holes in the
Desktop (A). Secure using M6x16 Screws (S-C) and Allen Wrench
(T-A).
- Mount the Left Crossbar (D) to Left Leg (B) and Right Crossbar
(E) to Right Leg (C), and secure the other end to Desktop (A) using
M6x16 Screws (S-C) and Allen Wrench (T-A).
- Stick Cable Clips (S-D) along the backside of the desk in
desired locations. Mount Hook (F) and Cup Holder (G) to predrilled
holes on either side of Desktop (A) using ST4.2×14 Screws (S-B) and
a Phillips screwdriver.
- Insert Power Cable (I) into Desktop (A).
- Mount Cable Cover (H) to Desktop (A) using ST3.5×20 Screws
(S-A) and a Phillips screwdriver. Connect Power Cable (I) to USB
wall charger, or other device. NOTE: Power Cable (I) can be routed
through either slot on Cable Cover (H).
- Peel and stick Magnet (S-E) to the back of Remote (J) and
secure it to the desk frame assembly. If necessary, the foot pads
can be adjusted to level the desk assembly.
CAUTION: Do not exceed the weight capacity of the desk, as it
may result in serious injury.
If you have any questions or concerns about the product, feel
free to contact the VIVO support team. The support team is
available Monday to Friday from 7:00am-7:00pm CST and can be
reached via phone, email, or live chat.
Black 48″ x 24″ Gaming Desk with RGB Lighting
Instruction Manual
SKU: DESK-GM48BG
Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-gm48bg GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
www.vivo-us.com Chat live with an agent!
309-278-5303
WARNING!
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect assembly, or inappropriate use.
WARNING: CHOKING HAZARD
SMALL PARTS – NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
PACKAGE CONTENTS
A (x1) Desktop
B (x1) Left Leg
C (x1) Right Leg
D (x1) Left Crossbar
E (x1) Right Crossbar
F (x1) Hook
G (x1) Cup Holder
H (x1) Cable Cover
I (x1) Power Cable
J (x1) Remote
S-A (x4) ST3.5×20 Screw
S-B (x5) ST4.2×14 Screw
S-C (x16) M6x16 Screw
S-D (x6) Cable Clip
S-E (x1) Magnet
T-A (x1) Allen Wrench
TOOLS NEEDED
Phillips Screwdriver
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
220lbs (100kg)
2
ASSEMBLY STEPS
STEP 1
Place Desktop (A) upside down on a flat surface and place Left Leg (B) and Right Leg (C) over mounting holes in Desktop (A). Secure using M6x16 Screws (S-C) and Allen Wrench (T-A).
C B
S-C A
T-A
3
STEP 2
Mount Left Crossbar (D) to Left Leg (B) and Right Crossbar (E) to Right Leg (C), and secure the other end to Desktop (A) using M6x16 Screws (S-C) and Allen Wrench (T-A).
B D C A E
T-A S-C
D
4
STEP 3
Stick Cable Clips (S-D) along the backside of the desk in desired locations. Mount Hook (F) and Cup Holder (G) to predrilled holes on eith side of Desktop (A) using ST4.2×14 Screws (S-B) and a phillips screwdriver.
S-D G
A F
S-B
STEP 4
Insert Power Cable (I) into Desktop (A). A
I
5
STEP 5
Mount Cable Cover (H) to Desktop (A) using ST3.5×20 Screws (S-A) and a phillips screwdriver. Connect Power Cable (I) to USB wall charger, or other device. NOTE: Power Cable (I) can be routed through either slot on Cable Cover (H).
I
3
A S-A
H
6
STEP 6
Peel and stick Magnet (S-E) to the back of Remote (J) and secure to desk frame assembly. If necessary, the foot pads can be adjusted to level the desk assembly.
J S-E
3
7
