6FM12 12Volt 12Ah General Series Battery
Product Information
The General Series Battery is a 12V 12Ah sealed lead-acid
battery. It is designed for various applications and features a
floating design life of 5 years at 25°C (77°F). The battery has a
nominal voltage of 12V and a rated capacity of 12Ah (20-hour rate).
It weighs approximately 3.30kg and has an internal resistance of
17mΩ when fully charged.
General Features
- Construction: Sealed Lead-Acid
- Battery Model: 6FM12
- Cells Per Battery: 6
- Dimension (L x W x H): 151mm x 98mm x 94mm
- Approx Weight: 3.30kg
Specification
- Capacity @ 25°C: 12Ah (20 Hour Rate)
- Capacity Affected by Temp (20 Hour Rate): 102% at 40°C (104°F),
91% after 3 months storage, 82% after 6 months storage, 64% after
12 months storage - Self Discharge @ 25°C: 100% after full charge, 85% after 3
months storage, 65% after 6 months storage - Max. Discharge Current: 180A (5s)
- Floating Design Life @ 25°C: 5 years
Product Usage Instructions
Caution: – Avoid short circuit – Do not charge
in sealed container – Keep sparks, flame away
The battery should be charged using a constant voltage charge
method. For cycle use, the charging voltage should be maintained
between 14.5V and 14.9V. For standby use, the charging voltage
should be maintained between 13.6V and 13.8V. The initial charging
current should be less than 3.6A.
When discharging the battery, refer to the discharge
characteristic curve provided in the user manual to determine the
expected discharge time at different discharge rates.
The battery’s performance and lifespan are affected by
temperature. The relationship between charging voltage and
temperature is provided in the manual. It is recommended to operate
the battery within the specified temperature range to optimize its
performance.
The cycle service life of the battery is influenced by the depth
of discharge (DOD). The user manual provides a graph showing the
number of cycles the battery can withstand at different DOD
levels.
For further assistance or technical support, please contact the
National Sales Centre at 010 202 3400 or the Technical Support at
010 202 3500.
For more information, visit www.championpower.cn or www.acdc.co.za.
General Series Battery
6FM12/12Volt 12Ah
General Series VRLA batteries are designed with AGM(Absorbent extra power output for common power backup system. General SeriesBatteries are the general purpose batteries with 5 years floating design life at 25°C. Glass Mat) technology,High performance plates and electrolyte togive
Application
· Emergency Power System · Communication equipment · Telecommunication systems · Uninterruptible power supplies · Electric toy car and wheelchairs, etc
· Power tools · Alarm system · Marine equipment · Medical equipment · Fire and Security System
General Features
· Heavy Duty Grid · Mechanized assembly · Non-spillable construction · High Reliability and Stability · Sealed and Maintenance-free · Long Life and low self-discharge design
Construction
· Positive……..Lead dioxide
· Negative……..Lead
· Electrolyte……..Sulfuric acid
· Safety Valve……..EPDR
· Separator……..Fiber glass
· Terminal……..Copper
· Container……..ABS(UL94-HB) / Flame Retardant ABS (UL94-V0)
Specification
Battery Model
Dimension Approx Weight Internal Resistance Max.discharge current Floating design life @ 25 (77 ) Capacity @ 25 (77 )
Capacity affected by Temp(20 HR)
Self Discharge @ 25 (77 )
Charge method @ 25 (77 )
Nominal Voltage Rated capacity (20Hour rate)
Cells Per battery Length 151mm
20Hour rate(0.6A/10.5V) 12Ah
40 (104 ) 102%
After 3 months storage 91%
Cycle Use Float Use
12V
12Ah
6
Width
Height
Total Height
98mm
94mm
100mm
3.30Kg
Full charged at 25 (77 ): Approx 17m
180A(5s)
5 years
10Hour rate(1.08A/10.8V) 5Hour rate(1.73A/10.8V)
1Hour rate(4.62A/10.5V)
10.8Ah
8.67Ah
4.62Ah
25 (77 )
0 (32 )
-15 (5 )
100%
85%
65%
After 6 months storage
After 12 months storage
82%
64%
14.5-14.9V (Initial charging current less than 3.6 A)
13.6-13.8V
Outer Dimension(mm)
Terminal Type(mm)
151
98
94 100
0.8 4.75
0.8 6.35
6FM12
12Volt 12Ah
Sealed Lead-Acid Battery
Caution: -Avoid short circuit -Do not charge in sealed container -Keep sparks,flame away
Constant voltage charge -Cycle use:14.5-14.9V -Standby use:13.6-13.8V -Initial current:3.6A
www.championpower.cn
3.2 6.35
3.4 7.85
Constant Current(Amp) and Constant Power(Watt) Discharge Table at 25°C (77°F)
F.V / TIME
A 9.60V
W
A 10.20V
W
A 10.50V
W
A 10.80V
W
A 11.10V
W
5min 43.20 457.92 39.60 431.64 36.73 403.98 33.44 367.84 28.92 326.80
10min 28.20 299.48 26.50 294.15 25.32 284.85 24.20 275.88 22.80 263.34
15min 21.00 224.70 19.30 215.19 18.00 203.40 16.80 192.36 15.60 180.96
30min 13.80 149.04 13.10 147.38 12.70 144.78 12.12 139.99 11.28 131.98
1h 7.20 78.48 7.44 83.70 7.20 82.08 6.96 80.39 6.60 77.22
2h 4.20 45.78 4.03 45.54 3.95 45.23 3.85 44.47 3.75 43.88
3h 3.12 34.32 3.06 34.58 3.00 34.35 2.94 34.10 2.82 33.14
4h 2.48 27.28 2.40 27.24 2.28 26.22 2.24 26.10 2.20 25.96
5h 2.11 23.16 2.06 23.44 2.04 23.46 1.95 22.72 1.87 22.01
8h 1.39 15.43 1.37 15.53 1.35 15.53 1.31 15.32 1.28 15.10
10h 1.14 12.65 1.12 12.66 1.10 12.70 1.07 12.52 1.05 12.39
20h 0.61 6.89 0.61 6.87 0.60 6.90 0.59 6.82 0.57 6.73
National Sales Centre – 010 202 3400 | Technical – 010 202 3500
www.acdc.co.za
THINK ELECTRICAL
General Series Battery
6FM12/12Volt 12Ah
Discharge characterstic Curve
Voltage (V)
2.16/6.48/13.0
1.85/5.55/11.1 1.80/5.40/10.8 1.75/5.25/10.5 1.70/5.10/10.2 1.65/4.95/9.90 1.60/4.80/9.60
0.25C 0.20C 0.17C 0.12C 0.1C
0.55C 0.40C
0.05C
3C 2C 1C
7min 15min 27min 1h 2h 3h 4h
Discharge time
5h 8h 10h 20h
Relationship between charging voltage and temperature
(V/12V) (V/8V) (V/6V) (V/4V) (V/CE)
15.6 10.4 7.8 5.2 2.6 15.0 10.0 7.5 5.0 2.5 14.4 9.6 7.2 4.8 2.4 13.8 9.2 6.9 4.6 2.3 13.2 8.8 6.6 4.4 2.2
-10
Cycle Use Standby Use
0
10
20
30
40
50 60
Ambient temperature(¥)
Temperature effects on float life
2.30V/Cell 5
1
Life (years)
0
10
20
30
40
50
Temperatura(¥)
Life characteristics of standby use
120 100
80 60 40 20
0
Testing conditions: floating voltage: 2.27 to 2.30V /cell Ambient temperature: 25 ¥ ()
1
2
3
Life (years)
Capacity (%)
Capacity(%)
Cycle service life in relation to depth of discharge
120
100
80
60
100%DOD
50%DOD
40
30%DOD
20
0
200
400
600
800 1000 1200 1400
Number of cycles (cycles)
Constant voltage charging characteristic (0.25CA, at 25°C)
Charged Volume Current Voltage
(%) (XCA) (V) 140
120 0.25 15.0
100 0.20 14.0 80 60 0.15 13.0 40 0.10 12.0
Charged Volume Charge Voltage
20 0.05 11.0
Charging Current
0
0
0 2 4 6 8 10 12 14 16 18 20
Charging time (hours)
Capacity (%)
Self-discharge characteristic
11 0
100
90
80
70
60
50
40
0
2
4
6
8
10 12 14 16 18 20
Storage time: months
Charge Volume (%) Charge Currient (CA)
Charge Voltage (V)
Charge characterstic for standby use
15 7.5 5.0 14 7.0 4.7 13 6.5 4.3 12 6.0 4.0 11 5.5 3.7
Charge Volume
Charge Voltage
Discharge 100% (0.05 CA*20h) 50% (0.05 CA*10h)
Charge Charge Voltaje 2.275V /cell Charge Current 0.1 CA
Temperature 25
120 100 80 60 40
10 5.0 3.3
20
Charge Current
9 4.5 3.0
0
0 2 4 6 8 10 12 14 16 18 20 24 28
Charge Time (h)
0.24 0.20 0.16 0.12 0.08 0.04
0
National Sales Centre – 010 202 3400 | Technical – 010 202 3500
www.acdc.co.za
THINK ELECTRICAL
