EVH4S07N2 Home Charging Station
Product Information
Capture the growing EV charging market with a simple and
easy-to-install residential EV charging solution. EVlink Home is a
charger that protects the asset (car) and user, ensures the right
charge in residential settings, minimizes peak impacts, and avoids
power overruns – all at an affordable price. It allows for
convenient vehicle charging at home without impacting power
availability. Please note that this EV charger does not contain any
smart home app connectivity options.
Solution Recommendation Part Number:
- Single phase, 7.4kW Socket (no charging cable): EVH4S07N2
DOM19807 EVA1HPC1 - Earth Leakage Circuit Breaker, Domae, 1P+N – C, 40A, 30mA,
6000A: 1 - 1 Phase Universal Peak Controller (optional)
- Three phase, 11kW Socket (no charging cable): EVH4S11N2
A9F54420 A9V51463 EVA1HPC3 - Acti9 iC60N 4P 20A C Miniature Circuit Breaker: 1
- Acti9 Vigi iC60 – earth leakage add-on block – 4P – 63A Circuit
– 30mA – A type: 1 - 3 Phase Universal Peak Controller (optional)
Attached charging cable:
- EVlink Home 1P Attached cable 5m 7.4 Kw 32A – with RDC-DD
Filter: EVA1HPC1 - EVlink Home 3P Attached cable 5m 11 kW 16A – with RDC-DD
Filter: EVA1HPC3
Home anti tripping system is a power load management system that
continuously adapts the power delivered by the charger to the EV
according to the power available at home. The power availability is
calculated by the Home Anti-tripping system by comparing the
utility power limit and the home consumption gathered by a current
transformer positioned on the bottom of the main circuit breaker.
The communication between the Home Anti-tripping system and EVlink
Home charger is done with power line communication, so no need to
add communication cable.
For more information, talk to your local Schneider Electric
representative, electrical wholesaler, or visit our website:
pdl.co.nz/ev
Product Usage Instructions
- Choose the appropriate EVlink Home charger based on your power
requirements:
- For single-phase charging with a socket (no charging cable),
use the EVH4S07N2 model. - For three-phase charging with a socket (no charging cable), use
the EVH4S11N2 model.
Controller or 3 Phase Universal Peak Controller for peak impact
minimization.
1P+N – C, 40A, 30mA, 6000A) for circuit protection.
model:
- For single-phase charging with an attached cable, use the
EVlink Home 1P Attached cable 5m 7.4 Kw 32A – with RDC-DD Filter
(EVA1HPC1). - For three-phase charging with an attached cable, use the EVlink
Home 3P Attached cable 5m 11 kW 16A – with RDC-DD Filter
(EVA1HPC3).
power load management:
- Position a current transformer at the bottom of the main
circuit breaker to gather home consumption data. - The Home Anti-tripping system will calculate power availability
by comparing utility power limit and home consumption. - No additional communication cable is required as the
communication between the Home Anti-tripping system and EVlink Home
charger is done through power line communication.
the user manual or visit our website: pdl.co.nz/ev.
Capture the growing EV charging market with a simple and easy-to-install residential EV charging solution
EVlinkTM Home
Looking to gear your business up to maximise the growing New Zealand EV residential charging market? EVlink Home is a simple and easy-to-install charger that protects the asset (car) and user, ensures the right charge in residential settings, minimises peak impacts, and avoids power overruns – all at an affordable price. It also allows a convenient charge of the vehicle at home without impacting power availability.
Please be aware this EV charger does not contain any smart home app connectivity options.
pdl.co.nz/ev
Key features: · In-built RDC-DD · 1Phase: 7.4kW | 3Phase: 11kW options · Wall mounted · Attached cable 5m or Type 2 socket · Compatible with home anti-tripping system
(Peak Controller) · CTs are included with Peak Controllers · Certification IEC 61851-1 Ed. 3.0 · RCM GMA-513376
Solution Recommendation Part Number
Single phase, 7.4kW
Socket (no charging cable)
EVH4S07N2 DOM19807 EVA1HPC1
Quantity Product Name
1
EVlink Home 1P T2 7,4 Kw 32A – with RDC-DD Filter
1
Earth Leakage Circuit Breaker, Domae, 1P+N – C, 40A, 30mA, 6000A
1
1 Phase Universal Peak Controller (optional)
Type
Charger
Circuit protection
Anti-tripping device
Single phase, 7.4kW
EVH4S07NC
Attached charging DOM19807 cable
EVA1HPC1
1
EVlink Home 1P Attached cable 5m 7,4 Kw 32A – with RDC-DD Filter
Charger
Earth Leakage Circuit Breaker, Domae, 1P+N – C, 40A, Circuit
1
30mA, 6000A
protection
1
1 Phase Universal Peak Controller (optional)
Anti-tripping device
Three phase, 11kW
Socket (no charging cable)
EVH4S11N2 A9F54420 A9V51463 EVA1HPC3
1
EVlink Home 3P T2 11 kW 16A – with RDC-DD Filter
Charger
1
Acti9 iC60N 4P 20A C Miniature Circuit Breaker
Circuit protection
1
Acti9 Vigi iC60 – earth leakage add-on block – 4P – 63A Circuit
– 30mA – A type
protection
1
3 Phase Universal Peak Controller (optional)
Anti-tripping device
Three phase, 11kW
EVH4S11NC
Attached charging A9F54420 cable
A9V51463
EVA1HPC3
1
EVlink Home 3P Attached cable 5m 11 kW 16A – with
Charger
RDC-DD Filter
1
Acti9 iC60N 4P 20A C Miniature Circuit Breaker
Circuit protection
1
Acti9 Vigi iC60 – earth leakage add-on block – 4P – 63A Circuit
– 30mA – A type
protection
1
3 Phases Universal Peak Controller (optional)
Anti-tripping device
EVlink Anti-tripping system technical specifications
Home anti tripping system is a power load management system to adapt continuously the power delivered by the charger to the EV according to power available at home.
The power availability is calculated by the Home Anti-tripping system by comparing the utility power limit and the home consumption gathered by a current transformer positioned on the bottom of the main circuit breaker.
The communication between the Home Anti-tripping system and EVlink Home charger is done with power line communication, so no need to add communication cable.
For more information talk to your local Schneider Electric representative, electrical wholesaler or visit our website.
pdl.co.nz/ev
