Hyena E-bike Bp-b250 Leader Fox Sandy Lady Instruction Manual

BP-B250 Leader Fox Sandy Lady

Product Information

Product Usage Instructions

Parts Description

Pin Definition

Charge (3 pins female, connect to charging
socket)

Motor (9 pins female, connect to motor)

Sensor (6 pins female, connect to torque
sensor)

Rear Light (2 pins female, connect to rear
light)

Front Light (2 terminals, connect to front
light)

HMI (6 pins female, connect to HMI)

Charging Socket Output (3 pins male, connect to charge
connector of battery)

Charging Socket Input (6 pins female, connect to battery
charger)

Technical Data

Product Manual BP-B250
Original Instruction
Version 221110 Copyright © 2022 HYENA INC. All Right Reserved.

Table of Contents
Introduction Product Features
Product Description ………………………………………………………………………. 1 Parts Description ………………………………………………………………………….. 1 Product Dimension ……………………………………………………………………….. 1 Pin Definition…………………………………………………………………………………3 Technical Data Battery …………………………………………………………………………………………7 Integrated Controller ………………………………………………………………………8 Mounting Tool List …………………………………………………………………………………….. 10 Accessory List……………………………………………………………………………..10 Mounting Instructions……………………………………………………………………10 Operation Operation Instructions…………………………………………………………………..12 Charging Instructions …………………………………………………………………… 13 Safety Instructions Important Notice …………………………………………………………………………. 14 Grounding Instructions………………………………………………………………….14 Moving and Storage Instructions …………………………………………………… 14 Maintenance ………………………………………………………………………………. 14 Product Warning Label ………………………………………………………………… 15

Introduction
This manual is intended primarily for the trained technician to install, disassemble, or maintain the Hyena e-bike system only. Please read all the safety warnings and instructions carefully. Failure to follow the warnings and instructions may result in death or severe injuries. Save this manual for future reference.

Product Features
Product Description BP-B250 in-tube battery is the ideal companion for a slim outlook e-bike. It features a lightweight and ultraslender to keep an elegance bike outlook.
Parts Description

C C

D F

C A B

G E

Item A B C D

Description Front light connector HMI connector Battery fixation gasket (optional) Rear light connector

H
Item Description E Charging socket connector F Sensor connector G Motor connector H Charging socket

HYENA E-BIKE SYSTEMS

1

Product Dimension

Unit: mm

A. Charging Socket Cable Cable OD: Ø 4mm Cable Length: 100±10mm Connector: Ø 9.5mm, L34mm
B. Sensor Cable Cable OD: Ø 4mm Cable Length: 185±20mm Connector: Ø 9.5mm, L34mm
C. Rear Light Cable Cable OD: Ø 4mm Cable Length: 185±20mm Connector: Ø 9.5mm, L34mm

D. Motor Cable Cable OD: Ø 6.3mm Cable Length: 400±10mm Connector: Ø 13mm, L47mm
E. HMI Cable Cable OD: Ø 4mm Cable Length: 265±20mm Connector: Ø 9.5mm, L34mm
F. Front Light Cable Cable OD: Ø 4mm Cable Length: 415±20mm

HYENA E-BIKE SYSTEMS

2

Pin Definition
Pin Name 1 Power 2 NTC 3 Ground
Pin Name 1 W 2 Speed 3 U 4 +5V 5 GND 6 Hall W 7 V 8 Hall U 9 Hall V

Charge
(3 pins female, connect to charging socket)

1

2

3

Direction Input Output Input

Description Charge NTC Ground

Motor

(9 pins female, connect to motor)

1

5

2

6

3

7

8 4
9

Direction Output Input Output Output Output Input Output Input Input

Description Phase W Speed signal, TTL input Phase U 5V motor power 5V motor ground Hall signal of phase W Phase V Hall signal of phase U Hall signal of phase V

Remark Remark

HYENA E-BIKE SYSTEMS

3

Pin Name 1 Cadence Cnk2 2 Null 3 Cadence Cnk1 4 V+ 5 GND 6 Torque

Direction Input Input Input Output Output Input

Sensor
(6 pins female, connect to torque sensor)

1

4

5 2

6

3

Description Cadence signal N/A Cadence signal 5V sensor power 5V sensor ground Torque signal. Analog signal.

Rear Light
(2 pins female, connect to rear light)

1

2

Pin Name 1 RL+ 2 RL-
Pin Name 1 FL+ 2 FL-

Direction Output Input

Description 6V rear light power 6V rear light ground

Direction Output Input

Front Light
(2 terminals, connect to front light)
1 2
Description 6V front light power 6V front light ground

Remark
Remark
Remark Red Black

HYENA E-BIKE SYSTEMS

4

Pin Name 1 CAN L 2 Null 3 CAN H 4 DEN/HMI 5 GND 6 VCC+

Direction Bidirectional Input Bidirectional Input Input Output

HMI
(6 pins female, connect to HMI)

1

4

5 2

6

3

Description CAN Low N/A CAN High Active low, used to wake up from sleep mode 12V HMI ground 12V HMI power

Remark

HYENA E-BIKE SYSTEMS

5

Pin Name 1 NTC 2 Power 3 Ground

Charging Socket Output
(3 pins male, connect to charge connector of battery)

1

2

3

Direction Input Output Output

Description NTC Charge Ground

Charging Socket Input
(6 pins female, connect to battery charger)

6

5

1

4

2

3

Pin Name 1 Ground 2 NTC 3 Power 4 Null 5 Null 6 Null

Direction Input Output Input Input Bidirectional Bidirectional

Description Ground NTC Charge N/A N/A N/A

Remark Remark

HYENA E-BIKE SYSTEMS

6

Technical Data
Function
Rated voltage Typical capacity Energy content Cut off voltage Charging mode Charge voltage Charge current Continuous discharge current Weight Waterproof level
Characteristic
Protocol Cell type Serial-parallel Operating temperature
Storage temperature
Charging temperature Charging time approx.
Mounting Parameter
Mounting Position Dimension
Certification
EN 15194:2017 CE UN38.3

Battery
36V 7Ah 252Wh < 28.0V±0.3V CC-CV (constant voltage with limited current) 42.0V±0.3V 4A±0.2A 15A 1.45 kg IPX5

Support 2A Hyena standard charger

CAN2.0A

18650

10S2P
-10 to +60 (14 to 140) 80%RH -20 to +50 (-4 to 122) 80%RH (<1 month) -20 to +40 (-4 to 104) 80%RH (<3 month) -20 to +20 (-4 to 68) 80%RH (<12 month) 0 to +45 (32 to 113) 80%RH

Percentage of recoverable capacity = 80%

2A charger – 3h30min

In frame L470, W50, H47.5 mm

w/o cable

Yes Yes Yes

HYENA E-BIKE SYSTEMS

7

Characteristic
Rated power Rated voltage Operating voltage Maximum current
Quiescent current
Operating temperature Storage temperature Hi-Pot Brake sensor Front light Rear light
Certification
EN 15194:2017 CE RoHS 2.0
Protection
Short circuit protection Hall defect protection Over temperature protection
Lock rotor protection (Pedal)
Lock rotor protection (Motion) Communication loss protection Under voltage protection Over voltage protection

Integrated Controller
250W 36V 25 to 45Vdc 12A 3min
< 1mA
-10 to +60 80%RH -20 to +50 80%RH (<1 month) No permanent damage under 500V 60 seconds N/A 6V up to 2.4W 6V up to 0.6W

Corresponding battery output at most 12A.
Measure condition: a. System off. b. Battery, HMI, Display, Controller, Motor and Sensor are connected well. c. Remove all smart parts.

Yes Yes Yes

Each pin connecting to ground pin introduces no permanent damage.
No hall change when motor spin. Temperature > 100 for 1.99 seconds continuously Current > 0.85*Current Limit A and motor speed < 25 km/hr for 2.9 seconds (not continuously) Current > 8 A and motor speed < 30 km/hr for 2.9 seconds (not continuously)
No HMI communication for 2 seconds
Controller stops assist when voltage < 28.0V for 10 seconds Controller stops assist when voltage > 45.0V for 10 seconds

Recovery temperature is set below 65.

HYENA E-BIKE SYSTEMS

8

Software Standard Function
Motor control Motor phase Battery protocol Parameter table Error code table Walk assistance Riding support level
Current limit
Speed limit Auto sleep
Assist priority
Low battery capacity Throttle

Sinusoidal Motor Control
120
Hyena proprietary protocol
Parameter 2.0
Hyena proprietary error code table
Up to 4 km/hr
3 segments Level 1: 08±1 A Level 2: 10±1 A Level 3: 12±1 A OFF: N/A 25 km/hr Automatically sleep when the system remains idle for 6 minutes. When pedal assist and walk assist occur simultaneously, output assist according to pedal input. RSOC < 4% for 5 seconds
Throttle

With Hyena HMI only Optional

HYENA E-BIKE SYSTEMS

9

Mounting

Tool List
Phillips screwdriver
Cable lead wire

Accessory List
Plastic gasket Phillips screw Charging socket with cable Countersunk Phillips screw

Optional depends on the frame type M5x0.8P (length depends on frame thickness)
M3x0.5P (length depends on frame thickness)

3 pcs 3 pcs 1 pc 4 pcs

Mounting Instructions · Use the proper bicycle tools during the installation or removal process. · Carefully install this product is necessary, do not strike it with any tool such as a hammer or wrenches. · CAUTION! Please strictly follow these steps for assembly; otherwise, an incorrect assembly may cause permanent damage. · NOTE! The bike image in the manual may be different from the actual bike, but it will be enough to help you understand related instructions.

Battery Installation

STEP 1

STEP 2

Insert the battery through the bike frame.

Pull out the component cables and fasten the fixation screws with torque to 5Nm.

HYENA E-BIKE SYSTEMS

10

STEP 1

Charging Socket Installation
STEP 2

Insert the charging socket. Make sure the dustproof plug end toward the seat tube.
STEP 3

Fasten 4 pcs of screws.

Connect the battery and charging socket connectors. Cable Connecting
HYENA E-BIKE SYSTEMS

Rear Light Sensor Motor Charging Socket
HMI Front Light
11

Operation
Operation Instructions WARNING! Only charge the battery by following all safety descriptions. Also, please read and follow the instructions for using the battery charger.
CAUTION! The battery packs are partially charged and set to sleep mode before they are shipped; in order to wake up the battery and ensure it has full and sufficient power, please charge your battery pack before using it for the first time.
· All Hyena chargers only use genuine Hyena batteries and battery packs, or battery packs approved for use with your e-bike by the manufacturer, and purchase only from reliable sources.
· Use of uncertified battery packs may result in death or severe injuries.
· Charging is restricted to certified Hyena lithium battery packs. The battery pack voltage must comply with the charger output voltage; otherwise, it might result in risks of explosions or fires.
CAUTION! Charge the battery indoors to avoid exposure to rain or wind. Do not use outdoors or in environments with high humidity.
WARNING! Be sure to hold the power plug steady instead of holding the cord when connecting or disconnecting from the electrical outlet. Failure to do so may cause a fire or electric shock.
· If the following symptoms are observed, stop using the device and contact the place of purchase. A fire or electric shock may be caused: – If heat or acrid-smelling smoke is coming out from the power plug. – There may be a bad connection inside the power plug.
· Do NOT place the battery charger on the floor or in other dusty places when using it.
· Place the battery charger on a stable surface such as a table when using it.
· Do NOT place any objects on the battery charger or cable. Please do NOT place a cover on it either.
· Do NOT apply excessive tension to the cables and charging plugs.
· Do NOT touch the metallic parts of the device or the power plug on the AC adapter or other parts when the charger is wet. Electric shocks may occur.
· Use only a 100-240 V AC electrical outlet, do NOT overload the electrical outlet with appliances beyond its rated capacity.
· If the electrical outlet is overloaded by connecting too many appliances using adapters, overheating may result in a fire.
· Do NOT damage the power cord or power plug. (Do

NOT damage, process, forcibly bend, twist or pull them, bring them near hot objects, place heavy objects on them or bundle them tightly together.) If they are used while damaged, fire, electric shocks, or short-circuits may occur. · Do NOT use the battery charger with commerciallyavailable electrical transformers designed for overseas use (travel converters). They may damage the battery charger. · When charging the battery, do NOT move the bicycle. The battery charger’s power plug may come loose and not be fully inserted into the electrical outlet, resulting in a fire risk. · When charging the battery, be careful not to trip over the charger cord. This may lead to injury or cause the bicycle to fall over, damaging the components.
CAUTION! According to ECP, when the battery is in overcharged/over-discharged conditions, the battery will automatically disconnect the circuit for safety protection.

HYENA E-BIKE SYSTEMS

12

Charging Instructions · Check your battery pack before using it for the first time.
First, you must turn on the battery pack; if the charging LED does not light up, it means that this battery pack might be damaged. · Make sure to charge the battery pack fully before using it for the first time. · Do NOT place any items 50cm (19.69 inches) around the battery when charging. Make sure the battery and the charger are on a fireproof surface. · Do NOT leave batteries in the charger for more than 24 hours. Contact your local bicycle dealer for assistance if the charging cannot complete in 24 hours. · The battery pack can be charged under any power mode; interrupting the charging process will not damage the battery pack.
CAUTION! The battery packs are partially charged before they are shipped; in order to ensure that the battery has full and sufficient power, please charge your battery pack fully before using it for the first time.
CAUTION! For battery health and safety reasons, the e-bike battery will automatically turn into sleep mode if its charge is below 70% and has not been used for over 72 hours. Please charge the battery again to wake up the battery.
Charging · Plug the charger’s plug into an outlet (100-240V), using
the appropriate plug for the country’s standards. · Uncover the charging socket on the battery, then
connect the charging plug to the charging socket on the battery.

· The type of socket for charge connector might be different on the different types of batteries. Please refer to the battery instruction.
· If the battery has become empty, charge it as soon as possible. If the battery is left uncharged, it may cause the battery to deteriorate and become unusable.
CAUTION! When possible, you should charge the battery in an area with a smoke detector or ensure someone is taking care of the battery during the charging process.
CAUTION! Do NOT place the battery charger at locations that are easily accessible to children.
Charge the Battery Pack Before and After Storage · When you do not use the battery pack of the e-bike for
extended periods, charging the battery to 30-60% will be the optimum storage condition. · Confirm the charge status again after six months; if the remaining power of the battery pack is less than 30%, charge it again to between 30-60%.
CAUTION! If the battery is stored under the condition of lacking power, the battery pack may be damaged, and the power storage capacity of the battery pack itself will also be affected significantly.

· When charging is complete, disconnect the charging plug from the battery socket.
· Unplug the charger from the wall socket. · Make sure to close the charging port cap after charging.
If foreign matter, such as dirt or dust, adheres to the charging port, there is a risk that the charging plug will not fit into the charging port.

HYENA E-BIKE SYSTEMS

13

Safety Instructions
Instructions Pertaining To A Risk Of Fire,
Electric Shock, Or Injury To Persons
WARNING! When using the BP-B250 e-bike battery, basic precautions should always be followed, including the following: · Read all the instructions before using the product. · To reduce the risk of injury, close supervision is
necessary when the product is used near children. · Do NOT put fingers or hands into the product. · Do NOT use this product if the flexible power cord or
output cable is frayed, has broken insulation, or any other signs of damage. · All the component leads shall use original Hyena components. · This product is not intended to be used at ambient temperatures less than -10°C (14°F) or above ambient temperatures of 60°C (140°F). · Do NOT immerse the product or any e-system component in water. The penetration of water into the charger could cause an electric shock. · Do NOT place the product or any e-system component near fire or heat. · Always turn off the e-bike system and remove the battery before installing, disassembling, or modifying any components on the e-bike.
Important Notice · This product manual is intended primarily for the trained
technician to install, disassemble or maintain the e-bike. · Users not professionally trained for bicycle assembly
should not attempt to install, disassemble or modify the components themselves. · All Hyena e-system manuals and technical documents are accessible online at “www.hyena-ebike.com”. · The term “battery” is used in these instructions to mean all original Hyena e-bike batteries. · Read and observe the safety warnings and directions contained in all the Hyena e-bike system operating instructions and in the operating instructions of your e-bike.
Grounding Instructions · The whole charging behavior must be kept grounded. If it
should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes ordinances.
WARNING! Improper connection of the equipment grounding conductor is able to result in a risk of electric shock. Check with a qualified electrician if you are in doubt as to whether the product is properly grounded. Do NOT modify the plug provided with the product – if it will

not fit the outlet, have a proper outlet installed by a qualified electrician.
Moving and Storage Instructions · When possible, keep the product and all e-system
components in their original package and keep tools or other metal objects away from them while storage and moving. · If you did not keep the original packaging, they can be packed in solid cartons with proper packing materials such as bubble wrap or soft cloth, and label the cartons Fragile. · Do NOT bundle the charger cables. · Do NOT hold the battery charger by the cables when carrying it. · To prevent the cable from being damaged, avoid wrapping it around the main body during storage. · Do NOT store the product at ambient temperatures less than -20°C (-4°F) or above ambient temperatures of 50°C (122°F). For long-term storage temperature, refer to page 7. · Cover the product to prevent sunlight damage if you keep it stored at any place for more than a week. · Store the product on a fireproof surface without contact with water, heat, or sand. · Do NOT place any heavy item on the product or any e-bike system component. · Do NOT place the product or any e-system component in the car trunk for more than one day. · Do NOT load or move the product in the rain whenever possible, and make sure it has no moisture or mildew before loading it. · Do NOT drop the product from more than 30cm (11.81 inches) height. · Periodically check the battery charger and adapter, particularly the cord, plug, and case, for any damage. If the battery charger or adapter is broken, do NOT use it until it has been repaired by the place of purchase or a distributor.
Maintenance · When performing cleaning, disconnect the power plug
from the electrical outlet and the charging plug from the battery. If this is not observed an electric shock may occur. · Do NOT clean the product or any e-system component with any detergent or organic solvent. Only clean the product with a water-dampened soft cloth. · Do NOT clean the product or any e-system component with pressured water.

HYENA E-BIKE SYSTEMS

14

Product Warning Label On the product warning label at the bottom of the charger, you can find simple descriptions of safety warnings in different languages; the content will include the following items: · Please read the user manual before use. · Store the battery in a cool, dry, and safe place with good
air circulation. · Keep the battery out of reach of children. · Keep the battery away from any metal objects and avoid
any mechanical impacts on the battery. · Charge the battery with a certified authentic charger. · Contact certified dealers in case of any malfunction of
the battery. · Do NOT open the battery by yourself or by the non-
certified dealer. · The battery must be recharged at least every three
months to ensure the best performance and longest lifetime while not in use. · Dispose of the used battery according to local ordinances and/or regulations.

Disposal · In accordance with Directive 2012/19/EU and Directive
2006/66/EC respectively, electronic devices that are no longer usable and defective/drained batteries must be collected separately and recycled in an environmentally friendly manner.
This symbol is only valid within the European Union. Follow local regulations when disposing of used batteries. If you are not sure, consult the place of purchase or a bicycle dealer
· The e-system drive unit including, the motor, controller, battery, speed sensor, HMI, accessories, and packaging, should be disposed of in an environmentally correct manner.
· Do NOT dispose of e-bikes and their components with household waste.
SAVE THESE INSTRUCTIONS

HYENA E-BIKE SYSTEMS

15

This page is intended to be blank.

HYENA E-BIKE SYSTEMS

16

This page is intended to be blank.

HYENA E-BIKE SYSTEMS

17

Hyena Inc. Tel: +886 4 23598810 Fax: +886 4 23598610 www.hyena-ebike.com Address: No.25, Jingke N. Rd., Nantun Dist., Taichung City 408, Taiwan (R.O.C.)

HYENA E-BIKE SYSTEMS

18

References

• Hyena E-bike Systems | Comprehensive E-Bike System Solutions
