SN30 2.4g –
– instruction manual
Super Nintendo Entertainment System &
Super Family Computer & Analogue Super Nt
- plug the receiver into your chosen device, blue LED blinks once per cycle
- Press start button on the controller to pair
- blue LEDs on both the controller and receiver become solid when the connection is successful
battery
| status — | LED indicator - |
| low battery mode | red LED blinks |
| battery charging | red LED stays solid |
| battery fully charged | red LED turns off |
- built-in 180 mAh Li-on with 18 hours of playtime
- rechargeable via USB cable with1-2 hour charging time
- The controller turns off in 1 minute with no connection and 15 minutes with connection but no use
Retrieve a lost connection or connect to a new receiver
- Turn on the controller then press and hold the select button for 3 seconds. Blue LED starts to rapidly blink
- Move the controller close to the receiver. Blue LED becomes solid when the connection is successful
support
- Please visit support.8bitdo.com for further information & additional support
