S18XX50X-25-02 ELTs Emergency Locator Transmitters
Product Information
The document provides information about the maintenance and
aftermarket policy for Kannad ELTs (Emergency Locator Transmitters)
manufactured by S.E.D. Beacons. It includes service items,
effective from January 1st, 2018, and cancels previous maintenance
policies.
The document is the property of Safran and should not be copied
or shared without prior written authorization from Safran. It also
states that it does not replace formal maintenance documentation or
training available upon request from S.E.D. Beacons.
The document lists the specific ELT models to which the service
letter applies:
- ATP S1818502-02 S1819502-02
- Kannad 406 S1820502-01/-02 S1820502-04 S1821502-01/-02
S1821502-06 S1822502-01/-02 - Kannad 121 S1824502-01/-02 S1826502-02
- Compact S1840501-01 S1840501-04
- 406 AS / Survival S1823502-01/-02 S1823502-03 S1823502-05
- Integra S1850501-02 S1851501-02 S1852501-02 S1854501-02
- Integra (ER) S1850501-01 S1851501-01 S1852501-01
S1854501-01 - Integra (ER-N) S1850501-03 S1851501-03 S1852501-03
S1854501-03 - Ultima-S S1863501-03 S1863501-13 S1863501-04 S1863501-14
The document also mentions the prerequisites for different
service levels, including installation and commissioning, periodic
inspection, programming center, Kannad approved operator, battery
replacement center, and training requirements.
It provides a list of recommended documents and training
materials for different ELT models, along with additional
post-installation tests that may be required by national
authorities.
The document mentions the availability of level 2 and level 3
test equipment and provides a detailed list upon request.
Lastly, it mentions the existence of Kannad approved repair and
warranty centers for level 3 maintenance.
Product Usage Instructions
To use the Kannad ELTs effectively and ensure proper
maintenance, follow the below instructions:
- Ensure you have the necessary prerequisites for the desired
service level. These include installation and commissioning,
periodic inspection, programming center, Kannad approved operator,
battery replacement center, and appropriate training. - Refer to the installation and operation manual provided for
your specific ELT model. - If required, perform additional post-installation tests as per
your national regulation. - If you have the PR600 Programming Kit (P/N 1201570), utilize
the self-training document included to familiarize yourself with
the ELT programming process. - For periodic inspection, refer to the service letter specific
to your ELT model. The following service letter manuals are
recommended for different ELTs:- Level 2 CMM 25-63-05 (for standard ELTs)
- Level 2 CMM 25-63-07 (for COMPACT ELTs)
- Level 2 CMM 25-63-08 (for INTEGRA ELTs)
- Limited to maintenance Level 3 CMM 25-63-02 (for ATP ELTs)
- If maintenance or repair is required, contact a Kannad approved
repair and warranty center for level 3 service.
By following these instructions, you can ensure the effective
usage and maintenance of your Kannad ELT.
Maintenance / Aftermarket
Policy for Kannad ELTs
May 2023
Service Letter S18XX50X-25-02
Rev.05
Presentation
Reason
This document provides a summary of service items which may be performed on the listed ELTs. Effective 1st of January 2018, the following policy applies to Kannad ELT service and maintenance. This Service Letter cancels SL S182X502-25-02, Maintenance Policy for S182X502-XX ELTs and all previous revisions of SL S18XX50X-25-02, Maintenance Policy for Kannad ELTs.
Disclaimer
This document is not intended to replace formally issued maintenance documentation or training available upon request from S.E.D. Beacons.
2 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
Effectivity
This Service Letter is applicable to the following ELTs manufactured by S.E.D. Beacons
ATP S1818502-02 S1819502-02
Kannad 406 S1820502-01/-02 S1820502-04 S1821502-01/-02 S1821502-06 S1822502-01/-02
Kannad 121 S1824502-01/-02 S1826502-02
Compact S1840501-01 S1840501-04
406 AS / Survival S1823502-01/-02 S1823502-03 S1823502-05
Integra S1850501-02 S1851501-02 S1852501-02 S1854501-02
Integra (ER) S1850501-01 S1851501-01 S1852501-01 S1854501-01
Integra (ER-N) S1850501-03 S1851501-03 S1852501-03 S1854501-03
Ultima-S S1863501-03 S1863501-13 S1863501-04 S1863501-14
3 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
Service Network Structure: Prerequisites
Installation & Commissioning
Prerequisites
Level 1
Periodic Inspection
Programming Center
Kannad Approved Operator
Level 2
Kannad Approved Battery Replacement Center
Yearly subscription fee PR600 Programming Kit (P/N 1201570) with PC and Internet Connection Level 2 test equipment* Level 3 test equipment* Other Optional equipment
Training Part 145 / FAR 145 or equivalent approval Documentation
· 121,5Mh Receiver · COSPAS-SARSAT
beacon tester · SWR meter
Installation / Operation Manual
Additional postinstallation tests may be required by your national authorities: in this case refer to your national regulation.
Recommended
Recommended
Installation / Operation Manual
Service Letter for Periodic Inspection:
· SL S18XX502-25-12 (for standard ELTs & ATP ELTs)
· SL S1840501-25-05 (for COMPACT ELTs & INTEGRA ELTs)
Self-training document included with PR600 Programming kit:
· DOC21053 ELT Programming Training
Level 2 CMM 25-63-05 (for standard ELTs)
Level 2 CMM 25-63-07 (for COMPACT ELTs)
Level 2 CMM 25-63-08 (for INTEGRA ELTs)
Limited to maintenance Level 3 CMM 25-63-02 (for ATP ELTs)
Recommended
Level 2 CMM 25-63-05 (for standard ELTs) Level 2 CMM 25-63-07 (for COMPACT ELTs) Level 2 CMM 25-63-08 (for INTEGRA ELTs) Limited to maintenance Level 3 CMM 25-63-02 (for ATP ELTs)
· SL S1863501-25-01 (for ULTIMA-S ELTs)
* Detail list provided upon request ; ** Optional
4 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
Level 3 Kannad Approved Repair & Warranty Center
Mandatory
Level 3 CMM 25-63-01 (for standard ELTs) Level 3 CMM 25-63-03 (for COMPACT ELTs) Level 3 CMM 25-63-06 (for INTEGRA ELTs) Level 3 CMM 25-63-02 (for ATP ELTs) Level 3 CMM 25-64-06 (for ULTIMA-S ELTs)**
Service Network Structure: Benefits
Installation & Commissioning
Benefits
ACMMs for Dongles ACMMs for Accessories Access to Level 2 CMMs
(Not available for Ultima-S ELT)
Access to Level 3 CMMs
(Optional for Ultima-S ELT)
Authorized to replace batteries Authorized to replace PCB & other parts Authorized to handle Warranty on behalf of S.E.D. Beacons Order Battery kits from Order spare parts from S.E.D. Beacons with preferred pricing conditions Can provide service to external customers
Displayed on S.E.D. Beacons Website
Logo to promote activity
Level 1
Periodic Inspection
Programming Center
Kannad Approved Operator
With Training Package
Level 2 Kannad Approved Battery Replacement Center
Distributor
Level 1 With Training Package With Training Package
Distributor
Level 1 & 2
5 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
Level 3 Kannad Approved Repair & Warranty Center
S.E.D. Beacons
Level 1, 2 & 3
FAQ PROGRAMMING
I just acquired an aircraft, the ELT must be re-programmed, I have also heard about dongle, I don’t know how to proceed? To determine the best way to have your ELT/Dongle reprogrammed, we invite you to go through our online decision tree
Where can I find a Kannad ELT programming facility? All Kannad distributors, programming centers trained, Level 2 and Level 3 service centers are approved for ELT programming. The list is available on https://safran-navigation-timing.com/support-hub/#mapmenu
How do I become a Kannad ELT Programmer? Order a PR600 programming kit (P/N 1201570) from a Kannad Aviation distributor. Register your PR600 tools with form as described in the instructions included in the PR600 package. After activation of your account by Customer Service, you’ll be able to download and install the programming software and the Kannad ELT commissioning training document. For a full mastery of the Kannad ELT programming, you have the option of requesting online training for your team. Don’t hesitate to contact us.
I have got a PR550 programming kit. Can I keep using it to program Kannad ELTs and Dongles? PR550 is not compatible with 64 bits OS. Even if you are using it on an older PC with 32bits OS, we do not provide support for it. We invite you to replace it by a PR600 USB programming kit.
My company is not approved as Kannad Approved Operator, Kannad Approved Battery Replacement Center or Kannad Approved Repair & Warranty center. Can I program Kannad ELT ?
Yes, Kannad ELT programming can be performed without formal approval from Kannad. There is no recurrent fee associated with Kannad ELT programming.
6 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
FAQ BATTERY REPLACEMENT
Why can’t I obtain a Level 2 CMM free of charge as before? In order to provide improved service quality for Kannad customers, S.E.D. Beacons has decided to restrict distribution of some maintenance documents to S.E.D. Beacons qualified and approved partners. Level 2 CMMs will be provided only to Kannad Approved Operator and Kannad Approved Battery Replacement Centers.
I used to perform battery replacement, following the previous Kannad ELT Maintenance Policy. Why can’t I continue to do it with the level 2 CMM that I downloaded a few years ago?
Level 2 CMMs are no longer available for download on our website. The last revision of CMM is mandatory to perform battery replacement or repair. An index of current revisions let you know if your Level 2 CMM can still be used.
Why should I have my ELT battery replaced by a Kannad Approved Battery Replacement Center? As well as opening the ELT, and replacing the battery, the full ELT battery replacement process includes complete testing of the ELT’s performance, ensuring that your ELT will perform as expected until the next scheduled maintenance operation.
What is a Kannad Approved Battery Replacement Center? What is a Kannad Approved Operator? A Kannad Approved Battery Replacement Center (KABRC) has a formal approval delivered by S.E.D. Beacons. KABRCs are regularly audited by S.E.D. Beacons to confirm their capability to fulfill our requirements. This means S.E.D. Beacons can guarantee that your ELT is overhauled by technicians using appropriate test equipment and following current maintenance instructions. A Kannad Approved Operator (KAO) is a fleet owner approved the same way as a KABRC but entitled to perform battery replacement on its own fleet only.
What happens if a fault is found on the ELT by a KABRC or KAO during a battery replacement operation? A KABRC is NOT a repair center. The repair of a Kannad ELT can only be performed by a Kannad Approved Repair & Warranty Center (KARWC). Note that Kannad Approved Repair & Warranty Centers are approved for battery replacement.
7 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
FAQ REPAIR / OTHER
What do you call “repair” ? A repair is any unscheduled maintenance operation carried out as a result of a fault found during self-test, inspection, or battery replacement. The replacement of any mechanical part, other than a battery replacement kit, is a repair. Re-coding an ELT or replacing the ELT battery is not a repair.
What is a Kannad Approved Repair & Warranty Center? A Kannad Approved Repair & Warranty Center (KARWC) has a formal approval delivered by S.E.D. Beacons following product training. Its technicians are regularly trained by S.E.D. Beacons to perform all authorized repairs, including operations on the PCB board. When applicable, a Kannad Approved Repair & Warranty Center will handle the warranty of your Kannad ELT on behalf of S.E.D. Beacons.
My company holds a Kannad Level 3 CMM / My aircraft was delivered with a Kannad Level 3 CMM. Can I perform repairs on my own ELT based on this CMM?
No. Some Level 3 CMMs are distributed to aircraft manufacturers for information only. Having a Level 3 CMM is not sufficient to carry out Level 3 maintenance. To be approved by S.E.D. Beacons for Kannad ELT repair requires specific product training provided by S.E.D. Beacons.
How do I become a KAO / KABRC / KARWC? Our aftermarket philosophy is to rationalize our worldwide repartition of Kannad approved maintenance centers, so that we can keep good control of the level of maintenance quality performed by our partner shops while ensuring good service level to operators. Still, we are always open to consider new applications based on the data you will provide. To apply for KAO/KABRC/KARWC please log a Support Ticket for Aviation Product Line on https://safran-navigation-timing.com/support-hub/kannad-elt/ and ask for an application form or send us an email to [email protected].
8 Customer Service / Safran Electronics & Defense Beacons / May 2023
This document and the information therein are the property of Safran. They must not be copied or communicated to a third party without the prior written authorization of Safran
Customer Support Contact
Safran Electronics and Defense Beacons SAS
Zone industrielle des cinq chemins CS10028 56520 GUIDEL FRANCE Tel: +33 2 97 02 49 00
E-mail: [email protected] https://safran-navigation-timing.com/support-hub/kannad-elt/
