T8658 Grips for T210 Handles
Product Information
The product is a set of grips designed for T210 handles. It
comes in three different references: T8658 (green), T3310 (blue),
and T3311 (black). The grips are included with the following items
in the packaging:
- Grips for T210 Handles – 4 units
- Fitters – 4 units
- Manual – 1 unit (Ref. 0018667)
The grips can be easily replaced using the included fitters. The
product complies with CE standards and is ESD safe.
Specifications
| Grip Dimensions | – |
|---|---|
| Total Net Weight | – |
| Package Dimensions/Weight | 90 x 55 x 40 mm / 17.8 g (L x W x H) 3.54 x 2.17 x 1.57 in / 0.039 lb |
Product Usage Instructions
- Inserting Fitters
Insert the fitters into the new grip.
- Assemble Grip
Push the grip with the fitters onto the handle.
- Removing Fitters
To remove the fitters, hold the grip and pull the fitters out.
Use pliers if necessary.
INSTRUCTION MANUAL
T8658 / T3310 / T3311
Grips for T210 Handles
This manual corresponds to the following references:
0018658 green
0023310 blue
0023311 black
Packing List
The following items are included*:
Grips for T210 Handles ……………………………………………………. 4 units
Fitters …………………………. 4 units
Manual ……………………… 1 unit Ref. 0018667
* According to product reference, either green, blue or black grips are included.
2
Changing Grips
w w w.j b c to o l s .c o m
Replace the grips easily using the included fitters like shown in the following pictures.
1. Inserting Fitters
Fitter New Grip
Insert the fitters into the new grip.
2. Assemble Grip
Push the grip with the fitters onto the handle.
3. Removing Fitters
Hold this way so the fitters can slide
To remove the fitters, hold the grip and pull the fitters out. Use pliers if necessary.
3
Specifications
T8658 / T3310 / T3311 Grips for T210 Handles Ref.: 0018658 green Ref.: 0023310 blue Ref.: 0023311 black
– Grip Dimensions: – Total Net Weight:
53 x ø12.6 mm / 2.09 x ø0.50 in 6.2 g / 0.013 lb
– Package Dimensions/Weight: 90 x 55 x 40 mm / 17.8 g
(L x W x H)
3.54 x 2.17 x 1.57 in / 0.039 lb
Complies with CE standards. ESD safe.
0018667-190623
JBC Soldering and Rework equipment for electronics
