PD3000 Partial Discharge Monitor
Product Information: PD3000 Partial Discharge Monitor
The PD3000 partial discharge monitor is a device that can be
used in conjunction with UHF sensor, TEV sensor, Ultrasound sensor
and online detection of partial discharge of high voltage equipment
such as transformers, high voltage switchgear, GIS, and cable
joints. It is designed to be easy to carry, provide fast
measurement, strong anti-interference ability, and easy to use on
site.
Features:
- Waveform data recording function
- Non-intrusive detection method
- Alarm multi-level threshold setting
- Sensor detects TEV and audible ultrasonic
- Automatic PD data acquisition and analysis
- Rapid detection of partial discharge conditions
- 2*DO NC & NO contact for external alarm trig
- Joint detection of partial discharge signals by transient earth
waves - Anti-interference performance and measurement accuracy
- RS 485, Modbus-RTU, SCADA systems
Applications:
- Ensure the safety of personnel and equipment
- Improve equipment reliability and safety
- Evaluate the performance parameters and electrical
characteristics of the equipment - Monitoring of transformers, cables, switchgear, busbars
- Data analysis to predict equipment failure and lifetime
- Monitor equipment operating status and prevent equipment
accidents
Technical Parameters:
85-265Vac/dc,20-60Vdc Optional
Product Usage Instructions:
Before using the PD3000 partial discharge monitor, it is
important to read the user manual carefully and understand the
implications and correct guidance of operations. The user manual
provides instructions on installation and start-up, which includes
installation dimensions (unit: mm), and test principle.
The PD3000 partial discharge monitor can be used in conjunction
with UHF sensor, TEV sensor, Ultrasound sensor and online detection
of partial discharge of high voltage equipment such as
transformers, high voltage switchgear, GIS, and cable joints. It is
designed to be easy to carry, provide fast measurement, strong
anti-interference ability, and easy to use on site.
The device features waveform data recording function,
non-intrusive detection method, alarm multi-level threshold
setting, sensor detects TEV and audible ultrasonic, automatic PD
data acquisition and analysis, rapid detection of partial discharge
conditions, 2*DO NC & NO contact for external alarm trig, joint
detection of partial discharge signals by transient earth waves,
anti-interference performance and measurement accuracy, and RS 485,
Modbus-RTU, SCADA systems.
The PD3000 partial discharge monitor can be used to ensure the
safety of personnel and equipment, improve equipment reliability
and safety, evaluate the performance parameters and electrical
characteristics of the equipment, monitor transformers, cables,
switchgear, busbars, perform data analysis to predict equipment
failure and lifetime, and monitor equipment operating status and
prevent equipment accidents.
User Manual
PD3000
Partial Discharge Monitor
User Manual
Version:1.0
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Revision 2023.04 Em ail:[email protected]
Read me
User Manual
When you use PD3000 partial discharge monitor, be sure to read this user manual carefully, and be able to fully understand the implications, the correct guidance of operations in accordance with user manual, which will help you make better use of PD3000 partial discharge monitor, and help to solve the various problems at the scene.
1.Always keep safe distance between the high voltage part and the instrument, probe and operator. 2.Measurements must not be taken when thunderstorms are nearby. 3.Do not operate the instrument or accessories in explosive atmospheres. 4.After the battery alarm of the instrument, please turn off the power to charge. 5.Do not open the instrument without permission, this will affect the warranty of the product. The factory is not responsible for self-disassembly. 6.When the instrument is transported, it should avoid rain erosion and prevent collision and falling. 7.When storing and keeping the instrument, attention should be paid to the ambient temperature and humidity, and it should be protected from dust, moisture, shock, aci d, alkali and corrosive gas.
Please read this user manual carefully Please save this document
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 1 –
User Manual
Directory
1. – SUMMARI ZE ………………………………………………………………………………………………………. – 3 2. – TECHNICAL PARAM ETERS ………………………………………………………………………………….. – 4 3.- INSTALLATION AND START-UP ……………………………………………………………………………… – 5 –
3.1 – INSTALLATION DIMENSIONS (UNIT: MM) ……………………………………………………………………… – 5 4.TEST PRI NCIPLE …………………………………………………………………………………………………… – 6 –
4.1 – B UILT-IN SENSORS (ULTRASONICAND TEV) ……………………………………………………………….. – 6 4.2 – OPTIONAL EXTERNAL SENSORS (AE, HFCT, UHF) ……………………………………………………….. – 8 5. – SAFETY CONSIDERATIONS ………………………………………………………………………………….. – 9 6.- TECHNI CAL S ERVICE …………………………………………………………………………………………… – 9 –
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 2 –
User Manual
1. – SUMMARIZE
Partial discharge is a kind of pulse discharge, which will produce a series of physical phenomena and chemical changes such as light, sound, electrical and mechanical vibration in the interior and surrounding space of power equipment. These various physical and chemical changes accompanied by partial discharge can provide detection signals for monitoring t he internal insulation state of power equipment. When insulation defects appear inside high -voltage electrical equipment, it will be accompanied by the generation of partial discharge signals. Through the detection and analysis of partial discharge signals, it can be judged whether there is a hidden danger of insulation inside the high-voltage electrical equipment, and the further expansion of potential accidents can be prevented.
PD3000 partial discharge monitor can be used in conjunction with UHF sensor, TEV sensor, Ultrasound sensor and online detection of partial discharge of high voltage equipment such as transformers, high voltage switchgear, GIS, and cable joints. Easy to carry, fast measurement, strong anti-interference ability, easy to use on site.
FEATURES
Waveform data recording function. Non-intrusive detection method, Alarm multi-level threshold setting. Sensor detects TEV and audible ultrasonic. Automatic PD data acquisition and analysis. Rapid detection of partial discharge conditions. 2*DO NC & NO contact for external alarm trig. Joint detection of partial discharge signals by transient earth waves. Anti-interference performance and measurement accuracy. RS 485, Modbus-RTU, SCADA systems.
APPLICATIONS
Ensure the safety of personnel and equipment Improve equipment reliability and safety Evaluate the performance parameters and electrical characteristics of the equipment. Monitoring of transformers, cables, switchgear, busbars Data analysis to predict equipment failure and lifetime Monitor equipment operating status and prevent equipment accidents
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 3 –
User Manual
2. – TECHNICAL PARAMETERS
HMI electrical parameters Auxiliary Power Power consumption Communication Digital output Environment temperature Environment humidity Dimensions (L × W × H) Open install hole Remote sensor node Wireless band Signal transmission distance Static power consumption Temperature monitor range Measurement accuracy Body withstand temperature Installation method Remote sensor common Power supply Wireless band* Signal transmission distance Static power consumption Installation method TEV sensor Detect range HF Frequency Response Resolution / Accuracy Ultrasound sensor Detect range Resolution / Accuracy Sensitivity Sensor Center Frequency
85-265Vac/dc,20-60Vdc Optional <6W RS-485, MODBUS-RTU 2* NC & NO, passive node -10 ~ +60°C RH 20% ~ 95% (No condensation) 96*96*85mm or 144*144*100mm 91*91mm or 138*138mm
433Mhz ~2.4Ghz optional Up to 80m (260 feet) <10mW -20~250C ±2% 70°C Silicone strap self-binding, Metal ring band fixing
12Vdc or 2000mAh build in battery* 433Mhz ~2.4Ghz optional Up to 80m (260 feet) <10mW 4* strong magnet, wall mount
0~60 dBmV 3~100MHz 1dBmV / ±1dBmV
-7dBV ~ 68dBV 1dB / ±1dB -65 dB (0 dB=1 volt/bar rms SPL) 40 kHz
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 4 –
3.- INSTALLATION AND START-UP
3.1 – Installation Dimensions (Unit: mm)
User Manual
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 5 –
User Manual
4.TEST PRINCIPLE
4.1 – Built-in sensors (Ultrasonic and TEV)
There are two principles for partial discharge detection of switchgear: ultrasonic principle and transient earth voltage (TEV) principle. The built-in ultrasonic sensor and TEV sensor of this product are used to measure partial discharge of high-voltage switchgear. Front position, this part needs to be close to (ultrasonic measurement> or close to (TEV measurement) high -voltage switchgear during testing. Note that approaching and closeness are different, depending on which principle is used to test the switchgear.
4.1.1 – Ultrasonic measurement
If you choose the built-in ultrasonic sensor to measure the partial discharge of the switchgear, you hardly need to do other operations or settings after starting up, Because the built -in ultrasonic sensor is selected by default after the product is turned on, the upper left of the screen will display which sensor is currently connected.
In the ultrasonic measurement mode, the measurement data is dBuv, because dBuV is a logarithmic function value based on 1uV, therefore, the measured data in the ultrasonic mode can be positive or negative. According to the processing capacity of the ultrasonic amplifier of this product, it can reach -6dBuV The test ranges to 68dBuV, the larger the negative value, the smaller the ultrasonic signal, the closer to Ouv, not negative! Usually the measured data in an interferencefree environment is between -6dBuV and odBuV.
Insulation condition of switchgear: Data
De finition
-6~0dBuV, no discharge sound
No partial discharge
0 ~ 6dBuV, short discharge sound
Slight discharge, and attention should be paid to it later.
Above 6dBuV, have discharge sound
Obvious discharge, should be judged in combination with TEV.
Note: The demarcation point (6dBuV) is slightly different in different regions, so it is recommended to use 6dBuV as the demarcation point, so that the operating status of the switchgear can be warned in advance.
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 6 –
User Manual
4.1.2 – TEV measurement
In the TEV measurement mode, the reference pulse count value P/Cycle is also required, and the pulse number and amplitude comprehensively measure the health of the switchgear.
When the environmental value is large, it is necessary to find out the interference source. The interference source of TEV is different from that of ultrasonic. Ultra sonic interference is generally limited to a limited space, while TEV interference affects the entire space through radio frequency, such as electric welding machines, frequency converters, walkie -talkies, Wireless broadcasting stations, etc. Compared with ultrasonic interference, such interference signals are sometimes difficult to avoid or clear, so it is recommended to use ultrasonic measurement when the environment (interference) value is detected to be large.
Insulation condition of switchgear:
Data The reading is <20dB. The reading is 20-29dB.
De finition No partial discharge, Recheck once a year.
Slight discharge.
The reading is 29-40dB. The reading is 40-50dB. The reading is 50-60dB.
Moderate partial discharge should be reported and shorten the inspection
cycle.
Serious partial discharge should be reported and shorten the inspection
cycle, and be checked when power failure.
Severe partial discharge, power outage and maintenance as soon as
possible.
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 7 –
4.2 – Optional external sensors (AE, HFCT, UHF)
User Manual
Contact ultrasonic se nsor
AE measurement
For Transformers, GIS, Motors, Frequency: 40 ~ 150kHz
High frequency transformer
HFCT measurement
For Cable Frequency: 1 ~ 30MHz
UHF sensor
UHF measurement
For GIS Frequency: 300-2000MHz
Note:
All the above sensors are connected through the multi-function sensor extension port at the bottom of the host. When the sensor is connected through the same extension port, the host will automatically identify the sensor type, select the sampling channel of the corresponding frequency, and display the relevant parameters of the sensor on the top of the interface.
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 8 –
5. – SAFETY CONSIDERATIONS
User Manual
All installation specification described at the previous chapters named: INSTALLATION AND STARTUP, INSTALLATION MODES and SPECIFICATIONS.
Please note that with the instrument powered on, the terminals could be dangerous to touching and cover opening actions or elements removal may allow accessing dangerous parts. This instrument is factory-shipped at proper operation condition.
The device must have a professional installation and maintenance . Any operation of the device, you must cut off the input signal and power;
6.- TECHNICAL SERVICE
For any inquiry about the instrument performance or whether any failure ha ppens, contact to Blue Jay’s technical service.
Blue Jay – After-sales service
1802, Building 2, No.88, Jianxin East Road, Chongqing,400020, China
Tel – + 0086 023 67628702 E-mail: [email protected]
Tel: +0086-023-67628702 www.cqbluejay.com Add: 1802,Building 2,No.88,Jianxin East Road,Chongqing,400020,China
Em ail:[email protected] – 9 –
Blue Jay - Development, production and sales of power automation monitoring products and energy metering instruments.
