Hampton Bay Hdp00814 Grangehill 1 Light Medium Wall Lantern User Guide

HDP00814 Grangehill 1 Light Medium Wall Lantern

Item # 1007183442 Model # HDP00814
USE AND CARE GUIDE
GRANGEHILL 1-LIGHT MEDIUM WALL LANTERN
Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. ­ 7 p.m., EST, Monday ­ Friday, 9 a.m. ­ 6 p.m., EST, Saturday
1-855-HD-HAMPTON HAMPTONBAY.COM
THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this lantern. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

Table of Contents
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Pre-Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Planning Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Hardware Included. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5, 6 Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Safety Information
Consult a qualified electrician with any electrical questions you may have.

IMPORTANT: Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have occurred during shipping. If there is a defect in the wire, do not continue the assembly process. Please call our Customer Service Team at 1-855-HD-HAMPTON.

Warranty
3-YEAR LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in the materials and workmanship for a period of three (3) years from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use. If this product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modifications, alterations, neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, assembled, or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship.
WHAT IS NOT COVERED
This warranty shall not apply to the finish on any portion of the product due to weathering, as this is considered normal wear. The manufacturer does not warrant and specifically disclaims any warranty, whether expressed or implied, other than the warranty contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential or incidental loss or damage, including but not limited to, any labor or expense costs involved in the replacement or repair of the product. Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.

2

Pre-Installation
PLANNING INSTALLATION
Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. Inspect each part for defects that may have occurred during shipping. Keep your receipt and these instructions for proof of purchase.
NOTE: This lantern requires the use of one 120V, 60Hz, 100-Watt max., medium-base type A bulb (not included). Do not exceed the recommended wattage.
TOOLS REQUIRED

Safety goggles

Phillips screwdriver

Flathead screwdriver

Pliers

Wire strippers

Wire cutters

Ladder

HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.

Electrical tape

Silicone

AA
EE
Part Description AA Wire nut BB Mounting plate CC Outlet box screw DD Mounting screw EE Ground screw FF Small nut GG Rubber washer HH Finial

BB

CC

FF

GG

Quantity 3 1 2 2 1 2
2 2

3

DD HH
HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.

Pre-Installation (continued)
PACKAGE CONTENTS

A B
C

D

Part Description

A Lantern body

B

Socket (Pre-assembled on the lantern body (A))

C Shade

D

Socket ring (Pre-assembled on the socket (B))

Quantity 1 1 1 1

4

Installation

1 Removing the mounting plate

3 Connecting the wires

Remove the mounting plate (BB) and two rubber washers (GG) from the lantern body (A) by unscrewing two finials (HH).

Install the fixture bare copper ground wire (1) under the ground screw (EE) on the mounting plate (BB).

Connect the fixture bare copper ground wire (1) to the green (or bare, or green and yellow) supply ground wire (2) in the outlet box using a wire nut (AA).

Connect the white fixture wire (3) to the white (or ribbed) supply wire (4) in the outlet box using a wire nut (AA).

Connect the black fixture wire (5) to the black (or red, or blue) supply wire (6) in the outlet box using a wire nut (AA).

EE 2 1 6 1 5

BB

A

GG HH

2 Installing the mounting plate
DANGER: Ensure the power is off at the main fuse box prior to beginning installation. Turn off the switch at the wall. Turn the power off at the main fuse box. Attach the mounting plate (BB) to the outlet box using two outlet box screws (CC).
CC
BB

4 AA 3

House wire black
(or red, or blue) (HOT)

Fixture wire Black (HOT)

House wire white
(NEUTRAL)
House wire green
(or bare wire, or green & yellow)
(GROUND)

Fixture wire White (NEUTRAL)
Fixture wire Bare wire (GROUND)

5

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Installation (continued)

4 Installing the lantern

6 Installing the bulb

Push all excess wires into the outlet box.
Align the holes of backplate with two mounting screws (DD), and then secure the fixture body (A) to the wall with two rubber washers (GG) and two finials (HH).

Prior to installing the bulb, inspect the socket for a silica packet. If a packet is present, remove and throw away. Do not expose to children and pets.
Install one 120V, 60HZ, 100-watt max. medium-base type A bulb (not included) into the socket (B).

B

DD

A GG HH

5 Assembling the shade
Unscrew the socket ring (D) from the socket (B). Place the shade (C) over the socket (B) and secure with
the socket ring (D).
B

Bulb (Not included)
7 Sealing the mounting surface
Apply silicone or RTV compound (not included) between the edges of the backplate and wall.

C

D

6

Care and Cleaning
Clean the light fixture with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.

Troubleshooting

Problem The bulb will not light.

Possible Cause The bulb is burned out. The power is off. There is a faulty wire connection.
The circuit breaker is off.

The fuse blows or a circuit breaker There is an exposed wire.

trips when the light is turned on.

There are too many items on one circuit.

Solution Replace the light bulb.
Ensure that the power supply is turned on. Check the wiring.
Ensure that the circuit breaker is set in the on position.
Discontinue use of the light fixture. Contact a qualified electrician or
call the Customer Service Team at 1-855-HD-HAMPTON. Unplug other items on the circuit.

7

HAMPTONBAY.COM

Please contact 1-855-HD-HAMPTON for further assistance.

Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service
8 a.m. ­ 7 p.m., EST, Monday ­ Friday, 9 a.m. ­ 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
