JN 2087 Avery 26 Inch Sconce
Product Information
Product Name: Avery 26 Sconce
Item Number: JN 2087
Product Usage Instructions
- Carefully remove all parts from the box and place them on a
clean, soft surface. - Locate the mounting plate (A) and remove it from the fixture
(E) by unscrewing the screws (D). - Position the mounting plate (A) onto the junction box and
secure it using the provided mounting screws (B). - Take the fixture ground wire (bare copper) and wrap it around
the green grounding screw (C) located on the mounting plate
(A). - Connect the fixture wires to the corresponding wires in the
junction box. Use wire connectors or twist the ends of the wires
together and secure them with electrical tape. - Carefully align the fixture (E) with the mounting plate (A) and
attach it by tightening the screws (D). - If a bulb is not included, insert a compatible bulb into the
fixture. - Finally, turn on the power and test the light fixture to ensure
proper installation.
Care Instructions
Clean the light fixture only with a soft dry cloth or feather
duster. Do not use abrasive or chemical agents.
Note: This light fixture should be installed in accordance
with all applicable, local installation codes, and by a person
familiar with the construction and operation of it, as well as the
hazards involved. Inspect the item and its contents carefully. If
any damage or defect is found, do not install. Retain all packaging
material until installation is complete and approved.
Tools Required (Not Included):
- Phillips Screwdriver
- Slotted Screwdriver
- Scissors
This product is UL Listed for use in the United
States.
ASSEMBLY INSTRUCTIONS
Diagram 1
AB C
DE
F (Packaged separately) Bulb not included
Avery 26″ Sconce
Item # JN 2087
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Scissors
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (A) from fixture (E) by removing screws (D). 3. Install mounting plate (A) to the junction box and secure with
mounting screws (B). 4. Wrap fixture ground wire (bare copper) around the green grounding
screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (C). NOTE: It is imperative that the fixture is grounded. 5. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (C). 6. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (C). CAUTION: Do not reverse the hot and neutral connections. 7. Make sure all wire connections are tight, then carefully tuck into the junction box. 8. Install fixture (E) to mounting plate (A) and secure with screws (D). 9. Install light bulb into the socket. 10. Remove shade (F) from packaging, then clip shade (F) onto the bulb. NOTE: If shade has additional packaging, carefully cut off from interior of shade to avoid damages.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
