201070 Triomphe Sconce
Product Information
The product is the Triomphe Sconce 201070, manufactured by
Hubbardton Forge. It consists of several component parts:
- A. Fixture
- B. Mounting Bracket
- C. Ground Screw
- D. Cupped Washer
- E. #8 Screws (4)
- F. Socket
- G. Bulb (Not Included)
- H. Glass
- I. Cup
Product Usage Instructions
To install the fixture, please follow these steps:
- Ensure that the power is turned off at the main breaker box
before starting the installation. - Carefully unpack the fixture (A) from the carton.
- Remove the mounting bracket (B) from the fixture (A).
- Thread the wires in the electrical box through the hole in the
mounting bracket (B) while moving the bracket into position.
If you need further assistance or find that you are missing any
parts, please contact the dealer from which you purchased this
product. Please note that improper installation, lamping, or use of
this fixture may result in injury or damage, and Hubbardton Forge
will not be liable for such incidents.
B514
ASSEMBLY & INSTALLATION INSTRUCTIONS
Triomphe Sconce 201070
52570
1 OF 4
B514
ASSEMBLY & INSTALLATION INSTRUCTIONS
Triomphe Sconce 201070
Component Parts
A. Fixture B. Mounting Bracket C. Ground Screw D. Cupped Washer E. #8 Screws (4) F. Socket G. Bulb (Not Included) H. Glass I. Cup
52570
2 OF 4
B514
ASSEMBLY & INSTALLATION INSTRUCTIONS
Triomphe Sconce 201070
CAUTION: FAILURE TO INSTALL THIS FIXTURE PROPERLY MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATHAND PROPERTY DAMAGE. We recommend installation by a licensed electrician. This product must be installed in accordance with applicable installation code(s), by a person familiar with the construction and operation of the product and the hazards involved.* Caution: Do not exceed maximum wattage noted on fixture. Use only recommended bulbs with fixture. Please Note: After installation extra hardware and accessories are possible; our kits are used on multiple products.
To Install Fixture (Figure 1) – on following page
CAUTION: BE SURE POWER IS OFF AT THE MAIN BREAKER BOX PRIOR TO INSTALLATION. 1. Carefully unpack the fixture (A) from the carton. 2. Remove mounting bracket (B) from fixture (A). 3. Thread the wires in the electrical box through the hole in the mounting bracket (B) while moving the bracket into
position. Place mounting bracket over electrical box and secure with two machine screws (not provided). Note: A new electric box comes with screws. When replacing a fixture, retain the existing screws for use. 4. Attach a pigtail lead to the mounting bracket (B) using the ground screw (C) and cupped washer (D) found in kit bag. 5. Hold fixture (A) close to wall. Using suitable wire connectors (not provided), connect fixture wires to supply wires (white to white and black to black). Connect all ground wires (bare copper or green to bare copper or green). CAUTION: MAKE SURE WIRE CONNECTORS ARE TWISTED ON SECURELY, AND NO BARE WIRE IS EXPOSED. 6. Place fixture (A) over mounting bracket (B).Secure with #8 screws (E) on top and bottom of fixture. Be sure no wires are pinched between fixture and wall. 7. Install bulb (G) (not included) into socket (F). 8. Thread glass (H) onto socket (F) and inside cup (I) 9. Restore electricity at main breaker.
52570
3 OF 4
B514
ASSEMBLY & INSTALLATION INSTRUCTIONS
Triomphe Sconce 201070
MACHINE
E
SCREWS
C
D
B
A
H
F
G
I
(Figure 1) If you need further assistance, or find that you are missing any parts, please contact the dealer from which you purchased this product. We hope you enjoy your fixture! * Hubbardton Forge will not be liable for injury or damage caused by improper installation, lamping or use of this fixture.
