ARN 1530 Lorna Extra Large Arc Floor Lamp
Product Information:
Product Name: Lorna Extra Large Arc Floor Lamp
Item Number: ARN 1530
Product Features:
- Extra large arc design
- Bulb not included
- LED technology
- Complies with US safety standards (Listed)
Usage Instructions:
- Before starting assembly, ensure that you have read and
understood all the safety instructions provided in the user
manual. - Carefully remove all parts from the box and place them on a
clean, soft surface. - Insert rod (F) into the lamp body (G).
- Insert rod (E) into rod (F).
- Remove the set screw (I) from the bottom of rod (G) using the
provided tool. - Attach the lampshade or bulb holder to the top of the lamp body
(G) according to the specific instructions provided with the
lampshade or bulb holder. - If using a bulb, insert the appropriate bulb into the bulb
holder. Make sure to follow the recommended wattage and type
specified by the manufacturer. - Plug the lamp into a suitable power outlet.
- Turn on the lamp using the switch or control mechanism
provided.
Care Instructions:
To clean the lamp, use only a soft dry cloth or feather duster.
Do not use abrasive or chemical agents, as they may damage the
lamp’s surface or components.
Note: This light fixture should be installed in
accordance with all applicable, local installation codes, and by a
person familiar with its construction and operation, as well as the
hazards involved. Inspect the item and its contents carefully
before installation. If any damage or defect is found, do not
install the lamp. Retain all packaging material until installation
is complete and approved.
ASSEMBLY INSTRUCTIONS
D C B A
Bulb not included
E F
G L H
K I
J
Lorna Extra Large Arc Floor Lamp Item # ARN 1530
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Insert rod (F) to lamp body (G), then insert rod (E) to rod (F). 3. Remove set screw (I) from bottom of rod (G) using provided
screwdriver (J), then align notches on lamp body (G) to screws on base (H) and lock into place. Tighten set screw (I) using provided screwdriver (J). NOTE: If lamp body is loose after installation, remove and turn screws on base clockwise (making them shorter) then reinstall. Repeat this process as needed until lamp body is tight to base. 4. Remove switch knob (C) and socket ring (A) from socket (D), then install shade (B) to socket (D) and secure with socket ring (A). 5. Reinstall switch knob (C) to the socket (D). 6. Install light bulb into the socket. 7. Remove protective cover (K) from plug. 8. Plug into electrical outlet and test fixture.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do not use abrasive or chemical agents.
M
LI ST ED
US
LED
