SYNCHRONY SCRS Upright Vacuum Cleaner

Simplicity Parts Book – Synchrony Model

Product Information

The Simplicity Synchrony Model is available in all versions
including SCRS, SCRD, SCRD.FETCH, and SCRD.LE. It comes with a
handle assembly, dust cover, and main body. The handle assembly
includes parts such as handle left and right, screws, power cord
assembly, and more. The dust cover assembly includes parts like
dust cover latch body assembly, latch cover, dust cover latch seal,
and more. The main body assembly includes parts like HEPA bag,
electrostatic post filter, dust compartment assembly, air path back
cover seal, and more.

Product Usage Instructions

To assemble the handle of the Synchrony model:

1. Take the handle left and right parts (part numbers B484-0214B
   and B484-0414B respectively) and attach them to the handle tube
   base connector (part number A328-1300) using screws (part number
   B384-0900).
2. Attach the carpet/floor switch on/off wire connector (part
   number B123-0100) to the switch (part number A328-1200) and then
   attach the switch to the handle tube base (part number A732-1500C)
   using screws (part number B384-0800).
3. Attach the handle tube (part number A732-3400) to the handle
   tube base (part number A732-1500C) using screws (part number
   B384-1400D).
4. Attach the upper cord hook base (part number A430-0405) to the
   handle tube base (part number A732-1500C) using screw (part number
   B430-0200).
5. Attach the upper cord hook (part number A732-2400) to the upper
   cord hook base (part number A430-0405) using screw (part number
   D333-0100).
6. Attach the lower cord hook (part number A732-8314) to the
   handle tube (part number A732-3400) using screw (part number
   B333-3014B).
7. Attach the handle mount screw (part number B484-0314) to the
   handle tube (part number A732-3400).
8. Insert the spring (part number D484-1100) into the handle tube
   (part number A732-3400).
9. Attach the handle assembly complete (part number D484-3000) to
   the main body assembly.

To assemble the dust cover of the Synchrony model:

1. Take the dust cover latch body assembly (part number D480-3000)
   and attach it to the latch cover (part number B480-0914B) using
   screws (part number B480-0814).
2. Attach the dust cover latch (part number B480-4900) to the dust
   cover latch body assembly using screw (part number B480-1014).
3. Attach the dust cover latch seal (part number D480-0761) to the
   dust cover latch body (part number B480-4900).
4. Attach the dust cover lever (part number B480-4014) to the dust
   cover latch body (part number B480-4900) using screw (part number
   B480-3014).
5. Attach the dust cover seal (part number D480-0314.2) to the
   dust cover lever (part number B480-4014).
6. Attach the dust cover assembly (part number D480-1100) to the
   main body assembly.

To assemble the main body of the Synchrony model:

1. Take the HEPA bag 6 pack (part number SWH-6) and insert it into
   the dust compartment assembly (part number D480-5314).
2. Attach the dust compartment tilt lock body plate (part number
   B480-3014) to the dust compartment assembly (part number
   D480-5314).
3. Attach the wire inlet seal (part number B480-5700) to the back
   cover (part number B480-5600).
4. Attach the short seal air path back cover seal (part number
   B480-4600) to the back cover (part number B480-5600).
5. Attach the direct air motor filter post filter seal (part
   number B480-1214) to the direct air motor filter cover (part number
   A732-8314).
6. Attach the direct air motor filter cover (part number
   A732-8314) to the motor cover (part number B480-1114C) using screw
   (part number B480-5200).
7. Insert the Ametek clean air motor bulk (part number D486-2100)
   into the motor cover (part number B480-1114C).
8. Attach the CAM rear strip seal (part number B388-4900) to the
   back cover (part number B480-5600).
9. Attach the motor cover filter foam (part number B480-5200) to
   the motor cover (part number B480-1114C).
10. Attach the upper crevice tool clip (part number B480-2114B) and
    lower crevice tool clip (part number B480-2014B) to the main body
    assembly.

SIMPLICITY PARTS BOOK
SYNCHRONY MODEL ALL VERSIONS SCRS SCRD SCRD.FETCH SCRD.LE SCRP
Rev 06 02/25/2022

HANDLE ASSEMBLY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

20
1 2 18
17

3 5

21
1 2

19

22
16

4

15 14

11 10

6
9 8 7

12 7

7
3
13

HANDLE ASSEMBLY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

KEY 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20

PART NUMBER B484-0214B B484-0414B A732-8314 A732-2400 D333-0100 B333-3014B A732-1500C A430-0405 B430-0200 B384-0900 B384-0800 B484-0314 A732-3400 B384-1400D B484-1000D A328-1300 A328-1200 B123-0100 B333-2200B D484-3000

21 D484-1100

22 B333-3014B

DESCRIPTION Handle Right Handle Left Screw E-Clip 35′ Power Cord Assembly Strain Relief Screw Washer Spring Upper Cord Hook Upper Cord Hook Base Lower Cord Hook Handle Mount Screw Handle Tube Base Connector Handle Tube Switch Carpet/Floor Switch On/Off Wire Connector Md. Handle to Body Harness Handle Assembly Complete Heavy Duty Handle Kit w/6 Screws For Replacement Strain Relief

DUST COVER
6

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

1

45 3

8

2

9

7

DUST COVER

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

KEY 1 2 3 4 5 6 7 8

PART NUMBER D480-3000 B480-0914B B480-1014 B480-4900 B480-0814 D480-0761 B480-4014 A732-8314

D480-0314.2

Not Available

Not Available 9
Not Available Not Available

Not Available

DESCRIPTION Dust Cover Latch Body Assembly Latch Cover Dust Cover Latch Latch Seal Dust Cover latch Body Dust Cover Lever Dust Cover Seal Screw Pan Head HiLo #8×5/8 Dust Cover Assembly All Synchrony Black Replacement Painted Dust Cover Assembly ( SCRD) Chestnut Painted Dust Cover Assembly (SCRD.FETCH) Green Painted Dust Cover Assembly (SCRD.LE) Silver Painted Dust Cover Assembly (SCRP) Painted Dust Cover Assembly (SCRS) Burnt Orange

MAIN BODY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

15 3 16
7

1

54

29 30

7
31 49 50

34

7

46

7

45

10

32

44

28 27
12
14 25 11 13

35
7 33
36
7

5

7

2

37
26 38
40 9
39

8

17

5

47

22

24 7

23

21

51 53 52 12
7 47 48

7

55

56 7
43

7 42
41

18 19 20

MAIN BODY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

KEY

PART NUMBER

DESCRIPTION

KEY

PART NUMBER

DESCRIPTION

SWH-6 1
B211-6000
B480-5314 2
B480-3014

HEPA Bag 6 Pack
HEPA Bag Single Bulk
Electrostatic Post Filter Bulk (All Models) HEPA Post Filter (All Models)

31 D480-1100 32 Order #31 33 B480-2214 34 B480-6300 35 B480-6200 36 B480-4200

Dust Compartment Assembly Dust Compartment Tilt Lock Body Plate Wire Inlet Seal Back Cover Short Seal Air Path Back Cover Seal

B480-5500

Secondary Filter Electroststic 37 D486-2100 Ametek Clean Air Motor

Bulk (SCRS)

38 B388-4900 CAM Rear Strip Seal

3 B480-5700
4 B480-5600 5 B480-4600 6 B480-1214 7 A732-8314

Secondary Filter Electrostatic & Charcoal Bulk(SCRD SCRD.LE SCRD.FETCH SCRP) Direct Air Motor Filter Post Filter Seal Direct Air Filter Cover Screw Hi Lo #8X5/8

39 B388-5600B Ametek Rear Ring Seal 40 B486-0600 Ametek Front Motor Mount 41 B480-1914 Hose Inlet Elbow 42 B480-5100 Hose Inlet Elbow Seal 43 B480-4700 Hose Inlet Seal 44 B480-2014B Lower Crevice Tool Clip
(SCRD SCRD SCRD.LE SCRD.FETCH SCRP)

8 B480-1114C Motor Cover

45 B480-1714D Back Cover

9 B480-5200 Motor Cover Filter Foam

B480-2114B Upper Crevice Tool Clip

10 B480-1414B Bag Mount

46

(SCRD SCRD.LE SCRD.

11 A328-1100B Thermal Reset Switch

FETCH SCRP)

12 B333-0600 Thermal Switch Seal

47 A328-1400 Roto Valve Switch

13 A732-8414 Screw Hi Lo #8×7/16

48 A732-9005 Screw

14 A328-1000 Winged Rocker Switch

15 B480-3214 Secondary Filter Screen

16 B480-3114 Secondary Filter Frame

17 B483-0100C Internal Wire Harness

18 B480-5014 Pressure Switch Insert

19 D480-5000

Pressure Switch Hose Assembly

20 B418-0100BK Main PC Board

21 D486-2000 Direct Air Motor Assembly

22 B480-4514 Direct Air Motor Inlet Seal

23 B480-4400B Direct Air Motor Outlet Seal

24 B486-0414B Motor Fan

B380-2014 49

Crevice Tool Clip (SCRD SCRD.LE SCRD.FETCH SCRP)

50 A732-2500 Screw

51 B480-1614C Valve Knob

52 D480-1514

Valve Body Assembly (With Seal)

53 B480-1814 Valve Switch Cover

54 Not Available Tool Cavity Cover (SCRS)

55 B455-0514

Hose Inlet Cap Teather (SCRS)

56 B455-0414B Hose Inlet Cap (SCRS)

25 B470-2100 Pivot Bushing Right

26 B470-2000B Pivot Bushting Left

27 B480-5814 Motor Cover Seal Right

28 B480-4314 Motor Cover Seal Left

29 B480-1314B Carry Handle Insert

30 B480-4100C Upper Compartment Seal

NOZZLE ASSEMBLY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP
2

1

3

4

6 7

5

8 19

38

9

39

10 12

13

11

14

15 17
16

18 21
20

32 33
31

37 34 36

30

29

35

28 14 13

12 11

27

10

26

22

21

20 24
25 23

NOZZLE ASSEMBLY

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

KEY PART NUMBER

DESCRIPTION

KEY PART NUMBER

DESCRIPTION

Nozzle Cover Assembly D470-0214.2 Black Replacement (All
Models)

D470-0285

Nozzle Assembly (SCRD) Chestnut

1

Not Available

Nozzle Cover Assembly (SCRD.FETCH)Green

Not Available

Nozzle Assembly (SCRD. LE) Chestnut Painted

Not Available

Nozzle Cover Assembly (SCRP)

Not Available

Nozzle Cover Assembly (SCRS) Burnt Orange

2 B470-3200 Nozzle Badge Cover

3 B370-0615 Indicator Light Adjust Lens

4 A732-2700 Retaining Ring .125

5 B470-0514 Nozzle Bumper

25

D475-0400

Belt Idler Assembly Hall Sensor

26 B388-2400C Agitator Top Seal

27 B375-0214 Idler Arm Cover

28 A014-0100 Belt

29 B470-1514F Nozzle Base Tray

30 B034-0100 Strain Relief Washer

31 B470-2200 Pivot Bracket Left

32 B470-2300 Pivot Bracket Right

33 B370-3600 Tilt Lock Pivot

34 C370-1400E Foot Pedal Assembly

35 A732-3000 E-Clip .250

36 B370-3800 Tilt Lock Spring

37 B470-2700B Spring Assist Spring

38 B370-4214C Spring Assist Mount

39 B470-2600 Spring Assist Axle Shaft

6 B470-0315 Nozzle Lens Right

7 B470-0415 Nozzle Lens Left

C474-1100B

Height Adjust Assembly 5 position (SCRD

8

D474-1200

Height Adjust Assembly 6 position

9 B470-1714 Inlet Manifold

10 B370-4366B Hub Cap

11 A732-3100 E-Clip .3125

12

C370-1200B

Large OvermoldedWheel Assembly

13 A732-3000 E-Clip .250

14 B370-2900B Rear Wheel Axle

15 B418-0200 LED Board

16 A350-0000 Light Bulb Xenon 12Volt

17 A350-0100B Light Socket

18 B470-1200B Reflector

19 D475-0500 Agitator Assembly

20 B350-4000B Retaining Ring

21

C370-1300

Small Overmolded Wheel Assembly

22 B470-2500B Height Adjust Axle

23 B388-2500C Agitator Bottom Seal

24 D470-1100D Baseplate Cover Assembly

ACCESSORIES
9

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP
5 6

4

8

1

7 3

2
13 10
11 12

ACCESSORIES

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

KEY 1 2 3 4 5 6 7 8 9 10
11
12
13

PART NUMBER D355-1200 B455-0214B B355-1214 B355-0214C B355-0314B B388-2700 C355-0814B C355-0914 C626-2500 B355-2014 C455-1214
C355-1214
C455-1314
C355-1314B
TB1-SU

DESCRIPTION
Hose Assembly Complete Hose Inlet Cuff 5-1 Stretch Hose Hose Handle Lock Ring Hose Handle Swivel Cuff Hose Cuff Seal Hose Handle Assembly Bleed Valve Slide w/Gasket Assy Wand Crevice Tool Upholstery Tool Nylon Bristles (SCRD, SCRD.FETCH, SCRD.LE) Upholstery Tool Natural Bristles (SCRP) Dust Brush Attachment Nylon Bristles (SCRD, SCRD.FETCH, SCRD.LE) Dust Brush Attachment Natural Bristles (SCRP) Handheld Turbo Brush (SCRD.FETCH)

AGITATOR

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

8

KEY 1 2 3 4 5 6 7 8
9
10 11 12 13 14

PART NUMBER A375-0100 A375-0200 A733-1810 A733-1800 B375-3900 B375-3600 B375-3700 NotAvailable B475-0400B B475-1200 B475-1300 B475-1700 B475-1800 B475-1900 Not Available D475-0500

DESCRIPTION Hex Nut Bearing Screw 80mm Screw 44mm Felt Seal End Cap End Cap Cover Shaft Single Brush Strip Nylon Single Brush Strip White Single Brush Strip Natural Agitator Pulley Agitator Bearing Cartridge Agitator Felt Retainer Agitator Steel Core Agitator Assembly

DIRECT AIR MOTOR

Simplicity MODELS: SCRS SCRD SCRD.FETCH SCRP

1

5 4

2 3

6

KEY 1 2 3 4 5 6

PART NUMBER D486-2000 B480-4400B B486-0314 B486-0414B B486-0214 A732-8314

DESCRIPTION Direct Air Motor Assembly Direct Air Motor Outlet Seal Sroll Housing Left MV Inner Behind Fan Motor Fan Scroll Housing Right MV Fan Cover Outer Screw Hi Lo #8X5/8
