10401 Mini Crescent Wall Light
Product Information
- Product Name: Mini Crescent Wall
- Model Number: 10401
- Manufacturer (UK): BH17 7BY
- Manufacturer (EU): Brilliant AG, Brilliantstrasse 1, D-27442
Gnarrenburg - Website: www.saxbylighting.com
- Voltage: 220-240V 50Hz a.c.
- IP Rating: 20
- Maximum Bulb Wattage: 40W E27 GLS
- Double Insulated: Yes
Product Usage Instructions
- Commissioning:
- Position the product by fixing it to the wall using nuts and
washers. - Ensure that the terminal block is properly located in the
recess in the wall back. - The light is now ready for use.
- Position the product by fixing it to the wall using nuts and
- Fitting/Replacing Bulbs:
- When changing a bulb, always switch off the mains power and
allow the bulb to cool before handling. - Do not dispose of used bulbs with household waste; please
recycle them where facilities exist. - Use the correct type and wattage bulb. The maximum recommended
bulb wattage is 40W E27 GLS. - To fit a new bulb, insert it into the fitting and twist it
clockwise to secure.
- When changing a bulb, always switch off the mains power and
- Cleaning:
- We recommend cleaning the product with a soft dry cloth.
- Avoid using solvents, liquids, or abrasive cleaners as they may
damage the finish and the product.
- Recycling Advice:
- Do not dispose of waste electrical products with household
waste; please recycle them where facilities exist. - Check with your local authority or retailer for recycling
advice.
- Do not dispose of waste electrical products with household
- Safety Information:
- Always switch off the power supply before changing lightbulbs
or cleaning for your safety. - If you are unsure, consult a qualified electrician.
- Always switch off the power supply before changing lightbulbs
Commissioning
into position.
nuts and washers fix to the wall.
Ensure that the terminal block is properly located in the recess in the wall back.
light is now ready for use.
Fitting/replacing bulbs
When changing a bulb, always swith off at the mains and allow the bulb to cool before handling. Used bulbs should not be disposed of with household waste. Please recycle where facilities exist.
shape bulb from that indicated on the fitting.
Max. 40W E27 GLS
clockwise to secure.
We recommend cleaning with a soft dry cloth. Do not use solvents, liquids or abrasive cleaners as these could damage the finish and the product.
Recycling advice
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
Safety information
For your safety, always switch off the power supply before changing lightbulbs, or cleaning.
Instruction leaflet
Mini Crescent Wall
10401
UK Manufacturer: BH17 7BY EU Manufacturer: Brilliant AG, Brilliantstrasse 1, D-27442 Gnarrenburg
www.saxbylighting.com
V4 06/04/2022 Saxby Lighting
Thank you for purchasing this light fitting. Please read the instruction carefully before use to ensure safe and satisfactory operation of this product. Please retain these instruction for future reference.
Warning
This product is Double Insulated and does not require connection to an Earth circuit.
Please read these instructions carefully before commencing any work.
This unit must be fitted by a competent and qualified electrician.
Install in accordance with IEE Wiring regulations and
To prevent electrocution switch off at mains supply before installing or maintaining this fitting. Ensure other persons cannot restore the electrical supply without your knowledge. If you are in any doubt, please consult a qualified electrician.
If replacing an existing fitting, make a careful note of the connections.
Always use the correct type and wattage bulb. Exceeding the bulb wattage will damage the product.
When changing a bulb, always switch off at the mains and allow the old bulb to cool down before handling. Dispose of used bulbs carefully and responsibly.
This product is suitable for dimming when used in conjunction with a dimmable lamp. Please ensure verification of dimming abilities with the lamp manufacture prior to use.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice.
Specification
Voltage: IP rating:
220-240V 50Hz a.c. 1 x Max. 40W E27 GLS 20
Layout
ensuring the cables will reach the distance between the junction box and the light fitting
cause a hazard. Position cables and junction boxes (not supplied) away from areas where they may be at risk from being cut, trapped or damaged
conduit or plastic trunking. sectional area of 1.0mm².
Installation
Existing fittings must be completely removed before installation of a new product. Before removing the existing fitting, carefully note the position of each set of wires.
the fixing holes. Ensure that the product is level.
of the product. Take care to avoid damaging any concealed wiring and pipes. The correct fixings should be used for brick, cavity walls or plasterboard.
the collar just touches.
Wall Fixing Screws
Dome Nuts
Wiring
This unit is double insulated and must not be earthed. If there are any incoming earth cables, they must be joined together and well insulated with good quality insulation tape. This is to ensure earth continuity throughout your proper ty.
Having correctly identified the wiring from your existing light fitting and connect to the connection block inside the product in the following way:
SUPPLY NEUTRAL
SWITCHED LIVE
LIGHT FITTING BLUE (N)
BROWN (L)
Check that…
The connections are tight.
No loose strands have been left out of the connection block.
