Intel® Cyclone® 10 LP Device Overview

Online Version Send Feedback

C10LP51001

ID: 683879 Version: 2022.05.27

Contents
Contents
Intel® Cyclone® 10 LP Device Overview…………………………………………………………………… 3 Summary of Intel Cyclone 10 LP Features………………………………………………………………4 Intel Cyclone 10 LP Available Options……………………………………………………………………5 Intel Cyclone 10 LP Maximum Resources ……………………………………………………………… 6 Intel Cyclone 10 LP Package Plan ………………………………………………………………………. 6 Intel Cyclone 10 LP I/O Vertical Migration……………………………………………………………… 7 Logic Elements and Logic Array Blocks…………………………………………………………………. 7 Embedded Multipliers……………………………………………………………………………………… 8 Embedded Memory Blocks…………………………………………………………………………………8 Clocking and PLL…………………………………………………………………………………………….8 FPGA General Purpose I/O…………………………………………………………………………………9 Configuration…………………………………………………………………………………………………9 Power Management………………………………………………………………………………………. 10 Document Revision History for Intel Cyclone 10 LP Device Overview…………………………….10

Intel® Cyclone® 10 LP Device Overview 2

Send Feedback

683879 | 2022.05.27 Send Feedback
Intel® Cyclone® 10 LP Device Overview
The Intel® Intel Cyclone® 10 LP FPGAs are optimized for low cost and low static power, making them ideal for high-volume and cost-sensitive applications.
Intel Cyclone 10 LP devices provide a high density sea of programmable gates, onboard resources, and general purpose I/Os. These resources satisfies the requirements of I/O expansion and chip-to-chip interfacing. The Intel Cyclone 10 LP architecture suits smart and connected end applications across many market segments: · Industrial and automotive · Broadcast, wireline, and wireless · Compute and storage · Government, military, and aerospace · Medical, consumer, and smart energy The free but powerful Intel Quartus® Prime Lite Edition software suite of design tools meets the requirements of several classes of users: · Existing FPGA designers · Embedded designers using the FPGA with Nios® II processor · Students and hobbyists who are new to FPGA
Advanced users who require access to the full IP Base Suite can subscribe to the Intel Quartus Prime Standard Edition or purchase the license separately.
Related Information · Software Development Tools, Nios II Processor
Provides more information about the Nios II 32-bit soft IP processor and Embedded Design Suite (EDS). · Intel Quartus Prime IP Base Suite · Intel Quartus Prime Editions

Intel Corporation. All rights reserved. Intel, the Intel logo, and other Intel marks are trademarks of Intel Corporation or its subsidiaries. Intel warrants performance of its FPGA and semiconductor products to current specifications in accordance with Intel’s standard warranty, but reserves the right to make changes to any products and services at any time without notice. Intel assumes no responsibility or liability arising out of the application or use of any information, product, or service described herein except as expressly agreed to in writing by Intel. Intel customers are advised to obtain the latest version of device specifications before relying on any published information and before placing orders for products or services. *Other names and brands may be claimed as the property of others.

ISO 9001:2015 Registered

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Summary of Intel Cyclone 10 LP Features

Table 1.

Summary of Features for Intel Cyclone 10 LP Devices

Feature

Description

Technology

· Low-cost, low-power FPGA fabric · 1.0 V and 1.2 V core voltage options · Available in commercial, industrial, and automotive temperature grades

Packaging Core architecture

· Several package types and footprints: — FineLine BGA (FBGA) — Enhanced Thin Quad Flat Pack (EQFP) — Ultra FineLine BGA (UBGA) — Micro FineLine BGA (MBGA)
· Multiple device densities with pin migration capability · RoHS6 compliance
· Logic elements (LEs)–four-input look-up table (LUT) and register · Abundant routing/metal interconnect between all LEs

Internal memory blocks

· M9K–9-kilobits (Kb) of embedded SRAM memory blocks, cascadable · Configurable as RAM (single-port, simple dual port, or true dual port), FIFO buffers, or ROM

Embedded multiplier blocks

· One 18 × 18 or two 9 × 9 multiplier modes, cascadable · Complete suite of DSP IPs for algorithmic acceleration

Clock networks

· Global clocks that drive throughout entire device, feeding all device quadrants · Up to 15 dedicated clock pins that can drive up to 20 global clocks

Phase-locked loops (PLLs)

· Up to four general purpose PLLs · Provides robust clock management and synthesis

General-purpose I/Os (GPIOs)

· Multiple I/O standards support · Programmable I/O features · True LVDS and emulated LVDS transmitters and receivers · On-chip termination (OCT)

SEU mitigation

SEU detection during configuration and operation

Configuration

· Active serial (AS), passive serial (PS), fast passive parallel (FPP) · JTAG configuration scheme · Configuration data decompression · Remote system upgrade

Intel® Cyclone® 10 LP Device Overview 4

Send Feedback

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Intel Cyclone 10 LP Available Options

Figure 1.

Sample Ordering Code and Available Options for Intel Cyclone 10 LP Devices –Preliminary

Package Type
F : FineLine BGA (FBGA) E : Enhanced Thin Quad Flat Pack (EQFP) U : Ultra FineLine BGA (UBGA) M : Micro FineLine BGA (MBGA)
Family Variant
L : LP

Operating Temperature
C : Commercial (TJ = 0°C to 85°C) I : Industrial (TJ = -40°C to 100°C)
Extended Industrial (TJ = -40°C to 125°C) A : Automotive (TJ = -40°C to 125°C)

Family Signature

10C L 120 Z F 780 I 8 GES

Optional Suffix

10C : Cyclone 10

Indicates specific device

Member Code

options or shipment method
FPGA Fabric G : RoHS6-compliant packaging

006 : 6,272 logic elements 010 : 10,320 logic elements 016 : 15,408 logic elements 025 : 24,624 logic elements

Core Voltage
Y : Standard voltage (1.2 V) Z : Lower core voltage (1.0 V)

Speed Grade
6 (fastest) 7 8

ES : Engineering sample

040 : 39,600 logic elements

Package Code

055 : 55,856 logic elements 080 : 81,264 logic elements 120 : 119,088 logic elements

FBGA Package Type 484 : 484 pins 780 : 780 pins

UBGA Package Type 256 : 256 pins 484 : 484 pins

EQFP Package Type MBGA Package Type

144 : 144 pins

164 : 164 pins

Related Information
Extended Temperature Device Support Lists the ordering part number of devices that support the extended industrial operating temperature, the devices’ operational speed grade, and Intel Quartus Prime option to set for performing timing analysis at the extended junction temperature range.

Send Feedback

Intel® Cyclone® 10 LP Device Overview 5

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Intel Cyclone 10 LP Maximum Resources

Table 2.

Maximum Resource Counts for Intel Cyclone 10 LP Devices

Resource

Device

Logic Elements (LE)

10CL006 10CL010 10CL016 10CL025 10CL040 10CL055 10CL080 10CL120

6,272

10,320

15,408

24,624

39,600

55,856

81,264 119,088

M9K

Block

126

260

305

432

Memory

Capacity

270

414

504

594

1,134

2,340

2,745

3,888

(Kb)

18 × 18 Multiplier

126

156

244

288

PLL Clock

Maximum I/O Maximum LVDS

176

340

150

325

321

423

525

137

124

132

178

230

Intel Cyclone 10 LP Package Plan

Table 3.

Package Plan for Intel Cyclone 10 LP Devices
The GPIO counts do not include the DCLK pins. The LVDS counts include DIFFIO and DIFFCLK pairs only– LVDS I/Os with both p and n pins. Refer to the related information.

Device

Package

Type

M164

U256

U484

E144

F484

F780

164-pin MBGA 256-pin UBGA 484-pin UBGA 144-pin EQFP 484-pin FBGA 780-pin FBGA

Size 8 mm × 8 mm 14 mm × 14 mm

19 mm × 19 mm

22 mm × 22 mm

23 mm × 23 mm

29 mm × 29 mm

Ball Pitch

0.5 mm

0.8 mm

0.5 mm

1.0 mm

I/O GPIO LVDS GPIO LVDS GPIO LVDS GPIO LVDS GPIO LVDS GPIO LVDS Type

10CL006

—

176

—

10CL010

101

176

—

10CL016

162

340

137

340

137

—

10CL025

—

150

—

10CL040

—

325

124

—

325

124

—

10CL055

—

321

132

—

321

132

—

10CL080

—

289

110

—

289

110

423

178

10CL120

—

277

103

525

230

Related Information
· Why does the Intel Quartus Prime software device pin-out show a different number of pins compared to the Intel Cyclone 10 LP Device Overview?
· How is the LVDS pair count that is published in the Intel Cyclone 10 LP Device Overview calculated?

Intel® Cyclone® 10 LP Device Overview 6

Send Feedback

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Intel Cyclone 10 LP I/O Vertical Migration

Figure 2.

Migration Capability Across Intel Cyclone 10 LP Devices
· The arrows indicate the migration paths. The devices included in each vertical migration path are shaded. Devices with lesser I/O resources in the same path have lighter shades.
· To achieve full I/O migration across devices in the same migration path, restrict I/O usage to match the device with the lowest I/O count.
Package Device
M164 U256 U484 E144 F484 F780
10CL006 10CL010 10CL016 10CL025 10CL040 10CL055 10CL080 10CL120

Note:

To verify the pin migration compatibility, use the Pin Migration View window in the Intel Quartus Prime software Pin Planner.

Logic Elements and Logic Array Blocks

The LAB consists of 16 logic elements (LE) and a LAB-wide control block. An LE is the smallest unit of logic in the Intel Cyclone 10 LP device architecture. Each LE has four inputs, a four-input look-up table (LUT), a register, and output logic. The four-input LUT is a function generator that can implement any function with four variables.

Figure 3.

Intel Cyclone 10 LP Device Family LEs

LAB-Wide

from previous LE synchronous load synchronous clear LE carry-in

data 1

data 2 data 3

Look-Up Table Carry (LUT) Chain

Synchronous Load and

data 4

Clear Logic

labclr1 labclr2 Chip-wide reset (DEV_CLRn)
labclk1 LE Carry-Out
labclk2 labclkena1 labclkena2

Asynchronous Clear Logic
Clock and Clock Enable
Select

Q D ENA CLRN

Row, column, and direct link routing
Row, column, and direct link routing
Local routing Register chain output

Send Feedback

Intel® Cyclone® 10 LP Device Overview 7

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Embedded Multipliers
Each embedded multiplier block in Intel Cyclone 10 LP devices supports one individual 18 × 18-bit multiplier or two individual 9 × 9-bit multipliers. You can cascade the multiplier blocks to form wider or deeper logic structures.
You can control the operation of the embedded multiplier blocks using the following options: · Parameterize the relevant IP cores with the Intel Quartus Prime parameter editor · Infer the multipliers directly with VHDL or Verilog HDL
Intel and partners offer popular DSP IPs for Intel Cyclone 10 LP devices, including: · Finite impulse response (FIR) · Fast Fourier transform (FFT) · Numerically controlled oscillator (NCO) functions
For a streamlined DSP design flow, the DSP Builder tool integrates the Intel Quartus Prime software with MathWorks Simulink and MATLAB design environments.

Embedded Memory Blocks

The embedded memory structure consists of M9K memory blocks columns. Each M9K memory block of a Intel Cyclone 10 LP device provides 9 Kb of on-chip memory. You can cascade the memory blocks to form wider or deeper logic structures.

You can configure the M9K memory blocks as RAM, FIFO buffers, or ROM.

Table 4.

M9K Operation Modes and Port Widths

Operation Modes

Port Widths

Single port

×1, ×2, ×4, ×8, ×9, ×16, ×18, ×32, and ×36

Simple dual port

×1, ×2, ×4, ×8, ×9, ×16, ×18, ×32, and ×36

True dual port

×1, ×2, ×4, ×8, ×9, ×16, and ×18

Clocking and PLL
Intel Cyclone 10 LP devices feature global clock (GCLK) networks, dedicated clock pins, and general purpose PLLs. · Up to 20 GCLK networks that drive throughout the device · Up to 15 dedicated clock pins · Up to four general purpose PLLs with five outputs per PLL
The PLLs provide robust clock management and synthesis for the Intel Cyclone 10 LP device. You can dynamically reconfigure the PLLs in user mode to change the clock phase or frequency.

Intel® Cyclone® 10 LP Device Overview 8

Send Feedback

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

FPGA General Purpose I/O
Intel Cyclone 10 LP devices offer highly configurable GPIOs with these features: · Support for over 20 popular single-ended and differential I/O standards. · Programmable bus hold, pull-up resistors, delay, and drive strength. · Programmable slew rate control to optimize signal integrity. · Calibrated on-chip series termination (RS OCT) or driver impedance matching (RS)
for single-endd I/O standards. · True and emulated LVDS buffers with LVDS SERDES implemented using logic
elements in the device core. · Hot socketing support.
Configuration
Intel Cyclone 10 LP devices use SRAM cells to store configuration data. Configuration data is downloaded to the Intel Cyclone 10 LP device each time the device powers up.
You can use EPCS or EPCQ (AS x1) flash configuration devices to store configuration data and configure the Intel Cyclone 10 LP FPGAs. · Intel Cyclone 10 LP devices support 1.5 V, 1.8 V, 2.5 V, 3.0 V, and 3.3 V
programming voltages and several configuration schemes. · The single-event upset (SEU) mitigation feature detects cyclic redundancy check
(CRC) errors automatically during configuration and optionally during user mode(1).

Table 5.

Configuration Schemes and Features Supported by Intel Cyclone 10 LP Devices

Configuration Scheme Active serial (AS)

Configuration Method Serial configuration device

Decompression Yes

Remote System Upgrade
Yes

Passive serial (PS)

External host with flash memory

Yes

Download cable

Yes

—

Fast passive parallel (FPP)

External host with flash memory

—

Yes

JTAG

External host with flash memory

—

Download cable

—

Related Information
Configuration Devices Provides more information about the EPCS and EPCQ configuration devices.

(1) User mode error detection is not supported on 1.0 V core voltage Intel Cyclone 10 LP device variants.

Send Feedback

Intel® Cyclone® 10 LP Device Overview 9

Intel® Cyclone® 10 LP Device Overview 683879 | 2022.05.27

Power Management
Intel Cyclone 10 LP devices are built on optimized low-power process: · Available in two core voltage options: 1.2 V and 1.0 V · Hot socketing compliant without needing external components or special design
requirements

Document Revision History for Intel Cyclone 10 LP Device Overview

Document Version
2022.05.27 2020.05.21
2019.12.30

Changes
Removed instances of Enpirion from the Power Management section.
At the package plan table, added description and related information links that explain how the GPIO and LVDS pins are counted.
Added related information link to the Extended Temperature Device Support page that provides a list of devices that support the extended temperature range, their operational speed grade, and related Intel Quartus Prime settings for timing analysis.

Date May 2017

Version 2017.05.08

Initial release.

Changes

Intel® Cyclone® 10 LP Device Overview 10

Send Feedback
