TIPS:
- To keep the light (except for daytime) at 100% brightness for 7~9 hours: use Manual Mode.
- To keep the light (except for daytime) always at 40% brightness and at 100% when someone is around the light: use Auto Mode.
- To test at any time (daytime or night) if the motion detection works properly: use Test Mode.
| Functions: | Feature: | |||
| Basic Function | Environment Luminance/MotionDetection | Brightness 40% | Brightness 100% | LED Indicator (Red Light) |
| 1. Start-Up Time | The first time powered on, the light needs start-up time (Duration: 7-23s). | |||
| After start-up, the light automatically enters Test Mode. | ||||
| 2. Test Mode | Daytime/Night | Light ON | ||
| Motion Detected | · Light ON · Then decrease to 40% without motion detection 50-70s after | 3 times flashing | ||
| After Test Mode, the light automatically enters Auto Mode (Duration: 100-140s). To skip Test Mode and enter Auto Mode: Switch off and on once. | ||||
| 3. Auto Mode | Low (Night) | Light always ON | ||
| Motion Detected (During Night) | · Light ON · Then decrease to 40% without motion detection 50-70s after | 3 times flashing | ||
| High (Daytime) | Light OFF 20-40s after high luminance triggered | |||
| To enter Manual Mode: Switch off and on once at Auto Mode To exit Manual Mode and back to Auto Mode: Switch off and on again. | · Quickly flash 6 times when entering Manual Mode · Quickly flash 3 times when exiting Manual Mode | |||
| 4. Manual Mode | Low (Night) | Light ON for 7-9h | ||
| High (Daytime) | Light OFF 20-40s after high luminance triggered | |||
| To restart and back to Test Mode: Switch off for 5s or longer and then switch on. | ||||
| Specification Details: | ||||
| Motion Detection Range | Working Temp. | Environment Luminance Range | ||
| Tested at 25°C Mounted at 1.8-2.2M | Length: 35 ft (Max.) Angle: 220° (Max.) | -30′ C–50′ C | Low Luminance Triggered: 5-90 lux | High Luminance Triggered: 800 lux (Max.) |
