Sortwise Sw-pocs-mg004-l 2-tier Left Opening Kitchen Cabinet Instruction Manual

SW-POCS-MG004-L 2-Tier Left Opening Kitchen Cabinet

Product Information:

This product is a swing tray assembly designed for cabinets. It
consists of various components including a middle tube holder, side
supports, gas supports, long arm supports, short arm supports,
plastic clips, and screws.

  • Size of Product: 2054mm (Width) x 520mm (Depth) x 450mm
    (Height)
  • Contents:
    • 1 Middle Tube Holder
    • 2 Trays
    • 5 Side Supports
    • 2 Gas Supports
    • 2 Long Arm Supports
    • 2 Soft Dampers
    • 4 Short Arm Supports
    • 8 Plastic Clips
    • 4 ST4*16 Screws
    • 2 M5*20 Screws
    • 4 M5*10 Screws
    • 8 M4*6 Screws

Product Usage Instructions:

  1. Fix the bottom and top of the middle tube holder to the cabinet
    using 5 ST4*16 screws each.
  2. Fix the middle tube holder to the cabinet using 2 M5*20
    screws.
  3. Fix the side support to the cabinet using 4 ST4*16 screws.
  4. Attach one long arm support to the middle tube holder using 4
    M5*10 screws.
  5. Attach the other long arm support to the middle tube holder
    using 4 M5*10 screws.
  6. Attach one short arm support to the side support using 4 M5*10
    screws.
  7. Attach the other short arm support to the side support using 4
    M5*10 screws.
  8. Attach the gas supports to the long arm supports and short arm
    supports using 2 M4*6 screws each.
  9. Insert the 2 trays into the long arm supports and short arm
    supports.
  10. Attach the 2 gas supports one by one as shown in Drawing NO.
    1.
  11. Click the 4 plastic clips one by one on one side of the long
    arm supports and short arm supports as shown in Drawing NO. 2.

Swing Tray Assembly Instruction(LEFT)

2

Size of Product W*D*H

Min

Min Min Net Depth

Door Cabinet of cabinet

Open Helght

D

3252″×17″×(26″30″) 1621″

28″

810×427×(650750mm) 414mm 700mm

2054″ 520mm

5

Contents

3

64

8

1-Middle Tube holder 1pc 5-Side Support 1pc M4*6 8pcs

2-Tray 2pc

6-Gas Support 2pc M5*10 16pcs

7

3-Long Arm Support 2pc 7-Soft Damper 2pcs M5*20 2pcs

4-Short Arm Support 2pc 8-Plastic Clip 4pcs ST4*16 14pcs

1
Screw ST4*16 4pcs

253″

18″

Screw M5*20 2pcs

450mm

32mm

153″
40mm
2.Fix the bottom of middle tube holder and cabinet with 5pcs screws ST4*16 as the requested size, fix the top of middle tube holder and cabinet as same , then fix the middle tube holder with 2pcs screws M5*20 shown as the picture.

450m1m8″
Screws M5*10 4pcs

Screw ST4*16 5pcs

554″ 144mm

554″ 144mm

554″ 144mm

4″

5

20mm

151″

30mm

1. Fix the side support and cabinet with 4pcs screws ST4*16 as the requested size shown as the picture.

414mmimn162 1″

3.Fix one long arm support with middle tube holder with 4pcs screws M5*10 as show in picture , the fix another one long arm support as same shown as the picture.

Screws M5*10 4pcs
4.Fix one short arm support with side support with 4pcs screws M5*10 as show in picture , the fix another one short arm support as same shown as the picture.

5.Fix the gas support and 2pcs long arm support & 2pcs short arm support with 2pcs screws M4*6 each shown as the picture.

Screws M4*6 8pcs
2

6.Insert the 2pcs tray into the long arm supports & short arm supports shown as the picture.picture.
Drawing NO.1
7 6
7.Fix the 2pcs gas supports one by one shown as Drawing NO. 1 .

8

2221″ 565mm

min 22″ 550mm

Drawing NO.2
7 6
8.Click the 4pcs plastic clips one by one on one side of long arm support & short arm support shown as Drawing NO. 2 .
min 36″ 900mm

min 18″ 450mm
