RWBHS150RH Wall Basin Hostess System
Product Information
The Circa Wall Basin Hostess System is a plumbing fixture
designed for wall-mounted basins. It comes with various product
codes and sizes, including RWBHS150RH (150mm), RWBHS200RH (200mm),
and RWBHS250RH (250mm). There is also a Vertex version available
for each size.
The product is compliant with AS/NZS 3718:2005 standards and has
a water rating of 5.5 litres per minute, making it water-efficient.
It is manufactured by Sussex Taps Pty Ltd, licensed under AS/NZS
6400 Licence No. 0124.
Product Usage Instructions
Rough-In Plumbing Mounting Guide
- The Masterfit system will be supplied with the spindles
pre-installed. - Prepare a nogging and secure it 28-32mm back from the front of
the wall using the provided screws (x4) onto the stud. Refer to
Figure 1 for visual guidance. - The Masterfit (in-wall) will be marked “This Side Up” to
indicate its orientation. - Using the provided screws (x4), mount the Masterfit (in-wall)
to the nogging. - Ensure the Masterfit is level and square to the wall
studs.
Pipe Connections
Proceed with the following steps for fitting off:
- Seal the wall around the locking sleeve and immediately fit the
dress ring. - Fit the handle body onto the spindle, ensuring it is fully
engaged. Note the set screw contact point. Refer to Figure 1B for
visual guidance. - Secure the handle body by tightening the set screw using the
provided 2mm Allen key. Tighten it well. - After completing the installation, establish water supply,
check the function of the tapware, and ensure there are no water
leaks.
Please note that tapware installation should be done by a
licensed plumber in accordance with AS/NZS 3500:2003. The
recommended working water pressure is 300-500 kpa, and the maximum
water temperature is 65 degrees Celsius.
Circa
Wall basin hostess system
1
“ROUGH-IN” View from above
NOGGING
THIS SIDE UP
OUTLET
WALL
STUD
90
IN-WALL BODY MASTERFIT
AS/NZS 3718:2005 LIC. 20081
28-32
Wall Covering 25mm
LOCKING SLEEVE
DRESS RING
HANDLE
1A
Pipe Connections
OUTLET
1/2″ BSP
HOT IN
1/2″ BSP
COLD IN
sussextaps.com.au
Product code
RWBHS150RH Wall basin hostess syst 150mm RWBHS200RH Wall basin hostess syst 200mm RWBHS250RH Wall basin hostess syst 250mm
RWBHS150RH-V Wall basin hostess syst 150mm – Vertex RWBHS200RH-V Wall basin hostess syst 200mm – Vertex RWBHS250RH-V Wall basin hostess syst 250mm – Vertex
Rough in plumbing (MASTERFIT) mounting guide
– The Masterfit will be supplied with the Spindles pre-installed. – Prepare a nogging and secure 28-32mm back from the front Using the screws (x4) of the stud (See Fig.1) – The Masterfit (in-wall) will be marked “This side Up” to Ensure the Masterfit is indicate orientation. – Using the screws (x4) provided, mount the Masterfit (in-wall) to the Nogging. – Ensure the Masterfit is level and square to the Wall Studs.
Pipe connections
– The Masterfit is supplied with coloured thread Caps to protect and identify the Hot and Cold inlet connections. – All lines must be free from any dirt and debris before connecting to the Masterfit. Flush all water feed lines. – Connect Hot and Cold lines to the corresponding 1/2″ BSP ports of the Masterfit. (See Fig.1A) – Do not remove or disturb any factory fitted Pressure Plugs or Fixings. – Once all water connections are made, use the “Spindle Handle Adapter” and check Hot/Cold water operation. – Check all fittings and connections for leaks. – Store the Dress Kit in a safe place until required for Fit off.
Fitting off
– Seal the wall around the Locking Sleeve and immediately fit the Dress Ring. – Fit the Handle Body, the Handle Body must be fully engaged onto the Spindle; note the Set Screw contact point.
(See Fig.1B) – Secure the Handle body by tightening the Set screw using the 2mm Allen key provided. (Tighten well) – After completing the installation, establish water supply, check function of Tapware and ensure no water leaks.
AS/NZS 3718:2005 LIC. 20081
The more stars the more water efficient
WATER RATING
www.waterrating.gov.au
5.5 litres per minute
In accordance with AS/NZS 6400 Licence No. 0124 Sussex Taps Pty Ltd
Tapware is to be installed by a Licensed Plumber in accordance with AS/NZS 3500:2003 Recommended working water pressure 300-500 kpa. Maximum water temperature is 65 deg.c
