VWBMS160RH Voda Wall Basin Mixer Outlet System
Product Information
The Voda Wall Basin Mixer Outlet System Dress Kit is a product
designed for wall-mounted basin mixers. It comes with various
product codes depending on the length of the outlet system:
VWBMS160RH (160mm), VWBMS200RH (200mm), and VWBMS250RH (250mm). The
product is manufactured by Sussex Taps Pty Ltd and is compliant
with AS/NZS 3718:2005 standards. It has a water rating of 5.0
litres per minute, making it highly water efficient.
The rough-in version of the product is also available, with the
same product codes. It is designed for plumbing installations and
requires proper calculation of the finished wall thickness, which
should not exceed 30mm. For walls thicker than 30mm, alternative
options can be obtained by contacting the manufacturer.
The recommended working water pressure for this product is
between 300-500 kpa, and the maximum water temperature is 65 deg.c.
It is important to have the product installed by a licensed plumber
in accordance with AS/NZS 3500:2003 standards.
Product Usage Instructions
- Mixer Dress Kit:
- Apply sealing tape (Teflon) to the male thread.
- Place the Dress Ring and Dress Flange over the prepared male
thread. - Fit the Outlet.
- To complete the installation, operate the Mixer(s) and check
the flow of both hot and cold water from the Outlet. - Check all fittings and fixtures for water leaks.
- Apply silicone sealant to the bath outlet.
- Attach the handle body.
- Refer to the specific product code for the appropriate
installation process.
Plumber Notes
- On-site high-pressure line testing must be conducted with the
Mixer in the closed position (STATIC TEST ONLY). - Under no circumstances should the Mixer be opened when
exceeding the maximum stated water pressure. - After testing, do not relieve any high pressure by opening the
Mixer. - Exposing the internals of the Mixer Cartridge to higher than
specified water pressures will void the manufacturer’s
warranty.
Voda
Wall basin mixer outlet system Dress kit
Product code: CBM
1
Stud Face
Finished Wall Surface
Handle Pin
Apply Silicone
Set Screw
NOGGING t
80 mm B/Plate
64mm Dress Ring
2
NOGGING t
Stud Face Finished
Wall Surface Backplate
Dress Ring
Bath Outlet
Apply Silicone
Handle Body
Product code
VWBMS160RH Wall basin mixer outlet system 160mm VWBMS200RH Wall basin mixer outlet system 200mm VWBMS250RH Wall basin mixer outlet system 250mm
1. Mixer dress kit
– Remove Mixer protective cover. – Using silicone, seal the wall surface around the Mixer and Outlet threads. – Apply a small amount of silicone to the rear of the backplate prior to mounting onto the wall. – After Backplate has been mounted, fit the Mixer Dress Ring. – Fit the handle body onto the Mixer Cartridge Lever ensuring the Handle is fully engaged. – Secure the Handle Body by tightening the Set screw using the Allen Key provided (tighten well). – Attach the Handle Pin. Note: Apply a small amount of silicone or mild adhesive (Loctite) to the thread of the Handle Pin to assist in preventing the Pin from becoming loose).
2. Outlet fit off
– Apply sealing tape (Teflon) to male thread. – Place Dress Ring and Dress Flange over prepared male thread. – Fitthe Outlet. To complete the installation, operate the Mixer(s) checking the flow of both hot and cold water from Outlet. Check all fittings and fixtures for water leaks.
sussextaps.com.au
AS/NZS 3718:2005 LIC. 20081
The more stars the more water efficient
WATER RATING
www.waterrating.gov.au
5.0 litres per minute
In accordance with AS/NZS 6400 Licence No. 0124 Sussex Taps Pty Ltd
Tapware is to be installed by a Licensed Plumber in accordance with AS/NZS 3500:2003 Recommended working water pressure 300-500 kpa. Maximum water temperature is 65 deg.c
Copyright © Sussex Taps.
Voda
Wall basin mixer outlet system Rough-in
Product code: CBM
1 View f rom above
90
NOGGING
Stud face
30-32mm
Wall Covering Max. 30mm
Pipe Connections Outlet
Back Plate
1/2″ BSP Male Outlet 1
Hot
Mixer
Cold
Outlet
Min. 8mm
This side UP
70 Mixer
Dress Ring
Handle Body
Product code
VWBMS160RH Wall basin mixer outlet system 160mm VWBMS200RH Wall basin mixer outlet system 200mm VWBMS250RH Wall basin mixer outlet system 250mm
Rough in plumbing
– Prior to installing, calculate the finished wall thickness, maximum is 30mm thick, contact manufacturer for further options.
– If Wall thickness is greater than 30mm, contact manufacturer for further options. – Prepare a Nogging to be fixed parallel between the Wall Studs. – The Nogging must be fitted to enable the base of the Masterfit to be 30-32mm back from the Stud Face. – The Masterfit will be marked “This side Up” to indicate orientation. – Using the screws (x4) provided, mount the Masterfit to the Nogging. Ensure the Masterfit is level and square.
Pipe connections
– The Hot and Cold ports are marked on the Masterfit. (Mixers have individual Hot/Cold inlet ports). – Flush all water feed lines. All lines must be free from any dirt and debris before connecting to the Masterfit. – Connect Hot and Cold lines to the corresponding 1/2″ BSP ports of the Masterfit. (see Drawing) – Do not remove any factory fitted pressure plugs or Fixings. – Once all water connections are made, check Hot/Cold water flow by operating the Mixer Cartridge. – Check all fittings and fixtures for leaks. – Leave the Mixer(s) in the closed position and replace the Mixer protective cover. – Store the Dress Kit in a safe place until required (see Dress Finishing Guide)
Plumber note
– On-site high pressure line testing must be conducted with the Mixer in the closed position. (STATIC TEST ONLY) – Under no circumstances is the Mixer to be opened when exceeding the maximum stated water pressure. – At the completion of the testing, do not relieve any high pressure by opening the Mixer. – Exposing the internals of the Mixer Cartridge to higher than specified water pressures, will void the
manufacturer’s warranty.
sussextaps.com.au
AS/NZS 3718:2005 LIC. 20081
Tapware is to be installed by a Licensed Plumber in accordance with AS/NZS 3500:2003 Recommended working water pressure 300-500 kpa. Maximum water temperature is 65 deg.c
Copyright © Sussex Taps.
