SP500W Power Inverter
Product Information
PNI SP500W / PNI SP1000W / PNI SP2000W
Power Inverter / Invertor de tensiune
The PNI SP500W, PNI SP1000W, and PNI SP2000W are power inverters
that convert DC power from a battery into AC power that can be used
to run various electronic devices. They are designed to provide a
reliable and stable power supply in various applications, such as
camping, road trips, emergency situations, and more.
Main Features
- Output wave: Pure sine wave
- Total harmonic distortion: THDV 3% (100% linear load)
- Overload capacity: >120%
- Protections: undervoltage, overvoltage, overheating, overload,
short circuit
Recommended Battery Parameters
- Type: Plumb-acid/Lithium
- Voltage: 12V
- Maximum current: 100A, 150A, 200A (depending on the model)
- Under/over voltage protection: 10V/15.5V
- Voltage warning level: 10.5V
- Cut-off level (interrupt): 9.7V-10.2V
- Recovery level: 12.5V
General Parameters
- LED indicators: Green, Red
- Active cooling: Fan
- Working temperature: -10°C
to 40°C - Working humidity: 90% (non-condensing)
Declaration of Conformity
The PNI SP500W, SP1000W, and SP2000W power inverters comply with
the Directive EMC 2014/30/EU. The EU Declaration of Conformity can
be accessed at the following Internet addresses:
- PNI
SP500W Declaration of Conformity - PNI
SP1000W Declaration of Conformity - PNI
SP2000W Declaration of Conformity
Product Usage Instructions
1. Connecting the Power Inverter
Before connecting the power inverter, ensure that the input
voltage matches the recommended battery parameters mentioned
above.
- Connect the positive (+) terminal of the battery to the
positive (+) terminal of the power inverter. - Connect the negative (-) terminal of the battery to the
negative (-) terminal of the power inverter.
2. Operating the Power Inverter
Once the power inverter is properly connected, follow these
steps to operate it:
- Turn on the power inverter using the power switch.
- Connect your electronic device(s) to the AC output socket(s) of
the power inverter. - Ensure that the total power consumption of your device(s) does
not exceed the overload capacity of the power inverter.
3. Monitoring and Troubleshooting
The power inverter is equipped with LED indicators to provide
information about its status:
- Green LED: Indicates that the power inverter is operating
normally. - Red LED: Indicates a fault or protection mode (e.g.,
undervoltage, overvoltage, overheating, overload, short
circuit).
If the red LED is lit or flashing, refer to the user manual for
troubleshooting steps or contact customer support for
assistance.
4. Safety Precautions
When using the power inverter, please keep the following safety
precautions in mind:
- Do not expose the power inverter to moisture or water.
- Avoid using the power inverter in extreme temperatures or high
humidity conditions. - Ensure proper ventilation around the power inverter to prevent
overheating. - Do not connect devices with a power rating higher than the
overload capacity of the power inverter. - Disconnect the power inverter from the battery when not in use
to prevent battery drain.
For more detailed information on operating and maintaining the
power inverter, please refer to the user manual provided.
PNI SP500W / PNI SP1000W / PNI SP2000W
Power inverter / Invertor de tensiune
EN User manual ………………………………………
3
RO Manual de utilizare ……………………………..
13
English
Main features
· Pure sine wave output · THD (Total Harmonic Distorsion) <3% · Protections: undervoltage, overvoltage, overheating, overload, short
circuit
Introduction
SP series PNI inverters convert 12V DC input voltage into 230V AC 50Hz voltage. We recommend that you read this manual carefully before putting the product into operation.
Warnings
· Do not store the product in environments with corrosive gases, high humidity and high temperature, dust and electromagnetic interference.
· In the event of a fault, do not open or repair this product by yourself. Call a specialized service center.
Symbol convention
Symbol
Signification
Potential serious danger that could cause casualties.
Potential medium danger that could cause minor injuries. Potential danger that could cause device failure, data loss, device performance impairment, and other unexpected losses.
3
User manual
English
Safety precaution
We recommend that you read this chapter carefully before using the product, in order to avoid personal injury and product damage.
Symbols description
Safety sign
Antistatic sign
Danger, electric shock
The inverter generates high temperatures during usage. Carefully read the installation and operating instructions to avoid personal injury or damage to the equipment. Warning: We do not take responsibility for non-compliance with safety measures.
Batteries of different sizes and from different manufacturers may have different voltage. Make sure that the inverter voltage corresponds to the battery voltage. Contact the seller for more details. Any change in the configuration or structure of the system may affect its proper functioning.
Danger High Voltage!
Touching the inverter in a humid or wet object (or hands) can put you in a dangerous situation. 1. Do not open the product’s housing under any circumstances. The input and output of the inverter presents a high voltage danger. Opening the inverter and touching the internal components can put you in a dangerous situation. 2. Before maintenance, you must completely disconnect the power supply of the inverter. It is recommended that you check both the input and output of the inverter with a voltmeter to ensure that it is disconnected properly. 3. Even if the power is completely disconnected, residual energy may remain in the inverter. Leave the inverter disconnected for 10 minutes to ensure that the system is completely discharged.
User manual
4
English
4. Keep the inverter packaged before installation and use. 5. Do not manipulate the inverter in the presence of electrical conductors: metal watch, bracelets, rings. 6. The inverter must be repaired, installed and maintained only by qualified personnel.
Inductive load and half-wave rectification load attentions!
We recommend choosing an inverter with a power 2-3 times higher than the half-wave rectification or inductive load.
Avoid antistatic danger
We recommend that you wear antistatic wrist strap to protect sensitive parts from static discharge equipment.
Do not disconnect the inverter when turned on
Do not install or disconnect the appliance while it is switched on. Pay maximum attention when connecting the power cords.
Use only regulated batteries
Use only regulated batteries. Use of unregulated batteries may result in product malfunction.
Use the battery according to the manufacturer’s rules
Use the battery according to the connection rules provided by its manufacturer. Improper operation can endanger you. 1. Do not shortcircuit the wires. The connections must be made very tightly. 2. Do not touch both battery terminals or wires connected to them at the same time. 3. Avoid spilling electrolyte. The electrolyte is corrosive for metal and poses a short-circuit hazard. 4. Keep the battery safe, away from fire or a source of sparks.
Avoid fans harm
Avoid accidental blocking of the fans. Do not use tools or your fingers to stop them.
Keep the inverter well ventilated Make sure that the ventilation and air exhaust outputs of the inverter are
5
User manual
English
not blocked in any way. Also, do not mount the passive radiator part of the housing attached to a wall, ceiling or floor, but at a distance that allows air to pass.
Inverter installation
Enviroment conditions
Keep the inverter in a dry and ventilated environment. Keep the inverter away from moisture, dust, heat, sunlight, volatile gas or high salinity.
Caution
The operating temperature range of the product is -26°C ~ + 60°C. Do not overload the inverter in conditions with temperatures above 40°C. If you use the inverter excessively at temperatures above 40°C, reduce the consumption by 10% for each degree above 40°C.
The optimum operating temperature of the inverter is between + 20°C ~ + 30°C. If used at temperatures above 30°C, the battery life will decrease considerably. Below 20°C the electric storage time will decrease.
Keep safety distance
The inverter must be mounted at least 60 mm from the surrounding walls, with the cooling radiator unobstructed by other objects. Do not cover the side panels of the inverter to ensure efficient cooling and to avoid overheating.
The electric cables connection
Make sure the power button of the inverter is OFF. Observe the polarity of the wires and do not connect them in reverse to avoid shorting the inverter. Follow these steps to connect the inverter cables: 1. Switch off the inverter with the ON / OFF button. 2. Connect the wires to the battery terminals respecting the polarity. 3. Make sure that the 2 cables are connected tightly, to avoid overheating.
User manual
6
English
4. Connect the load to the Schuko socket. 5. After making sure all connections are made correctly, turn on the inverter. If the green LED indicator lights up, it means that the output voltage is correct and the inverter is working properly.
The correct connection of the inverter is shown in the following diagram.
Caution
1. Do not use the AC output of the inverter to connect it to the 230V mains, so as not to burn the inverter. 2. Connect the loads one by one and do not exceed the declared maximum power of the inverter. 3. For inductive loads choose an inverter with a maximum power 2-3 times higher. 4. It is recommended to start the car only with the inverter turned off, because this procedure will consume a lot of current and can affect the inverter. 5. The inverter must be mounted in a ventilated place, must not be covered and must be protected from access by people. 6. Do not connect the inverter to discharged, defective or old batteries, as this may cause the inverter to burn out.
7
User manual
About battery
English
A storage battery or accumulator is a device that generates energy following a chemical process. Make sure you have chosen a suitable battery for this inverter, to ensure a correct and optimal operation.
Battery preformance index
1. Capacity: Represents the amount of energy at maximum power composed of the discharge current multiplied by the discharge time. Capacity = Discharge current (I) x Discharge time (H) 2. Discharge rate: Represents the speed of each discharge current per specific time 3. Discharge current: The discharge current is the output current. It is usually expressed in Amperes or volume multiplied by a coefficient. 4. Final discharge voltage: Represents the voltage when the battery is not discharged. It is usually about 1.75V / cell 5. Nominal capacity: Represents the capacity after 20 hours of unloading. 6. Self-discharge rate: The battery is discharged even if it is not used. The unit is C / unit.
Choosing the right battery
Because inverters need strong current when operating, the maximum capacity and current of the battery are factors that determine the efficiency at which the inverter operates (50% – 100%). These factors can also damage the battery.
Battery storage capacity depends on the maximum discharge current: Maximum discharge current = Rated power / (storage voltagex0.85) Battery storage capacity = average discharge current discharge time
Example: PNI SP1000W has a rated power of 1000W, 12V input voltage: Average discharge current = 1000 / (12×0.85) = 98A If kept on for 2 hours: Battery storage capacity = 98×2 = 196 Ah
User manual
8
English
Choose a battery with a capacity greater than 196 Ah.
Recommended values for the batteries
Invertor SP500W SP1000W SP2000W
Power (W) 500 1000 2000
Recommended battery 12V, 100Ah 12V, 150Ah 12V, 200Ah
9
User manual
English
Troubleshooting
The inverter does not turn on and the Power LED does not light up
The inverter is under protection and the red error LED (Fault) lights up
1. The battery is defective 1. Replace the battery
2. The battery
2. Connect the battery
connection is abnormal carefully
3. The fuse is blown
3. Change the fuse
The inverter is protected 1. Reduce the number
and the red Fault LED of connected consumers
is on.
and restart the inverter.
1. The inverter enters 2. Inductive consumers
protection when the total (motors, pumps) have
number of consumers a very high starting
exceeds the rated power consumption. Choose an
of the inverter.
inverter with a nominal
2. The starting power of power 4-5 times higher
the consumers is higher in these cases.
than the declared peak 3. If the battery voltage
power for the inverter. rises above the minimum
The inverter enters
protection level,
protection.
the inverter restarts
3. The battery voltage automatically. (or change
is too low. The inverter the battery).
triggers surge protection. 4. If the battery
4. The battery voltage voltage drops below the
is too high. The inverter maximum protection
triggers overvoltage
level, the inverter
protection.
restarts automatically (or
5. The inverter
change the battery).
temperature is too high. 5. Close the inverter
for 15 minutes, check
and clean the fans and
side vents and keep
ventilation space around
the housing.
User manual
10
English
The inverter does not work at 100% load
1. The wires between the 1. Shorten the threads or
battery and the inverter use thicker threads. We
are too long.
recommend using the
2. The connection to the wires in the package.
battery / inverter is weak. 2. Check and tighten
the connectors on the
inverter and battery.
If the inverter does not work after applying the above solutions, we recommend that you contact the Seller, Importer or Service Representative, consulting the warranty certificate. Do not unpack the product as you will lose the product warranty.
We recommend a regular maintenance of the product to prolong its life. 1. Avoid using the inverter in humid, dusty environments with too high a temperature. 2. Avoid subjecting the product to mechanical shocks 3. Periodically check cables and connections 4. Periodically clean the inverter fans.
11
User manual
English
Technical specifications
SP500W
SP1000W
SP2000W
Input voltage
12V DC
Output power
500W
1000W
2000W
Output voltage
230V AC
Frequency
50Hz/60Hz
Transfer efficiency
>88%
Output wave
Pure sine wave
Total harmonic distortion
THDV 3% (100% linear load)
Overload capacity
>120%
Protections
undervoltage, overvoltage, overheating, overload, short circuit
Recommended battery parameters
Type
Plumb-acid/Litiu
Voltage
12V
Maximum current
100A
150A
200A
Under / over voltage protection
10V/15.5V
Voltage warning level
10.5V
Cut-off level (interrupt)
9.7V-10.2V
Recovery level
12.5V
General parameters
LED indicators
Green, Red
Active cooling
Fan
Working temperature
-26°C ~ +60°C
Working humidity
90% (non-condensing)
User manual
12
Romana
Caracteristici de baza
· Forma de unda de iesire: sinusoida pura · THD (Total Harmonic Distorsion) <3% · Protectie la subtensiune, supratensiune, supraincalzire, suprasarcina,
scurtcircuit
Introducere
Invertoarele PNI din seria SP transforma tensiunea de intrare 12V DC in 230V AC 50Hz. Va recomandam sa cititi cu atentie acest manual inainte de punerea in functiune a produsului.
Atentionari
· Nu tineti produsul in medii cu gaze corozive, cu humiditate si temperatura mare, cu praf si interferente electromagnetice.
· In caz de defectiune nu desfaceti si nu reparati singur acest produs. Apelati la un centru service specializat.
Semnificatia simbolurilor
Simbol
Semnificatie
Potential pericol grav care ar putea cauza victime.
Potential pericol mediu ca gravitate care ar putea cauza vatamari usoare. Potential pericol care ar putea cauza defectarea dispozitivului, pierderea de date, alterarea performantelor dispozitivului si alte pierderi nepravazute.
13
Manual de utilizare
Romana
Masuri de siguranta
Va recomandam sa cititi cu atentie acest capitol inainte de utilizarea produsului, pentru a evita accidentarea personala si defectarea produsului
Descriere simboluri
Semn de siguranta
Semn antistatic
Pericol de electrocutare
Invertorul genereaza temperaturi inalte in timpul functionarii. Cititi cu atentie instructiunile de montaj si utilizare, pentru e evita ranirea personala sau deteriorarea echipamentului. Atentie: Nu ne asumam raspunderea pentru nerespectarea masurilor de siguranta.
Baterii de dimensiuni diferite si de la producatori diferiti pot avea tensiune diferita. Asigurati-va ca tensiunea invertorului corespunde cu tensiunea bateriei. Contactati vanzatorul pentru mai multe detalii. Orice modificare a configuratiei sau structurii sistemului poate afecta functionarea corecta a acestuia.
Pericol tensiune mare!
Atingerea cu un mediu umed a invertorului va poate pune intr-o situatie de pericol. 1. Nu desfaceti produsul in nici o situatie. Intrarea si iesirea de curent de pe invertor prezinta pericol de tensiune inalta. Desfacerea invertorului si atingerea componentelor interne va pot pune intr-o situatie de pericol. 2. Inainte de operatiunile de mentenanta, trebuie sa deconectati complet alimentarea invertorului. Este recomandat sa verificati cu un voltmetru atat intrarea cat si iesirea invertorului pentru a va asigura ca este deconectat. 3. Chiar daca alimentarea este deconectata complet, poate ramane energie reziduala in invertor. Lasati invertorul deconectat timp de 10 minute pentru a
Manual de utilizare
14
Romana
va asigura ca sistemul este descarcat complet. 4. Pastrati invertorul impachetat inainte de instalare si utilizare. 5. Nu manipulati invertorul in prezenta unor conductori electrici: ceas metalic, bratari, inele. 6. Invertorul trebuie fixat, instalat si intretinut doar de personal calificat.
Atentie la sarcinile inductive si la rectificari de jumatate de unda
Va recomandam sa alegeti un invertor cu o putere de 2-3 ori mai mare decat puterea consumatorilor de tip inductiv sau jumatate de unda modificata.
Evitare pericol antistatic
Va recomandam sa purtati bratara antistatica conectata la impamantare pentru a proteja partile sensibile ale echipamentului de descarcari statice.
Nu deconectati produsul conectat la tensiune si pornit
Nu instalati sau deconectati aparatul cat timp acesta este pornit. Acordati atentie maxima la conectarea firelor de alimentare.
Utilizati doar baterii reglementate
Utilizati doar baterii reglementate. Utilizarea unor baterii nereglementate poate duce la nefunctionalitatea produsului.
Utilizati bateria respectand regulile producatorului
Utilizati bateria respectand regulile de conectare oferite de producatorul acesteia. Operarea incorecta va poate pune in primejdie. 1. Nu scurtcircuitati firele. Legaturile trebuie sa fie executate foarte strans. 2. Nu atingeti simultan ambele borne ale bateriei sau fire conectate la acestea. 3. Evitati varsarea lichidului electrolitic. Electrolitul este coroziv pentru metal, si reprezinta pericol de scurtcircuit. 4. Pastrati bateria in siguranta, departe de foc sau sursa de scantei.
Atentie la ventilatoare
Evitati blocarea accidentala a ventilatoarelor. Nu utilizati unelte sau degetele pentru oprirea aceastora.
Montati echipamentul intr-o zona aerisita
Asigurati-va ca zonele de ventilatie si de evacuare aer ale invertorului nu sunt obturate in nici un fel. De asemenea, nu montati partea de radiator pasiv
15
Manual de utilizare
Romana
a carcasei lipita de un perete, tavan sau podea, ci la o distanta ce permite trecerea aerului.
Instalarea invertorului
Conditii mediu de instalare
Pastrati invertorul in mediu uscat si ventilat. Pastrati invertorul departe de umezeala, praf, caldura, lumina soarelui, gaz volatil sau cu salinitate ridicata.
Precautii
Intervalul de temperatura de functionare a produsului este -26°C ~ + 60°C . Nu solicitati invertorul la maxim, la temperaturi de peste 40°C. Daca utilizati excesiv invertorul la temperaturi de peste 40°C, scadeti consumul cu 10% pentru fiecare grad peste 40°C.
Temperatura optima de functionare a invertorului este intre +20°C ~ +30°C. Daca se utilizeaza la temperaturi de peste 30°C, autonomia bateriei va scadea considerabil. Sub 20°C va scade timpul de acumulare electrica.
Distanta de siguranta
Invertorul trebuie montat la minim 60mm de peretii inconjuratori, cu radiatorul de racire neobturat de alte obiecte. Nu acoperiti panourile laterale ale invertorului pentru a asigura o racire eficienta si pentru a evita supraincalzirea acestuia.
Conectarea cablurilor electrice
Asigurati-va ca butonul de power al invertorului este pe OFF (oprit). Respectati polaritatea firelor si nu le conectati invers, pentru a evita scurtcircuitarea invertorului. Urmariti urmatorii pasi pentru conectarea cablurilor invertorului: 1. Opriti invertorul din butonul ON/OFF (Pornit/Oprit). 2. Conectati firele la bornele bateriei respectand polaritatea. 3. Asigurati-va ca cele 2 cabluri sunt conectate strans, pentru a evita supraincalzirea acestora. 4. Conectati consumatorii la priza Schuko.
Manual de utilizare
16
Romana
5. Dupa ce va asigurati ca toate conexiunile sunt facute corect, porniti invertorul. Daca indicatorul LED verde se aprinde, inseamna ca tensiunea de iesire este corecta si invertorul functioneaza corect.
Conectarea corecta a invertorului este prezentata in urmatoarea schema.
Atentionari
1. Nu utilizati iesirea de curent alternativ a invertorului pentru conectarea la reteaua nationala de 230V, ca sa nu ardeti invertorul. 2. Conectati consumatorii pe rand si nu depasiti puterea maxima declarata a invertorului. 3. Pentru sarcini inductive alegeti un invertor cu putere maxima de 2-3 ori mai mare. 4. Este recomandat sa porniti autoturismul doar cu invertorul oprit, deoarece aceasta procedura va consuma foarte mult curent si poate afecta invertorul. 5. Invertorul trebuie montat intr-un loc aerisit, nu trebuie acoperit si trebuie ferit de accesul persoanelor. 6. Nu conectati invertorul la baterii descarcate, defecte sau vechi, deoarece poate determina arderea invertorului.
17
Manual de utilizare
Despre baterie
Romana
Bateria de stocare sau acumulatorul este un dispozitiv ce genereaza energie in urma unui proces chimic. Asigurati-va ca ati ales un acumulator potrivit pentru acest invertor, pentru a asigura o functionare corecta si optima.
Index performanta baterie
1. Capacitate: Reprezinta cantitatea de energie la putere maxima compusa din curentul de descarcare multiplicat cu timpul de descarcare. Capacitate = Curent descarcare (I) x Timp descarcare (H) 2. Rata de descarcare: Reprezinta viteza fiecarui curent de descarcare 3. Curent de descarcare: Curentul de descarcare este curentul de iesire. Este exprimat de obicei in Amperi sau volum multiplicat cu un coeficient. 4. Tesniune descarcare finala: Reprezinta tensiunea cand bateria nu se descarca. In mod usual este aproximativ 1.75V / celula 5. Capacitate nominala: Reprezinta capacitatea dupa 20 ore de descarcare. 6. Rata de autodescarcare: Bateria se descarca chiar daca nu este utilizata. Unitatea este C / unitate.
Dimensionarea corecta a bateriei
Deoarece invertoarele au nevoie de un curent puternic atunci cand functioneaza, capacitatea si curentul maxim ale bateriei sunt niste factori care determina eficienta la care functioneaza invertorul (50% – 100%). Acesti factori pot determina si deteriorarea bateriei.
Capacitatea de stocare a bateriei depinde de curentul maxim de descarcare: Curent maxim de descarcare = Putere nominala/(tensiune stocarex0.85) Capacitate de stocare baterie = curent mediu de descarcarextimp de descarcare
Exemplu: PNI SP1000W are o putere nominala de 1000W, tensiune de intrare 12V, deci: Curent mediu de descarcare = 1000/(12×0.85)= 98A Daca se mentine 2 ore pornit:
Manual de utilizare
18
Romana
Capacitate de stocare baterie = 98×2=196 Ah Alegeti o baterie cu o capacitate mai mare de 196 Ah.
Valori recomandate pentru baterie
Invertor SP500W SP1000W SP2000W
Putere (W) 500 1000 2000
Baterie recomandata 12V, 100Ah 12V, 150Ah 12V, 200Ah
19
Manual de utilizare
Romana
Probleme si solutii
Invertorul nu porneste si LED-ul Power nu se aprinde
Invertorul este in protectie si LED-ul rosu de eroare (Fault) se aprinde
1. Bateria este defecta 1. Schimbati bateria
2. Conexiunea la baterie 2. Conectati bateria cu
este anormala
grija
3. Siguranta este arsa 3. Schimbati siguranta
Invertorul este in
1. Micsorati numarul
protectie si ledul rosu consumatorilor conectati
Fault este aprins.
si reporniti invertorul.
1. Invertorul intra in
2. Consumatorii inductivi
protectie cand totalul (motoare, pompe) au un
consumatorilor depaseste consum de pornire foarte
puterea nominala a
mare. Alegeti un invertor
invertorului.
cu o putere nominala de
2. Puterea de pornire a de 4-5 ori mai mare in
consumatorilor este mai aceste cazuri.
mare decat puterea de 3. Daca tensiunea
varf declarata pentru
bateriei creste peste
invertor. Invertorul intra nivelul minim de
in protectie.
protectie, invertorul
3. Tensiunea bateriei este reporneste automat. (sau
prea scazuta. Invertorul schimbati bateria).
declanseaza protectie la 4. Daca tensiunea
subtensiune.
bateriei scade sub nivelul
4. Tensiunea bateriei este maxim de protectie,
prea ridicata. Invertorul invertorul reporneste
declanseaza protectia la automat (sau schimbati
supravoltaj.
bateria).
5. Temperatura
5. Inchideti invertorul
invertorului este prea pentru 15 min, verificati
ridicata.
si curatati ventilatoarele
si gurile laterale de
aerisire si pastrati spatiu
de ventilare in jurul
carcasei.
Manual de utilizare
20
Romana
Invertorul nu functioneaza in sarcina 100%
1. Firele intre baterie si 1. Scurtati firele sau
invertor sunt prea lungi. folositi fire mai groase.
2. Conectarea la baterie / Recomandam utilizarea
invertor este slabita.
firelor din colet.
2. Verificati si strangeti
conectorii pe invertor si
baterie.
Daca invertorul nu functioneaza dupa aplicarea solutiilor de mai sus, va recomandam sa contactati Vanzatorul, Importatorul sau Reprezentantul service, consultand certificatul de garantie. Nu desfaceti produsul, deoarece pierdeti garantia produsului.
Recomandam o intretinere periodica a produsului pentru prelungirea duratei de viata a acestuia. 1. Evitati utilizarea invertorului in medii umede, cu praf, cu temperatura prea ridicata. 2. Evitati supunerea produsului la socuri mecanice 3. Verificati periodic cablurile si conexiunile 4. Curatati periodic ventilatoarele invertorului.
21
Manual de utilizare
Specificatii tehnice
Romana
SP500W
SP1000W
SP2000W
Tensiune de intrare
12V DC
Putere de iesire
500W
1000W
2000W
Tensiune de iesire
230V AC
Frecventa
50Hz/60Hz
Eficienta de transfer
>88%
Unda de iesire
Sinusoida pura
Distorsiune armonica totala
THDV 3% (100% linear load)
Capacitate suprasarcina
>120%
Protectii
Scurtcircuit, suprasarcina, supraincalzire, supratensiune, subtensiune
Parametri acumulator recomandat
Tip
Plumb-acid/Litiu
Tensiune
12V
Curent maxim
100A
150A
200A
Protectie sub/ supratensiune
10V/15.5V
Nivel atentionare subtensiune
10.5V
Nivel cut-off (intrerupere)
9.7V-10.2V
Nivel recuperare (recovery)
12.5V
Parametri generali
Indicatori led
Verde, Rosu
Racire activa
Ventilator
Temperatura de lucru
-26°C ~ +60°C
Umiditate de lucru
90% (fara condens)
Manual de utilizare
22
Romana
EN: EU Simplified Declaration of Conformity SC ONLINESHOP SRL declares that Power inverter PNI SP500W, SP1000W, SP2000W complies with the Directive EMC 2014/30/EU. The full text of the EU declaration of conformity is available at the following Internet address: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
DE: Vereinfachte EU- Konformitätserklärung SC ONLINESHOP SRL erklärt, dass das Wechselrichter PNI SP500W, SP1000W, SP2000W der Richtlinie EMC 2014/30/ EU entspricht. Sie finden den ganzen Text der EU-Konformitätserklärung an der folgenden Internetadresse: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
ES: Declaración UE de conformidad simplificada SC ONLINESHOP SRL declara que el Inversor de energia PNI SP500W, SP1000W, SP2000W cumple con la Directiva EMC 2014/30/EU. El texto completo de la declaración de conformidad de la UE está disponible en la siguiente dirección de Internet: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
FR Déclaration de conformité simplifiée de l’UE SC ONLINESHOP SRL déclare que Convertisseur de energia PNI SP500W, SP1000W, SP2000W est conforme à la directive EMC 2014/30/EU. Le texte complet de la déclaration de conformité UE est disponible à l’adresse Internet suivante: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
HU: Egyszersített EU Megfelelési Közlemény SC ONLINESHOP SRL kijelenti azt, hogy a áramváltó PNI SP500W, SP1000W, SP2000W megfelel az EMC 2014/30/EU irányelvnek. Az EU-megfelelségi nyilatkozat teljes szövege a következ internetes címen érhet el: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
IT: Dichiarazione UE di conformità semplificata SC ONLINESHOP SRL dichiara che il Invertitore PNI SP500W, SP1000W, SP2000W è conforme alla direttiva EMC 2014/30/UE. Il testo completo della dichiarazione di conformità europea è disponibile al seguente indirizzo Internet: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
PL: Uproszczona deklaracja zgodnoci UE SC ONLINESHOP SRL owiadcza, e Falownik PNI SP500W, SP1000W, SP2000W jest zgodny z dyrektyw EMC 2014/30/EU. Pelny tekst deklaracji zgodnoci UE dostpny jest pod nastpujcym adresem internetowym: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
RO: Declaratie UE de conformitate simplificata SC ONLINESHOP SRL declara ca Invertor de tensiune PNI SP500W, SP1000W, SP2000W este in conformitate cu Directiva EMC 2014/30/EU. Textul integral al declaraiei UE de conformitate este disponibil la urmatoarea adresa de internet: https://www.mypni.eu/products/6848/download/certifications https://www.mypni.eu/products/6849/download/certifications https://www.mypni.eu/products/6850/download/certifications
23
Manual de utilizare
mypni.eu/products/6848/download/certifications
