SONOFF-MICRO Wifi Smart USB Adapter
Product Information
Sonoff Micro is a portable mini USB smart adaptor that allows
you to make your USB devices smart. It enables remote control of
connected devices, scheduling of on/off operations, sharing control
with family members, and various other features.
Specifications
- Model: Micro
- Input: 5V
- Output: 5V, 2.5A
- Operating Systems: Android & iOS
- Wi-Fi: IEEE 802.11 b/g/n, 2.4GHz
- Working Temperature: -10°C to 40°C
- Material: PC V0
- Dimension: 31×26.5x33mm
Features
- Remote Control
- Single/Countdown Timing
- Voice Control
- Share Control
- Sync Status
- Camera Linking
- Power-on State
- Smart Scene
- Switch Network
Wi-Fi LED Indicator Status Instruction
- Blue light flashes quickly: Pairing mode
- Blue light is always on: Device is connected successfully
- Blue light flashes quickly once: Unable to find the router
- Blue light flashes quickly twice: Successfully connect to the
router but Wi-Fi is not connected - Blue light flashes quickly three times: Upgrading
Product Usage Instructions
1. Download eWeLink App
Download the eWeLink app from your app store.
2. Power On
When powering on the device for the first time, it will enter
the quick pairing mode (Touch). The Wi-Fi indicator will flash
quickly.
- If the device is not paired within 3 minutes, it will exit the
pairing mode (Touch). - To enter the pairing mode again, long press the configuration
button for 5 seconds until the Wi-Fi indicator flashes quickly and
release.
3. Add the Device
Method 1: Scan the Code to Add
(recommended)
Make sure the device is in pairing mode.
- Tap “+” in the app and select “Scan QR code”.
- Scan the QR code on the card in the package to add the
device.
Method 2: Manual to Add
Please enter all the numbers beside the QR code as the device
ID.
- Set the device to pairing mode and find the Wi-Fi SSID with
ITEAD-*********** on your mobile phone. - Save the last 10 digital codes (the unique ID of the
device). - Go back to eWeLink App, tap “+”, select “Scan QR code”, then
tap “Scanning failed. Please enter device ID manually” on the
bottom. - Save the device ID, tap “Next” and wait until the adding is
successful.
Switch Network
If you need to change the network, long press the pairing button
for 5 seconds until the Wi-Fi indicator flashes quickly and
release. The device will enter pairing mode and you can pair it
again.
Factory Reset
To perform a factory reset, please refer to the user manual or
contact customer support for assistance.
SONOFF TECHNOLOGIES CO., LTD.
Operation instruction
1. Download eWeLink APP eWeLink
2. Power on
English
eWeLink
AndroidTM & iOS
Powering on, the device will enter the quick pairing mode (Touch) during the first use. The Wi-Fi indicator flashes quickly.
It will exit the pairing mode (Touch) if the device is not paired within 3mins. If you want to enter this mode again, long press the configuration button for 5s until the Wi-Fi indicator flashes quickly and release.
3. Add the device Method 1: Scan the code to add (recommended)
Add Device
Quick Pairing
WIFI devices can be added in this mo de(make sure the device is in pairing mode).
Scan QR code
GSM devices and devices with QR co de can be added in this mode.
Sound Pairing Add device in this mode if your devic e support this feature.
Tap “+” and select “Scan QR code”, then scan the QR code on the card in the package to add the device.
5
SONOFF TECHNOLOGIES CO., LTD. Method 2: manual to add
English
Se ings WLAN WLAN SONOFF-DIY My networks ITEAD SONOFF
ITEAD-**********
Add Device
Quick Pairing WIFI devices can be added in this mo de(make sure the device is in pairing mode).
Scan QR code
GSM devices and devices with QR co de can be added in this mode.
Add Device
Add manually
Ple ase enter all the numbers beside s the QR code .
ID id Device ID Please enter device ID.
Sound Pairing
Add device in this mode if your devic e support this feature.
Scanningfailed. Please enter device ID manually>
Next
Set the device to the pairing mode, and find the Wi-Fi SSID with ITEAD-*********** on your mobile phone, and save last 10 digital codes (The digital code is the unique ID of the device)
Go back to “eWeLink” App, tap”+”, select “Scan QR code” , then tap the word “Scanning failed. Please enter device ID manually” on the bottom and save the device ID, tap “Next” and wait until the adding is successful.
Specifications
Model Input Output Operating systems Wi-Fi Working temperature Material Dimension
Micro 5V 5V 2.5A Android & iOS IEEE 802.11 b/g/n 2.4GHz -10~40 PC V0 31×26.5x33mm
Product Introduction
5V input
Wi-Fi LED indicator(Blue)
On/Off LED indicator(Red) Pairing button/Manual switch
5V output 6
SONOFF TECHNOLOGIES CO., LTD.
Wi-Fi LED indicator status instruction
English
LED indicator status Blue light flashes quickly Blue light is always on Blue light flashes quickly once
Blue light flashes quickly twice
Blue light flashes quickly three times
Status instruction Pairing mode Device is connected successfully
Unable to find the router Successfully connect to the router but Wi-Fi is not connected Upgrading
Features
Micro is a portable mini USB smart adaptor that makes your USB devices smart. You can remotely turn on/off the connected devices of your home anywhere, schedule it on/off and share it with your family to control together.
Remote Control Single/Countdown Timing
Voice Control
Share Control
Sync Status
Camera Linking
Power-on State
Smart Scene
Switch Network
If you need to change the network, long press the pairing button for 5s until the Wi-Fi indicator flashes quickly and release., then the device enters pairing mode and you can pair again.
Factory Reset
Deleting the device on the eWeLink app indicates you restore it to factory setting.
7
SONOFF TECHNOLOGIES CO., LTD.
English
Common Problems
Q: Why my device stays “Offline”? A: The newly added device needs 1 2mins to connect Wi-Fi and network. If it stays
offline for a long time, please judge these problems by the blue Wi-Fi indicator status:
1. The blue Wi-Fi indicator quickly flashes once per second, which means that the switch failed to connect your Wi-Fi: Maybe you have entered a wrong Wi-Fi password. Maybe there’s too much distance between the switch your router or the environment causes interference, consider getting close to the router. If failed, please add it again. The 5G Wi-Fi network is not supported and only supports the 2.4GHz wireless network. Maybe the MAC address filtering is open. Please turn it off. If none of the above methods solved the problem, you can open the mobile datanetwork on your phone to create a Wi-Fi hotspot, then add the device again.
2. Blue indicator quickly flashes twice per second, which means your device has connected to Wi-Fi but failed to connect to the server. Ensure steady enough network. If double flash occurs frequently, which means you access an unsteady network, not a product problem. If thenetwork is normal, try to turn off the power to restart the switch.
8
