TOB 5725 Turlington Arched Chandelier
Product Information:
The Turlington Arched Chandelier (Item # TOB 5725) is a stylish
and elegant light fixture designed to enhance the aesthetic appeal
of any room. This chandelier features a unique arched design and
comes with multiple shades to create a warm and inviting ambiance.
Please note that bulbs are not included with the chandelier and are
packaged separately.
Before installing the chandelier, it is important to follow all
applicable local installation codes and have a person familiar with
the construction and operation of light fixtures perform the
installation. Carefully inspect the item and its contents upon
receipt, and if any damage or defects are found, do not proceed
with the installation.
Product Usage Instructions:
- Tools Required (Not Included): Phillips Screwdriver, Slotted
Screwdriver, Wire Strippers, Wire Cutters. - Remove all parts from the box and place them on a clean, soft
surface. - Detach the mounting plate (A) from the canopy (E) by removing
the collar ring (F). - Install the mounting plate (A) to the junction box using the
provided mounting screws (B). - Feed the electrical and ground wires through the bottom rod (J)
and connect them to the corresponding supply wires. - Connect the fixture neutral wire (white) to the supply neutral
wire (usually white) using a wire nut (C). - Connect the fixture hot wire (black) to the supply hot wire
(usually black) using a wire nut (C). Ensure that the hot and
neutral connections are not reversed. - Ensure all wire connections are tight and carefully tuck them
into the junction box. - Attach the canopy (E) to the mounting plate (A) and secure it
with the collar ring (F). - Place the shades (K) upside down on a clean surface and attach
the brackets (M) using the provided cap screws (L). Repeat this
step for all shades. - Install the shade brackets (M) to the fixture (N).
- Install the light bulbs into the sockets.
Care Instructions:
To clean the chandelier, use only a soft dry cloth or a feather
duster. Avoid using abrasive or chemical agents, as they may damage
the surface of the fixture.
ASSEMBLY INSTRUCTIONS
A B C D
Diagram 1
E
F
G
H
I
J
Bulbs not included K (Packaged separately) L
M N
Turlington Arched Chandelier
Item # TOB 5725
NOTICE:
This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
TOOLS REQUIRED (NOT INCLUDED):
Phillips Screwdriver
Slotted Screwdriver
Wire Strippers
Wire Cutters
1. Carefully remove all parts from the box. Place on a clean, soft surface. 2. Remove mounting plate (A) from canopy (E) by removing collar
ring (F). 3. Install mounting plate (A) to junction box and secure with mounting
screws (B). 4. Feed electrical and ground wires through bottom rod (J) and connect
to fixture (N). Repeat for middle rod (I), connecting to bottom rod (J). Repeat for middle rod (H),connecting to middle rod (I) . 5. Continue feeding wires through collar ring (F) and canopy (E). 6. Holding fixture upright, slide collar ring (F) and canopy (E) down and rest on fixture (N). Then connect top rod (G) to middle rod (H). NOTE: Slide components down slowly to avoid damages. 7. Hang fixture swivel ball (D) to the center of mounting plate (A). 8. Cut excess wires, being sure to leave enough to reach the junction box. Separate wires, and strip insulation on each 5/8″. 9. Wrap fixture ground wire (bare copper) around the green grounding screw (see diagram 1). Tighten. Continue fixture ground wire and connect to supply ground wire (usually green or bare copper) using wire nut (C). NOTE: It is imperative that the fixture is grounded.
M
US
L IS T ED
ASSEMBLY INSTRUCTIONS
A B C D
Diagram 1
E
F
G
H
I
J
Bulbs not included K (Packaged separately) L
M N
Turlington Arched Chandelier Item # TOB 5725
NOTICE: This light fixture should be installed in accordance with all applicable, local installation codes, and by a person familiar with the construction and operation of it, as well as the hazards involved. Inspect item and contents carefully. If any damage or defect is found, do not install. Retain all packaging material until installation is complete and approved.
10. Connect fixture neutral wire (white) to the supply neutral wire (usually white) using wire nut (C).
11. Connect fixture hot wire (black) to the supply hot wire (usually black) using wire nut (C). CAUTION: Do not reverse the hot and neutral connections.
12. Make sure all wire connections are tight, then carefully tuck into the junction box.
13. Install canopy (E) to mounting plate (A) and secure with collar ring (F). 14. Place shade (K) upside down on clean surface and attach bracket (M)
by securing wirh cap screws (L). Repeat with other shades. 15. Install shade bracket (M) to fixture (N). 16. Install light bulbs into the sockets.
Care Instructions: Clean only with a soft dry cloth or feather duster. Do Not use abrasive or chemical agents.
