2705586 DIN Connector Plug Socket
Product Information:
The Straight Pin Plug to Pin Socket is a connector with 10
contacts and a mating thread type of M16. It is made of
high-quality materials, with a shell made of nickel-plated zinc
alloy, insulation made of black Bakelite, and contacts made of
silver-plated copper. The electrical specifications include an
operating voltage of 30V, a rated current of 1A, an insulation
resistance of at least 100M, and a contact resistance of a maximum
of 10m.
Product Usage Instructions:
- Ensure that the power source is turned off before connecting or
disconnecting the Straight Pin Plug to Pin Socket. - Identify the Plug and Socket ends of the connector.
- Align the pins on the Plug end with the corresponding sockets
on the Socket end. - Gently push the Plug into the Socket until it is firmly
connected. - To disconnect, hold the Plug and Socket firmly and pull them
apart with a straight, even force. - Do not force or twist the connector during connection or
disconnection as it may cause damage. - Ensure that the connector is properly secured and locked when
in use to prevent accidental disconnection. - Regularly inspect the connector for any signs of damage or
wear. Replace if necessary.
For any further assistance or troubleshooting, refer to the
complete user manual or contact our customer support.
Straight Pin Plug to Pin Socket
ø6.5
6.0 36.4
44.0 Dimension: mm±0.2
ø12.3 ø17.8
ø18.2 M16 x 1.0
Specification Number of Contacts: 10 Mating thread type: M16
Material Shell: Nickel plated Zinc Alloy Insulation: Black Bakelite Contact: Silver plated Copper
Electrical Operating voltage: 30V Rated current: 1 A Insulation resistance: 100 M min. Contact resistance: 10 m max.
Environment Operation temperature: -20 to 85°C Protect class: IP55 Termination: Solder Suit Cable size: O.D. ø6.5mm max. Wire guide: AWG 22 – 20 Conductor cross-section: 0.34 – 0.5mm²
ø13.5 ø6.5
