SUN2000 On Grid Solar Inverter

Product Information:

Product Model: SFF1546N
Technical Manual: Available
Characteristics: Klimaklasse C, Sicherheitsklasse 1
Outside Dimensions: 800x850x2000 mm
Inside Dimensions: 680x430x1078 mm
Freezing Temperature: -18°C
Thermostat Set Temperature: -30°C
Ambient Temperature: +38°C
Humidity: 65%
Energy Consumption: 3 KW/H
Power: 3.50 KW
Voltage – Frequency: 380V / 50 Hz
Digital Thermometer: Included (1 piece)
GN Tray Capacity: 15x GN 1/1 + EN 400 x 600 mm
GN Tray Holders: 15x GN 1/1 brackets (4 pieces)
Technical Characteristics: INOX 304 SB+PVC, INOX 304 MAT+PVC,
Insulation Material Thickness: 60 mm, Insulation Material Volume:
42 Kg/m3 +/-1
Weight: Gross: 200 kg, Net: 180 kg
Compressor: DORN H300CS–3 HP R404A-R452A
Fan Motor: Hidria R11R – 40LPS-4M-5150 190/260W-0,85/1,1 A
1310/1450 Rpm 50/60 Hz
Refrigerant: R404A / R452A (3000 gr)
Standards: EN 60335-2-89 and EN 60335-1
Packaging: Wooden Pallet, Packed in Carton and Nylon

Product Usage Instructions:

Place the SFF1546N in a suitable location with enough space for
proper ventilation.
Ensure that the ambient temperature does not exceed +38°C and
the humidity is kept at around 65%.
Connect the product to a power source with a voltage of 380V
and frequency of 50 Hz.
Set the thermostat temperature to -30°C for optimal
freezing.
Use the included digital thermometer to monitor the temperature
inside the unit.
Load the GN trays into the unit, ensuring they fit securely on
the 15x GN 1/1 brackets.
Make sure the door is properly closed to maintain the freezing
temperature.
Regularly check and clean the evaporator, fan cover, and
condenser for optimal performance.
If any spare parts need replacement, refer to the SFF1546N
Spare Part List in the user manual.

View Fullscreen

SFF1546N
TECHNISCHES HANDBUCH TECHNICAL MANUAL
INHALTSVERZEICHNIS / INDEX :
1. MERKMALE / CHARACTERISTICS 2. INNEN- UND AUSSENMAE/ INSIDE , OUTSIDE DIMENSIONS 3. EXPLOSIONSZEICHUNG / EXPLODED VIEW 4. ERSATZTEILLISTE/ SPARE PART LIST 5. SCHALTPLAN / WIRING DIAGRAM

SFF1546N

AUSSENMAE/ OUTSIDE DIMENSIONS = 800x850x2000 INNENMAE/ INSIDE DIMENSIONS = 680x430x1078

BESONDERE MERKMALE / CHARACTERISTIC SPECIALITIES

Klimaklasse/ C/ ClimlimataeteCclalasss

Sicherheitsklasse / Safety class

Kühltemperatur / Cooling temperature

:+90 / +3C

Gefriertemperatur / Freezing temperature

:+90 / -18C

Thermostat-Solltemperatur / Thermostat set temperature :-30C

Umgebungstemperatur / Ambient temperature

: +38C

Luftfeuchtigkeit / Humidity

: %65

Energieverbrauch / Energy consumption

: 3 KW/H

Leistung / Power

: 3,50 KW

Spannung – Frequenz / Voltage – Frequency

: 380V / 50 Hz

ZUBEHÖR UND STEUERSCHALTER/ ACCESORIES AND CONTROL SWITCHES

Digitales Thermometer / Digital thermometer Scharniergruppe / Hinge group Standfuß / Stand Regal /Shelf

: Digitales Thermometer /Digital thermometer D:VSIEtkW. / Pcs. 1
: Stk. / Pcs. 4 :15x GN 1/1 + EN 400 x 600 mm :15x GN 1/1 Halterungen / :15 x GN 1/1 brackets

TECHNISCHE DATEN/ TECHNICAL CHARACTERISTICS

Außenmaße / Outside dimensions

: 800x850x2000mm

Innenmaße / Inside dimensions

: 680x430x1078mm

Verpackungsmaße / Packing dimensions

: 900x950x2160mm

Kühlvolumen / Cooling volume

: 35 kg

Gefriervolumen / Freezing volume

: 30 kg

Bruttogewicht / Gross weight

: 200 kg

Nettogewicht / Net weight

: 180 kg

Außengehäuse / External housing

: 0,60 mm INOX 304 SB+PVC

Innengehäuse / Internal housing

: 0,50 mm INOX 304 MAT+PVC

Dicke des Isoliermaterials/Insulation material thickness : 60 mm

Volumen des Isoliermaterials / Insulation material volume : 42 Kg / m3 +/-1

Kompressor / Compressor Kondensator / Condanser Kondensator-Lüfter / Condenser fan

: DORN H300CS–3 HP R404A-R452A : 3,4 KW :Hidria R11R – 40LPS-4M-5150 190/260W-0,85/1,1 A 1310/1450 Rpm 50/60 Hz

Verdampfer / Evaporator Verdampfer-Lüfter / Evaporator fan

: 1,76 KW : EBM 72/90W , A4E300 , 1320/1500 RPM 0,32-0,4 A Axiallüfter x 3 / Axial fan x 3

Trockner / Dryer Kältemittel /Refrigerant Gasmenge/Gas quantity Zertifizierungen / Certifications Seriennummer / Serial No Verpackung / Package

: 3/8 : R404A / R452A : 3000 gr : EN 60335-2-89 ve EN 60335-1 : Auf der Verpackung / On the packaging : Holzpalette , Verpackt in Karton und Nylon / Wooden pallet , Packed in carton and nylon

OPTIONEN – OPTIONS

SFF1546N ERSATZTEILLISTE / SFF1546N SPARE PART LIST

NR.

CODE

BEZEICHNUNG

DESCRIPTION

1 01A01KA173 TÜR 2 A00C0137 TÜR-DICHTUNG 3 P30090008 SCHARNIER 4 B02ME100 SCHARNIER 5 B02ME101-VBL SCHARNIER

DOOR DOOR GASKET HINGE HINGE HINGE

6 B02ME102 SCHARNIER MIT BUCHSE

HINGE WITH BUSH

7 A00EV110 VERDAMPFER

EVAPORATOR
