immedia Satin Sheet 2Direction Base Sheet
Product Information
The SatinSheet 2Direction BaseSheet is a medical device that
reduces friction when turning and positioning users in bed. It is
designed to make work easier for the carer and can be combined with
DrawSheets or SatinSheet 4Direction. The SatinSheet range comprises
different models of BaseSheet with low-friction material and
DrawSheets. The choice of model or combination is made with
reference to the user’s functions and needs and the carers’ working
environment. The product complies with the standards applicable for
Class 1 products in the Medical Device Regulation (EU) 2017/745 on
medical devices.
Product Usage Instructions
To use the SatinSheet 2Direction BaseSheet, please follow the
instructions below:
- Position the SatinSheet 2Direction BaseSheet on the mattress
according to the size of the mattress. Refer to the illustrations
provided in the user manual for guidance. - Place the SatinSheet DrawSheet correctly on top of the
SatinSheet 2Direction BaseSheet, aligning it with the arrows marked
on the BaseSheet. Refer to the illustrations provided in the user
manual for guidance. - The person described as the user in this Instruction for Use is
the person who is lying or sitting on the product. The carers are
the people who manoeuvre the product. - To avoid accidents and injury when moving and handling the
products, please read this manual carefully. This symbol appears
alongside the text in the manual. It draws the reader’s attention
to points at which there may be a risk to the health and safety of
the user or carer. - Do not bleach, dry clean or tumble dry the product. Ironing is
also not recommended. - Never leave the product on the floor as there is a risk of
sliding down. Keep the product dry and out of the sun. - The product has an expected service life of 1 to 2 years under
normal use. The service life of the device varies depending on
usage frequency, loads and how often and how it is washed. - If in doubt, please contact Etac. In case of an adverse event
occurred in relation to the device, incidents should be reported to
your local dealer and the national competent authority in a timely
manner.
It is important to note that if the customer makes adjustments,
repairs or uses combinations not predetermined by Etac, the Etac CE
certification and Etac warranty will not be valid.
Instruction for use
IMM1024_IFU.Version14.2020-08-24
SatinSheet 2Direction
BaseSheet
Index
Illustrations ……………………………………. 3 User manual English ……………………. 4 Bruksanvisning Svenska……………..11 Bruksanvisning Norsk …………………18 Brugervejledning Dansk………………25 Käyttöohjeet Suomi…………………….32 Gebrauchsanweisung Deutsch ……39 Gebruiksaanwijzing Nederlands…..46 Instruction d’utilisation Francais….53 Istruzioni per l’uso Italiano ………….60 Instrucciones de uso Español ……..67
See www.etac.com
2
GB ILL.
Illustrations
Positioning different sizes of SatinSheet BaseSheet 2Direction on a mattress
100 x 200 cm
140 x 200 cm
200 x 200 cm
230 x 200 cm
280 x 200 cm
Positioning different sizes of SatinSheet DrawSheet placed correct on top of SatinSheet 2Direction
S V
N O
D A
F I
D E
N L
F R
1
2
3
4
3
I T
E S
General
Thank you for choosing an Etac product.
To avoid accidents and injury when moving and handling the products, please read this manual carefully.
The person described as “the user” in this “Instruction for Use” is the person who is lying or sitting on the product. The carers are the people who manoeuvre the product.
This symbol appears alongside the text in the manual. It draws the reader’s attention to points at which there may be a risk to the health and safety of the user or carer.
These products comply with the standards applicable for Class 1 products in the Medical Device Regulation (EU) 2017/745 on medical devices.
At Etac we strive to continually improve our products and therefore we reserve the right to make changes to products without prior warning. All measurements given on illustrations and similar material are for guidance only and Etac cannot be held liable for errors and defects.
The information given in this manual, including
Symbols in general
recommendations, combinations and sizing, does not apply to special orders and modifications. If the customer makes adjustments, repairs or uses combinations not predetermined by Etac, the Etac CE certification and Etac warranty will not be valid. If in doubt, please contact Etac.
Warranty: Two-year warranty on material and manufacturing defects, provided that the product is used correctly.
Expected lifetime: The device has an expected service life of 1 to 2 years under normal use. The service life of the device varies depending on usage frequency, loads and how often and how it is washed.
For further information on the Etac transfer range, see www.etac.com.
In case of an adverse event occurred in relation to the device, incidents should be reported to your local dealer and the national competent authority in a timely manner. The local dealer will forward information to manufacturer.
Washing Do not bleach
Disinfect / Wipe off Never leave on the floor
Warning
Production year, month and day
Manufacturer CE -certification
Tumbledry Iron Do not dryclean
Risk of sliding down Keep out of the sun Read the user manual
Batch no./Lot no.
User mass limit = maximum rated load
The product can be scrapped according to national regulations
Keep dry Non sterile Article number
Medical device
Intended use
SatinSheet is a BaseSheet that reduces friction when turning and positioning users in bed and makes work easier for the carer. SatinSheet is positioned in the bed like an ordinary sheet and can be combined with DrawSheets or SatinSheet 4Direction. The SatinSheet range comprises different models
of BaseSheet with low-friction material and DrawSheets. The choice of model or combination is made with reference to the user’s functions and needs and the carers’ working environment.
Intended environment Acute care, Long-term care, Home care
4
GB ILL.
S V
Practical handling
Positioning
Position SatinSheet with the low-friction material uppermost in the middle of the bed (see Illustrations).
All SatinSheet models have a “this side up” label, to help ensure that the correct side faces upwards in the bed.
An information label, describing the correct use of the product, is sewn into all SatinSheet models/products.
Use
A SatinSheet can be very beneficial where the user is able to turn him/herself but needs to reduce friction. Using SatinSheet the user can turn him/herself without sliding down in the bed, even if the head end is raised (see Illustration 1).
If the user needs help to turn, SatinSheet can be beneficial when used with a draw sheet (Illustration 2). A SatinSheet 4Direction (IM4115S) can be used to help move the user up and down in the bed and from one side to the other (Illustrations 3+4).
Turning is achieved by grasping the sheet at the user’s hips and shoulders. To achieve a better ergonomic grip, the carer should grasp as much fabric as possible.
Always work with flat wrists and weight transference. Turning with SatinSheet can also be done by two carers. The carers work together. One carer helps pull on DrawSheet while the other carer pulls down on the mattress at the level of the user’s hips and shoulders, pushing gently.
Turn the user (see Illustration 2). To lock the glide system after turning: Fold the excess material from DrawSheet under the mattress on both sides of the bed. Before locking the glide system under the mattress, any unevenness/creases should be smoothed to avoid decubitus. The carers pull simultaneously and diagonally from both sides.
N O
D A
F I
D E
N L
F R
I T
E S
5
Notice
Special features
Always check the product before use and after washing.
Never use a defective product. If the product shows signs of wear-and-tear, it must be scrapped.
Read these instructions carefully.
It is important that carers receive instruction in manual handling. Etac offers advice and training for carers. For further information, contact Etac.
Always use the correct manual handling techniques
Encourage the user to assist where possible.
To ensure that the user feels safe and that every manual handling is smooth, always plan the manual handling in advance.
There is a risk that the user may slide off. Never leave the user alone on the edge of the bed.
Never leave the product on the floor.
Always conduct a risk assessment, and ensure that the assistive product can be used for the individual user and, in combination with other devices, that it is safe for the user and carers.
It is recommended that the guard rail is in place when the user is left on the glide system, unless a risk assessment has found that the user can be safely left on the glide system without the need of guard rails.
Always lock the glide system when you have completed the transfer.
If in any doubt – please contact Etac.
Material and cleaning
Material: Polycotton: 55% cotton/45% polyester. Satin: Polyester
The product should be checked regularly, preferably each time it is used and especially after washing.
Check that there is no damage to seams or fabric.
Never try to repair a product yourself. Never use a defective product.
Recommended to wash the product before use.
Washing instructions: Ironing improves the glide effect. Do not use fabric softener. This product can be cleaned with a solvent-free cleaning agent with a pH level between 5 and 9, or a 70% disinfection solution.
6
GB ILL.
S V
Products and accessories
Article no.
IM4133S IM4108S IM4175S IM4178S IM4119S IM4113S IM4176S IM4179S IM4181S IM4114S IM4177S IM4180S IM4122S IM4157S IM4107S IM4147S IM4137S IM4197S IM4112S IM4142S
Product Description
SatinSheet 2Direction mini – small (satin W600xL1050 mm) SatinSheet 2Direction mini (satin W700xL1050 mm) SatinSheet 2Direction mini – wide (satin W850xL1050 mm) SatinSheet 2Direction mini – double (satin W960xL1050 mm) SatinSheet 2Direction midi – small (satin W600xL1400 mm) SatinSheet 2Direction midi (satin W700xL1400 mm) SatinSheet 2Direction midi – wide (satin W850xL1400 mm) SatinSheet 2Direction midi – double (satin W960xL1400 mm) SatinSheet 2Direction maxi – small (satin W600xL2000 mm) SatinSheet 2Direction maxi (satin W700xL2000 mm) SatinSheet 2Direction maxi – wide (satin W850xL2000 mm) SatinSheet 2Direction maxi – double (satin W960xL2000 mm) SatinSheet 2Direction 180 cm bed (satin W600xL2000 mm) SatinSheet 2Direction Corner (satin W650xL1400 mm) SatinSheet 2Direction Corner (satin W650xL2000 mm) SatinSheet 2Direction Corner – wide (satin W800xL200 mm) SatinSheet 2Direction Corner – double (satin W900xL2000 mm) SatinSheet 2Direction Corner – double – maxi (satin W1550xL2000 mm) SatinSheet 2Direction Fit (satin W700xL2000 mm) SatinSheet 2Direction Elastic Fit (satin W700xL2000 mm)
Size (mm)
W1950xL1050 W1950xL1050 W2300xL1050 W2300xL1050 W2000xL1400 W2000xL1400 W2300xL1400 W2300xL1400 W2000xL2000 W2000xL2000 W2300xL2000 W2300xL2000 W2800xL2000 W850xL2000 W850xL2000 W1050xL2000 W1200xL2000 W1800xL2000 W900xL2000 W900xL2000
N O
D A
F I
D E
N L
F R
I T
E S
7
Combinations
Article no. IM4133S IM4108S IM4175S IM4178S
BaseSheet – Mini SatinSheet 2Direction mini – small SatinSheet 2Direction mini SatinSheet 2Direction mini – wide SatinSheet 2Direction mini – double
BaseSheet – Mini can be combined with:
Article no.
DrawSheet and 4Direction
IM4116S IM4110S IM4110SH
SatinSheet Drawsheet – mini In2Sheet 4Direction w/wings – mini In2Sheet 4Direction w/wings + handles – mini
Article no. IM4119S IM4113S IM4176S IM4179S IM4157S
BaseSheet – Midi SatinSheet 2Direction midi – small SatinSheet 2Direction midi SatinSheet 2Direction midi – wide SatinSheet 2Direction midi – double SatinSheet 2Direction Corner – midi satin
BaseSheet – Midi can be combined with:
Article no.
DrawSheet and 4Direction and In2Sheet 4Direction
M4118S
SatinSheet Drawsheet – midi
IM4115S
SatinSheet 4Direction – midi
IM4115SH
SatinSheet 4Direction w/handles – midi
IM4140S
In2Sheet 4Direction w/wings – midi
IM4140SH
In2Sheet 4Direction w/wings + handles – midi
Article no. IM4181S IM4114S IM4177S IM4180S IM4122S
Article no. IM4107S IM4147S IM4137S IM4197S
BaseSheet – Maxi SatinSheet 2Direction maxi – small SatinSheet 2Direction maxi SatinSheet 2Direction maxi – wide SatinSheet 2Direction maxi – double SatinSheet 2Direction 180 cm bed
BaseSheet – Maxi Corner SatinSheet 2Direction Corner SatinSheet 2Direction Corner – wide SatinSheet 2Direction Corner – double SatinSheet 2Direction Corner – double – maxi
Article no. IM4112S IM4142S
BaseSheet – Maxi Fit SatinSheet 2Direction Fit SatinSheet 2Direction Elastic Fit
BaseSheet – Maxi/Corner/Fit can be combined with:
Article no.
4Direction and In2Sheet 4Direction
M4115S
SatinSheet 4Direction – midi
IM4115SH
SatinSheet 4Direction w/handles – midi
IM4140S
In2Sheet 4Direction w/wings – midi
IM4140SH
In2Sheet 4Direction – w/wings + handles – midi
IM4121S
SatinSheet 4Direction – maxi
IM4121SH
SatinSheet 4Direction w/handles – maxi
Remember SatinSheet PillowCase (2D)
IM4117S
SatinSheet 2Direction PillowCase
8
GB ILL.
S V
N O
D A
Set
Article no.
IM4201S IM4210S IM4209S IM4205S IM4200S IM4207S IM4204S IM4202S IM4203S IM4208S IM4211S IM4212S IM4213S IM4214S IM4215S IM4216S IM4217S IM4218S IM4219S IM4220S IM4221S IM4222S IM4223S IM4224S IM4226S
IM4227S IM4228S
IM4229S
IM4230S
IM4231SRCNL IM4232S
IM4233S IM4234S
IM4235S
IM4236S
IM4238S IM4239S
IM4242S IM4243S IM4249S
Description
SatinSheet DrawSheet mini set SatinSheet In2Sheet mini set SatinSheet In2Sheet midi mini set SatinSheet DrawSheet midi small set
SatinSheet 2Direction BaseSheet
IM4108S SatinSheet 2Direction mini IM4108S SatinSheet 2Direction mini IM4119S SatinSheet 2Direction midi – small IM4119S SatinSheet 2Direction midi – small
SatinSheet DrawSheet midi set SatinSheet 4Direction midi small set SatinSheet 4Direction midi set SatinSheet DrawSheet maxi midi set SatinSheet 4Direction Fit midi set SatinSheet Corner DrawSheet midi set
IM4113S IM4119S IM4113S IM4114S IM4112S IM4107S
SatinSheet 2Direction midi SatinSheet 2Direction midi – small SatinSheet 2Direction midi SatinSheet 2Direction maxi SatinSheet 2Direction Fit SatinSheet 2Direction Corner
SatinSheet Corner 4Direction midi set
IM4107S
SatinSheet Corner 4Direction maxi set
IM4107S
SatinSheet 4Direction maxi set
IM4114S
SatinSheet 4Direction maxi set – wide
IM4177S
SatinSheet 4Direction maxi set – double
IM4180S
SatinSheet 4Direction midi set – wide
IM4176S
SatinSheet 4Direction midi set – double
IM4179S
SatinSheet 4Direction maxi midi set
IM4114S
SatinSheet 4Direction maxi midi set – wide IM4177S
SatinSheet 4Direction maxi midi set -double IM4180S
SatinSheet DrawSheet maxi midi set – wide IM4177S
SatinSheet DrawSheet maxi midi set-double IM4180S
SatinSheet DrawSheet midi set – wide
IM4176S
SatinSheet DrawSheet midi set – double
IM4179S
SatinSheet Corner 4Direction midi set double
IM4137S
SatinSheet Corner DrawSheet midi set-wide
SatinSheet Corner DrawSheet midi set double
IM4147S IM4137S
SatinSheet 2Direction Corner SatinSheet 2Direction Corner SatinSheet 2Direction maxi SatinSheet 2Direction maxi – wide SatinSheet 2Direction maxi – double SatinSheet 2Direction midi – wide SatinSheet 2Direction midi – double SatinSheet 2Direction maxi SatinSheet 2Direction maxi – wide SatinSheet 2Direction maxi- double SatinSheet 2Direction maxi – wide SatinSheet 2Direction maxi – double SatinSheet 2Direction midi – wide SatinSheet 2Direction midi – double SatinSheet 2Direction Corner double SatinSheet 2Direction Corner – wide SatinSheet 2Direction Corner double
SatinSheet Corner 4Direction maxi set wide
SatinSheet Corner 4Direction maxi set double
SatinSheet Corner 4Direction w/handle midi – set with dutch insert
SatinSheet 4Direction w/handles midi small set
SatinSheet 4Direction midi set – wide
SatinSheet 4Direction w/handles maxi set – wide
IM4147S SatinSheet 2Direction Corner – wide
IM4137S IM4107S
SatinSheet 2Direction Corner double
SatinSheet 2Direction Corner
IM4119S SatinSheet 2Direction midi – small
IM4176S SatinSheet 2Direction midi – wide IM4177S SatinSheet 2Direction maxi – wide
atinSheet 4Direction w/handles midi set – double
SatinSheet 4Direction w/handles maxi set – double
IM4179S SatinSheet 2Direction midi – double IM4180S SatinSheet 2Direction maxi – double
SatinSheet 4Direction maxi set – small
SatinSheet 4Direction w/handles maxi set – small
IM4181S SatinSheet 2Direction maxi – small IM4181S SatinSheet 2Direction maxi – small
SatinSheet DrawSheet mini set – wide SatinSheet DrawSheet mini set – double SatinSheet In2Sheet midi midi set
IM4175S IM4178S IM4119S
SatinSheet 2Direction mini – wide SatinSheet 2Direction mini – double SatinSheet 2Direction midi – small
SatinSheet DrawSheet and SatinSheet 4Direction
IM4116S SatinSheet DrawSheet – mini IM4110S In2Sheet 4Directions w/wings – mini IM4110S In2Sheet 4Directions w/wings – mini IM4118S SatinSheet DrawSheet – midi IM4118S SatinSheet DrawSheet – midi IM4115S SatinSheet 4Direction – midi IM4115S SatinSheet 4Direction – midi IM4118S SatinSheet DrawSheet – midi IM4115S SatinSheet 4Direction – midi IM4118S SatinSheet DrawSheet – midi IM4115S SatinSheet 4Direction – midi IM4121S SatinSheet 4Direction – maxi IM4121S SatinSheet 4Direction – maxi IM4121S SatinSheet 4Direction – maxi IM4121S SatinSheet 4Direction – maxi IM4115S SatinSheet 4Direction – midi IM4115S SatinSheet 4Direction – midi IM4115S SatinSheet 4Direction – midi IM4115S SatinSheet 4Direction – midi IM4115S SatinSheet 4Direction – midi IM4118S SatinSheet DrawSheet – midi IM4118S SatinSheet DrawSheet – midi IM4118S SatinSheet DrawSheet – midi IM4118S SatinSheet DrawSheet – midi IM4115S SatinSheet 4Direction – midi
IM4118S IM4118S
SatinSheet DrawSheet – midi SatinSheet DrawSheet – midi
IM4121S SatinSheet 4Direction – maxi IM4121S SatinSheet 4Direction – maxi
IM4115SH SatinSheet 4Direction w/ handles – midi
IM4115SH SatinSheet 4Direction w/ handles – midi
IM4115SH IM4121SH
IM4115SH
SatinSheet 4Direction w/ handles – midi SatinSheet 4Direction w/ handles maxi SatinSheet 4Direction w/ handles – midi
IM4121SH
IM4121S IM4121SH
IM4116S IM4116S IM4140S
SatinSheet 4Direction w/ handles maxi SatinSheet 4Direction – maxi SatinSheet 4Direction w/ handles maxi SatinSheet DrawSheet – mini SatinSheet DrawSheet – mini In2Sheet 4Direction w. wings
F I
D E
N L
F R
I T
E S
9
Service information
Inspection
First inspection: · Is the packaging intact? · Read the label on the packaging and check the article no. and product description · Check that Short Instruction is enclosed updated User Manual/Instruction for use can be downloaded from www.etac.com or contact your Etac
Customer Service or the local dealer. · Check the label on the product – does it include article no., product description, lot/batch no., cleaning instructions and supplier name?
Periodic Inspection: · Make sure that your Manual transfer system always is in a perfect condition. · After wash always check materials, stitching, handles, buckles. · If the product shows signs of wear and tear, it must be removed from service immediately.
Visual inspection/Check the product: Ensure that the materials, seams, stitching, handles, buckles are intact/faultless.
Mechanical load or stress/Test handles: Draw hard in the handles in opposite directions and control the material, seams and stitching. Test buckles: Lock the buckle and draw in opposite directions, control the buckle and the stitching.
Check: Manual transfer aids with handles, straps and buckles:
Stability test: Try to bend the product verify that it feels firm, stable and solid.
Test low/high friction: Place the product on a firm surface or a bed, place your hands on the material and test the friction by pushing your hands down into the product. Low friction slides effortlessly High friction no sliding/moving
Manual transfer aids with for sitting and lying transfer and with high or low friction:
Production year, month and day
The product can be scrapped in accordance with national regulations
Read the user manual
10
