IM4304 Transfer Mattress
Product Information
The Etac TransferMattress is a medical device that complies with
the standards applicable for Class 1 products in the Medical Device
Regulation (EU) 2017/745 on medical devices. It is intended for use
in transferring users between two beds or from a bed to an
operation table, stretcher, X-ray or hygiene table, etc. The device
has an expected service life of 1 to 2 years under normal use.
Warranty
The Etac TransferMattress comes with a two-year warranty on
material and manufacturing defects, provided that the product is
used correctly.
Practical Handling
To use the TransferMattress, follow these steps:
- Position the TransferMattress including nylon cover and/or tube
foil under the user by rolling the user slightly away from the
direction of movement, preferably using a draw sheet. - Position the TransferMattress under the user after which the
user is rolled back. - TransferMattress should only be laid a few inches under the
user. Position the user’s head and legs carefully onto the
mattress. - If possible, it is helpful to cross the user’s legs so that the
leg that is closest to the glide mattress is lowest with the other
leg crossed over it. - It is also helpful to start the transfer with a slight
push.
Symbols
The manual includes symbols that indicate washing instructions,
disinfecting instructions, ironing instructions, and other
important information. Please read and follow all symbols to ensure
proper use and maintenance of the TransferMattress.
Additional Information
For further information on the Etac Patient handling, see
www.etac.com. In case of an adverse event occurred in relation to
the device, incidents should be reported to your local dealer and
the national competent authority in a timely manner.
Instruction for use
IMM1041_IFU.Version7.2020-09-15
TransferMattress
Index
Illustrations…………………………………..3 User manual English ………………….4 Bruksanvisning Svenska…………….9 Bruksanvisning Norsk …………….. 14 Brugervejledning Dansk………….. 19 Käyttöohjeet Suomi…………………24 Gebrauchsanweisung Deutsch … 29 Gebruiksaanwijzing Nederlands … 34 Instruction d’utilisation Francais … 39 Istruzioni per l’uso Italiano ……… 44 Instrucciones de uso Español …. 49
See www.etac.com
2
3
ES
IT
FR
NL
DE
FI
2
1
DA
NO
SV
GB ILL.
Illustrations
General
Thank you for choosing an Etac product.
To avoid accidents and injury when moving and handling the products, please read this manual carefully.
The person described as “the user” in this “Instruction for Use” is the person who is lying or sitting on the product. The carers are the people who manoeuvre the product.
This symbol appears alongside the text in the manual. It draws the reader’s attention to points at which there may be a risk to the health and safety of the user or carer.
These products comply with the standards applicable for Class 1 products in the Medical Device Regulation (EU) 2017/745 on medical devices.
At Etac we strive to continually improve our products and therefore we reserve the right to make changes to products without prior warning. All measurements given on illustrations and similar material are for guidance only and Etac cannot be held liable for errors and defects.
The information given in this manual, including recommendations, combinations and sizing, does not apply to special orders and modifications. If the customer makes adjustments, repairs or uses combinations not predetermined by Etac, the Etac CE certification and Etac warranty will not be valid. If in doubt, please contact Etac.
Warranty: Two-year warranty on material and manufacturing defects, provided that the product is used correctly.
Expected lifetime: The device has an expected service life of 1 to 2 years under normal use. The service life of the device varies depending on usage frequency, loads and how often and how it is washed.
For further information on the Etac Patient handling, see www.etac.com.
In case of an adverse event occurred in relation to the device, incidents should be reported to your local dealer and the national competent authority in a timely manner. The local dealer will forward information to manufacturer.
Symbols in general Washing
Disinfect / Wipe off
Do not bleach
Never leave on the floor
Tumbledry
Risk of sliding down
Iron
Keep out of the sun
Do not dryclean
Read the user manual
Medical device
Intended use For use in transferring users between two beds or from a bed to an operation table, stretcher, X-ray or hygiene table, etc.
Warning
Production year, month and day
Batch no./Lot no.
User mass limit = maximum rated load The product can be scrapped according to national regulations
Manufacturer CE -certification Keep dry Non sterile Article number
Intended environment Acute care, Long-term care, Home care
4
GB ILL.
Practical handling
Positioning
TransferMattress including nylon cover and/or tube foil is positioned under the user by rolling the user slightly away from the direction of movement, preferably using a draw sheet. TransferMattress is positioned under the user after which the user is rolled back.
TransferMattress should only be laid a few inches under the user. Position the user’s head and legs carefully onto the mattress. If possible, it is helpful to cross the user’s legs so that the leg that is closest to the glide mattress is lowest with the other leg crossed over it. It is also helpful to start the transfer with a slight push (Illustration 1).
Use
By applying a little pressure to the shoulder and hip, the carer can move the user over onto the other bed/table. If a draw sheet is used, it is a good idea to position TransferMattress underneath the draw sheet. Positioning then takes place as described above, but using the draw sheet to pull on (Illustrations 1 and 2).
TransferMattress can easily be removed by sliding the glide mattress out from under the user: The carer places one hand over the mattress and the other under it. Then, the carer eases the nylon material away with the upper hand while pulling towards him/herself with the lower hand.
S V
N O
D A
F I
D E
N L
F R
I T
E S
5
Notice
Special features
Always check the product before use and after washing.
Never use a defective product. If the product shows signs of wear-and-tear, it must be scrapped.
Read these instructions carefully.
It is important that carers receive instruction in manual handling. Etac offers advice and training for carers. For further information, contact Etac.
Always use the correct manual handling techniques.
Encourage the user to assist where possible.
To ensure that the user feels safe and that every manual handling is smooth, always plan the manual handling in advance.
There is a risk that the user may slide off. Never leave the user alone on the edge of the bed.
Never leave the product on the floor.
Always conduct a risk assessment, and ensure that the assistive product can be used for the individual user and, in combination with other devices, that it is safe for the user and carers.
It is recommended that the guard rail is in place when the user is left on the glide system, unless a risk assessment has found that the user can be safely left on the glide system without the need of guard rails.
If in any doubt – please contact Etac.
Material and cleaning
Material: Outer surface: 65% polyester/35% cotton Inner surface: Nylon.
The product should be checked regularly, preferably each time it is used, and especially after washing.
Check that there is no damage to seams or fabric.
Never try to repair a product yourself. Never use a defective product.
Washing instructions: Do not use fabric softener. This product can be cleaned with a solvent-free cleaning agent with a pH level between 5 and 9, or a 70% disinfection solution.
6
GB ILL.
Products and accessories
Article no. IM60/195 IM70/195 IM60220N IM7000N IM4034 IM4036
Product Description TransferMattress – narrow TransferMattress – wide TransferMattress Cover – narrow TransferMattress Cover – wide Cover Disposable L Cover Disposable XL
Set
Article no. IM4304 IM4305
Product Description TransferMattress – narrow set. Incl. IM60/195 + IM60220N TransferMattress – wide set. Incl. IM70/195 + IM7000N
Size (mm) W600xL1950 W700xL1950 W600xL2200 W715xL2000 W600xL2100 W800xL2100
Size (mm)
S V
N O
D A
F I
D E
N L
F R
I T
E S
7
Service information
Inspection
First inspection: · Is the packaging intact? · Read the label on the packaging and check the article no. and product description · Check that Short Instruction is enclosed updated User Manual/Instruction for use can be downloaded from www.etac.com or contact your Etac
Customer Service or the local dealer. · Check the label on the product – does it include article no., product description, lot/batch no., cleaning instructions and supplier name?
Periodic Inspection: · Make sure that your Manual transfer system always is in a perfect condition. · After wash always check materials, stitching, handles, buckles. · If the product shows signs of wear and tear, it must be removed from service immediately.
Visual inspection/Check the product: Ensure that the materials, seams, stitching, handles, buckles are intact/faultless.
Mechanical load or stress/Test handles: Draw hard in the handles in opposite directions and control the material, seams and stitching. Test buckles: Lock the buckle and draw in opposite directions, control the buckle and the stitching.
Check: Manual transfer aids with handles, straps and buckles:
Stability test: Try to bend the product verify that it feels firm, stable and solid.
Test low/high friction: Place the product on a firm surface or a bed, place your hands on the material and test the friction by pushing your hands down into the product. Low friction slides effortlessly High friction no sliding/moving
Manual transfer aids with for sitting and lying transfer and with high or low friction:
Production year, month and day
The product can be scrapped in accordance with national regulations
Read the user manual
