51395 Kingsbury 1-Light Black Outdoor Flush Mount Light
FLUSHMOUNT- LANTERN
Assembly Instructions
Model 51395
CAUTION
· Inspect the wire insulation for any cuts, abrasions, or exposed copper that may have resulted during shipping. If there is a defect in the wire, do not attempt installation.
· Before starting installation of this fixture or removal of a previous fixture, disconnect the power by turning off the circuit breaker or by removing the fuse at the fuse box.
TOOLS REQUIRED
Ladder
Safety glasses
Electrical Phillips
tape
screwdriver
Flat blade screwdriver
Pliers
Wire strippers
Fixture
Glass
Rubber washer
Mounting Unit
Mounting Screws
Wire Nuts
*PARTS SHOWN MAY DIFFER SLIGHTLY PER LIGHT FIXTURE
Cap Nuts page 1
FLUSHMOUNT -LANTERN
Assembly Instructions
Model 51395
STEP 1
Use the mounting screws to attach the mounting unit to the junction box
STEP 2
Make the electrical connection from the junction box to the fixture. Connect the ground wire to the mounting unit using the preinstalled green ground screw. Then, connect the positive, negative and ground wires with the supplied wire nuts. Secure with electrical tape
Connect Clear, Brown, Gold or Black Parallel Wire without tracer (round & smooth) or Black Fixture Wire to:
Black or Red Supply Wire or Insulated Wire (other than green) with copper conductor.
Connect Clear, Brown, Gold or Black *Parallel Wire with tracer (square & ridged) or White Fixture Wire to:
White Supply Wire or Insulated Wire (other than green) with silver conductor
Copper Smooth Silver Ridged
STEP 3
Secure the fixture to the mounting unit with the cap nuts. Install a bulb E26 60W MAX(not included).
Place the glass over the fixture and twist it clockwise until tightened.
page 2
