294421 Taupe Leather Zero Gravity Triple Power Recliner with Power Headrest
Product Information:
The product is a recliner with a base (A) and a backrest (B). It
comes with a C14 cable (C) for power connection. The recliner has
power lumbar and power headrest features.
Product Usage Instructions:
- Step 1: Locate the C14 cable (C) which is tied to the steel
mechanism motor at the bottom of the recliner base (A) and remove
it. - Step 2: Assemble the backrest (B) by lining up the brackets on
the backrest with the seat rest and pushing down until the pieces
click into place. Make sure the brackets are firmly inserted and
secure. - Step 3: Connect the wires as shown in the picture provided.
Connect the wire for power lumbar by matching the red wire to the
red wire and connect the wire for power headrest by matching the
black wire to the black wire. - Step 4: Insert the C14 cable (C) into the C14 power socket
located at the back corner of the recliner base (A). - Step 5: Plug the power cord into an available electrical outlet
as shown in the provided picture.
Note: Before using the recliner, make sure all components are
securely assembled and all wires are properly connected.
Components:
A: Recliner Base (x1)
B: Recliner Back (x1)
Assembly Instructions
C. C14 Cable (x1)
A
B
C
Step 1: Remove the C(C14 cable) which is tied to the steel mechanism motor at the bottom of A.
Step 2: Assemble the backrest as seen below.Line up the brackets on the back rest with the seat rest and push down until pieces click into place.Please make sure the brackets are firmly inserted and secure.
Step 3: Wire connection as below picture in circle shows.Wire for power lumbar,red to red.Wire for power headrest,black to black. Power connection:Insert C(C14 Cable) to C14 power socket at the back corner of the recliner.And then plug power cord into the available electrical outlet as below picture shows.
C
