Powertech Sl4120 Led Flood Light Solar Rechargeable Instruction Manual

SL4120 LED Flood Light Solar Rechargeable

Product Information

The SL4120 is a 100W LED Flood Light Solar Rechargeable. It is
designed to provide bright and efficient lighting using solar
power. The product comes with a lamp, solar panel, remote
controller, support bracket, wall bolts, and an operating
manual.

Installation

1. Take out the lamp from the packaging.
2. Press the AUTO button on the remote controller to activate the
   primary version.
3. Press the button above the AUTO button.
4. The light should turn on automatically.
5. Connect the waterproof connector correctly and place the solar
   panel towards sunlight. The light will automatically turn off, and
   the charging indicator will flash regularly, indicating that the
   solar panel is charging the batteries correctly. Make sure to align
   the arrows on the connector correctly.
6. Fix the product on the wall using the supplied wall bolts. The
   suggested installation height is between 3-6 meters.
7. Ensure that the solar panels are installed at the correct angle
   for your country and in the correct direction for your hemisphere.
   Also, make sure that there are no obstacles blocking sunlight, such
   as trees, shadows, or buildings. Unobstructed sunlight is necessary
   for proper charging.
8. Tips:
   • Install the solar panel at an angle of 5-10 degrees south to
     west and 35 degrees with the horizontal plane.
   • Affix the panel firmly to a permanent structure to prevent it
     from being affected by winds or movement.
   • Use the supplied remote controller to adjust the brightness and
     duration time of the light according to your requirements. Note
     that some keys on the remote may be reserved for use with other
     models.

Remote Controller Instructions

The remote controller operates in light-operated mode. Once the
waterproof wiring connector is connected and tightened, pressing
the AUTO key will turn on the light automatically when darkness
falls and turn it off to charge once the sun rises.

Important Notification

1. Never connect 220VAC to this unit as it may damage the lamp and
   pose a risk of personal injury or electric shock.
2. Ensure that the installation is firmly affixed to a solid and
   permanent fixture to avoid falling and causing injury.
3. Disassembling the lamp, panel, or any of its parts will void
   the warranty immediately.
4. Clean the solar panels regularly to remove dust, debris, and
   bird droppings. This will maintain the panels’ highest efficiency
   for charging the batteries.

Distributed by: Electus Distribution Pty
Ltd
Address: 46 Eastern Creek Dr, Eastern Creek NSW
2766 Australia
Phone: 1300 738 555 (Int’l +61 2 8832 3200)
Fax: 1300 738 500
Website: www.electusdistribution.com.au

SL4120
100W LED Flood Light Solar Rechargeable
Instruction Manual

BOX CONTENTS: Lamp Solar Panel Remote Controller
INSTALLATION:

Support Bracket Wall Bolts Operating Manual

1. Take out the lamp from the packaging

Press AUTO button Primary Version
2. Press button above

3. The light should turn on automatically

Once the Waterproof connector is connected correctly,place the Solar Panel towards the Sunlight.The light should automatically turn off and the Charging indicator (See position Below) will flash regularly. This means the Solar panels is charging the batteries correctly.

(Please use arrows on connector to align correctly) 2

Fix the product on the wall with supplied wall bolts.The installation height is suggested to be between 3-6 meters.
Please make sure the Solar panels are installed at the correct Angle for your Country and in the correct direction for your Hemisphere. Also ensure that the sunlight to them is not blocked by obstacles such as trees,shadows,buildings etc. The panel needs unobstructed sunlight to charge correctly.
Tips: 1. Installation direction of the solar panel is 5-10 degrees south to west, an angle
of 35 degrees with the horizontal place. 2. Please also ensure that the panel is affixed firmly to a permanent structure so it
is not affected by winds or movement. 3. Please use the supplied remote to select your required brightness and duration
time of the light to your desired requirements. (Reserved keys on the remote are for use with other models.)
3

REMOTE CONTROLLER INSTRUCTIONS:
Light-operated Mode. Once the waterpoof Wiring Connector is connected and tightened, by pressing the [AUTO] key,the light will automatically turn on when darkness falls,and will turn off to charge once the sun rises. Remote Controller Functions:

IMPORTANT NOTIFICATION:
1. Please never connect 220VAC to this unit as it will damage the lamp and very likely cause personal injury or electric shock.
2. Please ensure the Installation is affixed firmly to solid/permanent fixture so as to avoid it falling & causing injury.
3. Disassembling the Lamp,Panel or any of its parts will void the warranty immediately.
4. Please clean the Solar Panels regularly of Dust,debris and Bird dropping,as this will keep the Panels output at it’s highest efficiency for charging the batteries.

Distributed by: Electus Distribution Pty Ltd 46 Eastern Creek Dr, Eastern Creek NSW 2766 Australia Ph 1300 738 555 Int’l +61 2 8832 3200 Fax 1300 738 500
www.electusdistribution.com.au
