CCP240 Clean and Clear Plus Filters
Product Information
Filters – Cartridge
Featured Highlights:
- Inlet
- Outlet
- Clean & Clear Plus Filter
- Corrosion resistant injection molded filter tank
- Strength and reliability
- Four easy to clean, non-woven, polyester cartridges
- Supplied with a bulkhead union set for easy installation
Ordering Information:
| Model | Effective Filtration Area (Sq. Ft.) | Flow Rate 2 (GPM Res) | 8 Hour Turnover Capacity (In Gallons) | 10 Hour Turnover Capacity (In Gallons) | 12 Hour Turnover Capacity (In Gallons) |
|---|---|---|---|---|---|
| CLEAN & CLEAR PLUS FILTERS CCP240 | 240 | 90 | 43,200 | 54,000 | 64,800 |
| CLEAN & CLEAR PLUS FILTERS CCP320 | 320 | 120 | 57,600 | 72,000 | 86,400 |
| CLEAN & CLEAR PLUS FILTERS CCP420 | 420 | 150 | 72,000 | 90,000 | 108,000 |
| CLEAN & CLEAR PLUS FILTERS CCP520 | 520 | 150 | 72,000 | 90,000 | 108,000 |
| CLEAN & CLEAR PLUS REPLACEMENT CARTRIDGES – Model 240 (4/pack) | – | – | – | – | – |
| CLEAN & CLEAR PLUS REPLACEMENT CARTRIDGES – Model 320 (4/pack) | – | – | – | – | – |
| CLEAN & CLEAR PLUS REPLACEMENT CARTRIDGES – Model 420 (4/pack) | – | – | – | – | – |
| CLEAN & CLEAR PLUS REPLACEMENT CARTRIDGES – Model 520 (4/pack) | – | – | – | – | – |
* Certified to NSF/ANSI Standard 50.
** Residential rate .375 GPM per sq. ft. of filter area.
Vertical Clearance to remove filter elements:
Note: Actual system flow will depend on plumbing size and other
system components.
Note: Pentair does not recommend flow rates above 150 GPM.
* Integrated continuous High Flow internal air relief is
operational only when there is unobstructed flow in the circulating
system.
See page 400 for replacement parts.
California Proposition 65 Warning
WARNING: Cancer and Reproductive Harm.
P/N 200174.A
Product Usage Instructions
Installation:
- Ensure that the plumbing size is compatible with the
filter. - Place the Clean & Clear Plus Filter in the desired
location. - Connect the inlet and outlet pipes to the corresponding ports
on the filter. - Use the supplied bulkhead union set for easy installation.
Filter Cartridge Replacement:
- Refer to the model number of your filter to identify the
correct replacement cartridge pack. - Remove the old cartridges from the filter assembly.
- Insert the new cartridges into the filter assembly, ensuring
they are properly aligned. - Tighten any necessary fasteners to secure the cartridges in
place.
Note: Regularly clean the cartridges to maintain optimal
filtration performance.
Vertical Clearance:
Refer to the provided vertical clearance diagram to ensure
proper clearance for removing filter elements.
Flow Rate:
Pentair does not recommend flow rates above 150 GPM for optimal
performance.
High Flow Internal Air Relief:
The integrated continuous High Flow internal air relief is
operational only when there is unobstructed flow in the circulating
system.
FILTERS – CARTRIDGE
CLEAN & CLEAR® PLUS FILTERS FIBERGLASS REINFORCED POLYPROPYLENE TANK
Featured Highlights
· Certified to NSF/ANSI Standard 50 · Large filter area for increased
dirt capacity · 1-1/2 in., 100% drain clean-out port · Continuous High FlowTM Internal
Air Relief * · Base and plumbing kits available · Injection molded tank · Balanced hydraulic flow · Tension ControlTM Clamp · 100% factory tested · Black bulkhead unions · High Flow manual air relief valve
Inlet
Outlet
Clean & Clear Plus Filter
Clean & Clear Plus Filters have a corrosion resistant injection molded
filter tank featuring strength and reliability. The cartridge assembly uses four easy to clean, non-woven, polyester cartridges. Each filter is supplied with a bulkhead union set for easy installation.
Product
160310 160340 160301 160332
179133 179134 179135 179136
Ordering Information
Model
Effective Filtration Area (Sq. Ft.)
Flow Rate 2 (GPM Res)
8 Hour
Turnover Capacity (In Gallons)
10 Hour
12 Hour
CLEAN & CLEAR PLUS FILTERS
CCP240
240
90
43,200
54,000
64,800
CCP320 1
320
120
57,600
72,000
86,400
CCP420 1
420
150
72,000
90,000
108,000
CCP520 1
520
150
72,000
90,000
108,000
CLEAN & CLEAR PLUS REPLACEMENT CARTRIDGES
Model 240 Replacement Cartridges (4/pack)
Model 320 Replacement Cartridges (4/pack)
Model 420 Replacement Cartridges (4/pack)
Model 520 Replacement Cartridges (4/pack)
Carton Qty.
Carton Wt. (Lbs.)
1
60
1
70
1
80
1
90
1 Certified to NSF/ANSI Standard 50. 2 Residential rate .375 GPM per sq. ft. of filter area.
Vertical Clearance to remove filter elements
B A
15-½”
Dimensions and Performance
Note: Actual system flow will depend on plumbing size and other system components.
Note: Pentair does not recommend flow rates above 150 GPM.
* Integrated continuous High Flow internal air relief is operational only when there is unobstructed flow in the circulating system.
Note: Operating Limits maximum continual operating pressure of 50 PSI. Pool/spa (bather) applications, maximum operating water temperature (internal filter) 104°F (40°C).
8″ 21-½”
See page 400 for replacement parts.
CALIFORNIA PROPOSITION 65 WARNING
WARNING: Cancer and Reproductive Harm.
AVERTISSEMENT: Peut Causer le Cancer et des Dommages au Système Reproducteur.
ADVERTENCIA: Cáncer y Daño Reproductivo.
www.p65warnings.ca.gov.
P/N 200174.A
57
