PENTAIR EC-160353 Clean & Clear RP Cartridge Filter
CLEAN & CLEAR® RP CARTRIDGE FILTER
The most efficient single-cartridge filter ever.
The Clean & Clear RP Filter gives you everything you could ask for in a filter. This design is nearly 50% more efficient than most single-cartridge filters on the market. At the same time, it delivers top-of-the-line performance to keep your pool sparkling clear. Plus, cleaning is a breeze, and its quick-connect ring makes maintenance a cinch. Just open the top, remove the cartridge, hose it off and the Clean & Clear RP Filter is ready to go again.
The Clean & Clear RP Filter has an innovative side-entry port to optimize flow and energy efficiency. And inside, we’ve maximized the cartridge surface consistency to block and trap particles as small as 20 microns. (An average grain of beach sand is 1,000 microns!) Plus, its durable, fiberglass-reinforced tank helps to ensure exceptionally long life.
Efficient and carefree…by design.
The Clean & Clear RP Filter’s innovative side-entry design optimizes flow for greater energy efficiency. It features an easily cleaned cartridge for the ultimate in carefree pool filtration. The fiberglass-reinforced tank halves are secured with a low-force locking ring—just loosen the ring and remove the top half for easier cartridge access and rinsing. Filter maintenance doesn’t get any easier.
KEY FEATURES
Single-piece base and tank
Constructed of fiberglass-reinforced polypropylene for strength, chemical resistance and maximum durability.
High Flow™ Manual Air Relief Valve
Relief valve and continuous internal air relief work together to maintain optimum filtration efficiency.
1-1/2″ drain cap and washout
For quick and convenient maintenance and winterization.
Innovative lock-ring
Requires only an easy half of a revolution for a leak-proof seal.
Easy access 1-1/2″ drain
2″ x 2-1/2″ plumbing
For maximum flow; innovative side entry maximizes energy efficiency.
Low-force locking ring
Opens and closes easily for quick access to cartridge.
Easy to remove and rinse cartridge
For nearly effortless cleaning.
Quick-connect union
Quick-connect union with diamond seal assures easy installation and servicing.
Unmatched hydraulic efficiency
Nearly 50% more energy efficient than single-cartridge cartridge filters.
SPECIFICATIONS
Model Number | Filter Area Sq. Ft. | Vertical Clearance* | Filter Diameter | Flow Rate GPM | Turnover Capacity (Gallons) | ||
| 8 hrs. | 10 hrs. | 12 hrs. | |||||
| CCRP 100 | 100 | 61″ | 15.5″ | 100 | 48,000 | 60,000 | 72,000 |
CCRP 150 | 150 | 76″ | 15.5″ | 150 | 72,000 | 90,000 | 108,000 |
| CCRP 200 | 200 | 76″ | 15.5″ | 150 | 72,000 | 90,000 | 108,000 |
*Required clearance to remove filter elements.
The Clean & Clear® RP Cartridge Filter has earned the Eco Select® brand distinction as one of the greenest and most efficient choices from Pentair.
TRADEGRADE
The TradeGrade family of products is exclusively made for and sold by the world’s most demanding pool professionals.
All indicated Pentair trademarks and logos are property of Pentair Inc. or its global affiliates in the U.S.A. and/or other countries. Third party registered and unregistered trademarks and logos are the property of their respective owners.
1620 Hawkins Ave | Sanford, NC 27330 | United States | 800.831.7133 | www.pentair.com
